Audio CD-Recorder

CDR770C

Single deck premium CD-Recorder CDR 770C

• Sample Rate Conversion (12-56 kHz)

• Direct Line Recording (DLR)

• Records HQ-CD format

• Analogue + digital (separate channel) record level control (64 steps)

• Continuous calibration (Running OPC)

• AD - DA convertor UDA1341TS (CODEC)

• 2x CD text features (input & editing for max. 60 characters)

• Max. 99-track program

• CD Synchronised auto start recording from all

analogue and digital sources (disc & track)

• Text scrolling

• Standby (via RC) + hard on/off

• Music calendar

• Easy jog (Menu controlled user interface)

• High quality starbust FTD (display)

• Auto (un) finalise

• Erasing per track, selection of last tracks & whole disc

(takes max. 2 min.)

• Introscan

• Tray blocking (dealer function)

• Gold plated headphone connection

• Remote control

Audio CD-Recorder

CDR770C

700+ series CD player

Technical Specifications CDR 770C

General

• System Compact disc digital Audio (CD-recorder)

• Number of channels 2 (stereo)

• Applicable supply Multi voltage 100V - 240V 50-60 Hz (/00 only) 117V (/17)

• Power consumption 15W (<= 6W in standby)

• Operating temperature 5-35°C

• Weight 4 kg

• Dimensions 435 x 305 x 88 mm (w x d x h)

Audio

• Digital frequency range 2 Hz - 22,05 kHz

• Playback S/N 100 dB (A- weighted)

• Playback dynamic range 95 dB

• Play back total harmonic distortion

+ noise 88 dB (0,0039%)

• Recording S/N (Analogue) 98 dB (A- weighted)

• Recording S/N (Digital) Recording quality equal to Source

• Recording dynamic range 92 dB

• Recording total harmonic distortion

+ noise 825 dB (0,0079%)

• Headphones 3Vrms / 8-2000Ω

Output

• 1x Analogue line output 2Vrms +/- 2 dB / 0.2 kΩ

• 1x Digital coaxial output 0.5V(pp) / 75Ω

Input (level adjustment)

• Direct line recording (bypass SRC) for 44.1 kHz +/- 100 ppm

• 1x Digital coaxial input (SRC) 12 - 56 kHz / 0.5Vrms / 75Ω

• 1x Digital optical input (SRC) 12 - 56 kHz

• 1x Analogue input 500 mVrms / 50 kΩ= 0 dB

Recording functions

• Recording on CD-R & CD-RW disc

• Records from all home stereo analogue and digital sources

• Auto start recording per disc, track

• Multi track erase (CD-RW disc)

• Soft mute insert function

• Erase disc (CD-RW disc)

• Auto finalise / unfinalise disc (CD-RW disc)

• Manual / Auto track increment

• Remaining recording time display

• Double speed finalising (make disc compatible to CD-player)

• SCMS (Serial Copy management system)

• RID code (Recorder Unique identifier)

Playback functions

• Plays all Audio CD’s

(120 mm + 80 mm discs)

• Play - Introscan - Pause - Stop

• Direct track selection

• Track selection with easy jog

• Search forward / reverse

• Repeat (all / per track)

• Program play (99 tracks)

• Time display switching

• Permanent text option

The products and services described here are not necessarily to become available in the market. This document contains preliminary information. Due to continuous improvements this specification is subject to changes without notice. Printed in the Netherlands. 2/99

Accessories

• Remote control (+batteries)

• Audio cable (x2)

• Digital coaxial cable (x1)

• AC mains cord

Recordable

OPEN / CLOSE

SHUFFLE

PLAY/ PAUSE STOP SCROLLPROGRAM

DISPLAY

REPEAT

PHONES INFRA RED

ENTER

EASY JOG

CDR770AUDIO CD RECORDER

REC

TYPE

REC

START

ERASE SOURCEFINALIZE CANCEL/

DELETE

STORE/

AUDIO CD RECORDABLE/REWRITABLE

ON/OFF

TRACK

REC

DIGITAL SHUFFLE

MANUAL RECORD

ALL

TRACK

FADE

123456789

10 11 12 13 14 15 16 17 18 19 20 +

SCAN

ABC

GHI

DEF

JKL OPQ

RST XYZ

UVW

SPACE

ENTER CANCEL

TRACK INCR.

MENU/

STORE

PROG.

CDR CD

SCROLL

SHUFFLE REPEAT
