Planet VC-203PT Manuel utilisateur

Power over Coaxial Extender

VC-203PT and VC-203PR

User's Manual

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All

other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work

properly in all environments and applications, and makes no warranty

and representation, either implied or expressed, with respect to

the quality, performance, merchantability, or tness for a particular

purpose.

PLANET has made every effort to ensure that this User’s Manual is

accurate; PLANET disclaims liability for any inaccuracies or omissions

that may have occurred.

Information in this User’s Manual is subject to change without notice

and does not represent a commitment on the part of PLANET. PLANET

assumes no responsibility for any inaccuracies that may be contained in

this User’s Manual. PLANET makes no commitment to update or keep

current the information in this User’s Manual, and reserves the right

to make improvements to this User’s Manual and/or to the products

described in this User’s Manual, at any time without notice.

If you nd information in this manual that is incorrect, misleading, or

incomplete, we would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with

the Instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area

is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may

cause radio interference, in which case the user may be required to

take adequate measures.

WEEE Warning

To avoid the potential effects on the environment and human

health as a result of the presence of hazardous substances in

electrical and electronic equipment, end users of electrical and

electronic equipment should understand the meaning of the

crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET Industrial Power over Coaxial Extender User's Manual

For Model: VC-203PT / VC-203PR

Revision: 1.0 (May, 2013)

Part No: EM-VC-203PT_203PR_v1.0 (2350-AC0300-000)

Table of Contents

1. INTRODUCTION ........................................................................ 5

1.1 Package Contents ............................................................... 5

1.2 Product Features................................................................. 6

1.3 Product Specications ......................................................... 7

1.4 Physical Dimensions ...........................................................10

2. INSTALLATION .........................................................................12

2.1 Product Description ............................................................12

2.1.1Power over Coaxial Extender Front Panel......................13

2.1.2LED Indicators ...........................................................13

2.1.3Power over Coaxial Extender Rear Panel ......................15

2.2 Applications of VC-203PT and VC-203PR ..............................16

3. TROUBLESHOOTING .................................................................20

APPENDIX A: NETWORKING CONNECTION.......................................22

A.1 Switch’s RJ-45 Pin Assignments ...........................................22

A.2 RJ-45 Cable Pin Assignments...............................................22

1. INTRODUCTION

Thank you for purchasing PLANET Industrial Power over Coaxial

Extender, VC-203PT and VC-203PR. The descriptions of the two models

are as follows:

VC-203PT PoE over Coaxial Extender - Transmitter

(1-Port 10/100TX 802.3at PoE PD + 1-Port BNC PoE )

VC-203PR PoE over Coaxial Extender - Receiver

(1-Port 10/100TX 802.3at PoE PSE + 12/24V DC Splitter)

“Industrial Power over Coaxial Extender” mentioned in this Manual

represents the above two models.

1.1 Package Contents

Open the box of the Industrial Power over Coaxial Extender and

carefully unpack it. The box should contain the following items:

For VC-203PT For VC-203PR

● Industrial Power over Coaxial

Extender – Transmitter x 1

● User’s Manual x 1

● Power Adapter and Power Cord

● Industrial Power over Coaxial

Extender –Receiver x 1

● User’s Manual x 1

If any of these are missing or damaged, please contact your dealer

immediately; if possible, retain the carton including the original packing

material, and use them again to repack the product in case there is a

need to return it to us for repair.

1.2 Product Features

Physical Port

Model

Name

Ports

Copper BNC

VC-203PT 1 x 10/100Base-TX (PoE IN) Power/Data Transmitter

VC-203PR 1 x 10/100Base-TX (PoE OUT) Power/Data Receiver

Power over Ethernet

Eliminates Power cabling with PoE over Coaxiall

Ethernet over coaxial up to 1km with 5C2V/RG6 75Ω cablel

Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet onl

RJ-45 ports

Supports PoE Power up to 30.8 watts (Vary on Power Source andl

Coaxial Distance)

Auto detect powered device (PD) (VC-203PR)l

Layer 2 Features

Supports Auto-negotiation and 10/100Mbps half / full duplex model

Prevents packet loss with back pressure (Half-Duplex) and IEEEl

802.3x PAUSE frame ow control (Full-Duplex)

VDSL2 Features

One box design, Master / Slave selectable via DIP Switchl

Denes Asymmetric (Band Plan 998) and Symmetric band plans l

for the transmission of Upstream and Downstream signals

Industrial Case / Installation

Supports extensive LED indicators for network diagnosticsl

IP30 metal case protectionl

Compact size, DIN Rail and Wall Mount Designl

Power Input: External DC or PoE power inputl

Supports EFT protection 2000 VDC for power linel

Supports 2000 VDC Ethernet ESD protectionl

-40 to 75 degrees C operating temperaturel

1.3 Product Specications

Model VC-203PT VC-203PR

Hardware Specications

Interface

Copper

10/100Base-TX RJ-45

Auto-negotiation/

Auto-MDI/MDI-X

802.3at/af PoE Input

10/100Base-TX RJ-45

Auto-negotiation/

Auto-MDI/MDI-X

802.3at/af PoE Output

Coaxial BNC, female

Power over Coaxial Output

BNC, female

Power over Coaxial Input

DC Socket

(Optional) 52~56V DC Input

DIP-Switch

2-Position DIP Switch

Selectable CO or CPE

mode (Default: CPE)

Selectable Band plan:

Asymmetric or

Symmetric (Default:

Asymmetric)

2-Position DIP Switch

(Front)

