Philips FC6161 Manuel utilisateur

FC6161

11 12

FC6161

ENGLISH 6

简体中文 22

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet

from the support that Philips offers, register your product at www.philips.

com/welcome.

General description (Fig. 1)

AStick unit

1 On/off button

2 Maximum power (MAX) button

3 Upper stick

4 Screw to attach upper stick to lower stick

5 Lower stick

6 Floor nozzle joint

7 Floor nozzle release button

8 ’Brush blocked’ light

9 Floor nozzle

10 Retainer

11 Roller brush

12 Cutting groove

13 Wheels

BHandheld vacuum cleaner

1 On/off button

2 Dust compartment release button

3 Dust compartment

4 Small nozzle release button

5 Handheld vacuum cleaner release button

6 Exhaust air openings

7 Filter unit

8 Detachable small nozzle

9 Outer lter

10 Inner lter

11 Filter holder with rattle mechanism

CAccessories

1 Charging base

2 Charging light

3 Storage compartment

4 Brush tool

5 Crevice tool

6 Adapter

7 Back support of charging base

8 Wall-mounting screw

Important

Read this user manual carefully before you use the appliance and save it for

future reference.

Danger

- Never suck up water or any other liquid. Never suck up ammable

substances and do not suck up ashes until they are cold.

- Never immerse the appliance, the charging base or the adapter in

water or any other liquid, nor rinse it under the tap.

ENGLISH

Warning

- Check if the voltage indicated on the adapter corresponds to the local

mains voltage before you connect the appliance.

- Do not use the vacuum cleaner, the charging base or the adapter if it is

damaged.

- If the adapter or charging base is damaged, always have it replaced with

one of the original type in order to avoid a hazard.

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

- Children should be supervised to ensure that they do not play with the

appliance.

Caution

- Remove the adapter from the wall socket before you clean the

charging base.

- Only charge the vacuum cleaner with the adapter and charging base

supplied. During charging, the adapter feels warm to the touch.This is

normal.

- Always switch off the vacuum cleaner after use.

- The voltage on the contact strips in the charging base is low and

therefore not dangerous.

- Never block the exhaust air openings during vacuuming.

- Switch off the appliance when you charge it.

- Always use the vacuum cleaner with the lter unit assembled.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards regarding electromagnetic

elds (EMF). If handled properly and according to the instructions in this

user manual, the appliance is safe to use based on scientic evidence

available today.

Before rst use

1 Remove any protective foil or plastic from the appliance.

2 Attach the back support to the back of the charging base (‘click’).

Note:You only have to do this once. Never disassemble the back support from

the charging base.

3 For better stability, you must mount the charging base to the wall.To

do so, drive the screw supplied through the hole in the back support

into the wall.

ENGLISH 7

4 Place the upper stick on the lower stick (‘click’).

Note: Make sure that the recesses of the upper stick t exactly on the

projections of the lower stick.

Note:You only have to do this once. Never disassemble the upper stick from

the lower stick.

5 Fasten the screw with a screwdriver or coin.

6 Placethestickontheoornozzle(‘click’).

Preparing for use

Charging the appliance

Charge the appliance for at least 7 hours before you use it for the rst

time.

It takes approx. 7 hours to fully charge the appliance.

The operating time of the appliance varies.When the handheld vacuum

cleaner is fully charged, it has an operating time of 12 minutes when it

is used without the stick unit.When the fully charged handheld vacuum

cleaner is placed in the stick unit, it has an operating time of 11 minutes at

maximum speed and more than 20 minutes at normal speed.

1 Make sure the appliance is switched off.

2 Put the adapter of the charging base in the wall socket.

3 Place the handheld vacuum cleaner in the stick unit (‘click’).

4 Place the appliance on the charging base.

ENGLISH8

,The charging light goes on to indicate that the appliance is charging.

Note:The charging light does not give any information about the battery

charge level of the vacuum cleaner.

,When the appliance is fully charged, the charging light goes out.

Note:You can leave the appliance on the charging base, even when it is fully

charged. Every 5 minutes, the charging light lights up for 3 seconds.This

indicates that the appliance is checking if the batteries are still fully charged.

Note: If you put the appliance on the charging base while it is switched on, the

appliance switches off automatically after 2 seconds.

Saving energy

If you are not going to use the appliance for a longer period of time,

remove the adapter from the wall socket to save energy.

Using the appliance

Using the stick unit

You can use the stick unit to clean oors and carpets.

When you use the stick unit, always make sure the dust compartment

is attached to the handheld vacuum cleaner, to prevent damage to the

handheld vacuum cleaner.

1 Place the handheld vacuum cleaner properly in the stick unit (‘click’).

2 Press the on/off button to switch on the appliance.

,The appliance starts to operate at normal speed. Use this speed for

optimal operating time and minimal noise.The operating time at this

speed is more than 20 minutes.

- Press the MAX button if you want to operate the appliance at

maximum speed. Use this speed for optimal cleaning performance.The

operating time at this speed is 11 minutes.

- If you want to switch back to normal speed, press the MAX button

again.

Note: During use, the ‘brush blocked’ light may ash red to indicate that the

roller brush is blocked. If this happens, you have to remove the item that is

blocking the brush or clean the brush (see chapter ‘Cleaning’).

ENGLISH 9

3 If you want to leave the appliance alone for a while or if you want to

remove the handheld vacuum cleaner from the stick unit during use,

youcanusetheparkingposition.Pushthesticktowardstheoor

nozzleintotheparkingposition.

4 After use, press the on/off button to switch off the appliance.

Using the handheld vacuum cleaner

You can use the handheld vacuum cleaner without the stick unit to vacuum

small and hard-to-reach areas, like tables, furniture, car seats etc.

When the handheld vacuum cleaner is fully charged, it has an operating

time of 12 minutes.

1 If the handheld vacuum cleaner is attached to the stick unit, switch

off the handheld vacuum cleaner before you remove it from the stick

unit.

Note: If you remove the handheld vacuum cleaner when the appliance is

switched on at normal speed, the handheld vacuum cleaner operates at

reduced power.To make sure the handheld vacuum cleaner operates at full

power, switch it off and back on again.

2 Press the handheld vacuum cleaner release button (1) and remove

the handheld vacuum cleaner from the stick unit (2).

3 Press the on/off button to switch on the appliance.

4 After use, press the on/off button again to switch off the appliance.

Make sure you switch off the handheld vacuum cleaner before you

put it back into the stick unit

Note: If you put the handheld vacuum cleaner back into the stick unit

when it is still switched on, the roller brush does not work and the cleaning

performance is not optimal.To make the roller brush operate, switch off the

appliance and switch it back on again.

Accessories

The appliance comes with the following accessories:

- a crevice tool to vacuum corners or narrow gaps.

- a brush tool to clean delicate surfaces.

1 Take the accessory you want to use from the storage compartment

of the charging base.

2 Attachtheaccessorytothesmallnozzle.

ENGLISH10
