Philips AW2000 Manuel utilisateur

www.philips.com/welcome

User manual

Always there to help you

AW2000

Question?

Contact

Philips

English

Contents

1 Important 2

Safety 2

Notice 3

2 Your Wireless Hi-Fi Receiver 4

Introduction 4

What's in the box 4

What else you need 4

Overview of the main unit 5

3 Prepare 6

Download Philips AirStudio to your

smartphone or tablets 6

Connect to an existing speaker system 7

Connect power and switch on 7

4 Connect AW2000 to your home

Wi-Fi network 9

Option 1: Set up wireless connection

to a non-WPS router through an

iOS device 9

Option 2: Set up through a non-WPS

Wi-Fi router and Android device 11

Option 3: Set up wireless connection

to `a WPS router 14

Option 4: Set up wired connection

through an Ethernet cable 15

5 Play 16

Stream audio to AW2000 16

Listen to Internet radio stations

through AW2000 18

Play from an external device 21

6 Upgradermware 23

7 Product information 25

Specications 25

8 Troubleshooting 26

9 Appendix: Understand meanings

of LED colors 28

2EN

1 Important

Safety

Information for Europe:

Know these safety symbols

The 'exclamation mark' calls attention to

features for which you should carefully read the

supplied literature to prevent operating and

maintenance problems.

The 'lightening bolt' symbol indicates

uninsulated components within the product

that can cause an electric shock.

Toreducetheriskofreorelectricshock,do

not expose the product to rain or moisture and

donotplaceanyobjectslledwithliquids,such

asvases,ontheproduct.

a Read these instructions.

b Keep these instructions.

c Heed all warnings.

d Follow all instructions.

e Do not use this product near water.

f Clean only with dry cloth.

g Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

h Do not remove the casing of this product.

i Do not expose the product to dripping /

splashing water, rain or high humidity.

j Keep this product away from direct

sunlight,nakedamesorheat.

k Do not install near any heat sources

such as radiators, heat registers, stoves,

or other electrical equipment (including

ampliers).

l Do not place any other electrical

equipment on the product.

m Do not place any sources of danger

on the product (e.g. objects containing

liquids,burningcandles).

n Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Keepthisapparatusawayfromdirectsunlight,naked

amesorheat.

•Ensure that you always have easy access to the power

cord,plugoradaptortodisconnectthisapparatusfrom

the power.

Risk of overheating! Never install this apparatus

inaconnedspace.Alwaysleaveaspaceof

at least four inches around this apparatus for

ventilation. Ensure curtains or other objects

never cover the ventilation slots on this

apparatus.

English

Notice

This product complies with the radio

interferencerequirementsoftheEuropean

Community.

Thisproductcomplieswiththerequirementof

the 1999/5/EC directive.

Modications

Modicationsnotauthorizedbythe

manufacturer may void user's authority to

operate this product.

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negativeconsequencesfortheenvironmentand

human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separateintothreematerials:cardboard(box),

polystyrene foam (buffer) and polyethylene

(bags,protectivefoamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

aspecializedcompany.Pleaseobservethe

local regulations regarding the disposal of

packagingmaterials,exhaustedbatteriesandold

equipment.

Android is a trademark of Google Inc. Use of

this trademark is subject to Google permissions.

Class II equipment symbol:

CLASSIIapparatuswithdoubleinsulation,and

no protective earth provided.

Note

•The type plate is located on the bottom of the

apparatus.

4EN

2 Your Wireless

Hi-Fi Receiver

Congratulationsonyourpurchase,and

welcometoPhilips!Tofullybenetfromthe

supportthatPhilipsoffers,registeryourproduct

at www.philips.com/welcome.

IfyoucontactPhilips,youwillbeaskedforthe

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this wireless Hi-Fi receiver connected to

anexistingspeakersystem,youcan:

• stream audio from your iOS or

Android device.

• listen to Internet radio stations or

online music services.

• stream audio from a PC/Mac installed

with Media Manager downloaded from

www.philips.com/mediamanager.

• play music from other audio devices

through the AUXIN(L/R),MP3-LINK,

COAXIAL or OPTICAL socket.

What's in the box

Check and identify the contents of your

package:

• Wireless Hi-Fi receiver with built-in

Wi-Fi

• 2 x AC power cords

• Quick start guide

• Safety sheet

What else you need

Note

•Toenjoymusic,connectAW2000toanexisting

speaker system through the SPEAKER CONNECTOR

L/R(+/-) sockets.

•Tohavebettersoundeffect,youcanalsoconnecta

subwoofer to the SUBWOOFER socket on the back

of AW2000.

TostreamaudiowirelesslytoAW2000,you

need:

• acertiedWi-Firouter

• aniOSorAndroiddevice,suchasan

iPod touch/iPhone/iPad or an Android

phone or tablet; or a PC/Mac enabled

with Wi-Fi

• the Philips AirStudio app available on

Apple App Store (for iOS devices)

or Google Play Store (for Android

devices)

Connect AW2000 to the same local network

as your iOS/Android device or PC/Mac through

the Wi-Fi router.

