User manual

Always there to help you

HTL2153B

HTL2153S

Question?

Contact

Philips

产品中有害物质的名称及含量

Names and Contents of Hazardous Substances

部件名称

Name of the parts

有害物质

Hazardous Substance

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

Housing

外壳 OOOOOO

Subwoofer

超重低音箱 OOOOOO

Loudspeakers

喇叭单元 OOOOOO

PWBs

电路板组件 XOOOOO

Accessories (Remote

control & cables)

附件（遥控器，

电源线，连接线）

XOOOOO

Batteries in Remote

Control (ZnC)

遥控器电池

XOOOOO

本表格依据 SJ/T 11364 的规定编制。

The table is formulated according to SJ/T 11364.

O：

表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。

O：Indicates that this hazardous substance contained in all of the homogeneous materials

for this part is below the limit requirement in GB/T 26572.

×：

表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。

×：Indicates that this hazardous substance contained in at least one of the homogeneous

materials used for this part is above the limit requirement in GB/T 26572.

环保使用期限 Environmental Protection Use Period

此标识指期限（十年），电子电气产品中的有害物质在正常使用的条件下不会发生外泄或突变，

用户使用该电子电气产品不会对环境造成严重污染或对其人身、财产造成严重损害的期限。

This logo refers to the period (10 years) during which the hazardous substances in electronic

and electrical products will not leak or mutate so that the use of these [substances] will not

result in any severe environmental pollution, any bodily injury or damage to any assets.

1EN

Contents

1 Important 2

Help and support 2

Safety 2

Care for your product 3

Care of the environment 3

2 Your SoundBar 4

Main unit 4

Remote control 4

Connectors 5

3 Connect and set up 6

Placement 6

Connect to TV 6

Connect audio from TV and other devices 7

4 Use your SoundBar 8

Adjust the volume 8

Choose your sound 8

MP3 player 9

USB storage devices 9

Auto standby 9

Set display brightness 9

Apply factory settings 9

5 Update software 10

Check software version 10

Update software via USB 10

6 Wall mount 11

7 Productspecications 11

8 Troubleshooting 12

2EN

1 Important

Read and understand all instructions before you

use your product. If damage is caused by failure

to follow instructions, the warranty does not

apply.

Help and support

For extensive online support, visit

www.philips.com/support to:

• download the user manual and the quick

start guide

• watch video tutorials (available only for

selected models)

• nd answers to frequently answered

questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select

your language, and then enter your product

model number.

Alternatively, you can contact Consumer Care

in your country. Before you contact, note down

the model number and serial number of your

product. You can nd this information on the

back or bottom of your product.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories

to rain or water. Never place liquid

containers, such as vases, near the product.

If liquids are spilt on or into the product,

disconnect it from the power outlet

immediately. Contact Consumer Care to

have the product checked before use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation

slots or other openings on the product.

• Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the

power outlet, ensure that the power

voltage matches the value printed on the

back or bottom of the product. Never

connect the product to the power outlet if

the voltage is different.

Riskofinjuryordamagetothisproduct!

• Never place the product or any objects

on power cords or on other electrical

equipment.

• If the product is transported in

temperatures below 5°C, unpack the

product and wait until its temperature

matches room temperature before

connecting it to the power outlet.

• Parts of this product can be made of

glass. Handle with care to avoid injury and

damage.

Riskofoverheating!

• Never install this product in a conned

space. Always leave a space of at least four

inches around the product for ventilation.

Ensure curtains or other objects never

cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or

carbon and alkaine, etc.).

• Danger of explosion if batteries are

incorrectly replaced. Replace only with the

same or equivalent type.

• Remove batteries if they are exhausted or

if the remote control is not to be used for

a long time.

3EN

• Batteries contain chemical substances, they

should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain

a coin/button type battery, which can be

swallowed. Keep the battery out of reach

of children at all times! If swallowed, the

battery can cause serious injury or death.

Severe internal burns can occur within two

hours of ingestion.

• If you suspect that a battery has been

swallowed or placed inside any part of the

body, seek immediate medical attention.

• When you change the batteries, always

keep all new and used batteries out of

reach of children. Ensure that the battery

compartment is completely secure after

you replace the battery.

• If the battery compartment cannot be

completely secured, discontinue use of the

product. Keep out of reach of children and

contact the manufacturer.

This is CLASS II apparatus with double

insulation, and no protective earth provided.

