User manual

Always there to help you

BTM2360

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

Notice 3

2 Your Micro Music System 4

Introduction 4

What's in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 7

Connect speakers 7

Connect power 7

Prepare the remote control 7

Demonstrate the features 8

Power on 8

Set the clock 8

Select a source 9

4 Play 10

Play from disc 10

Play from USB 10

Control play 10

Skip tracks 11

Program tracks 11

Play from Bluetooth-enabled devices 11

5 Listen to the radio 13

Tune to a radio station 13

Program radio stations automatically 13

Program radio stations manually 13

Select a preset radio station 13

6 Adjust sound 14

Select a preset sound effect 14

Adjust volume level 14

Mute sound 14

7 Other features 15

Set the alarm timer 15

Set the sleep timer 15

Listen to an external device 15

Charge your devices 16

8 Product information 17

Specications 17

USB playability information 18

Supported MP3 disc formats 18

9 Troubleshooting 19

2EN

1 Important

Safety

Read and understand all instructions before

you use this micro music system. If damage is

caused by failure to follow the instructions, the

warranty does not apply.

This 'bolt of lightning' indicates uninsulated

material within the device may cause an

electrical shock. For the safety of everyone in

your household, please do not remove the

covering.

The 'exclamation mark' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:Toreducetheriskofreorelectric

shock, the device should not be exposed to rain

ormoistureandobjectslledwithliquids,such

as vases, should not be placed on the device.

CAUTION:To prevent electric shock, fully

insert the plug. (For regions with polarized

plugs:To prevent electric shock, match wide

blade to wide slot.)

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never look into the laser beam inside this apparatus.

•Never place this apparatus on other electrical

equipment.

•Keep this apparatus away from direct sunlight, naked

amesorheat.

•Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect the apparatus from

the power.

• The device shall not exposed to dripping

or splashing.

• Do no place any source of danger on the

device(e.g.liquidlledobjects.litcandles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Make sure that there is enough free space

around the product for ventilation.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Batteries (packed or installed) shall not

be exposed to excessive heat such as

sunshine,reorthelike.

• Remove batteries when the unit is not

used for a long time.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

3EN

Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

WOOX Innovations may void the user’s

authoritytooperatetheequipment.

Compliance

This apparatus includes this label:

Care of the environment

Disposal of your old product

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

Do not throw away the product with the

normal household waste at the end of its life,

buthanditinatanofcialcollectionpointor

recycling. By doing this, you help to preserve the

environment.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

The Bluetooth® word mark and logos are

registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by WOOX

Innovations is under license.

The making of unauthorized copies of copy-

protected material, including computer

programs,les,broadcastsandsound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

Thisequipmentshouldnotbeusedforsuch

purposes.

Care for your product

• Do not insert any objects other than discs

into the disc compartment.

• Do not insert warped or cracked discs into

the disc compartment.

• Remove the discs from the disc

compartment if you are not using the

product for an extended period of time.

• Onlyusemicroberclothtocleanthe

product.

Note

•The type plate is located on the back of the product.

4EN

2 Your Micro

Music System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

• enjoy audio from discs, USB devices,

Bluetooth devices, and other external

devices;

• listen to radio stations.

You can enrich sound output with below

sound effect:

• Digital Sound Control (DSC)

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control (with one AAA battery)

• Speaker boxes (×2)

• AC power cable

• Short user manual

5EN

Overview of the main unit

• Turn on the product.

• Switch to standby mode or ECO

power standby mode.

b Bluetooth indicator

• Indicate the Bluetooth connection

status.

c Display panel

• Show current status.

d /

• Skip to previous/next track.

• Search within a track/disc.

• Tune to a radio station.

• Adjust time.

• Start or pause play.

f VOLUME knob

• Adjust volume.

• Open or close the disc compartment.

• Stop play.

• Erase a program.

ade

cb f

ghijkl mon

i Disc compartment

j AUDIO IN

• Connect external audio devices.

k SOURCE/PAIRING

• Press to select a source: DISC, USB,

TUNER, AUDIO IN, BT.

• In Bluetooth mode, press and hold for

three seconds until you hear a beep

sound to disconnect the currently

connected device and enter pairing

mode.

• Connect USB storage devices.

m SPEAKER OUT socket

• Connect with the speakers.

n ANTENNA socket

• Connect with the FM antenna.

o AC MAINS ~ socket

6EN

Overview of the remote

control

• Turn the product on or off.

• Switch to standby mode or ECO

power standby mode.

b CD

• Select CD source.

c USB

• Select USB source.

d /

• Skip to the previous/next track.

• Search within a track/disc/USB.

• Tune to a radio station.

• Adjust time.

• Play tracks randomly.

f ALBUM/PRESET /

• Select a preset radio station.

• Skip to previous/next album.

g DISPLAY

• Adjust display brightness.

• During playback, display the play

information.

h SLEEP/TIMER

• Set sleep timer.

• Set alarm timer.

i CLOCK

• Set the clock.

• View clock information.

j PROG

• Program tracks.

• Program radio stations.

• Auto store FM radio stations.

• Mute or restore volume.

l SOUND

• Enrich sound effect with Digital Sound

Control (DSC).

m VOL +/-

• Adjust volume.

• Play a track or all tracks repeatedly.