Selectable CO or CPE

mode (Default: CO)

Selectable Band plan:

Asymmetric or

Symmetric (Default:

Asymmetric)

---

2-Position DIP Switch

(Rear)

PoE out or DC out

(Default: PoE out)

12V DC / 24V DC

output voltage

(Default: 12V DC)

LED Indicators

LED is Green Color

PWR

PoE IN

LNK

CO

CPE

LNK/ACT

100

LED is Green Color

PWR

PoE IN

PoE Out

LNK

CO

CPE

LNK/ACT

100

ESD Protection 2KV DC

EFT Protection 2KV DC

Enclosure IP30 metal case

Installation Wall mount or DIN rail with optional kit

Dimensions

(W x D x H) 94 x 70.3x 39.2 mm

Weight 288g 302g

Power Requirements

RJ-45 PoE Input:

802.3at/af 44~57V DC

DC Input: 52~56V DC

BNC Power over Coaxial

Input: 44~57V DC

DC Input: 52~56V DC

Performance*

(Down / Up Stream)

Asymmetric Mode (Data Only)

200m -> 100/65Mbps 800m -> 100/53Mbps

400m -> 100/64Mbps 1000m -> 94/44Mbps

600m -> 100/59Mbps 1200m -> 84/36Mbps

Symmetric Mode (Data Only)

200m -> 100/100Mbps 800m -> 79/80Mbps

400m -> 97/100Mbps

1000m -> 69/66Mbps

600m -> 86/91Mbps 1200m -> 60/52Mbps

Power over Ethernet/Coaxial

PoE Standard IEEE 802.3at Type 2

IEEE 802.3af

PSE Interface

BNC

44~57V DC

(Depend on what is the

DC/PoE Power Input)

RJ-45

48~56V DC, 600mA max.

End-Span, Pin 1/2(+),

3/6(-)

PD Interface

RJ-45, both Mid-Span and

End-Span

Input Range: 44~57V DC

BNC

Input Range: 44~57V DC

DC Power Output -12V DC, 2A max.

24V DC, 1A max.

Max.

PoE

Budget

Power Input

by PoE BNC : 25 watts RJ-45 : 20 watts

Power Input

by DC BNC : 30 watts RJ-45 : 30 watts

Standards Conformance

Standards

Compliance

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3af Power over Ethernet (802.3at Type 1)

IEEE 802.3at Power over Ethernet Plus (802.3at Type 2)

Regulation

Compliance FCC Part 15 Class A, CE

Environment

Temperature Operating: -40~75 degrees C

Storage: -40~75 degrees C

Humidity Operating: 5~95% (Non-condensing)

Storage: 5~95% (Non-condensing)

Cable

Coaxial

RG-6/U cable (Recommended)

max. 500 m with PoE+ (1,640 ft.)

max. 700 m with PoE (2,297 ft.)

max. 1200 m without PoE (3,937 ft.)

* The actual data rate will vary on the quality of the copper wire and

environment factors.

Caution

As the VC-203PT is power over coaxial, it only can work

with PLANET VC-203PR or VC-205PR. If connects with

Non-PoE coax-LAN equipments, it might cause the equip-

ment to damage.

Warning:

This side of connector

contains electric power. Please be

careful before plugging into

the device.

Please be reminded that the cable con

Do Not Touch

the Center Pin

Please take care of the conditions of the resistance value of cables as

follows.

Coaxial Cable Type

RG-59/U Less than 30Ω/1000 ft.

RG-6/U Less than 12Ω/1000 ft

Because there are various resistance values in the category of RG-59/U

or RG-6/U cable.

1.4 Physical Dimensions

 VC-203PT dimensions (W x D x H): 94 x 70.3 x 39.2 mm

PoE over Coaxial Extender Transmitter

52~56V DC IN

PoE IN

10/100Base-TX

LNK

CPE

Coaxial

PoE IN

PWR

OFF

LNK/ACT

100

LAN

VC-203PT

PoE over Coaxial Extender

Mode Band Plan

CO Symm

CPE Asymm

Transmitter

1 2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Planet Extenseur

Planet

Planet IVC-2004PT Manuel utilisateur

Planet

Planet IPOE-E174 Manuel utilisateur

Planet

Planet WNAP-1110 Manuel de l'opérateur

Planet

Planet PL-510W Manuel utilisateur

Planet

Planet WAP-7500 Manuel de l'opérateur

Planet

Planet IPOE-E174 Manuel utilisateur

Planet

Planet LRE-101C Manuel utilisateur

Planet

Planet IVC-4011-T-V2 Manuel utilisateur

Planet

Planet IHD-410PT Manuel utilisateur

Planet

Planet VC-205PT Manuel utilisateur

Planet

Planet IPOE-E202 Manuel utilisateur

Planet

Planet IVC-234GT Manuel utilisateur

Planet

Planet WNAP-1110 Manuel utilisateur

Planet

Planet WNAP-C3220 Manuel utilisateur

Planet

Planet LRP-101C-KIT Manuel utilisateur

Planet

Planet WTB-1000 Manuel utilisateur

Planet

Planet WRE-1200 Manuel utilisateur

Planet

Planet WBT-1000 Manuel utilisateur

Planet

Planet LRP-101CE Manuel utilisateur

Planet

Planet IVC-2002 Manuel utilisateur

Planet

Planet WRE-1200 Manuel utilisateur

Planet

Planet LRE-101 Manuel utilisateur

Planet

Planet POE-E101 Manuel utilisateur

Planet

Planet IPOE-E172 Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
