Planet ISG-101 Manuel utilisateur

The products and programs described in this User’s Manual are licensed products of PLANET

Technology, This User’s Manual contains proprietary information protected by copyright, and this

User’s Manual and all accompanying hardware, software, and documentation are copyrighted.

No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to

any electronic medium or machine-readable form by any means by electronic or mechanical.

Including photocopying, recording, or information storage and retrieval systems, for any purpose

other than the purchaser's personal use, and without the prior express written permission of

PLANET Technology.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments

and applications, and makes no warranty and representation, either implied or expressed, with

respect to the quality, performance, merchantability, or fitness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims

liability for any inaccuracies or omissions that may have occurred.

Information in this User’s Manual is subject to change without notice and does not represent a

commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies

that may be contained in this User’s Manual. PLANET makes no commitment to update or keep

current the information in this User’s Manual, and reserves the right to make improvements to

this User’s Manual and/or to the products described in this User’s Manual, at any time without

notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would

appreciate your comments and suggestions.

CE mark Warning

The is a class B device, In a domestic environment, this product may cause radio interference, in

which case the user may be required to take adequate measures.

Trademarks

The PLANET logo is a trademark of PLANET Technology. This documentation may refer to

numerous hardware and software products by their trade names. In most, if not all cases, these

designations are claimed as trademarks or registered trademarks by their respective companies.

Revision

User’s Manual for PLANET Internet Subscriber Gateway:

Model: ISG-101

Rev: 1.0 (Jan. 2002)

Part No. EM-ISG101V1

PLANET ISG-101 Internet Subscriber Gateway

Table of Contents

1 Introduction…………………………………………………………………………….. 6

1-1 Feature………………………………………………………………………………. 6

1-2 Precautions………………………………………………………………………….. 7

2 Product Description…………………………………………………………………….8

2-1 Hardware…………………………………………...…………………………………8

2-2 Technical Specifications…………………………………………………………… 9

3 Installation………………………………………………………………………………..13

3-1 Package Contents……………………………………………………………………13

3-2 Installation Requirements…………………………………………………………...13

3-3 Getting started……………………………………………………………………… 14

4 User Interface……………………………………………………………………….……16

4-1 Console………………………………………………………………………………..16

4-1-1 Login…………………………………………………………………………...18

4-1-2 Main Menu…………………………………………………………………… 18

4-1-3 System Configuration……………………………………………………… 19

4-1-4 System Status……………………………………………………………… 21

4-1-5 Utilities Menu………………………………………………………………… 22

4-1-6 Firmware Upgrade……………………………………………………………22

4-1-7 Change Password…………………………………………………………… 23

4-1-8 Restart…………………………………………………………………………23

4-1-9 Factory Setting………………………………………………………………. 24

4-2 Web-Based Configurator…………………………………………………………… 24

4-2-1 Login…………………………………………………………………………...25

4-2-2 Main Menu…………………………………………………………………… 26

4-2-3 Configuration Menu…………………………………………………………. 26

4-2-4 System Configuration……………………………………………………….. 27

4-2-5 Subscriber Management……………………………………………………. 29

4-2-6 Subscriber Control……………………………………………………………30

4-2-7 Customize Login UI…………………………………………………………. 32

4-2-8 Add Subscribers……………………………………………………………...35

4-2-9 Subscribers List……………………………………………………………… 36

4-2-10 Current Users………………………………………………………………..37

4-2-11 Import Subscribers…………………………………………………………. 37

4-2-12 Advertisement Link Configurations………………………………………. 38

4-2-13 Pass through IP & MAC…………………………………………………… 40

4-2-14 Virtual Server Table…………………………………………………………41

4-2-15 System Status……………………………………………………………….42

4-2-16 DHCP Client Table…………………………………………………………. 43

4-2-17 Utilities Menu……………………………………………………………….. 43

4-2-18 Firmware Upgrade…………………………………………………………. 44

4-2-19 Change Password…………………………………………………………..44

4-2-20 Restart………………………………………………………………………..45

4-2-21 Logout……………………………………………………………………….. 45

4-3 Subscriber Applications…………………………………………………………….. 45

4-3-1 Subscriber Login Steps…………………………………………………………46

4-3-2 Subscriber Limitation……………………………………………………………46

4-3-3 Extra Feature…………………………………………………………………… 50

Appendix A: Signal Connection Arrangements………………………………………….. 56

Appendix B: Regulations/EMI Compliance……………………………………………… 59

PLANET ISG-101 Internet Subscriber Gateway

1 Introduction

The Internet Subscriber Gateway ISG-101 is deployed in a broadband service network for

high-speed access the Internet. The Internet Subscriber Gateway can immediately recognize

new users on the network (and remember returning users) and redirect their browser to a

proprietary Web page. That is to say, user needn’t change their network configuration to

access the Internet, just plug and play.