English

Overview of the main unit

• Switch the device on or to normal/Eco

standby mode.

b Power/status indicator

• Show the current status of the device.

c Source indicators

• Light up when the corresponding

source is selected.

d Volume knob

• Adjust volume.

e SOURCE button

• Press repeatedly to select an audio

source.

f Numerickeys(1to5)

• Select an Internet radio station.

g AC IN ~ socket

• Connect the power cord.

h SPEAKERCONNECTORL/R(+/-)

sockets

• Connect AW2000 to an existing

speaker system.

i AUX IN L/R sockets

• Connect an external audio device

through RCA audio cables (red/white;

not supplied).

qpon

gh ilmjk

j OPTICAL socket

• Connect an external audio device to

AW2000 through an optical cable (not

supplied).

k ETHERNET socket

• (Optional) Connect to a wireless

router through an Ethernet cable (not

supplied).

l WI-FI SETUP button

• Connect the device to a Wi-Fi

network.

m ANTENNA socket

• Connect the supplied Wi-Fi antenna.

n COAXIAL

• Connect an external audio device to

AW2000 through a coaxial cable (not

supplied).

o MP3-LINK

• Connect an external audio device to

AW2000 through a 3.5mm audio cable

(not supplied).

p SUBWOOFER socket

• Connect a subwoofer for better sound

effect.

6EN

3 Prepare

Always follow the instructions in this chapter

in sequence.

Download Philips AirStudio

to your smartphone or

tablets

1 (For iPod touch/iPhone/iPad users) Install

Philips AirStudio from Apple App Store,

and then run the app.

(For users of Android smartphones or tablets)

Install Philips AirStudio from Google Play Store

and then run the app.

2 Flick right to view the introduction pages

and then go to the initial Setuppage,or

tap Skip intro to enter the initial Setup

page directly.

English

3 On the initial Setuppage,tapSetup a new

speaker.

4 Readthegeneralsetupsteps,thentap

Next.

Connect to an existing

speaker system

1 Unscrew the speaker connectors.

2 Insert fully the end of a speaker cable with

red mark into the left red (+) connector.

3 Screw the left red (+) connector to secure

the cable.

4 Insert fully the end of a speaker cable

without red mark into the left black (-)

connector.

5 Screw the left black (-) connector to

secure the cable.

6 Repeat steps 2-5 to insert the other

speaker cable into the right connectors.

Connect power and switch

Caution

•Risk of product damage! Make sure that the power

supply voltage matches the voltage printed on the

bottom of the device.

•Riskofelectricshock!WhenyouunplugtheACcord,

always pull the plug from the socket. Never pull the

cord.

•BeforeyouconnecttheACcord,makesurethatyou

have completed all the other connections.

8EN

1 Read the power connection instructions

on the app.

2 Connect the AC power cord to

• the AC IN ~ socket on the back of the

device.

• the wall power socket.

» The device switches on automatically.

» The power/status indicator blinks

amber during boot-up.

» Afterawhile,forrst-timesetup,the

power/status indicator turns solid

amber.

AC IN ~

3 Tap Next on the app screen to continue.

Switch between normal and Eco power

standby mode

• To switch the device to normal standby

mode,brieypress .

» The power/status indicator turns green.

• To switch the device to Eco power standby

mode,pressandhold for less than 3

seconds and then release the button.

» The power/status indicator turns

amber for a short while and then turns

off.

• To switch the device on from normal or

Ecopowerstandbymode,brieypress

again.

Operation LED status

On -> Nor-

mal standby

Brieypress . Amber/white

-> Green

On/Normal

standby ->

Eco power

standby

Press and hold

for less than 3

seconds and then

release the button.

Amber/white

or green ->

Off

Normal

standby/

Eco power

standby ->

Brieypress . Green/Off ->

Amber/white

Autres manuels pour AW2000

Table des matières

Autres manuels Philips Récepteur

Philips

Philips AE 3750 Manuel du système

Philips

Philips MX2500D Manuel utilisateur

Philips

Philips HTS6500 - DivX Ultra Home Theater System Manuel utilisateur

Philips

Philips SLV5405/05 Manuel utilisateur

Philips

Philips STU1130/00G Manuel utilisateur

Philips

Philips MX3900D Manuel utilisateur

Philips

Philips FR 731 Manuel utilisateur

Philips

Philips FR 931 Manuel utilisateur

Philips

Philips MRD300/37/78 Manuel utilisateur

Philips

Philips HTR5000 Manuel utilisateur

Philips

Philips SLV4200 Manuel utilisateur

Philips

Philips UPC Direct DSR4101/58 Manuel utilisateur

Philips

Philips MatchLine FR980 Manuel utilisateur

Philips

Philips HTR5000 Manuel utilisateur

Philips

Philips HTS3090/55/77/78 Manuel utilisateur

Philips

Philips MX6050D Manuel utilisateur

Philips

Philips FR735 Manuel utilisateur

Philips

Philips DSR320 Manuel utilisateur

Philips

Philips MX2500/01 Manuel utilisateur

Philips

Philips LX-3000D Manuel utilisateur

Philips

Philips DSR2015/00 Manuel utilisateur

Philips

Philips Streamium SL400i Manuel du propriétaire

Philips

Philips STU824/05G Manuel utilisateur

Philips

Philips STU1100/00G Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
