User manual

1EN

Contents

1 Important 2

Safety 2

Notice 2

Declaration of conformity 2

2 Your Micro Music System 4

Introduction 4

What's in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 7

Connect FM/DAB+ antenna 7

Connect power 7

Prepare the remote control 8

Power on 8

Set the clock 8

4 Play 9

Play from disc 9

Play from USB 9

Control play 9

Skip tracks 10

Program tracks 10

Play from Bluetooth-enabled

devices 10

5 Listen to the radio 11

Listen to DAB+ radio 11

Listen to FM radio 12

6 Adjust sound 13

Adjust volume level 13

Mute sound 13

7 Other features 14

Set the alarm timer 14

Set the sleep timer 14

Listen to an external device 14

8 Product information 15

USB playability information 16

Supported MP3 disc formats 16

9 Troubleshooting 17

2EN

1 Important

Safety

This ‘bolt of lightning’ indicates

uninsulated material within the device

may cause an electrical shock. For the

safety of everyone in your household,

please do not remove the covering.

The ‘exclamation mark’ calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, the device should not be

exposed to rain or moisture and objects

lled with liquids, such as vases, should

not be placed on the device.

CAUTION: To prevent electric shock,

fully insert the plug. (For regions with

polarized plugs: To prevent electric

shock, match wide blade to wide slot.)

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never look into the laser beam inside this

apparatus.

•Never place this apparatus on other

electrical equipment.

•Keep this apparatus away from direct

sunlight, naked ames or heat.

•Ensure that you always have easy access

to the power cord, plug or adaptor to

disconnect the apparatus from the power.

• The device shall not be exposed to

dripping or splashing.

• Do no place any source of danger

on the device (e.g. liquid lled

objects. lit candles).

• Where the MAINS plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily

operable.

• Make sure that there is enough

free space around the product for

ventilation.

• Battery usage CAUTION - To

prevent battery leakage which may

result in bodily injury, property

damage, or damage to the unit:

• Install all batteries correctly, +

and - as marked on the unit.

• Batteries (packed or installed)

shall not be exposed to

excessive heat such as sunshine,

re or the like.

• Remove batteries when the unit

is not used for a long time.

• Only use attachments/accessories

specied by the manufacturer.

Notice

Any changes or modications made

to this device that are not expressly

approved by Gibson Innovations may

void the user’s authority to operate the

equipment.

Declaration of

conformity

Hereby, Gibson Innovations declares

that this product is in compliance

with the essential requirements

and other relevant provisions of

Directive 2014/53/EU. You can nd

the Declaration of Conformity on

www.philips.com/support.

3EN

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

materials and components, which can

be recycled and reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains batteries covered by European

Directive 2013/56/EU which cannot be

disposed of with normal household

waste.

Inform yourself about the local separate

collection system for electrical and

electronic products and batteries.

Follow local rules and never dispose of

the product and batteries with normal

household waste. Correct disposal

of old products and batteries helps

prevent negative consequences for the

environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see

battery installation section.

Environmental information

All unnecessary packaging has been

omitted. We have tried to make the

packaging easy to separate into three

materials: cardboard (box), polystyrene

foam (buer) and polyethylene (bags,

protective foam sheet.)

Your system consists of materials

which can be recycled and reused

if disassembled by a specialized

company. Please observe the local

regulations regarding the disposal

of packaging materials, exhausted

batteries and old equipment.

The Bluetooth® word mark and logos

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such

marks by Gibson Innovations Limited

is under license. Other trademarks

and trade names are those of their

respective owners.

This apparatus includes this label:

Note

•The type plate is located on the back of

the device.

4EN

2 Your Micro Music

System

Congratulations on your purchase,

and welcome to Philips! To fully

benet from the support that Philips

oers, register your product at

www.philips.com/support.

Introduction

With this unit, you can:

• enjoy audio from discs, USB

devices, Bluetooth devices, and

other external devices;

• listen to FM and Digital Audio

Broadcasting+ (DAB+) radio

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• 1 x AC power cord

• 1 x FM/DAB+ antenna

• Remote control (with one AAA

battery)

• Printed materials

• Open or close the disc

compartment.

• Press to select a source: DISC,

USB, FM, DAB+, AUDIO IN, BT.

• In Bluetooth mode, press and

hold for 2 seconds to disconnect

the currently connected device

and enter pairing mode.

• Switch this product on or to

standby.

• Connect USB storage devices.

• Connect external audio devices.

f IR sensor

g Disc compartment

h Display panel

• Show current status.

• Start or pause play.

j /

• Skip to previous/next track.

• Search within a track/disc.

• Tune to a radio station.

• Adjust time.

k Volume knob

• Adjust volume

• Connect to the supplied FM/

DAB+ antenna.

Overview of the main unit

• Tune to an FM station.

• Adjust time.

• Select a DAB+ station.

• Select shue mode to play

tracks randomly.

• Select repeat mode to play a

track or all tracks repeatedly.

f /

• Select a preset radio station.

• Skip to previous/next album.

• Display playback information, or

radio service information.

• Set sleep timer.

• Set alarm timer.

• Set the clock.

• View clock information.

• In standby, press and hold to

toggle clock display on or o.

• Program tracks.

• Program radio stations.

• Auto store radio stations.

• Mute or restore volume.

• Select a preset sound eect.

m (volume)

• Adjust volume.

• Adjust display brightness.

• Stop play or erase a program.

• Enter or exit DAB+ menu.

• Press to start, pause, or resume

play.

• Conrm or select a DAB+ item.

Overview of the remote

control

• Switch this product on or to

standby.

