Planet ADN-4101 Manuel utilisateur

802.11n Wireless

ADSL 2/2+ Router

ADN-4101

this publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or by

any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of PLANET.

PLANET makes no representations or warranties, either expressed or implied, with

respect to the contents hereof and specifically disclaims any warranties,

merchantability or fitness for any particular purpose. Any software described in

this manual is sold or licensed "as is". Should the programs prove defective

following their purchase, the buyer (and not this company, its distributor, or its

dealer) assumes the entire cost of all necessary servicing, repair, and any incidental

or consequential damages resulting from any defect in the software. Further, this

company reserves the right to revise this publication and to make changes from

time to time in the contents hereof without obligation to notify any person of such

revision or changes.

All brand and product names mentioned in this manual are trademarks and/or

registered trademarks of their respective holders.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

To assure continued compliance (example-use only shielded interface cables when

connecting to computer or peripheral devices). Any changes or modifications not

expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

Following two conditions: (1) This device may not cause harmful interference, and

(2) this Device must accept any interference received, including interference that

may cause undesired operation.

Federal Communication Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled

environment. In order to avoid the possibility of exceeding the FCC radio frequency

exposure limits, human proximity to the antenna shall not be less than 20 cm (8

inches) during normal operation.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF

THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio

equipment and telecommunication terminal Equipment and the mutual recognition

of their conformity (R&TTE)

The R&TTE Directive repeals and replaces in the directive 98/13/EEC

(Telecommunications Terminal Equipment and Satellite Earth Station Equipment)

As of April 8, 2000.

WEEE Regulation

To avoid the potential effects on the environment and human health as a

result of the presence of hazardous substances in electrical and electronic

equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of

WEEE as unsorted municipal waste and have to collect such WEEE separately.

Safety

This equipment is designed with the utmost care for the safety of those who install

and use it. However, special attention must be paid to the dangers of electric shock

and static electricity when working with electrical equipment. All guidelines of this

and of the computer manufacture must therefore be allowed at all times to ensure

the safe use of the equipment.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable or push the power button to

OFF position to disconnect the device from the power circuit.

Without removing power cable or Power off, the device will still consuming power

from the power source. In the view of Saving the Energy and reduce the

unnecessary power consuming, it is strongly suggested to remove the power

connection for the device if this device is not intended to be active.

Revision

User’s Manual for 802.11n Wireless ADSL 2/2+ Router

Model: ADN-4101

Rev: 1.0 (Apr. 2011)

Part No. EM-ADN4101_v1

iii

Contents

1Overview ..........................................................................................................1

1.1 Safety Precautions .................................................................................1

1.2 LEDs and Interfaces ...............................................................................2

1.3 System Requirements ............................................................................4

1.4 Features .................................................................................................4

2 Hardware Installation .......................................................................................6

3 Web Configuration ...........................................................................................8

3.1 Accessing the Device .............................................................................8

3.2 General Configuration ............................................................................9

3.2.1 Wizard .......................................................................................9

3.2.2 Internet Setup .........................................................................15

3.2.3 Wireless Setup ........................................................................18

3.2.4 Local Network .........................................................................26

3.2.5 Time and Date ........................................................................30

3.2.6 Logout .....................................................................................31

3.3 Advanced Configuration .......................................................................32

3.3.1 Advanced Wireless .................................................................32

3.3.2 Port Forwarding ......................................................................39

3.3.3 DMZ ........................................................................................41

3.3.4 Parental Control ......................................................................42

3.3.5 Filtering Options ......................................................................45

3.3.6 QoS Configuration ..................................................................50

3.3.7 Firewall Settings ......................................................................54

3.3.8 DNS ........................................................................................54

3.3.9 Dynamic DNS .........................................................................56

3.3.10 Network Tools .........................................................................57

3.3.11 Port Mapping ...........................................................................58

3.3.12 Routing ....................................................................................66

3.3.13 Schedules ...............................................................................69

3.3.14 NAT .........................................................................................71

3.3.15 Logout .....................................................................................71

3.4 Management ........................................................................................72

3.4.1 System ....................................................................................72

3.4.2 Firmware Update ....................................................................73

3.4.3 Access Controls ......................................................................74

3.4.4 Diagnostics .............................................................................78

3.4.5 Log Configuration ....................................................................80

3.4.6 Logout .....................................................................................81

3.5 Status ...................................................................................................81

3.5.1 Device Information ..................................................................81

3.5.2 Wireless Clients ......................................................................83

3.5.3 DHCP Clients ..........................................................................83

3.5.4 Logs ........................................................................................84

3.5.5 Statistics ..................................................................................84

3.5.6 Route information ....................................................................86

3.5.7 Logout .....................................................................................86

1 Overview

The ADN-4101 supports multiple line modes. It provides four 10/100Base-TX

Ethernet interfaces at the user end. The device provides high speed ADSL

broadband connection to the Internet or Intranet for high-end users, such as net

cafes and office users. It provides high performance access to the Internet,

downstream up to 24 Mbps and upstream up to 1 Mbps.

The device supports WLAN access. It can connect to the Internet through a

WLAN AP or WLAN device. It complies with IEEE 802.11, 802.11b/g/n

specifications, WEP, WPA, and WPA2 security specifications.

1.1 Safety Precautions

Refer to the following instructions to prevent the device from risks and damage

caused by fire or electric power:

Use volume labels to mark the type of power.

Use the power adapter packed within the device package.