The product is a freestanding or rack-mounted unit with two Ethernet ports (WAN and LAN), a

serial port for system management and administration. After the initial setup and network

configuration is established, the product is easily managed by a network administrator through

a Web management interface or the onboard serial port.

1-1 Feature

Plug and Play-Support All Network Configurations

The ISG-101 provides instant Internet access by using your own notebook PC without the

hassle of configuration setting. This innovative sophisticated design enables instant

Internet access wherever traveling may take you. Easy to use plug-and-play access to

broadband networks.

Remote Authentication Dial-In User Service

The Internet Subscriber Gateway supports RADIUS client. RADIUS enables ISPs to

maintain a very large central database of users (potentially in the millions).

Proprietary Authentication Server

The Internet Subscriber Gateway provides proprietary authentication server which is

allowed administer to control user’s login name and password.

Remote Configuration

The administrator can access this system by using web browsers such as Netscape

Navigator or Microsoft Internet Explorer. This system allows a remote user to view and/or

modify system configuration via Internet.

Advertisement URL link

ISP could specify the advertisement URL link. The advertisement Web page will show on

the browser when the subscribers start Network access.

1-2 Precautions

 Never remove or open the cover. You may suffer serious injury if you touch these parts.

 The ISG-101 is powered from 100/240 VAC. A standard IEC connector is used for the

power cable.

PLANET ISG-101 Internet Subscriber Gateway

2 Product Description

Chapter 2 provides illustrations of the front and rear panels of the ISG-101 and detailed

technical specifications including information about LEDs, connectors, cables, environmental

and compliance specifications.

2-1 Hardware

Outlook

Figure 2-1 ISG-101 Outlook

Front Panel

Figure2-2 ISG-101 Front Panel

1. Console Ports: Standard RS232 DB 9 female Connector for system configuration.

2. System LEDs: Power LED glows when the device is turned on.

3. LAN Port: crossover 10/100M Ethernet port connects to any Ethernet network.

4. LAN Port LEDs:

10 Link LED: glows when a 10M network is connected;

100 Link LED: glows when a 100M network is connected

Act LED: flash when there is a reception or transmission of data occurring.

5. WAN Port: parallel 10/100M Ethernet port connects to any Ethernet network.

6. WAN Port LEDs:

10 Link LED: glows when a 10M network is connected;

100 Link LED: glows when a 100M network is connected

Act LED: flash when there is a reception or transmission of data occurring.

Rear Panel

Figure 2-3 ISG-101 Rear Panel

1. AC Power Connector: Plug in the female connector of the provided power cord into the

ISG-101 rear panel socket, and the male terminal into a power outlet. Input voltages range

from 90~240 V.

2. System Fan/Vents: This fan is used to circulate air inside the ISG-101 and also to dissipate

heat. The vents on both sides also serve the same purpose. Do not block these openings,

and leave adequate space at the rear and sides of the device.

2-2 Technical Specifications

Hardware Specifications

Network Specification

．IEE802.3 10BaseT Ethernet

．IEE802.3u 100BasedTX Fast Ethernet

．Supports 1024 users concurrently

．Throughput: Line rate at 20Mbps

Connectors

．Ethernet Port: Two RJ-45 connectors for 10/100M Ethernet port

．Serial Port: 1 DB9 Female RS232 Console Interface

Power Requirement

．Internal universal switching power supply

．100-220 VAC, 50/60 Hz

．Power Consumption: 5V, 15 Watts, 3 Amp.

PLANET ISG-101 Internet Subscriber Gateway

Led Indicators

．10/100M Ethernet Ports: WAN, LAN port LINK10, LINK100, ACT indications

．POWER ON/OFF Indication

Dimension

．Size: 1U Rack-mount-sized 440(W) x 116(L) x 44(H) mm

．Weight: About 1.7 kg (Net)

Environment Conditions

．Operating Temperature: 0 to 45℃

．Storage Temperature: -10 to 65℃

．Humidity: 10% to 90% non-condensing

Compliance

．FCC part 15 Class B

．VCCI Class B

Software Specifications

Address Translate Function

This function can accommodate all network configuration, including DHCP, DNS, proxies

and dynamic and static IP address assignments. That is, whenever a subscriber login, the

ISG-101 automatically translates their computer’s network settings to provide them with

seamless access to the broadband network. Subscribers no longer need to alter their

computer network configuration settings.

