Philips Impact Vacuum Cleaner Manuel utilisateur

Impact

ENGLISH 4

DEUTSCH 11

FRANÇAIS 18

NEDERLANDS 25

ESPAÑOL 32

ITALIANO 39

PORTUGUÊS 46

NORSK 53

SVENSKA 60

SUOMI 67

DANSK 74

 81

TÜRKÇE 88

IMPACT

Important

◗Only use Philips s-bag`double-layer paper dustbags (type

FC8021) or the cotton dustbag provided (some versions only).

◗Check if the dustbag has been placed correctly.

◗Never suck up water or any other liquid.Never suck up ashes until

they are cold.

◗When the vacuum cleaner is used to suck up fine dust,the pores

of the dustbag may become clogged,causing the passage of air

through the dustbag to become obstructed.As a result,the

'dustbag full' indicator will indicate that the dustbag needs to be

replaced,even though the dustbag is not full at all.

◗Never use the appliance without the Motor Protection Filter.This

could damage the motor and shorten the life of the appliance.

Connecting accessories

C1To connect the hose to the appliance,push it into the appliance

and turn it clockwise.

To disconnect the hose from the appliance, turn it anticlockwise and

pull it out of the appliance.

C2Connect the tubes to the handgrip by inserting the narrow

section into the wider section while turning it a little.The tube

with the clip is the lower tube.

You can connect the combi nozzle and crevice/brush accessory in the

same way.

To disconnect the tubes and accessories,pull while turning a little.

◗The combi nozzle can be used on either carpets (without brush)

or hard floors (with brush).

C3Telescopic tube

Adjust the tube to the length you find most comfortable during

vacuum cleaning.

4Connect the combi nozzle to the tubes.

ENGLISH4

C5Push the rocker switch on top of the combi nozzle with your

foot to make the brush strip for cleaning hard floors come out

of the nozzle housing.

C6Push the rocker switch again to make the brush strip disappear

into the combi nozzle housing again.It can now be used for

cleaning carpets.

◗The combi crevice/brush accessory can be used either for cleaning

narrow corners and hard-to-reach places or for cleaning

computers,bookshelves,etc.

C7Lift the handle on the vacuum cleaner to gain access to the

accessory storage compartment.

8Connect the crevice/brush accessory to the tube or directly to

the handgrip.

C9You can use the crevice/brush accessory as a crevice nozzle.

C10 You can also use the crevice/brush accessory as a brush.

ENGLISH 5

Vacuum cleaning

C1Pull the cord out of the appliance and put the mains plug in the

wall socket.

C2Switch the appliance on by pushing the on/off switch on top of

the appliance with your foot.

C◗To carry the appliance,put the handle in upright position and lift

the appliance by the handle.

Adjusting suction power

You can adjust the suction power during vacuum cleaning:

C1Adjust the suction power by means of the slide on the

handgrip (specific types only).

C2Adjust the suction power by means of the electronic suction

power control (specific types only).

ENGLISH6

Storage

1Switch the appliance off.

2Remove the mains plug from the wall socket.

C3Rewind the mains cord by pressing the cord rewind button

with your foot.

C4Put the appliance in upright position and attach the lower tube

to the appliance by means of the clip.

◗The clip can be slid along the tube to adjust its height.

Replacing the dustbag

◗Replace the dustbag as soon as the 'dustbag full' indicator has

changed colour permanently (i.e.not only when the nozzle is

placed on a surface while the appliance is running).

1Switch the appliance off.

C2Open the cover.

C3Push the dustbag holder backwards.

C4Remove the full dustbag by pulling the cardboard lug upwards.

When you do this,the dustbag will automatically be sealed.

ENGLISH 7

C5Slide the cardboard front of the new dustbag into the two

grooves of the dustbag holder.Press it down as far as possible.

C6Pull the dustbag holder forwards (you will hear a click).

You cannot close the cover if no dustbag has been inserted.

◗If provided,you can use the cotton dustbag instead of paper

dustbags.The cotton dustbag can be used and emptied repeatedly.

For removing and inserting the cotton dustbag,simply follow the

instructions for replacing paper dustbags.

To empty the cotton dustbag:

- Hold the dustbag over a dustbin.

- Remove the clip by sliding it off the dustbag sideways.

- Undo the metal hooks.

- Shake out the contents.

- Close the dustbag by fastening the metal hooks and sliding the clip

back onto the bottom edge of the dustbag.

Filter replacement

◗This appliance has been equipped with a Motor Protection Filter.

1Replace the Motor Protection Filter when you insert the first

of a new set of dustbags.

C2Insert the filter into the appliance with the white side facing

upwards.

◗If you are using the cotton dustbag,wash the Motor Protection

Filter in lukewarm water once a year.

Make sure the Motor Protection Filter is completely dry before you

put it back into the appliance.

◗TheAFS Micro Filter in this appliance will remove a large part of

the smallest particles from the exhaust air by means of its

electrostatically charged fibres.

3Replace theAFS Micro Filter when you insert the first of a new

set of dustbags or once a year if you are using a cotton

dustbag.

C4Place the sides (1,2) and the bottom edge (3) of the new filter

properly behind the ridges of the holder.

ENGLISH8

C5Replace the holder by first hooking the bottom edge of the

holder into the appliance (1) and then pushing the holder

towards the appliance (2) until it clicks home.Make sure the

filter holder has been replaced properly.

Ordering dustbags and filters

Philips s-bag`paper dustbags are available under type number

FC8021.

Philips Sydney + paper dustbags are available under type number

HR6999.

Two AFS Micro Filters and one Motor Protection Filter are available

under type number FC8032.

If you have any difficulties obtaining dustbags,filters or other accessories

for this appliance,please contact the Philips Helpdesk.

See the worldwide guarantee leaflet for telephone numbers of the

Philips Helpdesk.

Environment

To make recycling possible, the plastics used for this appliance have

been coded.

The cardboard packaging has been made of recycled material and is

fully recyclable.

Cord replacement

If the mains cord of this appliance is damaged,it may only be replaced

by Philips or a service centre authorised by Philips,as repair requires

special tools and/or parts.

Solving problems

◗The suction power is insufficient:

1Check if the dustbag needs to be replaced.

2Check if the filters need to be replaced.

C3Set the electronic suction power control to a higher setting

(specific types only).

ENGLISH 9

C4Close the slide on the handgrip (specific types only).

C5Check if the nozzle,tube or hose is blocked up.To remove the

obstruction,disconnect the blocked-up item and connect it (as

far as possible) the other way around.Switch the vacuum

cleaner on to force the air through the blocked-up item in

opposite direction.

Information & service

If you need information or if you have a problem,please visit the Philips

Web site at www.philips.com or contact the Philips Customer Care

Centre in your country (you will find its phone number in the

worldwide guarantee leaflet).If there is no Customer Care Centre in

your country,turn to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and Personal Care BV.

ENGLISH10
