18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Issue 6.1 April 2017

User Manual

18-Bank, 3-Channel, 1-Pole

Multiplexer Module

(Model No. 40-617)

pickeringtest.com pickering

Page (II) 18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Cards.................4.1

Module Architecture 40-617.................................................4.3

Sub-unit Cross Reference ....................................................4.4

Programming The Module 40-617.......................................4.5

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Lookup Tables.............................................................7.1

Component Layout ...............................................................7.1

CONTENTS

Page (VI) 18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the PXI/LXI chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) 18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

Com.

Multiplexer Bank 1

Isolation

Switch

Chan 1

Chan 2

Chan 3

Com.

Isolation

Switch

Chan 1

Chan 2

Chan 3

Com.

Isolation

Switch

Chan 1

Chan 2

Chan 3

Multiplexer Bank 2 Multiplexer Bank 18

(No Channel Selected) (Channel 1 Selected) (Channel 3 Selected)

Inter-Bank Linking Switch Inter-Bank Linking Switch

A12

C12

12 off SPST Uncommitted Relays

40-617

18-Bank, 3-Channel, 1-Pole Multiplexer Module

●18 Separate Multiplexers in One Module

●Each Multiplexer is Single Pole, 3-Way

●Isolation Switches to Reduce Signal Loading

●Inter-Bank Linking Relays Allow Multiplexer

Size to be Increased in Multiples of 3

●Includes 12 SPST Uncommitted Relays

●Multiplexer Channels Can be Set Individually

●Any Number of Multiplexer Channels Can be

Set Simultaneously

●Switches Up To 100 Volts, 1 Amp, 20 Watt.

●Uses High Reliability Ruthenium Reed Relays

for Maximum Performance

●VISA, IVI & Kernel Drivers Supplied for

Windows

●Supported by PXI or LXI Chassis

●Supported by eBIRST

●3 Year Warranty

The 40-617 18-Bank, 3-Channel, 1-Pole Multiplexer Module

forms part of the System 40 PXI Programmable Switching

system. The Module consists of 18 electrically isolated banks

of multiplexers controlled by a PXI/PCI interface. Each bank

is a 1 to 3 multiplexer and operates with break-before-

make action when a new channel is selected. Any Individual

multiplexer bank can have a channel set by itself, alternatively,

multiple banks can have channels selected simultaneously.

Inter-bank linking relays allow multiplexer size to be increased

in multiples of 3 by joining the common terminals of adjacent

banks. Closing one linking switch produces a 6 channel

multiplexer, closing all linking switches produces an 54 channel

multiplexer

Built-in Isolation Switches are used to connect only currently

active multiplexer banks to their respective analogue

commons. This keeps capacitive loading and leakage currents

in large multiplexer systems to a minimum.

Switching Diagram for the 40-617 18-Bank, 3-Channel, 1-Pole Multiplexer Including 12 SPST Relays

Included in the module are 12 SPST uncommitted relays

which are separate from the multiplexers and are connected

to via pins on the front panel plug.

The 40-617 is ﬁtted with high performance instrumentation

grade Reed Relays (Ruthenium sputtered type). These offer

very long life with good low level switching performance and

excellent contact resistance stability.

The module is suitable for cascading in applications that

require large multiplexer systems, it is also suitable for test

systems that require the switching of a large number of

signals in parallel.

ISSUE 6.1 APR 2017

Supported by eBIRST

This product is supported by eBIRST which tests the switching

system using an external tool. eBIRST provides a graphical

output of its tests which includes an image showing the

location of any defective relay. For more information on eBIRST

see 93-000D.pdf

Page 1.2 18 BANK, 3 CHANNEL, 1-POLE MULTIPLEXER MODULE 40-617

pickering

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

Product Order Codes

18-Bank, 3-Channel, 1-Pole

Multiplexer Module 40-617-021

Speciﬁcation

Switch Type: Ruthenium Reed

Max Switching Voltage: 100V

Max Power:

Max Switch Current:

Max Carry Current:

20W

Initial Path Resistance

On (Single Module):

Off (Single Module):

Differential Thermal Offset:

<700mΩ

>109Ω

<10µV

Operate Time:

Release Time:

<0.5ms

Expected Life

Low power load:

Full power load:

>1x109operations

>1x106 operations

Power Requirements

+3.3V +5V +12V -12V

00.3A typ.