• Select CD source.

• Select FM or DAB+ source.

d /

• Skip to the previous/next track.

• Search within a track/disc/USB.

7EN

• Select USB source.

• Select AUDIO IN source.

• Select Bluetooth source

• In Bluetooth mode, press and

hold for more than 2 seconds to

enter pairing mode

3 Get started

Caution

•Use of controls or adjustments or

performance of procedures other than

herein may result in hazardous radiation

exposure or other unsafe operation.

Always follow the instructions in this

chapter in sequence.

Connect FM/DAB+

antenna

Connect the supplied antenna to this

product before listening to radio.

Connect power

Caution

•Risk of product damage! Ensure that the

power supply voltage corresponds to

the voltage printed on the back or the

underside of the unit.

•Risk of electric shock! Before you plug the

AC power cord, make sure that the plug is

xed securely. When you unplug the AC

power cord, always pull the plug, never pull

the cord.

•Before you connect the AC power cord,

make sure that you have completed all the

other connections.

8EN

Connect the power cord to the wall

socket.

Prepare the remote

control

Caution

•Risk of product damage! When the remote

control is not used for long periods, remove

the batteries.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert the supplied AAA batterry

with correct polarities (+/-) as

indicated.

3 Close the battery compartment.

Power on

Press .

» The product switches to the last

selected source.

Switch to standby mode

Press again to switch the product to

standby with no clock display (ECO

standby), or to standby with clock

display.

» The red standby indicator lights up.

• In standby, you may press and hold

to toggle clock display on

or o.

Note

•The product switches to standby mode

after 15 minutes of inactivity.

•To achieve the ecient energy saving

performance, unplug any external

electronic device from the USB port when

the device is not in use.

Set the clock

1 In power on mode, press and hold

for more than 2 seconds to

enter the clock setting mode.

» or is displayed.

2 Press to select 24H or 12H

hour format, and then press .

» The hour digits begin to blink.

3 Press to set the hour, and

then press .

» The minute digits begin to blink.

4 Press to set the minute, and

then press .

» The clock is set.

aTip

•To view clock, press briey.

9EN

4 Play

Play from disc

1 Press to select CD source.

2 Press to open the disc

compartment.

3 Insert a disc with the label side up.

4 Press to close the disc

compartment.

5 Play starts automatically. If not,

press .

BTB4800

Play from USB

Note

•Make sure that the USB device contains

playable audio content.

1 Insert a USB device into the

socket.

2 Press / repeatedly to

select the USB source.

» Play starts automatically. If not,

press .

BTB4800

Control play

Start, pause, or resume play.

Stop play.

/ Select an album or a folder.

/ Press to skip to the previous

or next track.

Press and hold to search

backward/forward within a

track.

Play a track or all tracks

repeatedly.

Play tracks randomly.

+/- Increase or decrease the

volume.

Mute or unmute sound.

Select a preset sound eect.

Adjust display brightness.

Show playback information.

Skip tracks

For CD:

Press / to select tracks.

For MP3 disc and USB:

1 Press / to select an album or a

folder.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système audio micro

Philips

Philips MCD 289/55 Manuel utilisateur

Philips

Philips MCM205/12 Manuel utilisateur

Philips

Philips DCM2060/96 Manuel utilisateur

Philips

Philips BTM177/12 Manuel utilisateur

Philips

Philips MCM1055B/98 Manuel utilisateur

Philips

Philips DCM2260 Manuel utilisateur

Philips

Philips MC-55/21M Manuel utilisateur

Philips

Philips BTM2056 Fiche d'information produit

Philips

Philips MCM1120 Manuel utilisateur

Philips

Philips DCB2070/10 Manuel utilisateur

Philips

Philips DCB293/79 Manuel utilisateur

Philips

Philips DCM1170 Manuel utilisateur

Philips

Philips DCM377/12 Manuel utilisateur

Philips

Philips BTM5000/12 Manuel utilisateur

Philips

Philips MCD712/93 Manuel utilisateur

Philips

Philips MCM398D/05 Manuel utilisateur

Philips

Philips DCM1075/98 Manuel utilisateur

Philips

Philips MCM169/96 Manuel utilisateur

Philips

Philips DCM105/05 Manuel utilisateur

Philips

Philips MCM233 Manuel utilisateur

Philips

Philips BTM2560 Manuel utilisateur

Philips

Philips DCM109/37 Manuel utilisateur

Philips

Philips Harmony DCD8000 Manuel utilisateur

Philips

Philips DCM378 Manuel utilisateur

Manuels Système audio micro populaires d'autres marques

Rautz

Rautz MC-5100DU Manuel utilisateur

Sanyo

Sanyo DC-D9 Manuel utilisateur

Curtis

Curtis RCD744 Manuel utilisateur

Samsung

Samsung MM-UC8 Manuel utilisateur

Akai

Akai AMP300UCI Manuel utilisateur

Hyundai

Hyundai MS 132 DU3BL Manuel utilisateur

JVC

JVC UX-GP5 Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manuel utilisateur

Optimus

Optimus SYSTEM 731 Manuel utilisateur

Hitachi

Hitachi AXM209UK Manuel utilisateur

Sharp

Sharp XL-MP110DVD Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manuel utilisateur

ProAudio

ProAudio MC 9010 iP Manuel utilisateur

Samsung

Samsung MM-ZJ9 Manuel utilisateur

Sharp

Sharp MD-X7 Manuel utilisateur

Sharp

Sharp DK-KP95P Manuel utilisateur

Akura

Akura APTCDC832PR Manuel utilisateur

iLive

iLive IHB248B Manuel utilisateur
