Philips Fidelio DS3800W/10 Manuel utilisateur

DS3800W/10

www.philips.com/welcome

EN User manual

English

Contents

1 Important 4

Safety 4

Notice 5

2 Your Entertainment System 7

Introduction 7

What’s in the box 7

What else you need 7

Overview of the main unit 8

Get started to use AirPlay 9

3 Prepare 10

Connect power 10

Turn DS3800W on 10

4 Connect to your home Wi-Fi network

for AirPlay 11

Scenario 1: Connect to a WPS router 11

Scenario 2: Connect to a non-WPS router 12

5 Play 18

Stream audio from your iTunes music

library to DS3800W 18

Control play 19

Use advanced sound settings 19

Play/charge your iPod/iPhone/iPad through

USB socket 20

Play from an external device 20

  22

 22

 22

7 Product information 24

 24

8 Troubleshooting 25

iDo not expose the product to dripping /

splashing water, rain or high humidity.

jKeep this product away from direct



kDo not install near any heat sources

such as radiators, heat registers, stoves,

or other electrical equipment (including



lDo not place any other electrical

equipment on the product.

mDo not place any sources of danger

on the product (e.g. objects containing



nThis product may include batteries. Please

refer to safety and disposal instructions

for batteries in this user manual.

oWhere the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

 Never remove the casing of this apparatus.

 Never lubricate any part of this apparatus.

 Never place this apparatus on other electrical

equipment.

 Keep this apparatus away from direct sunlight, naked



 Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect this apparatus from

the power.

1 Important

Safety

Information for Europe:

Know these safety symbols

The ‘exclamation mark’ calls attention to

features for which you should carefully read the

supplied literature to prevent operating and

maintenance problems.

The ‘lightening bolt’ symbol indicates uninsulated

components within the product that can cause

an electric shock.



not expose the product to rain or moisture and



as vases, on the product.

aRead these instructions.

bKeep these instructions.

cHeed all warnings.

dFollow all instructions.

eDo not use this product near water.

fClean only with dry cloth.

gDo not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

hDo not remove the casing of this product.

English

The device can be operated in the EU without

restrictions indoor, but cannot be operated

outdoors in France in the whole of the band

until further notice

This product complies with the requirement of

the 1999/5/EC directive.





manufacturer may void user’s authority to

operate this product.

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negative consequences for the environment and

human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.Please inform yourself about the local

rules on separate collection of batteries

because correct disposal helps to prevent

negative consequences for the environmental

and human health.

Warning

 

pipe (1) or your hands into the aluminum ring (2).

Risk of overheating! Never install this apparatus



at least four inches around this apparatus for

ventilation. Ensure curtains or other objects

never cover the ventilation slots on this

apparatus.

Mains fuse

This information applies only to products with a

UK mains plug.



plug. If you replace the fuse, use one with:

 the ratings shown on the plug,

 a BS 1362 approval, and

 the ASTA approval mark.

Contact your dealer if you are not sure about

what type of fuse to use.

Caution:To conform with the EMC directive

(2004/108/EC), do not detach the plug from

the power cord.

Notice

This product complies with the radio

interference requirements of the European

Community.

standards. Please note that the use of this

accessory with iPod, iPhone, or iPad may affect

wireless performance.

AirPlay, iPod, and iPhone are trademarks of

Apple Inc., registered in the U.S. and other

countries. iPad is a trademark of Apple Inc.

Class II equipment symbol:

CLASS II apparatus with double insulation, and

no protective earth provided.

Note

 The type plate is located on the bottom of the

apparatus.

Information about the use of batteries:

Caution

 

Do not mix new and used batteries. Do not mix

different brands of batteries. Observe correct polarity.

Remove batteries from products that are not in use for

a longer period of time. Store batteries in a dry place.

 Risk of injury:Wear gloves when handling leaking

batteries. Keep batteries out of reach of children and

pets.

 Risk of explosion: Do not short circuit batteries. Do

not expose batteries to excessive heat. Do not throw



batteries. Do not recharge non-rechargeable batteries.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by



local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

“Made for iPod,”“Made for iPhone,” and “Made

for iPad” mean that an electronic accessory



iPod, iPhone, or iPad, respectively, and has



Apple performance standards. Apple is not

responsible for the operation of this device

or its compliance with safety and regulatory

English

With DS3800W, you can also:

 charge your iPod/iPhone/iPad through

the USB socket with an Apple USB

cable (not supplied).

 play your iTunes music library on your

iPod/iPhone/iPad through the USB

socket directly while charging.

 play music from other audio devices

through the MP3-LINK socket.

What’s in the box

Check and identify the contents of your package:

 Main unit (with a built-in Wi-Fi module)

 1 x AC power adapter

 1 x MP3 link cable

 User manual (in CD-ROM)

 Quick start guide

What else you need

To stream audio wirelessly by AirPlay, you need:

 

 A host for your iTunes music library,

for example, an iPod touch/iPhone/

iPad installed with iOS 4.3 (or later)

or a Wi-Fi enabled PC/Mac installed

with iTunes 10 (or later)

Your DS3800W should be connected to the

same local network as your iTunes host device

through the Wi-Fi router.

