Philips MCM119/12 Manuel utilisateur

User Manual

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

FM Antenna MW Antenna Remote Control

User Manual

Quick Start Guide

Quick start guide

USB Cable

MCM119

DB Cable

Pull out the plastic

protective sheet

before use.

MCM119 QUG_Eng 2006.8.2, 14:291

Connect the main set to the left speaker with

the supplied DB cable.

Connect the right speaker to the left speaker.

Connect the MW and FM antennas.

Connect the power cable on the back of the

left speaker.

Tip

See the User Manual for how to

connect other equipment to this

system.

SPEAKER(4

©)

RIGHT

DB15 CONNECTOR

TO MAIN

AC MAINS ~

FM wire

antenna

Speaker

(right)

Speaker

(left)

AC Powe

DB cable

MCM119 QUG_Eng 2006.8.2, 14:292

Enjoy

Playing a disc

Press OPEN•CLOSEçto open the disc tray and load in a disc,

then press the same button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Press ÉÅ to start playback.

To stop playback, press 9.

Setting the clock

In standby mode, press and hold DISPLAY/CLOCK on the remote

control for more than 3 seconds.

Press VOLUME +/- (VOL+/- on the remote) repeatedly to select

clock mode.

Press VOLUME +/- (VOL+/- on the remote) repeatedly to set the

hour.

Press VOLUME +/- (VOL+/- on the remote) repeatedly to set the

minute.

Press DISPLAY/CLOCK again to store the setting.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold STANDBY-ON/ECO

POWER

on the set for 3 seconds or more to switch to normal standby mode

first before proceeding with the procedures below.

MCM119 QUG_Eng 2006.8.2, 14:293

Enjoy

PDCC-JS/JW-0611 GB

Programming and tuning to

radio stations

Press TUNER to select the tuner source.

Press PROGRAM for more than two seconds to program all

available stations in order of waveband.

Press íor ëuntil the desired preset station is displayed.

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more to select USB (or USB on the remote control).

Play the USB’s audio files as you do with the albums/tracks on a CD,

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1), USB flash players (USB 2.0 or

USB1.1), memory cards (requires an additional card reader to work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

Printed in China

MCM119 QUG_Eng 2006.8.2, 14:294