Care for your product

Use only microber cloth to clean the product.

Care of the environment

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products and batteries.

The correct disposal of these products helps

prevent potentially negative consequences on

the environment and human health.

Your product contains batteries, which cannot

be disposed of with normal household waste.

Please inform yourself about the local rules on

separate collection of batteries.The correct

disposal of batteries helps prevent potentially

negative consequences on the environment and

human health.

Please visit www.recycle.philips.com for

additional information on a recycling center in

your area.

4EN

2 Your SoundBar

Congratulations on your purchase, and

welcome to Philips! To fully benet from

the support that Philips offers, register your

SoundBar at www.philips.com/welcome.

Main unit

This section includes an overview of the main

unit.

a (Standby-On/Standby indicator)

• Switch the SoundBar on or to standby.

• When the SoundBar is in standby, the

standby indicator turns red.

b SOURCE

Select an input source for the SoundBar.

c Display panel

d +/- (Volume)

Increase or decrease volume.

da b c

Remote control

This section includes an overview of the

remote control.

a (Standby-On)

Switch the SoundBar on or to standby.

b Source buttons

HDMI ARC: Switch your source to HDMI

ARC connection.

OPTICAL: Switch your audio source to

the optical connection.

AUDIO IN: Switch your audio source to

the MP3 connection (3.5mm jack).

AUX: Switch your audio source to the

AUX connection.

USB: Switch to USB mode.

COAX: Switch your audio source to the

coaxial connection.

e l

5EN

c / (Previous/Next)

Skip to the previous or next track in USB

mode.

d (Play/Pause)

• Start, pause or resume play in USB

mode.

e BASS +/-

Increase or decrease bass.

f Volume control

• +/-: Increase or decrease volume.

• : Mute or restore volume.

g SOUND

Select a sound mode.

h SURROUND ON/OFF

Select surround or stereo sound.

i AUDIO SYNC +/-

Increase or decrease audio delay.

j DIM

Set the brightness of SoundBar display

panel.

k NIGHT

Turn night mode on or off.

l TREBLE +/-

Increase or decrease treble.

Connectors

This section includes an overview of the

connectors available on your SoundBar.

a DIGITAL IN-COAXIAL

Connect to a coaxial audio output on the

TV or a digital device.

b AUX IN (L/R)

Connect to an analog audio output on the

TV or an analog device.

c DIGITAL IN-OPTICAL

Connect to an optical audio output on the

TV or a digital device.

d DC IN

Connect to the power supply.

e HDMI OUT (ARC) - TO TV

Connect to the HDMI input on the TV.

f SUBWOOFER

Connect to the supplied subwoofer.

g (USB)

• Audio input from a USB storage

device.

• Upgrade software of this product.

• Charge a USB device.

h AUDIO IN

• Audio input from, for example, an

MP3 player (3.5mm jack).

bde

6EN

3 Connect and set

This section helps you connect your SoundBar

to a TV and other devices, and then set it up.

For information about the basic connections of

your SoundBar and accessories, see the quick

start guide.

Note

• For identication and supply ratings, see the type plate

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Placement

Place the subwoofer at least 1 meter (3 feet)

away from your SoundBar, and ten centimeters

away from the wall.

For best results, place your subwoofer as shown

below.

Connect to TV

Connect your SoundBar to aTV.You can listen

to audio from TV programs through your

SoundBar. Use the best quality connection

available on your SoundBar and TV.

Connect to TV through HDMI (ARC)

Your SoundBar supports HDMI with Audio

Return Channel (ARC). If yourTV is HDMI ARC

compliant, you can hear the TV audio through

your SoundBar by using a single HDMI cable.

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC)-TO TV connector

on your SoundBar to the HDMI ARC

connector on the TV.

• The HDMI ARC connector on the TV

might be labeled differently. For details,

see the TV user manual.

2 On yourTV, turn on HDMI-CEC

operations. For details, see the TV user

manual.

Note

• If yourTV is not HDMI ARC compliant, connect

an audio cable to hear theTV audio through your

SoundBar (see 'Connect audio from TV and other

devices' on page 7).

• If yourTV has a DVI connector, you can use an HDMI/

DVI adapter to connect to TV. However, some of the

features may not be available.

7EN

Connect audio from TV and

other devices

Play audio fromTV or other devices through

your Soundbar speakers.