List of compatible iTunes host devices

for AirPlay

In terms of AirPlay, DS3800W is compatible with:

 a Wi-Fi enabled PC/Mac installed with

iTunes 10 (or later); and

 the following iPod/iPhone/iPad models

installed with iOS 4.3 (or later):

 iPad 2

 iPad

 iPhone 4

 iPhone 3GS

 iPod touch (2nd, 3rd, and 4th

generation)

2 Your

Entertainment

System

Congratulations on your purchase, and



support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

Apple AirPlay technology enables you to play

your iTunes music library, hosted on a Mac, PC,

iPhone, iPod touch, or iPad on any AirPlay-

enabled device (for example, your DS3800W)

connected to the Wi-Fi network.

With an AirPlay-enabled device (for example,

your DS3800W), you can:

 stream audio from your iTunes music

library to any room in your house

 choose which AirPlay-enabled devices

you want to play music on (if you

have more than one such devices in

your house)

 stream audio to multiple AirPlay-

enabled devices at the same time

(from the iTunes music library on your

PC/Mac only)

Tip

 Please visit www.philips.com/welcome for information

about more Philips AirPlay-enabled devices.

fWI-FI SETUP button/indicator

 Connect the unit to a Wi-Fi network.

 Show the Wi-Fi connection status of

the unit.

gMP3-LINK

 Connect an external audio player

through the supplied MP3 link cable.

hUSB

 Connect an iPod/iPhone/iPad through

an Apple USB cable (not supplied).

Overview of the main unit

aPower indicator

 Turn the unit on/off.

 Start or pause play.

d+/-

 Adjust volume.

 (Press and hold both buttons) reset

the unit.

eDC IN

 Connect the power adaptor.

abcd

English

Get started to use AirPlay

To get started with AirPlay, you need to:

1Upgrade your iPod touch/iPhone/iPad to

the latest iOS version (iOS 4.3 or later).

 Or install the latest version of iTunes

(iTunes 10 or later) on your PC/Mac.

2Connect power to DS3800W, then turn it

on (see ‘Prepare’ on page 10).

3Connect DS3800W to your existing home

Wi-Fi network (see ‘Connect to your home

Wi-Fi network for AirPlay’ on page 11).

4Make sure that your iPod touch/iPhone/

iPad or PC/Mac are also connected to the

same Wi-Fi network.

Turn DS3800W on

1Press on the top to turn the unit on.

2Wait for successful boot-up of the unit.

»The boot-up takes about 35 seconds.

»During boot-up, the Wi-Fi SETUP

indicator on the back of the unit blinks

green quickly.

»After boot-up, if no Wi-Fi connection

has been set up for DS3800W, the

Wi-Fi SETUP indicator starts to blink

green slowly.

 To turn the unit off, press again.

3 Prepare

Always follow the instructions in this chapter in

sequence.

Connect power

Caution

 Risk of product damage! Make sure that the power

supply voltage matches the voltage printed on the

bottom of the unit.

 Risk of electric shock! When you unplug the AC

adaptor, always pull the plug from the socket. Never

pull the cord.

 Before you connect the AC adaptor, make sure that you

have completed all the other connections.

 Connect the AC power cord to

 the DC IN socket on the back of the

unit.

 the wall power socket.

Autres manuels pour Fidelio DS3800W/10

Table des matières

Autres manuels Philips Intervenants

Philips

Philips SW750M/05 Manuel utilisateur

Philips

Philips SPA9350/10 Manuel utilisateur

Philips

Philips Fidelio XS1 Manuel utilisateur

Philips

Philips HTB7150 Manuel utilisateur

Philips

Philips PS1 Manuel utilisateur

Philips

Philips Fidelio BTS7000 Manuel utilisateur

Philips

Philips SBCBC250/05 Manuel utilisateur

Philips

Philips SPA2201/10 Manuel utilisateur

Philips

Philips SPA4355/12 Manuel utilisateur

Philips

Philips Fidelio DS8800W/10 Manuel utilisateur

Philips

Philips HTL2101A/96 Manuel utilisateur

Philips

Philips SW700M/37 Manuel utilisateur

Philips

Philips SPA7300 Manuel utilisateur

Philips

Philips HTL3160B/05 Manuel utilisateur

Philips

Philips HTL3110B/F7 Manuel utilisateur

Philips

Philips SPA2360 Manuel utilisateur

Philips

Philips NX50 Manuel utilisateur

Philips

Philips MMS8080B Manuel utilisateur

Philips

Philips CSS5235Y/93 Manuel utilisateur

Philips

Philips HTL1100 Manuel utilisateur

Philips

Philips SBC BC8400 Manuel utilisateur

Philips

Philips SPA5162B Manuel utilisateur

Philips

Philips SPA7300/00 Manuel utilisateur

Philips

Philips DSS 370 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
