SPA8150B

4.1

General information

Safety instructions

Please read carefully the safetymark on the back side

This mark is intended to alert the user from

the non isolated dangerous voltage within the

constitute a risk of electric shock to persons.

This mark is intented to alert the user for

important operating and servicing instruction.

Warnings

•Avoid sustained periods on high-volume use, and

do not turn the volume to maximum level while using

high output signal, such as Mobile Phone or DVD,

etc., as this will cause distortion and may damage the

loudspeaker cones.

•

when not in use.

•Do not open the cover or back panel to avoid

electrical shock or any other accidents. No user-

serviceable parts are inside.

•Only for indoor use.

•Plug the system to the AC outlet with the right voltage

marked on the back panel of the Subwoofer.

•The MAINS plug is used as the disconnect device, the

disconnect device shall remain readily operable.

Care and safety information

Avoid high temperatures, moisture, water and dust

•Apparatus should not be exposed to dripping or

splashing of liquid.

•Do not place any source of danger on the Subwoofer,

•Do not install near heat sources.

Do not block any ventilation opening

•Place the apparatus in a location with adequate

ventilation to prevent internal heat build up. Allow at

least 100cm (4 inches) of free space all around the

apparatus for adequate ventilation.

•At high volume the back cover of Subwoofer becomes

hot. Do not touch it.

Care of the cabinet

•Use a soft cloth slightly moistened to clean the cabinet.

Do not use a solution containing alcohol, spirits,

ammonia or abrasives.

Accessories

The product shall not be exposed to dripping or splashing

and that no objects lled with liquids, such as vases, shall

be placed on the product.

•

•Attention should be drawn to the environmental

aspects of battery disposal.

•Batteries shall not be exposed to excessive heat such as

sunshine, re or the like.

Item Remote control User manual FM Antenna cable

Quantity 1 1 1 1

2RCA to 3.5mm stereo pin

Connections

Back panel Top panel

Mains Cord

Power On Switch

FM Antenna

FRRR RLFL

SD Card

USB

Front panel operation

* AVAILABLE IF CONNECTED

1. :

Press to turn on speaker,long press into stand-by.

Press “ ” on the USB*/SD*/BT mode for pause or play.

2. :

Press once to reduce the FM frequency0.1M,

long press for manual search for radio.

In USB*/SD*/BT mode, press “ ” play previous song.

3. VOL- :

Volume down.

4. SOURCE :

Change the input mode-AU for Audio, Cd for CD,

Ud for USB*, Sd for SD*, 88.3 for FM, bt for Bluetooth.

3. VOL-

4. SOURCE

6. VOL+

(1)

(5)

(6)

(2)

(3)

(4)

5. 5.

Press once to increase the FM frequency 0.1M,

long press for manual search for radio.

In USB*/SD*/BT mode, press “ ” play next song.

6. VOL+:

Volume up.

Remote controls

10.

11.VOL-

12.TUNING-

13.TUNING+

2.MUTE

3.0~9

4.SOURCE

5.BASS-/+

6.EQ

7.VOL+

* AVAILABLE IF CONNECTED

1. ----- Turn on/Stand-by the speaker.

2. Mute----- Press “MUTE ” to activate or deactivate mute.

3. 0-9 ----- Numeric keys, with the help of these keys you select

song or track in USB*, and in FM, you can key in station frequency,

i.e. for 927 key in 92.7.

4. SOURCE ----- Select the input/source- AU for Audio, Cd for CD,

Ud for USB*, Sd for SD*, 88.3 for FM, bt for Bluetooth.

5. BASS-/+ ----- To decrease/ increase the bass.

6. Equalizer ----- NORMAL,CLASSIC,POP,JAZZ,POCK. (works only in

USB/SD mode)

7. VOL+ ----- Volume up.

8. ----- Plays/pauses songs alternately.in FM mode,

long press“ ”,it will enter into automatic search channel and

automatic save channel.

9. ----- Play the previous song by pressing “ ” at USB*

input mode. Choose previous channel by pressing “ ” at

FM input mode.

10. ----- Play the next song by pressing “ ” at USB*

input mode. Choose next channel by pressing “ ” at

FM input mode.

11. Vol- ----- Volume down.

12. TUNING- ----- Each time to search channel step by step(each

step(-) 0.1 MHz),Press“TUNING-”long time to search previous

channel,and play the channel automatically.

13. TUNING+ ----- Each time to search channel step by step(each

step 0.1 MHz),Press“TUNING+”long time to search next channel,

and play the channel automatically.

(1)

(3)

(4)

(6)

(7)

(9)

(12)

(2)

(5)

(8)

(10)

(11)

(13)

1. :

Press to turn on speaker,long press into stand-by.

Press “ ” on the USB*/SD*/BT mode for pause or play.

2. :

Press once to reduce the FM frequency0.1M,

long press for manual search for radio.

In USB*/SD*/BT mode, press “ ” play previous song.

3. VOL- :

Volume down.

4. SOURCE :

Change the input mode-AU for Audio, Cd for CD,

Ud for USB*, Sd for SD*, 88.3 for FM, bt for Bluetooth.

System positioning :

The subwoofer is recommended to be put

on the oor to get a better acoustic eect.

For best possible surround sound, all the

speakers (except subwoofer) should be

placed at the same distance from the

listening position.

Place the front left and right speakers at

equal distances from the TV and at an angle

of approximately 45 degrees (horizontal)

from the listening position.

Place the centre speaker above the TV so

that the centre channel’s sound is localised.

Place the surround speakers at normal

listening. ear level facing each other or

mounted on the wall.

Helpful Hints:

- To avoid magnetic interference, do not position

the speakers, too close to your TV.