1.4A max. 0 0

Mechanical Characteristics

Single slot 3U PXI (CompactPCI card).

3D models in a variety of popular ﬁle formats are available on

request.

Connectors

PXI bus: 32-bit P1/J1 backplane connector

Front panel Connector: 96-pin male micro-D connector.

PCB Layout for the 40-616 16-Bank, 5-Channel, 1-Pole Multiplexer Module

Mating Connectors & Cabling

For connection accessories for the 40-617 module

please refer to the 90-016D 96-pin micro-D Connector

Accessories data sheet where a complete list and

documentation can be found for accessories, or refer to the

Connection Solutions catalog.

Support Products

eBIRST Switching System Test Tool

This product is supported by the eBIRST test tools which

simplify the identiﬁcation of failed relays, the required eBIRST

tools are below. For more information see eBIRST.

Product Test Tool Adapter Termination

All Types 93-002-001 93-002-226 93-016-103

Spare Relay Kits

Kits of replacement relays are available for the majority of

Pickering’s PXI switching products, simplifying servicing and

reducing down-time.

Product Relay Kit

All Types 91-100-003

For further assistance, please contact your local Pickering

sales ofﬁce.

Table des matières

Autres manuels Pickering Multiplexeur

Pickering

Pickering 40-735 Manuel utilisateur

Pickering

Pickering 50-670C Manuel utilisateur

Pickering

Pickering 40-614C Manuel utilisateur

Pickering

Pickering LXI 60-820 Manuel utilisateur

Pickering

Pickering 60-850 Manuel utilisateur

Pickering

Pickering 40-616A Manuel utilisateur

Pickering

Pickering PXI 40-882B Manuel utilisateur

Pickering

Pickering 40-613A Manuel utilisateur

Pickering

Pickering 40-640 Manuel utilisateur

Pickering

Pickering 20-745 Manuel utilisateur

Pickering

Pickering 40-760 Manuel utilisateur

Pickering

Pickering 40-667B Manuel utilisateur

Pickering

Pickering 40-658 Manuel utilisateur

Pickering

Pickering 40-617A Manuel utilisateur

Pickering

Pickering PXI 40-620A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-659A Manuel utilisateur

Pickering

Pickering 42-204 Manuel utilisateur

Pickering

Pickering 40-615A Manuel utilisateur

Pickering

Pickering 40-655A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-675 Manuel utilisateur

Pickering

Pickering 40-756 Manuel utilisateur

Pickering

Pickering 40-736 Manuel utilisateur

Manuels Multiplexeur populaires d'autres marques

Campbell

Campbell AM416 Manuel utilisateur

Paradyne

Paradyne SIM2000 Manuel utilisateur

Panasonic

Panasonic WJFS616 - SWITCHER Manuel utilisateur

Lanex

Lanex TM-77 Manuel utilisateur

Bosch

Bosch VSS8394/01T Manuel utilisateur

Quark-Elec

Quark-Elec QK-A035 Manuel utilisateur

ADTRAN

ADTRAN Frameport 768 Manuel utilisateur

Elo TouchSystems

Elo TouchSystems E247 Manuel utilisateur

Paradyne

Paradyne Hotwire 8786 Manuel utilisateur

RFL Electronics

RFL Electronics 9508D UCC Manuel utilisateur

Miranda

Miranda AMX-101i Mode d’emploi

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manuel utilisateur

GE StoreSafe SDVR-10 Manuel utilisateur

American Fibertek

American Fibertek MTX-8410C Manuel utilisateur

ADC

ADC HiGain ELU-319 5E Manuel utilisateur

Paradyne

Paradyne Hotwire 8774 Manuel utilisateur

American Fibertek

American Fibertek MTX-8810C-SL Manuel utilisateur

Viessmann

Viessmann 5229 Manuel utilisateur