Email Redirection

The ISG-101 will rewrite subscriber’s original message of E-mail according to SMTP rules

and sent it out via the specified Email server. This function could help subscribers to send

E-mail via the local E-mail server when their default Email server is out of work.

DNS Redirection

The DNS Redirection function would provide local DNS server when subscriber’s

configured DNS server is behind a firewall or located on a private intranet.

Home Page Redirection

The ISG-101 enables solutions providers to redirect subscribers to a portal web site of their

choice. This allows the solution provider to generate online advertising revenues and increase

business exposure.

DHCP Function

The Internet Subscriber Gateway will follow RFC2131 that is designed to supply dynamic IP

addresses.

RADIUS Client

RADIUS (Remote Authentication Dial-In User Service) Attribute Support reduces costs and

improves services levels by enabling service providers to easily manage and maintain a very

large central database of subscribers.

Internal User Account Management

The Internet Subscriber Gateway contains a user account database. And when the

subscriber starts to access the Internet, the ISG-101 will send a Web page to ask checking

user’s ID and password.

Virtual Server

Enables administrator to expose WWW, FTP and other services on your LAN to be

accessible to Internet users under the NAT Network.

Support VPN (Virtual Private Network)

The ISG-101 can allow subscriber to create VPN networks using the Internet as the medium

for transporting data.

Customize Subscriber Login in page

For different market, ISG-101 allow administrator to set customize login page for the

subscribers. The advance pattern includes welcome notes, company logo, page color, article,

comments and information items.

PLANET ISG-101 Internet Subscriber Gateway

Pass through IP and MAC Address

Some network devices might be constructed under the Internet Subscriber Gateway.

However these devices needn’t be checked and authorized. The ISG-101 provides a pass

through table and the administrator can control which devices can be pass through with

authentication.

3 Installation

This section describes equipments unpacking, pre-installation considerations and different

applications.

3-1 Package Contents

Carefully unpack the contents of the package and verify them against the checklist below

Figure 3-1 Package Contents

1. One ISG-101 Internet Subscriber Gateway body

2. One Power Code

3. Two rack-mounting brackets

4. Six screws

5. Four rubber feet

6. One User’s Manual

7. One DB-9 male/Female serial cable (RS-232 console cable)

3-2 Installation Requirements

Before installing the ISG-101 Internet Subscriber Gateway, make sure your network meets the

following requirements.

Mechanical Requirements

The ISG-101 is to be installed only in a restricted access area per National Electrical Code

Articles 110-16, 110-17, and 110-18. It is suitable for mounting over a noncombustible surface

only. The ISG-101 can be mounted in a rack, or on the table or shelf. Locate the unit near the

outlet. And the ISG-101 ships with two brackets and six screws for mounting in a 19” rack.

PLANET ISG-101 Internet Subscriber Gateway

Network Requirements

The ISG-101 will access the Internet through XDSL, Cable Modem or other type of leased-line

with one EIA/TIA-568 Category 5 UTP Ethernet cable.

Figure 3-2 Network diagram

Electrical Requirements

The ISG-101 is powered from 100/240 VAC. A standard IEC connector is used for the power

cable. Follow all applicable electrical codes. Frame ground should be tied to a common

grounding point using #18AWG cable.

3-3 Getting started

Installation Steps:

1. Place the ISG-101 on a flat work surface.

2. Connect the power cord

3. Connect the DB9 male-to-female serial cable between the ISG-101 and your computer.

4. Power up your computer and turn on the ISG-101.

5. Start a Hyper Terminal session to communicate with the ISG-101 via the serial interface.

6. Log in to the Console User Interface.

7. Establish the start-up configuration parameters for the ISG-101.

8. Logout and restart for saving the ISG-101 parameters.

9. Connect the WAN network to the ISG-101.

10. Configure the further parameters via a web browser.

11. Connect the LAN network to the ISG-101 and ISG-101 system is now ready for provide

Internet plug and play service.

