Philips S5305 Manuel utilisateur

TAPR802

www.philips.com/support

User manual

Wireless Speaker

S5305

Contents

1 Important 2

Safety 2

2 Your wireless speaker 3

Introduction 3

What's in the box 3

Overview of the speaker 3

3 Get started 4

Charge the built-in battery 4

Turn on/off 4

4 Play from Bluetooth devices 5

Play from Bluetooth devices 5

Control playback 5

Control phone call 5

Pairing for stereo mode 5

5 Other features 6

Play from an external audio device 6

Multi-color LED light 6

6 Product information 7

7 Troubleshooting 8

General 8

Bluetooth 8

8 Notice 9

Compliance 9

Care of the environment 9

FCC Statement 9

Trademark notice 10

2 EN

1 Important

Safety

Important safety instructions

· Make sure that the power supply voltage

corresponds to the voltage on the back or

the underside of the unit.

· The speaker shall not be exposed to

dripping or splashing.

· Do not place any source of danger on the

· Make sure that there is enough free space

around the speaker for ventilation.

· Please use the speaker safely in an

environment with temperature between

0° and 45°.

· Only use attachments and accessories

Battery safety precautions

· Danger of explosion if a battery is

incorrectly replaced. Replace only with the

same or equivalent type.

· A battery (battery pack or battery

installed) shall not be exposed to excessive

· A battery in extreme high or low

temperatures during use, storage or

transportation, and low air pressure at high

altitude can pose safety hazards.

· Do not replace a battery with an incorrect

type that can defeat a safeguard (for

example, some lithium battery types).

mechanically crushing or cutting a battery

can result in an explosion.

· Leaving a battery in an extremely high

temperature surrounding, or an extremely

low air pressure environment may result in

or gas.

Warning

· Never remove the casing of this speaker.

· Never lubricate any part of this speaker.

stable surface.

· Never place this speaker on other

electrical equipment.

· Only use this speaker indoors. Keep this

speaker away from water, moisture and

· Keep this speaker away from direct

· Risk of explosion if a battery is replaced

by an incorrect type.

2 Your wireless

speaker

Congratulations on your purchase, and

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this speaker, you can enjoy audio from

Bluetooth-enabled devices or other audio

devices through a 3.5mm audio-in cable.

What's in the box

Check and identify the contents of your

package:

•Speaker

•USB cable

•Audio cable

•Quick start guide

•Safety sheet

•Worldwide warranty

Overview of the speaker

•Enter Bluetooth pairing mode.

•Clear Bluetooth pairing information.

•Respond to an incoming call through

Bluetooth connection.

LED indicator

• In Bluetooth mode, press to pause or

resume play.

·In Bluetooth mode, press twice to

play the next track..

• Press to turn the Multi-color LED light

on or off.

·Press and hold to enter stereo

pairing mode.

Microphone

• Adjust volume.

•Turn the speaker on or off.

•Check the battery level.

•Show the Bluetooth status.

Battery level indicators

•Show the charging progress.

•Show the battery level.

Multi-color LED light

•

Charge the built-in battery.

•

Connect an external audio device.

EN4

3 Get started

Always follow the instructions in this chapter in

sequence.

Charge the built-in battery

Turn on/off

The speaker is powered by a built-in

rechargeable battery.

Note

· Fully charge the built-in battery before using.

· When the speaker is turned on and the battery

is low, the battery level LED indicator blinks

green.

Connect the USB-C socket on the speaker to

an outlet (5V 3A) by using the provided USB

cable.

5V 3 A

When the speaker is being charged,

the battery level LED indicator lights up

gradually.

When the speaker is fully charged, the

battery level LED indicator lights on.

Caution

· Risk of speaker damage! Make sure the power

supply voltage corresponds to the voltage

printed on the back or the underside of the

speaker.

· Risk of electric shock! When unplug the USB

cable, always pull the plug from the socket.

Never pull the cable.

· Use only a USB cable specified by the

manufacturer or sold with this speaker.

Press to turn the speaker on.

