Issue 4.3 May 2021

40-735 User Manual

PXI Data Comms Multiplexer Module

Page (II) DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture 40-735 ........ .......................................4.2

Programming The Module 40-735.......................................4.5

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Relay Lookup Tables.............................................................7.1

Component Layout................................................................7.4

CONTENTS

Page (VI) DATA COMMS MULTIPLEXER MODULE 40-735

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) DATA COMMS MULTIPLEXER MODULE 40-735

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

DATA COMMS MULTIPLEXER MODULE 40-735

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI Data Communications RF MUX 40-735

ISSUE 7.1 SEP 2019

Pickering’s Range of Data Comms Multiplexers

Model

No. Conﬁguration Application

40-735

Single 36 channel

or Dual 18 channel,

differential pair

USB, RS232

40-736

Single 32, Dual 16, Quad

8 channel, differential

pair

1 Gb Ethernet, AFDX,

BroadR-Reach, LVDS,

USB, RS232

40-737

Single 8:1 or 16:1

differential pair &

power

USB1, USB2

ySuitable For Switching USB or

RS-232 Data Lines

yConﬁgurable To Dual 18-Channel or Single

36-Channel

yMaintains USB Data Line Impedance

yCan be Used As General Purpose Two Pole

MUX

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported by PXI or LXI Chassis

y3 Year Warranty

18-WAY

MUX

SWITCH

SERIAL

INPUT 1

SERIAL

INPUT 2

18-WAY

MUX

Functional diagram of the

40-735 Data Communications RF Multiplxer

The 40-735 MUX is designed for switching the data lines of

serial interfaces such as RS232 and USB. Careful attention

to the design of the module ensures that the switching

system minimizes its impact on the transmission distance

of USB1.1 interfaces.

The MUX is available in 36:1 or 18:1 formats and enables

a single serial data source to be switched to one of 36 or

18 devices under test. The 36:1 version can be software

conﬁgured into two independent 18 way MUXs enabling

two separate serial data sources to be connected to

separate banks of 18 devices.

The module is ideal for performing bulk testing of devices

that use a serial data communications port to load

software or control device operation. The 40-735 can also

be used for a variety of other applications where a 2-pole

low power MUX is required.

Page 1.2 DATA COMMS MULTIPLEXER MODULE 40-735

pickering

SECTION 1 - TECHNICAL SPECIFICATION

Data Communications RF MUX, 40-735

pickeringtest.com

Speciﬁcations

Switching Speciﬁcation

Max Switching Voltage: 150 VDC/100 VAC*

Max Power:

Max Switch Current:

10 W

0.5 A

Initial On Path Resistance:

Off Path Resistance:

Thermal Offset:

<1200 mΩ

>1x109 Ω

<10 µV

Bandwidth: >200 MHz (differential, 90 Ω)

Operate Time:

Release Time:

<4 ms

Expected Life

Low power load:

Full power load:

>1x108 operations

>2x105 operations

* For full voltage rating, signal sources to be switched

must be fully isolated from mains supply and safety earth.

Power Requirements

+3.3 V +5 V +12 V -12 V

0 150 mA 0 0

Operating/Storage Conditions

Operating Conditions

Operating Temperature:

Humidity:

Altitude:

0 °C to +55 °C

Up to 90 % non-condensing

5000 m

Storage and Transport Conditions

Storage Temperature:

Humidity:

Altitude:

-20 °C to +75 °C

Up to 90 % non-condensing

15000 m

PXI & CompactPCI Compliance

The module is compliant with the PXI Speciﬁcation

2.2. Local Bus, Trigger Bus and Star Trigger are not

implemented.

Uses a 33 MHz 32-bit backplane interface.

Safety & CE Compliance

All modules are fully CE compliant and meet applicable

EU directives: Low-voltage safety EN61010-1:2010,

EMC Immunity EN61326-1:2013,

Emissions EN55011:2009+A1:2010.

Mechanical Characteristics

Single slot 3U PXI (CompactPCI card). For the slot

occupancy of special build modules, see the Connectors

section.

3D models for all versions in a variety of popular ﬁle

formats are available on request.

Connectors

PXI bus via 32-bit P1/J1 backplane connector.

Signals via front panel 96-pin male micro-D connector, for

pin outs please refer to the operating manual.

Special builds are available with the following connectors:

Dual 18 Channel MUX with 96-pin micro-D connector (1

slot)

Single 10 Channel MUX with XLR connectors (6 slot)

Single 18 Channel MUX with BNC connectors (2 slot)

Single 36 Channel MUX with SMB connectors (2 Slot)

Relay Type

The 40-735 is ﬁtted with a mix of ruthenium sputtered reed

relays and electro-mechanical relays. Spare relays are

built onto the circuit board to allow easy maintenance with

minimum downtime.

All reed relays are manufactured by our sister company

Pickering Electronics: pickeringrelay.com

Typical Insertion Loss

(Measured in a 90 Ω Differential Transmission Line)

Table des matières

Autres manuels Pickering Multiplexeur

Pickering

Pickering 40-655A Manuel utilisateur

Pickering

Pickering 40-680 Manuel utilisateur

Pickering

Pickering 40-683A Manuel utilisateur

Pickering

Pickering 40-662A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-670C Manuel utilisateur

Pickering

Pickering 40-666B Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering PXI Power MUX BRIC 40-571A Manuel utilisateur

Pickering

Pickering 40-658A Manuel utilisateur

Pickering

Pickering 40-784A Manuel utilisateur

Pickering

Pickering 20-745 Manuel utilisateur

Pickering

Pickering 40-660A-001 Manuel utilisateur

Pickering

Pickering 40-614B Manuel utilisateur

Pickering

Pickering 40-657 Manuel utilisateur

Pickering

Pickering 40-659A Manuel utilisateur

Pickering

Pickering PXi 40-660A Manuel utilisateur

Pickering

Pickering 40-761 Series Manuel utilisateur

Pickering

Pickering 20-610 Manuel utilisateur

Pickering

Pickering 60-590 Manuel utilisateur

Pickering

Pickering 60-721A Manuel utilisateur

Pickering

Pickering 40-675A Manuel utilisateur

Pickering

Pickering 40-616 Manuel utilisateur

Pickering

Pickering PCI 50-670 Manuel utilisateur

Manuels Multiplexeur populaires d'autres marques

Campbell

Campbell AM416 Manuel utilisateur

Paradyne

Paradyne SIM2000 Manuel utilisateur

Panasonic

Panasonic WJFS616 - SWITCHER Manuel utilisateur

Lanex

Lanex TM-77 Manuel utilisateur

Bosch

Bosch VSS8394/01T Manuel utilisateur

Quark-Elec

Quark-Elec QK-A035 Manuel utilisateur

ADTRAN

ADTRAN Frameport 768 Manuel utilisateur

Elo TouchSystems

Elo TouchSystems E247 Manuel utilisateur

Paradyne

Paradyne Hotwire 8786 Manuel utilisateur

RFL Electronics

RFL Electronics 9508D UCC Manuel utilisateur

Miranda

Miranda AMX-101i Mode d’emploi

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manuel utilisateur

GE StoreSafe SDVR-10 Manuel utilisateur

American Fibertek

American Fibertek MTX-8410C Manuel utilisateur

ADC

ADC HiGain ELU-319 5E Manuel utilisateur

Paradyne

Paradyne Hotwire 8774 Manuel utilisateur

American Fibertek

American Fibertek MTX-8810C-SL Manuel utilisateur

Viessmann

Viessmann 5229 Manuel utilisateur