Network Architecture

The Internet Subscriber Gateway sits in a local aggregation access points on a network,

usually paired with a router. For example:

Figure 3-3 ISG-101 basic connections

PLANET ISG-101 Internet Subscriber Gateway

4 User Interface

The PLANET ISG-101 offers friendly user interface, one is console user interface and other is

Web user interface. However, the Console UI provides only basic system configuration and

Status. For advanced function, please use the Web Configurator.

4-1 Console

To access the ISG-101 User Interface, the system operator needs to connect a VT100 terminal

and a PC running a VT100 compatible terminal emulation program to the ISG-101 Console

port by using the provided DB9 RS-232 cable.

Follow these steps to set up your first local serial console port session using the Window98/2K

Terminal emulation program HyperTerminal.

1. From the Windows screen, click on the Start button.

2. From the Start menu, choose “Programs” (or Open file Hypertrm.exe).

3. From the Programs menu, choose “Accessories”

4. From the Accessories menu, select the HyperTerminal folder. Click on the HyperTerminal

icon.

5. From the connection Description windows, enter a name (i.e., ISG-101) and choose an

icon for the connection. Click ”OK”.

6. When the Phone Number window opens, click on the “Cancel” button.

7. From the File menu, choose “Properties.”

8. From the Properties windows, click on the “Configure” button.

9. From the COM1 Properties windows, set the following parameters:

Baud Rate: 9600

Date bits: 8

Parity Checking: None

Stop bits: 1

Flow control: None

Click “OK”

10. If you intend to use this PC and serial connection in the future, save this configuration by

selecting “Files/Save As” and entering the name of the file for this configuration.

11. Once you have completed configuring your serial terminal, use the following steps to

logon to your ISG-101. If you have not already done so, use a male-female DB-9 serial

communication cable to connect the COM port on your PC to the Console port on the

front of the ISG-101.

12. Go to the Call menu and select Connect.

13. If you have not completed initial power up, power up the ISG-101 now. You will see Figure

4-1.

14. To verify that you have a correctly configured your Console port press <Enter> and the

15. If your serial terminal remains blank, make sure that you entered the correct parameters

in Step7. Also, verify that you are using the correct cable, that the cable is not damaged,

and that you have good cable connections.

ISG-101 Boot ROM Version 1.00

Ethernet Address:

- - - - - - -

- - - - - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - -

Figure 4-1 Serial/Session Display

PLANET ISG-101 Internet Subscriber Gateway

4-1-1 Login

ISG-101 Internet Subscriber Gateway

Version 1.02.11

Username:

Password:

Figure 4-2 Login menu display

The default Username is “admin”. The default Password is “password”.

User can change password setting after accessing the ISG-101 system.

Notice: The administrator can change the password via the utilities item.

4-1-2 Main Menu

Main Menu

1) System Configuration

2) Status

3) Utilities

4) Restart

5) Logout

6) Factory Setting

Figure 4-3 Main Menu Screen

1) System Configuration: Including ISG-101 system basic parameter setting.

2) Status: Display ISG-101 system basic status.

3) Utilities: Including firmware and configuration upload/download and change password

capability.

4) Restart: Restart the ISG-101 system

5) Logout: Logout the ISG-101 serial session

6) Factory Setting: Erase all setting and back to the original factory setting

Enter a numeric that you need between 1~6 and press ‘Enter’ to the subdirectory.

4-1-3 System Configuration

System Configuration

System Name : ISG-101

Console Baud Rate : 9600

Auto Logout Timer : 10

WAN Configuration

IP Address : 210.1.1.2

Subnet Mask : 255.255.255.0

Gateway : 210.1.1.1

Web Server Port : 80

DHCP Configuration

DHCP Service? (D/R/S) : D

E-Mail Server IP Address :

Primary DNS IP Address :

Secondary DNS IP Address :

Enter system name.

Figure 4-4 System Configuration Screen

1) System Name: You can assign a name to this unit. Up to 32 characters are allowed.

2) Console Baud Rate: The Console Baud Rate is only relative to connection of console. There

are three different rates: 9600, 19200, or 38400.

3) Auto Logout Timer: Enter 0 for never time out or 1 to 60 for timeout minutes.

4) WAN Configuration: Enter WAN port IP Address Configuration such like IP address, subnet

mask and gateway. The Web server port default is 80, however some user may set up the

ISG-101 under the NAT network. The administrator has to set the special Web server port so

that ISG-101 can be remote access under NAT network.

