Pickering 45-720A Manuel utilisateur

pickeringtest.com

Issue 4.4 August 2021

45-720A User Manual

PXI 6 U Expandable 250 MHz 16x16 RF Matrix

Page (II) 16 x 16 RF MATRIX MODULE 45-720A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

16 x 16 RF MATRIX MODULE 45-720A

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 16 x 16 RF MATRIX MODULE 45-720A

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

16 x 16 RF MATRIX MODULE 45-720A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture 45-720A .............................................4.2

Sub-Unit Tables ....................................................................4.4

Programming The Module 45-720A ....................................4.7

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Relay Lookup Tables 45-720A .............................................7.1

Component Layout 45-720A.................................................7.5

CONTENTS

Page (VI) 16 x 16 RF MATRIX MODULE 45-720A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

16 x 16 RF MATRIX MODULE 45-720A

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) 16 x 16 RF MATRIX MODULE 45-720A

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

16 x 16 RF MATRIX MODULE 45-720A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 6 U Expandable 250 MHz 16x16 RF Matrix 45-720A

ISSUE 7.1 APR 2020

y16x16 Coaxial Matrix

y250 MHz Bandwidth

yHigh Quality Ruthenium Reed Relays

yChoice of Front Panel Mounted Coaxial Connectors

yAvailable in 50 Ω and 75 Ω Versions

yUses High Reliability Reed Relays

yVISA/IVI Drivers Supplied for Windows

y3 Year Warranty

The 45-720A module is a 6 U 16x16 RF Matrix suitable for

switching frequencies beyond 250 MHz. It is available in

50 Ω and 75 Ω versions with a choice of coaxial connectors.

It is intended for the easy construction of high performance

bi-directional matrix switching systems.

Automatic isolation switches are located on all input and

output connections. These are used to disconnect unused

signals from the external test ﬁxture to maximize isolation

and RF performance.

Typical applications are switching signals to high speed

digitizers. The matrix is constructed using high reliability

ruthenium electro-plated reed relays, with an operational

life of >108 to give maximum switching conﬁdence with long

service and stable contact resistance.

Matrix Operation

The 45-720A is a true 16x16 high density

matrix, any combination of cross-points

may be selected. Only the signal is

switched, all grounds are common. Loop-

thru is included on X signals.

Easy Expansion with Automatic Loop-Thru

All unused X input channels are

automatically switched to the

corresponding “Loop-thru” output

connection. This allows for simple

expansion (with a little performance loss)

and permits the user to place matched

terminations on the outputs if required.

Switching Diagram for the 45-720A

16x16 Matrix Module

OUT

X10

OUT

X11

OUT

X12

OUT

X13

OUT

X14

OUT

X15

OUT

X16

IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN

Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13 Y14 Y15 Y16

Isolation Switch

Crosspoint

Changeover

Page 1.2 16 x 16 RF MATRIX MODULE 45-720A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

6 U 250 MHz 16x16 RF Matrix, 45-720A

pickeringtest.com

Overview

OUT

IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN

X10

X11

X12

X13

X14

X15

X16

Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13 Y14 Y15 Y16

MATRIX 1

XOUT

XIN

OUT

IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN

XOUT

MATRIX 2

OUT

IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN IN

MATRIX 6

XIN

X10

X11

X12

X13

X14

X15

X16

Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13 Y14 Y15 Y16

X10

X11

X12

X13

X14

X15

X16

Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13 Y14 Y15 Y16

Matrix Expansion

Larger matrices may be constructed by daisy-chaining the X signals from multiple modules, for example, six modules form a 96x16

matrix (1536 crosspoints). Expansion is achieved by interconnecting Xout (Loop-thru) of one matrix to Xin of the next using coaxial

cables as shown below. It should be noted that the operating bandwidth will reduce slightly as the number of modules is increased.

Diagram Showing How Multiple 16x16

Matrix Modules Can be Daisy-Chained to

Form a Larger Matrix

Table des matières

Autres manuels Pickering Matériel informatique

Pickering

Pickering 50-110 Manuel utilisateur

Pickering

Pickering 50-671A Manuel utilisateur

Pickering

Pickering PXI 40-923 Manuel utilisateur

Pickering

Pickering 50-510 Manuel utilisateur

Pickering

Pickering LXI 60-891-045 Manuel utilisateur

Pickering

Pickering 40-738 Manuel utilisateur

Pickering

Pickering 65-218 Manuel utilisateur

Pickering

Pickering 40-575A Manuel utilisateur

Pickering

Pickering PXI 40-419 Manuel utilisateur

Pickering

Pickering 50-200 Manuel utilisateur

Pickering

Pickering 50-510A Manuel utilisateur

Pickering

Pickering 50-297 Manuel utilisateur

Pickering

Pickering Pxi 40-922 Manuel utilisateur

Pickering

Pickering 50-295A Manuel utilisateur

Pickering

Pickering 41-650 Manuel utilisateur

Pickering

Pickering 50-296A Manuel utilisateur

Pickering

Pickering 60-901 Manuel utilisateur

Pickering

Pickering 40-755A-9 Series Manuel utilisateur

Pickering

Pickering 40-588-222 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
