Country Number Tariff

Austria 0820 901114 €0.20/min

Belgium 070 222 303 €0.17/min

Chech Rep 800142840 free

Denmark 3525 8759 local

Finland 09 2311 3415 local

France 08 9165 0005 €0.23/min

Germany 0180 5 356 767 €0.12/min

Greece 0 0800 3122 1280 free

Hungary 0680018189 free

Ireland 01 601 1777 local

Italy 199 404 041 €0.25/min

Luxemburg 40 6661 5644 local

Netherlands 0900 8407 €0.20/min

Norway 2270 8111 local

Poland 0223491504 local

Portugal 2 1359 1442 local

Slovakia 0800004537 free

Spain 902 888 784 €0.15/min

Sweden 08 5792 9100 local

Switzerland 0844 800 544 local

UK 0906 1010 016 £0.15/min

www.philips.com/support

Model

Serial

Thank you for purchasing this television set.

This handbook has been designed to help you install and operate your TV set.

We strongly recommend that you read it thoroughly.

Introduction

Table of Contents

Recycling

The packaging of this product is intended to be recycled. Apply to the local authorities

for correct disposal.

Disposal of your old product

Your product is designed and manufactured with highly quality material and components,

which can be recycled and reused. When this crossed-out wheeled bin symbol is attached

to a product, it means the product is covered by the European Directive 2002/976/EC.

Please inform yourself about the local seperate collection system for electrical and

electronic products.

Please act according to your local rules and do not dispose of your old products with your

normal household waste. The correct disposal of your product will help prevent potential

negative consequences for the environment and human health.

10 cm 10 cm

10 cm

Safety Information

Avoid placing your TV set under direct sunlight

or heat.

To prevent fire or shock hazard, do not expose

your TV to rain or moisture.

Take care not to connect too many equipment

to the same mains socket as it may cause

overloading resulting in fire or electric shock.

Pull the power lead by the plug. Do not pull on

the power lead. Do not use a poor fitting mains

socket. Insert the plug fully into the mains. If it is

loose, it may cause arching and result in fire.

No naked flame sources (lighted candles) should

be placed on the top of the set or near it.

When cleaning the surface or the screen of the

set, wipe gently with absorbent cotton or cloth

or other soft material like chamois. Do not use

too wet a cloth which is dripping with water.

Do not use acetone, toulene or alcohol to

clean the TV. As a safety precaution, unplug the

power cord from the mains.

As a safety precaution, do not touch any part of

the TV, power lead or aerial lead during lightning

storms.

Installation of the TV set on the wall should be

carried out by qualified serviceman. Improper

and incorrect installation may render the set

unsafe.

Avoid placing vase filled with water on the TV.

Water spilled into the set could result in electric

shock. Do not operate set if water is spilled into

it. Have it checked immediately by a qualified

serviceman.

Leave at least 10 cm around each side of the

TV set to allow for proper ventilation. Place

the set on a stable, level surface. Never cover

the ventilation slots of the TV with a cloth or

other material. It may cause overheating. Do not

insert anything in the ventilation holes. If metal

or something flammable is inserted in these

holes, it may result in fire or electric shock.

Switching on the TV set

• To switch on the TV set, press the POWER

button. A green indicator comes on and the

screen lights up.

• If the TV set remains in standby mode (red

indicator), press the PROGRAM – /

+ key on

the keyboard or the P – / + key on the

remote control.

Preparation / Getting started

Connections

• Insert the aerial plug into the 75Ω :

socket at the bottom of the set.

• Insert the mains plug into a wall socket

(220-240V / 50/60Hz).

• Ensure the power cord is fully inserted in

the TV mains socket and the wall socket.

Warning!

If the TV is mounted on a swivel base or

swivel arm, ensure no strain is placed on

the power cord when the TV is swivelled.

Strain on the power cord can loosen

connections. This may cause arching and

result in fire.

Using the Remote Control

Pull out the plastic insulation sheet from the

battery to enable the remote control to operate.

NOTE

For more details on other connections,

see “CONNECTION GUIDE”.

26”

32”

37”/42”/50”

26”

– PROGRAM +

– VOLUME +

POWER

32”

37”/42”/50”

Television keys and connectors

EXT 4

EXT 2 /SVHS2

EXT 1

DVI

(AUDIO IN)

HDMI 2 HDMI 1

AUDIO

R L

Pb Y

AC in ~

Headphone

Audio In

Video In

S-Video

AUDIO

VIDEO

S-VIDEO

EXT3/SVHS3

– PROGRAM +

– VOLUME +

POWER

32”

LCD

EXT 4

EXT 2 /SVHS2

EXT 1

DVI

(AUDIO IN)

HDMI 2 HDMI 1

AUDIO

R L

Pb Y

MAINS ~

AC in ~

Plasma TV

CAUTION : This

a Class 1

apparatus.

It must be connected

to a MAINS socket

out with a protective

earthing connection.

EXT3/SVHS3

37”/42”/50”

Television keys and connectors

1 POWER . : to switch the TV on and off.

2 VOLUME –/+: to adjust sound level.

3 MENU : to access or close menus.

The PROGRAM /CHANNEL –/+ keys can

be used to select a menu item and the

VOLUME –/+ keys to enter into the selected

menu item and make adjustments.

4 PROGRAM / CHANNEL –/+ : to select

programmes.