Playing the speakers and subwoofer

Rear SpeakerRear Speaker

Bluetooth Operating Instruction

1. Press SOURCE key from front panel or remote to go to Bluetooth;

2. When selected the Bluetooth mode, in display, “bt” will start blinking/ashing.;

3. For pairing with mobile or other Bluetooth devices, search the device named “SPA8150B” and

pair it. Once paired, “bt” stops blinking/ashing;

4. Press “ ”for continuous 3 seconds from remote in order to force disconnect the Bluetooth.

Note: While using Bluetooth, if external call comes, then speaker system goes in mute mode in

order to protect privacy of mobile phone user. Operation resumes once the call is disconnected.

Troubleshooting

In case these measures do not work contact the nearest PHILIPS service center or call at customer care numbers.

Problem Solution

1. No power.

2. No sound or distorted sound.

3. The remote control does not

function properly.

4. Low hum or buzz sound.

drive can not be read.

6. Slow operation of the USB / SD

8. FM reception not good.

Check if the AC power cord is properly inserted into the AC mains socket.

Adjust the volume / select the correct source to choose the equipment

that you want to hear through the system.

Reduce the distance between the remote control and the system. Replace

the batteries with new ones / Point the remote control directly towards the

IR sensor (located on front panel of the subwoofer) / Check that the batteries

Place the product as far away as possible from electrical devices that may be

causing interference / Check power supply voltage and consult electrician.

Drive is

and play. / Take out USB / SD drive and insert it again properly.

7. FM not properly tuned. Match with local frequency.

9. BT not working. Reduce the distance or device is not paired.

Warning -

Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.

below before taking the system for repair. If you are unable to remedy the problem by following hints

mentioned in below table, Consult your dealer or PHILIPS APSC for help.

Gibson Innovations India Private Limited 4th Floor, Block-1, Vatika Business Park, Sector 49, Sohna Road,

Gurgaon-122018, Haryana, India

This Philips 4.1 multimedia speakers system is warranted against any defect due to defective materials or

workmanship for 12 months from the date of purchase, should a defect develop during the period of warranty,

Gibson Innovations India Private Limited undertake to repair the apparatus FREE OF CHARGE through the dealer

from whom it has been purchased or at any of the Philips Authorised Service Centres.

The warranty is not valid in case :

1. Proof of purchase is not accompanied with this warranty card.

2. The warranty card is not completed immediately after purchase.

3. The apparatus is not used according to this manual.

4. Defects are caused by improper or reckless use.

5. Any repairs are done by persons other than Philips Authorised service centre.

7. The serial number is tampered with.

8. Defects due to causes beyond control like lightning, abnormal voltage, acts of God or while in

transit to the purchaser’s residence.

All consumables and parts susceptible to normal wear and tear are not covered under warranty.

Week/S.No.: ___________________________ Bill No. ___________________________

Date of purchase _________________________________________________________

Dealer’s name: ___________________________________________________________

Dealers stamp: __________________________________________________________

Customer’s name and address: _____________________________________________

Model No.: _____________________________________________________________

Dealer’s signature: ________________________________________________________

Warranty

Total system power 60W RMS

Satellite 9Wx4 RMS

Subwoofer power 30W RMS

Separation >40 dB

SNR >60 dB

Audio input socket RCA

Audio output socket RCA

Power consumption 65W

Subwoofer speaker 1 Way

Speaker size 5.25 inch

Impedance 8 Ohm

Frequency range 20Hz - 4KHz

Dimension (mm) W x H x D 186 x 324 x 323

Weight 4.65 Kg

The Philips trademark and Philips shield emblem are

registered trademarks of koninklijke Philips N.V. used

under license.

This product has been manufactured by and sold

under the responsibility of Gibson Innovation India

Private Ltd. and Gibson Innovations India private Ltd.

is the warrantor in relation to this product.

Or [email protected]

www.india.philips.com

Question?

Contact

Philips

Satellite speaker power

Speaker size

Impedance

Frequency range

Product Dimension (mm) W x H x D

Net Weight

BT version V3.0

90 x 140 x 82

1 Way, 4 Speakers

3 inch

8 Ohm

120Hz - 20KHz

1.34 Kg

BT range

USB class support

USB capacity

USB playability

UMS (USB mass

storage class)

Upto 16GB

Upto 10 meter

MP3 track

Table des matières

Autres manuels Philips Intervenants

Philips

Philips NTX400/79 Manuel utilisateur

Philips

Philips HTB3510 Manuel utilisateur

Philips

Philips HTL3160B/96 Manuel utilisateur

Philips

Philips SPA3350/10 Manuel utilisateur

Philips

Philips HTL5140B Manuel utilisateur

Philips

Philips Fidelio P9 Manuel utilisateur

Philips

Philips HTB9150 Manuel utilisateur

Philips

Philips FB 840 Manuel utilisateur

Philips

Philips SPA1312/10 Manuel utilisateur

Philips

Philips 4000 series Manuel utilisateur

Philips

Philips TAVS500 Manuel utilisateur

Philips

Philips HTL2151/F7 Manuel utilisateur

Philips

Philips SBA3005/00 Manuel utilisateur

Philips

Philips DSS 350 Manuel utilisateur

Philips

Philips HTB9150 Manuel utilisateur

Philips

Philips SBT75RED/37 Manuel utilisateur

Philips

Philips Fidelio DS8800W/10 Manuel utilisateur

Philips

Philips HTL4110B Manuel utilisateur

Philips

Philips Fidelio SoundRing DS3801W/37 Manuel utilisateur

Philips

Philips SBCBC280/00 Manuel utilisateur

Philips

Philips htl1193b Manuel utilisateur

Philips

Philips HTL3110B/F7 Manuel utilisateur

Philips

Philips 22 RH 544 Manuel utilisateur

Philips

Philips SBT300/12 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
