Ping Communication RGW208EN Manuel utilisateur
Product Guide
for
Residential Gateway
RGW208EN
Version: 17th of March 2010
Page 1 of 92
1 Getting started 6
1.1 Troubleshooting 6
1.2 How to read the manual 6
2 Basic menu 7
2.1 Internet 7
2.1.1 Internet Connection Setup Wizard 7
2.1.2 Manual setup 10
2.1.2.1 Modes 10
2.1.2.2 Advanced 12
2.2 Network Settings 13
2.2.1 outer Settings 14
2.2.2 IP ( outing Information Protocol) 15
2.2.3 DHCP Server Settings 15
2.2.4 Add DHCP eservation 17
2.2.5 DHCP eservations list 18
2.2.6 Number of Dynamic DHCP Clients 19
2.3 Wireless settings 19
2.3.1 Manual Wireless Network Setup 20
2.3.1.1 Wireless Network Settings 20
2.3.1.2 Wireless Network 1 21
2.3.1.3 Wireless Network 2-4 22
2.3.2 Add Private Wireless Device Wizard 22
2.3.3 Add Guest Wireless Device Wizard 23
2.3.4 Wireless Network Setup Wizard 23
3 Advanced 24
3.1 irtual Server 24
3.1.1 Add/Edit Virtual Server 25
3.1.2 Virtual Servers List 25
3.2 Port Forwarding 25
3.2.1 Port forwarding ules 27
3.3 Special Applications 27
3.3.1 Add/Edit Special Applications ule 28
3.3.2 Special Applications ules List 28
3.4 Traffic Shaping 28
3.5 StreamEngine™ 30
3.5.1 StreamEngine™ Setup 30
3.5.2 Add/Edit StreamEngine™ ule 31
3.5.3 StreamEngine™ ules List 32
3.6 Routing 32
3.6.1 Add/ Edit oute 33
3.6.2 outes List 34
3.7 Access Control 34
3.7.1 Access Control 35
3.7.2 Policy Table 35
3.7.3 WEB Filter 35
Page 2 of 92
3.7.4 Add/Edit Web Site 36
3.7.5 Allowed Web Site List 37
3.8 MAC Address Filter 37
3.8.1 MAC Filtering Setup 37
3.8.2 Add/ Edit MAC Address 38
3.8.3 MAC Address List 38
3.9 Firewall 38
3.9.1 Firewall Settings 39
3.9.2 NAT Endpoint Filtering 39
3.9.3 Various 40
3.9.4 DMZ Host 40
3.9.5 Non-UDP/ TCP/ IMCP LAN Sessions 41
3.9.6 Application Level Gateway (ALG) Configuration 41
3.10 Inbound filter 43
3.10.1 Add/Edit Inbound Filter ule 44
3.10.2 Inbound Filter ules List 44
3.11 Advanced Wireless 44
3.12 WISH 47
3.12.1 Priority Classifiers 48
3.12.2 Add/Edit WISH ule 48
3.12.3 WISH ules 49
3.13 Wi-Fi Protected Setup 49
3.13.1 Wi-Fi Protected Setup 49
3.13.2 PIN Settings 49
3.14 Advanced Network 50
3.14.1 UPnP 50
3.14.2 PPPoE Pass Through 51
3.14.3 LAN Auto IP 51
3.15 LAN 51
3.15.1 VLAN Tagging 52
3.15.2 Internal Services 52
3.15.3 Custom VLANs 52
3.15.4 Default VLAN 52
3.15.5 VLAN to SSID mapping 53
3.16 Provisioning 53
3.16.1 Three provisioning protocols 54
4 VoIP 55
4.1 Line 1 55
4.1.1 SIP Settings 55
4.1.2 Codec Settings 56
4.1.3 DTMF Events 56
4.1.4 Dialplan Settings 57
4.1.5 Telephony Settings 57
4.2 Advanced 58
4.2.1 STUN Settings 58
4.2.2 User Agent Server Settings 59
4.2.3 NAT Ping Settings 59
4.2.4 VoIP QoS 60
Page 3 of 92
4.3 Regional Settings 60
4.3.1 egion 60
4.3.2 Analog Settings 61
4.3.3 ing tone 61
4.3.4 Call Event Tones 61
4.3.5 Help Tones 62
4.3.6 Advanced Audio 63
5 Tools 64
5.1 User 64
5.2 Admin 65
5.2.1 Admin Password 65
5.2.2 System name 65
5.2.3 Administration 65
5.3 Time 66
Time Configuration 66
Automatic Time Configuration 67
Set the Date and Time 67
5.4 Syslog 67
5.5 Email settings 68
5.5.1 Email Settings 69
Email Log When Full or on Schedule 70
5.6 System 70
5.7 Firmware 71
5.7.1 Firmware Information 72
5.7.2 Firmware Upgrade 72
5.8 Dynamic DNS 72
5.9 System Check 74
5.9.1 Ping Test 74
5.9.2 Ping esult 74
5.10 Schedules 75
5.10.1 Add/Edit Schedule ule 75
5.10.2 Schedule ules List 76
5.11 Bandwidth 76
5.12 Mirror 78
5.13 Console 79
6 Status 0
6.1 Device Info 80
6.1.1 General 80
6.1.2 WAN 80
6.1.3 LAN 82
6.1.4 VoIP Line Status 82
6.1.5 LAN Computers & IGMP Multicast memberships 82
6.2 Wireless 83
Page 4 of 92
6.3 Routing 83
6.4 Logs 84
6.4.1 Log Options 85
6.4.2 Log Details 85
6.5 Statistics 85
6.5.1 LAN Statistics 86
6.5.2 WAN Statistics 86
6.6 Internet Sessions 87
6.7 Firewall Holes 88
6.8 WISH Sessions 89
7 Help 92
Page 5 of 92
1 Getting started
The Configuration Interface can be accessed fro your Web browser. Open up your
Web browser and type http://192.168.176.1 in the address field and press Enter.