Pay attention to the power load of the outlet or prolonged lines. An

overburden power outlet or damaged lines and plugs may cause electric

shock or fire accident. Check the power cords regularly. If you find any

damage, replace the power cords at once.

Proper space left for heat dissipation is necessary to avoid damage caused

by overheating to the device. The long and thin holes on the device are

designed for heat dissipation to ensure that the device works normally. Do

not cover these heat dissipation holes.

Do not put this device close to a place where a heat source exits or high

temperature occurs. Avoid the device from direct sunshine.

Do not put this device close to a place where it is over damp or watery. Do

not spill any fluid on this device.

Do not connect this device to any PCs or electronic products, unless our

customer engineer or your broadband provider instructs you to do this,

because any wrong connection may cause power or fire risk.

Do not place the device on an unstable surface or support.

1.2 LEDs and Interfaces

Front Panel

Figure 1 Front panel

The following table describes the LEDs of the device.

LED Color Status Description

On The device is powered on and the

initialization is normal.

Green Off The power is off.

PWR

Red On The device is self-testing or self-testing is

failed.

Slow

Blinks No signal is detected.

Fast

Blinks The device is handshaking with the physical

layer of the office.

Link Green

On The device is connected to the physical

layer of the office.

The Internet connection is normal in the

routing mode (for example: PPP dial-up is

successful), and no Internet data is being

transmitted.

Blinks Internet data is being transmitted in the

routing mode.

Green

Off The device is in the bridge mode.

Data

Red On The Internet connection fails after

successful synchronization in the routing

mode (for example: PPP dial-up is failed).

On The LAN connection is normal.LAN4-1 Green

Blinks Data is being transmitted through the LAN

interface, or the Internet data is being

transmitted in the bridge mode.

LED Color Status Description

Off The LAN connection is not established.

On The WLAN connection has been activated.

Blinks Data is being transmitted through the

WLAN interface.

WLAN Green

Off The WLAN connection is not activated.

Blinks WPS is activated and the device is waiting

for negotiation with the clients.

WPS Green

Off WPS is not activated.

Rear Panel

Figure 2 Rear panel

The following table describes the interfaces and buttons of the device.

Interface/Button Description

LINE RJ-11 interface, for connecting the interface of the

telephone set through the telephone cable.

LAN1,LAN2,

LAN3,LAN4 RJ-45 interface, for connecting the Ethernet interface of a

computer or an Ethernet device.

POWER Power interface, for connecting the interface of the power

adapter.

RESET

Restore to factory defaults. To restore factory defaults,

keep the device powered on, push a paper clip into the

hole to press the button for over 3 seconds and then

release.

WPS/ WLAN

Press the button and hold it for 1 second, to enable

WLAN.

Press the button and hold it for 1 second to 3

seconds, it does not take effect.

Interface/Button Description

Press the button and hold it for 3 or more than 3

seconds, to initialize WPS negotiation.

ON/OFF Power switch, power on or off the device.

1.3 System Requirements

Recommended system requirements are as follows:

A 10Base-T/100Base-TX Ethernet card is installed on your PC.

A hub or switch is available for connecting one Ethernet interface on the

device and several PCs.

Operating system: Windows XP, Windows 2000, Windows ME, or Windows

98SE.

Internet Explorer V5.0 or higher, Netscape V4.0 or higher, or Firefox 1.5 or

higher

1.4 Features

The device supports the following features:

IEEE802.11b/g/n

Various line modes

External PPPoE dial-up access

Internal PPPoE and PPPoA dial-up access

1483 Bridged, 1483 Routed, and MER access

Multiple PVCs (up to eight) that can be isolated from each other

A single PVC with multiple sessions

Multiple PVCs with multiple sessions

Binding of ports with PVCs

802.1Q and and 802.1P protocol

DHCP server

NAT and NAPT

Static routing

Firmware upgrade through Web or TFTP

Restore to the factory defaults

Autres manuels pour ADN-4101

Table des matières

Autres manuels Planet Routeur réseau

Planet

Planet VC-200S Manuel utilisateur

Planet

Planet 85M Powerline to Ethernet Bridge with 4-Port Switch... Manuel utilisateur

Planet

Planet PL-501-EU Manuel utilisateur

Planet

Planet Enterprise WiFi System Manuel utilisateur

Planet

Planet ADN-4100 Manuel utilisateur

Planet

Planet FGSW-2620 Manuel utilisateur

Planet

Planet IVR-100 Series Manuel utilisateur

Planet

Planet ADE-3100 Manuel utilisateur

Planet

Planet WNRT-625G Manuel utilisateur

Planet

Planet GS-5220-48T4X Manuel utilisateur

Planet

Planet VC-234G Manuel utilisateur

Planet

Planet FNSW-1600S Manuel utilisateur

Planet

Planet WGSD-10020 Manuel utilisateur

Planet

Planet IGS-5227-6T Manuel utilisateur

Planet

Planet ADSL 2/2+ Router with USB Port ADE-3410v2 Manuel utilisateur

Planet

Planet ADSL 2/2+ VPN Firewall Router ADE-4300A/B Manuel utilisateur

Planet

Planet ADE-3400 Manuel utilisateur

Planet

Planet EPN-104 Manuel utilisateur

Planet

Planet WNAP-7335 Manuel utilisateur

Planet

Planet PL-802 Manuel utilisateur

Planet

Planet FNSW-2400PS Manuel utilisateur

Planet

Planet WGSW-2620HP Manuel utilisateur

Planet

Planet ERT-805 Manuel utilisateur

Planet

Planet MGSW SERIES Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
