Issue 2.2 November 2021

40-681 User Manual

PXI Solid State Versatile Multiplexer Module

Page (II) SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

40-681 Functional Description .............................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options for PXI Modules ..............................4.1

Programming The Module ....................................................4.2

Programming Lookup Tables...............................................4.7

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Lookup Tables.............................................................7.1

CONTENTS

Page (VI) SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI Solid State Versatile Multiplexer 40-681

ISSUE 3.1 NOV 2021

Supported by

eBIRST

eBIRST switching system test tools simplify fault-ﬁnding by

quickly testing the system and graphically identifying the

faulty relay.

For more information go to: pickeringtest.com/ebirst

yVersatile Solid State Multiplexer

yConﬁgurable Architecture

y350 mA Hot or Cold Switching

ySurge Current of 1.5 A for 100 ms

y60 Volt Switching

yFast Switch Operation and Long Service Life

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported by PXI or LXI Chassis

ySupported by

eBIRST

™

y3 Year Warranty

The 40-681 Very High Density Versatile Multiplexer module

features a wide range of selectable switching conﬁgurations.

It is especially useful where a high density multiplexer is

required that can be adapted to different conﬁgurations for

different test targets, or where a test system may have to be

reconﬁgured in the future. The module uses high performance

solid state relays which have a long service life even when hot

switching capacitive loads. The 40-681 can sustain 1.5 A for

100 ms hot or cold switching.

MUX Conﬁgurations

The module can be set in software to be one of a large

number of multiplexer conﬁgurations. Switches allow the

multiplexer banks to be set as 1 or 2-pole and inter-bank

switching enables the channel count to be increased up to a

maximum of 128 (refer to schematic diagram overleaf).

Typical Conﬁgurations:

8-Banks, 16-Channel, 1-Pole

8-Banks, 8-Channel, 2-Pole

4-Banks, 32-Channel, 1-Pole

4-Banks, 16-Channel, 2-Pole

2-Banks, 64-Channel, 1-Pole

2-Banks, 32-Channel, 2-Pole

1-Bank, 128-Channel, 1-Pole

1-Bank, 64-Channel, 2-Pole

The versatility of the 40-681’s architecture allows all

multiplexer banks to be inter-linked and common connections

used as extra signal inputs.

The 40-681 may be operated as a conventional multiplexer

with break-before-make action when a new channel is

selected. For 2-pole conﬁgurations multiple channels can

be simultaneously selected without restriction, for 1-pole

conﬁgurations the channels that can be simultaneously

selected are limited by the use of 2-pole switching.

Isolation Switching connects only the currently active

multiplexer bank to the analog common, keeping capacitive

loading and leakage current in large multiplexer systems to

a minimum. Larger multiplexers may be constructed by daisy

chaining the common signals from multiple modules.

Pickering Interfaces is able to offer PXI solid state switching

solutions in a variety of conﬁgurations. If you have a different

requirement contact your local sales ofﬁce for a quotation.

Pickering’s Range of Versatile Multiplexer Modules

with the same switching architecture

Model

No.

Max

Voltage

Max

Current

Operate

Time

Relay

Type

40-612 300 VDC/

250 VAC 2 A 3 ms Electro-

mechanical

40-681 ±60 V 350 mA 200 µs Solid State

40-682 ±40 V 250 mA 80 µs Solid State

40-683 ±100 V 125 mA 500 µs Solid State

Page 1.2 SOLID STATE VERSATILE MULTIPLEXER MODULE 40-681

pickering

SECTION 1 - TECHNICAL SPECIFICATION

Solid State Verstatile MUX, 40-681

pickeringtest.com

Overview

1.2

1.1

2.2

2.1

3.2

3.1

4.2

4.1

5.2

5.1

8.2

8.1

6.2

6.1

7.2

7.1

MUX1

MUX2

16.2

9.1

MUX3

24.2

17.1

MUX4

32.2

25.1

MUX5

40.2

33.1

MUX6

48.2

41.1

MUX7

56.2

49.1

MUX8

64.2

57.1

Com 1.1

Com 1.2

Com 2.1

Com 2.2

Com 3.1

Com 3.2

Com 4.1

Com 4.2

Com 5.1

Com 5.2

Com 6.1

Com 6.2

Com 7.1

Com 7.2

Com 8.1

Com 8.2

1 Pole

Selection

Switches

Inter-bank Connection Switches Isolation

Switches

Functional Diagram of 40-681 Solid State Versatile Multiplexer

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Pickering Multiplexeur

Pickering

Pickering 40-666A Manuel utilisateur

Pickering

Pickering 20-610 Manuel utilisateur

Pickering

Pickering 40-619 Manuel utilisateur

Pickering

Pickering 40-611A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 60-590 Manuel utilisateur

Pickering

Pickering 40-613A Manuel utilisateur

Pickering

Pickering PXI 40-850A Manuel utilisateur

Pickering

Pickering SIMRC 1050 Manuel utilisateur

Pickering

Pickering 40-675 Manuel utilisateur

Pickering

Pickering 40-657 Manuel utilisateur

Pickering

Pickering LXI 65-231-9 Series Manuel utilisateur

Pickering

Pickering 40-613 Manuel utilisateur

Pickering

Pickering PXi 40-660A Manuel utilisateur

Pickering

Pickering 40-616A Manuel utilisateur

Pickering

Pickering PXI 40-635A Manuel utilisateur

Pickering

Pickering 40-756 Manuel utilisateur

Pickering

Pickering 40-614 Manuel utilisateur

Pickering

Pickering PXI Power MUX BRIC 40-571 Manuel utilisateur

Pickering

Pickering 40-659A Manuel utilisateur

Pickering

Pickering PXI 40-748 1 Series Manuel utilisateur

Pickering

Pickering PXI 40-785B Manuel utilisateur

Pickering

Pickering 40-610A Manuel utilisateur

Pickering

Pickering PCI 50-670 Manuel utilisateur

Manuels Multiplexeur populaires d'autres marques

Campbell

Campbell AM416 Manuel utilisateur

Paradyne

Paradyne SIM2000 Manuel utilisateur

Panasonic

Panasonic WJFS616 - SWITCHER Manuel utilisateur

Lanex

Lanex TM-77 Manuel utilisateur

Bosch

Bosch VSS8394/01T Manuel utilisateur

Quark-Elec

Quark-Elec QK-A035 Manuel utilisateur

ADTRAN

ADTRAN Frameport 768 Manuel utilisateur

Elo TouchSystems

Elo TouchSystems E247 Manuel utilisateur

Paradyne

Paradyne Hotwire 8786 Manuel utilisateur

RFL Electronics

RFL Electronics 9508D UCC Manuel utilisateur

Miranda

Miranda AMX-101i Mode d’emploi

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manuel utilisateur

GE StoreSafe SDVR-10 Manuel utilisateur

American Fibertek

American Fibertek MTX-8410C Manuel utilisateur

ADC

ADC HiGain ELU-319 5E Manuel utilisateur

Paradyne

Paradyne Hotwire 8774 Manuel utilisateur

American Fibertek

American Fibertek MTX-8810C-SL Manuel utilisateur

Viessmann

Viessmann 5229 Manuel utilisateur