Notice: The web server port allowed range is from 8000 to 8099 if administrator wants to remote

access under NAT Network. For access the ISG-101 system under NAT, please tab the

“http://WAN Port IP Address:Port Number”. The function of remote access ISG-101

system will be released after V1.00.02 version. For the release news please check the

PLANET Web Site or PLANET Support Team.

PLANET ISG-101 Internet Subscriber Gateway

5) DHCP Configuration: There are three types of DHCP Services. Enter 'D' to disable the

DHCP server function, 'R' to enable DHCP Relay function, or 'S' to enable DHCP Server

function.

Notice: The parameters will display on the screen only when the relative item is chosen.

DHCP Relay function: To route DHCP through an external server, the administrator needs to

enable the DHCP Relay and assign a valid DHCP server IP address.

Server IP Address: Tab the DHCP relay server IP address.

Agent IP Address: Tab the relay agent IP address, normally enter the ISG-101 WAN IP is OK.

Notice:You must disable the DHCP server before enable the DHCP relay. Both features can’t

be enabled concurrently.

Enable DHCP server function:ISG-101 include a DHCP sever inside. To enable this function

please choose the DHCP service as ‘S’, and set the DHCP server information.

Server IP Address: Tab the DHCP server IP address.

Start IP Address: Tab the DHCP pool start IP.

End IP Address: Tab the DHCP pool end IP.

Subnet Mask: Tab the DHCP subnet mask.

Lease Time: Tab the DHCP lease time. The maximum of DHCP lease time is 71582788

minutes.

Notice: To set up the DHCP pool that is the same network with WAN port you just tab the WAN

port IP address. If you want to set up a NAT DHCP pool please type the same network IP

Address with NAT network as the DHCP server IP address.

6) DNS IP Address: Enter the IP address for the DNS servers (located at the customer’s

network operating center where DNS requests are sent)

Notice: The secondary DNS servers are only initialized if the primary DNS server is unavailable.

7) E-mail Server IP Address: To prevent some subscriber’s original Email server may protect

by firewall or NAT network. ISG-101 provides an extra Email server parameter to forward the

subscriber’s Email. The ISG-101 not only forwards the subscribers’ E-mail via other E-mail

server but also changes the SMTP header. The recipient of your E-mail sees the message as if

you sent it from your local Internet Service Provide, not form the hotel or other place.

Notice: Before setting this sever, please make sure the E-mail sever relay function is opened.

4-1-4 System Status

System Status

System Name : ISG-101

Console Baud Rate : 9600

Auto Logout Timer : 10

WAN Configuration

IP Address : 210.1.1.2

Subnet Mask : 255.255.255.0

Gateway : 210.1.1.1

Web Server Port : 80

DHCP Configuration

DHCP Service? (D/R/S) : Disable

E-Mail Server IP Address : N/A

Primary DNS IP Address : 168.95.1.1

Secondary DNS IP Address : 140.112.1.2

Press any key to return.

Figure 4-5 System Status Screen

System Status is only displaying system information from screen no authority to change any

setting.

Notice: If the system parameter information is not available, the column will display N/A.

Table des matières

Autres manuels Planet Porte

Planet

Planet BM-2101 Manuel utilisateur

Planet

Planet VGW-402 Manuel utilisateur

Planet

Planet VIP-050 Manuel utilisateur

Planet

Planet SG-1000 Manuel utilisateur

Planet

Planet VIP-281 Series Manuel utilisateur

Planet

Planet CS-2001 Manuel utilisateur

Planet

Planet WPG-110 Manuel utilisateur

Planet

Planet LCG-300 Series Manuel utilisateur

Planet

Planet VIP-880 Series Manuel utilisateur

Planet

Planet VGW-804 Manuel utilisateur

Planet

Planet MH-1000 Manuel utilisateur

Planet

Planet VCG-1500WG-LTE Manuel utilisateur

Planet

Planet VGW Series Manuel utilisateur

Planet

Planet VIP-410 Manuel utilisateur

Planet

Planet MH-2001 Manuel utilisateur

Planet

Planet WSG-500 Manuel utilisateur

Planet

Planet WPG-110 Manuel utilisateur

Planet

Planet VIP-110 Manuel utilisateur

Planet

Planet VIP-1680 Series Manuel utilisateur

Planet

Planet Network Device MAP-2105 Manuel utilisateur

Planet

Planet BM-525 Manuel utilisateur

Planet

Planet WSG-404 Manuel utilisateur

Planet

Planet MH-2001 Manuel utilisateur

Planet

Planet VGW 10 Series Manuel utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