• Stop play or erase a program.

p /PAIRING

• Press to start, pause, or resume play.

• Press and hold for three seconds until

you hear a beep sound to enter pairing

mode.

q FM/AUDIO IN

• Select FM source.

• Select AUDIO IN source.

• Select Bluetooth source.

7EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

laser exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Connect speakers

Note

•Insert the stripped portion of each speaker wire into

the socket completely.

•Forbettersoundquality,usethesuppliedspeakersonly.

1 Fortherightspeaker,ndthesocketson

the back of the main unit marked "R".

2 Insert the red wire into the red (+) socket,

and the black wire into the black (-) socket.

3 Fortheleftspeaker,ndthesocketsonthe

main unit marked "L".

4 Repeat step 2 to insert the left speaker

wire.

To insert each speaker wire:

1 Holddownthesocketap.

2 Insert the speaker wire fully.

3 Releasethesocketap.

Connect power

Caution

•Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the unit.

•Before you connect the AC power cord, ensure that

you have completed all other connections.

Connect the power cord to:

• the AC MAIN~ socket on the product.

• the wall outlet.

Prepare the remote control

Caution

•Risk of product damage! When the remote control is

not used for long periods, remove the batteries.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert the supplied AAA battery with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

8EN

Demonstrate the features

In standby mode, press to demonstrate

features of this device.

» The features are displayed one by one

across the display panel.

• To turn off the demonstration, press

again.

Power on

Press .

» The product switches to the last selected

source.

Switch to standby mode

Press again to switch the product to standby

mode.

» The clock (if set) is displayed on the

panel.

• In standby mode, press to switch

between working mode and standby

mode.

Note

•The product switches to standby mode after 15

minutes inactive.

Switch to ECO power standby mode

Press and hold for more than two seconds.

» The red ECO power standby indicator

turns on.

• In Eco power standby mode, press to

switch between working mode and ECO

power standby mode.

Note

•The product switches to ECO power standby mode

after 15 minutes in standby mode.

Switch between standby mode and ECO

powerstandby mode:

• Press and hold for more than two

seconds.

Note

•If no button is pressed over 15 minutes in standby

mode, this product goes to ECO standby mode

automatically.

Set the clock

1 In standby mode, press and hold CLOCK

for more than two seconds to enter the

clock setting mode.

» [24H] or [12H] is displayed.

2 Press / to select 24H or 12H hour

format, and then press CLOCK.

» The hour digits begin to blink.

3 Press / to set the hour, and then

press CLOCK.

» The minute digits begin to blink.

4 Press / to set the minute, and then

press CLOCK.

» The set clock is displayed.

Note

•To view clock information in working mode, press

CLOCK.

•If no button is pressed in 90 seconds during setting,

the product exits clock setting without saving earlier

operations.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système audio micro

Philips

Philips DCB2020 - Manuel utilisateur

Philips

Philips DCB352/10 Manuel utilisateur

Philips

Philips MCM239D/79 Manuel utilisateur

Philips

Philips MC147 Manuel utilisateur

Philips

Philips MCD268/93 Manuel utilisateur

Philips

Philips DCB293 Manuel utilisateur

Philips

Philips MCD263/98 Manuel utilisateur

Philips

Philips RTH718/98 Manuel utilisateur

Philips

Philips MCM240B/98 Manuel utilisateur

Philips

Philips MC155/22 Manuel utilisateur

Philips

Philips MCM1115/51 Manuel utilisateur

Philips

Philips MCM280D/12 Manuel utilisateur

Philips

Philips DCM378/12 Manuel utilisateur

Philips

Philips MCM239/96 Manuel utilisateur

Philips

Philips MCM1055B/98 Manuel utilisateur

Philips

Philips MCD710/12 Manuel utilisateur

Philips

Philips MCM177/12 Manuel utilisateur

Philips

Philips BTM177/12 Manuel utilisateur

Philips

Philips DCM3060/93 Manuel utilisateur

Philips

Philips MCM2300 Fiche d'information produit

Philips

Philips MCD130/96 Manuel utilisateur

Philips

Philips DCB2020 - Manuel utilisateur

Philips

Philips DCM2060/93 Manuel utilisateur

Philips

Philips MCM398D/05 Manuel utilisateur

Manuels Système audio micro populaires d'autres marques

Rautz

Rautz MC-5100DU Manuel utilisateur

Sanyo

Sanyo DC-D9 Manuel utilisateur

Curtis

Curtis RCD744 Manuel utilisateur

Samsung

Samsung MM-UC8 Manuel utilisateur

Akai

Akai AMP300UCI Manuel utilisateur

Hyundai

Hyundai MS 132 DU3BL Manuel utilisateur

JVC

JVC UX-GP5 Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manuel utilisateur

Optimus

Optimus SYSTEM 731 Manuel utilisateur

Hitachi

Hitachi AXM209UK Manuel utilisateur

Sharp

Sharp XL-MP110DVD Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manuel utilisateur

ProAudio

ProAudio MC 9010 iP Manuel utilisateur

Samsung

Samsung MM-ZJ9 Manuel utilisateur

Sharp

Sharp MD-X7 Manuel utilisateur

Sharp

Sharp DK-KP95P Manuel utilisateur

Akura

Akura APTCDC832PR Manuel utilisateur

iLive

iLive IHB248B Manuel utilisateur