Use the best quality connection available on

yourTV, Soundbar, and other devices.

Note

• When your Soundbar andTV are connected through

HDMI ARC, an audio connection is not required. (see

'Connect to TV through HDMI (ARC)' on page 6)

Option 1: Connect audio through a

digital optical cable

Best quality audio

1 Using an optical cable, connect the

OPTICAL connector on your SoundBar to

the OPTICAL OUT connector on the TV

or other device.

• The digital optical connector might be

labeled SPDIF or SPDIF OUT.

Option 2: Connect audio through a

digital coaxial cable

Good quality audio

1 Using a coaxial cable, connect the

COAXIAL connector on your SoundBar

to the COAXIAL/DIGITAL OUT

connector on the TV or other device.

• The digital coaxial connector might be

labeled DIGITAL AUDIO OUT.

Option 3: Connect audio through

analog audio cables

Basic quality audio

1 Using an analog cable, connect the AUX

connectors on your SoundBar to the

AUDIO OUT connectors on the TV or

other device.

DVD

8EN

4 Use your

SoundBar

This section helps you use the SoundBar to play

audio from connected devices.

Before you start

• Make the necessary connections described

in the quick start guide and the user

manual.

• Switch the SoundBar to the correct source

for other devices.

Adjust the volume

1 Press +/- (Volume) to increase or decrease

a volume level.

• To mute sound, press (Mute).

• To restore the sound, press (Mute)

again or press +/- (Volume).

Choose your sound

This section helps you choose the ideal sound

for your video or music.

Sound mode

Select predened sound modes to suit your

video or music.

1 Press SOUND to select a sound option

from the display panel.

• AUTO: Automatically select a sound

setting based on the sound stream.

• POWERFUL: Enjoy thrilling arcade

sounds, ideal for action-packed videos

and loud parties.

• BALANCED: Experience the original

sound of your movies and music,

without added sound effects.

• BRIGHT: Spice up your dull movies

and music with added sound effects.

• CLEAR: Hear every detail in your

music and clear voices in your movies.

• WARM: Experience spoken words and

music vocals in comfort.

• PERSONAL: Personalize the sound

based on your preferences.

Surround sound mode

Experience an immersive audio experience with

surround sound modes.

1 Press SURROUND ON/OFF to turn

surround mode on or off.

• On: Create a surround listening

experience.

• Off:Two-channel stereo sound. Ideal

for listening to music.

Equalizer

Change the high frequency (treble) and low

frequency (bass) settings of the SoundBar.

1 Press TREBLE +/- or BASS +/- to change

the frequency.

Synchronize video and sound

If the audio and video are not synchronized,

delay the audio to match the video.

1 Press AUDIO SYNC +/- to synchronize

the audio with the video.

Night mode

For quiet listening, night mode decreases the

volume of loud sounds when audio is played.

Night mode is only available for Dolby Digital

soundtracks.

1 Press NIGHT to turn night mode on or

off.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système de haut-parleurs

Philips

Philips HTL3310/10 Manuel utilisateur

Philips

Philips HTL2101A/12 Manuel utilisateur

Philips

Philips F1385 Manuel utilisateur

Philips

Philips Fidelio CSS7235Y Manuel utilisateur

Philips

Philips FB206W/01 Manuel utilisateur

Philips

Philips 4000 series Manuel utilisateur

Philips

Philips Fidelio FB1 Manuel utilisateur

Philips

Philips A 3.300 Acoustic Power Manuel utilisateur

Philips

Philips 1000 Series Manuel utilisateur

Philips

Philips HTL2193B Manuel utilisateur

Philips

Philips HTL3120/77 Manuel utilisateur

Philips

Philips HTL5140B Manuel utilisateur

Philips

Philips Fidelio FB1 Manuel utilisateur

Philips

Philips Immersive HTB7530KD Manuel utilisateur

Philips

Philips NTX600 Manuel utilisateur

Philips

Philips MMS3031799 Manuel utilisateur

Philips

Philips 7000 series Manuel utilisateur

Philips

Philips HTL4110B Manuel utilisateur

Philips

Philips HTL5120 Manuel utilisateur

Philips

Philips BT6000 Fiche d'information produit

Philips

Philips DS8300/10 Manuel utilisateur

Philips

Philips HTL2161B Manuel utilisateur

Philips

Philips SBA220 Manuel utilisateur

Philips

Philips A2.310/05 Guide de référence

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
