Planet EPL-2000 Manuel utilisateur

EPL-2000

GEPON OLT

(2-PON Interface, 2 x GbE SFP, 1 x MGT Port)

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. Requirements ............................................................................................. 4

3. MySQL Server Installation ........................................................................... 5

4. PL-EMS Installation ....................................................................................14

5. Starting PL-EMS Management .....................................................................17

6. Customer Support .....................................................................................19

1. Package Contents

Thank you for purchasing PLANET GEPON OLT EPL-2000. The term “GEPON OLT”

refers to the Switch mentioned in this Quick Installation Guide.

The box should contain the following items:

zThe GEPON OLT x 1

zThe MGB-PX20 SFP Transceiver x 2

zThe Quick Installation Guide x 1

zUser’s Manual CD x 1

zPower Cord x 1

zTwo Rack-mounting Brackets with Attachment Screws x 1 (Set)

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. Requirements

The GEPON OLT provides a GUI utility to manage the system; the following

equipment is necessary for further management:

Subscriber PC is installed with Ethernet NIC (Network Card)

MySQL Software (Windows Platform) http://dev.mysql.com/

EMS Software (Windows Platform)

Management Port connection

zNetwork cables - Use standard network (UTP) cables with RJ45 connectors

PON Port connection

zFiber Transceiver - Slot with a 1000BASE-PX20 SFP PON transceiver

zFiber Cable - Use single mode of ber (SC) cabl

3. MySQL Server Installation

Install the MySQL software with the purpose of saving equipment’s alarm message,

administrator message, system log, etc.

1. Please visit MySQL ofcial website http://dev.mysql.com/ and download

MySQL-Essential-5.1.73-win32.msi or MySQL-Essential-5.1.73-win64.msi for the

Windows system.

2. Once the Setup program starts running, please click the “Next” button for

starting installation.

Figure 3-1 MySQL Installation Screen

3. The Setup Type window appears; the default is “Typical” mode. Please click the

“Next” button.

Figure 3-2 Setup Type Screen

4. The “Ready to Install the Program” window appears; please click the “Install”

button.

Figure 3-3 Begin Installation Wizard Screen

5. When the installation is done, the “MySQL Enterprise” window appears. Please

click the “Next” button.

Figure 3-4 MySQL Enterprise Screen

6. The “Wizard Completed” window appears, and it will ask for Congure the

MySQL server and Register the MySQL Server now. Please click the “Finish”

button.

Figure 3-5 Wizard Completed Screen

7. The “MySQL Server Instance Conguration Wizard” window appears; please click

the “Next” button.

Figure 3-6 MySQL Conguration Wizard Screen

8. The “MySQL Server Instance Conguration” window appears; keep the default

setting of “Detailed Conguration” and click the “Next” button.

Figure 3-7 MySQL Server Instance Conguration (1) Screen

9. Please select a Server type. Keep the default setting of “Developer Machine” and

click the “Next” button.

Figure 3-8 MySQL Server Instance Conguration (2) Screen

10. Please select the database usage. Keep the default setting of “Multifunctional

Database” and click the “Next” button.

Figure 3-9 MySQL Server Instance Conguration (3) Screen

11. Choose where you want to place the InnoDB Datale. Here is the remaining

default setting. Please click the “Next” button.

Figure 3-10 MySQL Server Instance Conguration (4) Screen

12. Please set the approximate number of concurrent connections. Keep the default

setting of “Decision Support (DSS)/OLAP and click the “Next” button.

Figure 3-11 MySQL Server Instance Conguration (5) Screen