You will hear the prompt sound.

If no external audio device is connected

to the AUX socket, it will enter

Bluetooth pairing mode automatically

and the LED indicator will blink blue.

again.

Note

or via AUX IN.

EN 5

4 Play from

Bluetooth

devices

Play from Bluetooth devices

With this speaker, you can enjoy audio from

your Bluetooth device.

Note

· Make sure that the Bluetooth function is enabled

on your device.

· The maximum distance for pairing the speaker

and your Bluetooth device is 20 meters (66 feet).

· Keep away from any other electronic device that

may cause interference.

1 Press to turn the speaker on, it will

enter Bluetooth pairing mode automatically.

You can also press and hold for 2

seconds to enter Bluetooth pairing mode.

2 Enable Bluetooth and select "Philips S5305 "

in the Bluetooth list on your device for

pairing.

If a message prompts for permission

for Bluetooth connection, confirm it.

If a password is required, enter 0000

and then confirm.

3 Play audio on your Bluetooth device to start

streaming music.

LED indicator Description

Blinking blue quickly Ready for pairing

Blinking blue slowly Reconnecting the last

connected device

Solid blue Connected

Note

· To disconnect a device, press and hold for

2 seconds until the LED indicator blinks blue

quickly.

· When you turn on the speaker, it always

automatically tries to reconnect the last

successfully connected device.

· To clear the pairing information, press and hold

for 8 seconds until the LED indicator slowly

blinking cyan for 3 times.

Control playback

During playing the music,

Press to pause or resume play

Press twice to play the next track

Adjust the volume

Control phone call

Press to answer or end a call

Press and hold to reject a call

Adjust the volume

Pairing for stereo mode

Two identical wireless speakers (Philips S5305)

can pair with each other for stereo sound.

Note

· Any speaker can be used as the primary speaker.

· The speaker connected to a Bluetooth device

can only be used as the primary speaker.

· Before stereo pairing, make sure that the

secondary speaker is under Bluetooth pairing

mode.

· The maximum distance for pairing the speaker

and your Bluetooth device is 20 meters (66 feet).

· In stereo mode, the button operation on the

secondary speaker is as same as that of the

primary speaker.

EN6

1Press to power on both speakers,

they will enter Bluetooth pairing mode

automatically. The speaker connected to

your Bluetooth device will be used as the

primary speaker.

2 On the primary speaker, press and hold

to enter stereo pairing mode until

the LED indicator blinks blue and green

alternately.

You will hear a prompt sound when

successfully connected.

The LED indicator lights up blue and

green alternately on the primary

speaker.

The LED indicator lights up in blue on

the secondary speaker.

3 Press on either speaker. The music will

be played through both speakers.

To exit the stereo mode, press and hold the

on either speaker.

5 Other features

Play from an external audio

device

With this speaker, you can enjoy music from an

external audio device such as an MP3 player.

1 Connect an audio cable to the socket

on the speaker and the headphone socket

on an external audio device.

The speaker will switch to AUX IN

mode automatically.

The LED indicator lights up in green.

2 Control playback and volume through the

connected external audio device.

Multi-color LED light

The speaker is equipped with multi-color LED

light on both sides. When playing the music, the

color and brightness of the multi-color LED light

vary by the audio signal.

Press to turn the multi-color LED light on

EN 7

6 Product

information

Note

· Product information is subject to change without

prior notice.

General information

Power supply: 5V 3A

Built-in Lithium battery 7.4V, 2600mAh

Dimensions (W x H x D) 190 x 80 x 80 mm

Weight (main unit) 0.61 kg

Amplifier

Output power 8W x 2

Frequency response 100 Hz - 20 kHz

Signal to noise ratio > 70 dB

Speakers

Impedance 4

Maximum input power 8 W

Size 1.75"

Bluetooth

Bluetooth version 5.0

Frequency range 2402 - 2480 MHz

Maximum transmition

power 5 dBm

Compatible Bluetooth

profiles A2DP, AVRCP

Bluetooth range approx. 20m

EN8

7 Troubleshooting

Warning

· Never remove the casing of the speaker.