The Configuration Interface login screen will appear. By default, there is no
password. Click on the Log In button to access the Configuration ain screen.
1.1 Troubleshooting
Make sure your co puter is connected to LAN port on the device. Then open a
co and window and type ipconfig (Windows) or ifconfig (Linux/Mac). You should
then be able to read the IP address of the Default Gateway of the LAN connection on
your co puter (assu ing you only have one LAN network interface). If this IP
address do not appear, the co puter is not connected to the device. If it does
appear, use that address instead of 192.168.176.1 (assu ing it differ).
1.2 How to read the manual
This anual will go through all enus in an orderly fashion. Chapter 2 starts with
the first left enu ite (Basic) and the sub chapters covers the upper enu. Then if
you look up a certain chapter in this anual you can always know that the ain
chapter heading denotes the left enu choice and the sub chapter heading denotes
the upper enu choice.
Page 6 of 92
2 Basic menu
2.1 Internet
The Internet Connection screen contains the Internet Connection Wizard that assists
you in configuring the device to allow it to connect to the Internet, as well as the
Manual Internet Connection Options screen in which you can set up your Internet
connection anually.
2.1.1 Internet Connection Setup Wizard
The Internet Connection Setup Wizard will assist you with connecting the device to
the Internet. The step by step guide will pro pt you for the necessary infor ation to
get you connected. The Internet Connection Setup Wizard guides you through the
following basic router setup steps:
To begin, click on the Launch Internet Connection Setup Wizard button.
The Welco e screen appears, click Next to continue.
Note: The device is intelligent, and will in so e cases anage to connect to the
Internet auto atically. In this case the Wizard will report that a connection has been
established successfully, but will still let the user proceed through steps 1 and 2.
Step 1: Set Your Password pro pts you to enter a password for the Web-based
configuration interface. You can enter the password in the Verify Password pro pt.
Page 7 of 92
Step 2: Select Your Ti e Zone pro pts you to select your ti e zone fro the
pull-down enu.
Step 3: Configure Your Internet Connection. At this stage we assu e that the
device is not connected to the internet, otherwise the wizard would have skipped this
step. Still, there are possibilities if the connection type of your Internet Service
Provider (ISP) is known (or can be established).
If your ISP is listed in the drop-down enu (and you choose it) then the connection
type is chosen for you. Otherwise, specify the connection type anually.
Depending upon your Internet Service Provider or the type of connection you
selected in the previous step, one of five screens will appear. If you are unsure of
any of the infor ation, please contact your Internet Service Provider (ISP) for
details.
•DHCP Connection (Dyna ic IP Address). DHCP is a uch used
connection type. It should usually not require any setup on your behalf.
However, at this point we have an “unusual” situation (since you're reading
this). If you have put your device behind a cable ode 1 (a device which is
connected to a coax cable) there are so e things you could try:
•Try to restart that ode . Cancel this setup and try again.
•If you previously had equip ent (like your PC) connected to the cable
ode and actually had a working internet connection, you can try to
clone/copy the MAC address of that equip ent into this device. By
pressing the Clone Your PC’s MAC Address you will copy the MAC
address of the PC you’re connecting to this device. If, let’s say, you had a
router connected behind the cable ode , you could read MAC address
(usually printed underneath the router) and enter it anually. You can
always reverse this step later by entering the MAC address printed on this
device (the WAN MAC).
A last resort ay be to add a hostna e if that is provided by the ISP. This is
not very co on.
The settings for DNS could be left untouched, unless you have been able to
retrieve this infor ation fro the ISP. Usually (again) this infor ation is
auto atically populated when connecting on DHCP.
•Set Userna e and Password Connection (PPPoE) pro pts you to enter
your Userna e and Password. This infor ation ust be provided by the ISP
(typically in a welco e letter). You ust also verify the Password. If your ISP
requires a Service Na e entry, please enter it here. The default setup is to
get the IP address dyna ically. In so e cases the ISP has chosen to give you
a static IP. You can then choose the static radio button and enter the IP
address.
•Set Userna e and Password Connection (PPTP) pro pts you to enter
your PPTP IP Address, PPTP Subnet Mask, PPTP Gateway IP Address, PPTP
Server IP Address, Userna e, and Password. You ust also verify the
Password. This infor ation ust be provided by the ISP (typically in a
welco e letter).
1 A cable modem or any device which is not connecting on the IP layer. That excludes all DSL modems.
Page 8 of 92
•Set Userna e and Password Connection (L2TP) pro pts you to enter
your L2TP IP Address, L2TP Subnet Mask, L2TP Gateway IP Address, L2TP
Server IP Address, Userna e and Password. You ust also verify the
Password. This infor ation ust be provided by the ISP (typically in a
welco e letter).
•Set Static IP Address Connection pro pts you to enter the IP address,
Subnet Mask, Gateway Address, Pri ary and Secondary DNS address
infor ation. This infor ation ust be provided by the ISP (typically in a
welco e letter).
•Setup Co plete will appear after all of the settings have been entered. Click
Connect to save your settings and reboot the router.
Page 9 of 92
2.1.2 anual setup
2.1.2.1 Modes
Page 10 of 92