POWER socket :

Insert the mains plug into

a wall socket.

DVI Audio Input : for connecting a HD

(high definition) equipment or computer with

DVI output.

Component Video inputs / Audio Inputs

(

EXT4)

: to connect to equipment like DVD,

Set-Top box which have the same sockets.

Connect the audio inputs of the TV to the

outputs of the device together with the

Component Video Inputs.

HDMI socket : to connect to set-top box,

DVD player/recorder, High Definition

equipment or Personal Computer.

EXT1 and EXT2/SVHS2 sockets : connect to

equipment

like DVD player/recorder, VCR,

Decorder which have scart connections.

Important : In order to connect your

decoder, please use EXT1 scart only.

TV Aerial socket :

Insert the aerial plug

into the 75 : socket.

Side connections

EXT3/SVHS3

: for

connecting to devices like camera or

camcorder. Also allows you to connect your

headphone for your personal listening

pleasure.

Note :

EXT3/SVHS3

is only available for

certain models.

NOTE

For more details on connections,

see CONNECTION GUIDE.

134

EXT 4

EXT 2 /SVHS2

EXT 1

DVI

(AUDIO IN)

HDMI 2 HDMI 1

AUDIO

R L

Pb Y

AC in ~

Headphone

Audio In

Video In

S-Video

AUDIO

VIDEO

S-VIDEO

EXT3/SVHS3

26”

Remote Control keys

Standby

To set the TV to standby mode. To switch the

TV set on again, press , to ,

P – / + or AV key.

Pixel Plus

Offers a unique combination of ultimate

sharpness, increased depth impression, true

natural detail, brilliant and vivid colours. Press

the key for a Pixel + demonstration.

DVD / AUX (see page 7).

Surround Sound

To activate / deactivate the surround sound

effect. In stereo, this gives the impression that

the speakers are further apart. For models

equipped with Virtual Dolby Surround, you can

experience Dolby Surround Pro Logic sound

effects

Telextext keys (see page 15).

To display Source List to select TV or peripheral

equipment connected to EXT 1, EXT 2/SVHS2,

EXT 3/SVHS3, EXT 4, HDMI 1 or HDMI 2.

Note :

EXT3/SVHS3

is only available for

certain models.

Active Control (

ee page 14).

To call up or exit the TV menus.

Cursors

These 4 keys are used for selection and adjustment

of menu items.

Conﬁrms selection.

Volume ( – VOL + )

To adjust the sound level.

12 Smart Picture /Sound

Used to access a series of predeﬁned picture

and sound settings (see page 14).

13 / Numerical keys

For direct access to programmes. For a 2

digit programme number, the 2nd digit must

be entered before the dash disappears.

14 Screen information

To display/remove the programme number,

the sound mode, the remaining time of the

sleeptimer and the *signal strength indicator.

Mode

Select between TV, DVD and AUX mode (see

“Remote Control - Other functions” on page 7).

Programme List

To display / clear the list of programmes.

Use the keys to select a programme and

the key to display it.

Picture-in-Picture

To display a PIP window on the TV screen (see

page 12 on how to use the PIP feature).

18 Sound mode

Used to force programmes in Stereo

and Nicam Stereo to Mono or, for

bilingual programmes, to choose between

Dualå or Dual». The Mono indication is red

when in forced position.

Screen Format (see page 13).

DVD / AUX (see page 7).

Mute

Press to mute or restore sound.

22 Selecting TV programmes (P – / +)

To select the next or previous programme.

The number and the sound mode

are displayed for a few seconds. For some

TV programmes, the title of the programme appears

at the bottom of the screen.

Previous/Present programme

To alternate between the last viewed and

present programme.

* The signal strength indicator shows

the signal strength of the transmission

of the programme you are watching.

AUX

Autres manuels pour 37PF7331/12

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips TV

Philips

Philips 65PUG6412/77 Manuel utilisateur

Philips

Philips 17PT1666/05 Manuel utilisateur

Philips

Philips 32PHT4001/60 Manuel utilisateur

Philips

Philips 21PT2327/79 Manuel utilisateur

Philips

Philips 32PFL6357 V7 Manuel utilisateur

Philips

Philips 37PFL5322D Document technique

Philips

Philips Magnavox TS3659C1 Manuel utilisateur

Philips

Philips 7908 Series Manuel utilisateur

Philips

Philips 32 IN HDTV MONITOR WITH ACTIVE CONTROL 32PT830H... Manuel

Philips

Philips 29PT5408/01 Manuel utilisateur

Philips

Philips 8546 Series Manuel utilisateur

Philips

Philips TV Manuel utilisateur

Philips

Philips 50PUT8217 Manuel utilisateur

Philips

Philips 7608 Series Manuel utilisateur

Philips

Philips 32PFL5404H/12 Manuel utilisateur

Philips

Philips 55PUS7556/12 Manuel utilisateur

Philips

Philips 7906 Series Manuel utilisateur

Philips

Philips 6002 Series Manuel utilisateur

Philips

Philips 42PW9982 Manuel utilisateur

Philips

Philips 32PHH5129/79 Manuel utilisateur

Philips

Philips Matchline 36LM8908 Manuel utilisateur

Philips

Philips 30PW6341 Manuel utilisateur

Philips

Philips OLED856 Series Manuel utilisateur

Philips

Philips 200V4LSB Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