To keep the warranty valid, never try to repair

the speaker yourself.

If you encounter problems when using this

speaker, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips website (www.philips.

com/welcome). When you contact Philips,

ensure that the speaker is nearby and the model

number and serial number are available.

General

No power

· Make sure the speaker is fully charged.

· Make sure the USB socket of the speaker is

properly connected.

· As a power-saving feature, the speaker

audio signal is received or no audio device

is connected.

No sound

· Adjust the volume on this speaker.

· Adjust the volume on the connected

device.

· In AUDIO IN mode, make sure that music

playback through Bluetooth is stopped.

· Make sure that your Bluetooth device is

within the operational range.

No response from the speaker

· Restart the speaker.

Bluetooth

The audio quality is poor after

connection with a Bluetooth-enabled

device

· The Bluetooth reception is poor. Move the

device closer to this speaker or remove any

obstacle between them.

Fail to find [Philips S5305] on your

Bluetooth device for pairing

· Press and hold for 2 seconds to enter

Bluetooth pairing mode, and then try again.

Cannot connect with your Bluetooth

device

· The Bluetooth function of your device is

not enabled. Refer to the user manual of

your device to find out how to enable the

function.

· This speaker is not in pairing mode.

· This speaker is already connected to

another Bluetooth-enabled device.

Disconnect and try again.

EN 9

8 Notice

Any changes or modifications made to this

device that are not expressly approved by

MMD Hong Kong Holding Limited may

void the user’s authority to operate the

product.

Compliance

Hereby, MMD Hong Kong Holding Limited

declares that this product is in compliance

with the essential requirements and other

relevant provisions of Directive 2014/53/EU.

You can find the Declaration of Conformity

on www.philips.com/support.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU.

This symbol means that the product contains

batteries covered by European Directive

2013/56/EU which cannot be disposed of with

normal household waste.

Inform yourself about the local separate

collection system for electrical and electronic

products and batteries. Follow local rules and

never dispose of the product and batteries with

normal household waste. Correct disposal of old

products and batteries helps prevent negative

consequences for the environment and human

health.

Removing the disposal batteries

To remove the disposable batteries, see battery

install section.

For INSPIRATION only

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

FCC Statement

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following

two conditions: (1) This device may not cause

harmful interference, and (2) This device must

accept any interference received, including

interference that may cause undesired

operation.

Warning: Changes or modifications not

expressly approved by the party responsible for

compliance could void the user’s authority to

operate the equipment.

Table des matières

Autres manuels Philips Intervenants

Philips

Philips MMS321/05 Manuel utilisateur

Philips

Philips HTL3160B Manuel utilisateur

Philips

Philips Soundmachine AZ3067 Manuel utilisateur

Philips

Philips S4405 Manuel utilisateur

Philips

Philips SPA3300 Manuel utilisateur

Philips

Philips EverPlay BT6900A/00 Manuel utilisateur

Philips

Philips Fidelio AW3000 Manuel utilisateur

Philips

Philips SPA9300 Manuel utilisateur

Philips

Philips SPA2201/10 Manuel utilisateur

Philips

Philips AD7050W/37 Manuel utilisateur

Philips

Philips MMS8080B Manuel utilisateur

Philips

Philips SPA5210 Manuel utilisateur

Philips

Philips Fidelio HTL7180 Manuel utilisateur

Philips

Philips SPA1260/37 Manuel utilisateur

Philips

Philips SPA3250 Manuel utilisateur

Philips

Philips CSP652/51 Manuel utilisateur

Philips

Philips CSP620 Manuel utilisateur

Philips

Philips HTL4115B Manuel utilisateur

Philips

Philips BT5580 Manuel utilisateur

Philips

Philips BT3500 Fiche d'information produit

Philips

Philips BT3010 Manuel utilisateur

Philips

Philips Fidelio HTL9100 Manuel utilisateur

Philips

Philips SBCBA300 Manuel utilisateur

Philips

Philips SBCBC250/05 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
