Philips 1050DRN Manuel utilisateur

Job Information Type:

Job Name:

Cat. No.:

Notes:

1050DRN

Lytecaster, 5", CFL, Round, IC, I Lt., FIK

Page 1 of 2

Complete fixture consists of frame-in kit and reflector trim. Select each separately.

Xceed frame-in kit Xceed compact fluorescent lensed round reflector Trims

Frame-in kit sku Lensed Downlight Lensed slope/wall wash

1050DRN26ES*

(Energy Star® - 120v)

26w Triple

GX24q-3 Base

120v - 0.23 amp max

1050RNDLWB

1050RNDLCDW

1050RNDLCDP

1050RNDLWDW

1050RNDLWDP

1050RNDLWC

1050RNDLFGWB

1050RNDLFGCDW

1050RNDLFGCDP

1050RNDLFGWDW

1050RNDLFGWDP

1050RNDLFGWC

1050RNSLWWB

1050RNSLWCDW

1050RNSLWCDP

1050RNSLWWDW

1050RNSLWWDP

1050RNSLWWC

1050RNSLWFGWB

1050RNSLWFGCDW

1050RNSLWFGCDP

1050RNSLWFGWDW

1050RNSLWFGWDP

1050RNSLWFGWC

* All frames come standard with preset mounting screws and a 2700k lamp. Models are available with preset nails and/or a 3500k

lamp. Simply add an n and/or 35 to the end of the model number for those options.

6,7

8 1/4"

(210 mm)

Overall Width

8 5/16" (211 mm)

13" Min

(330 mm)

24" Max

(610 mm)

Reflector Trim

Frame-In-Kit

14" (356 mm)

Overall Length

11 5/8" (295 mm)

Overall Length

Height = 3 1/2" (89 mm)

Aperture Opening = 5 5/16" (135 mm) Dia.

Top View

ENERGY STAR

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

1050DRN October 19, 2010

Specifications are subject to change without notice.

Job Information Type:

1050DRN

Lytecaster, 5", CFL, Round, IC, I Lt., FIK

Page 2 of 2

Features

1.Housing: .026" (#23ga.) galvanized steel. UL listed for direct

contact with thermal insulation. AirSeal® housing minimizes air

leakage to less than 2 CFM at 1.57 PSF (or 75Pa), which complies

with Title 24, the International Energy Conservation Code, and

Washington State Energy Code (Section 502.4). This reduces

heat loss and condensation in ceiling. Access door for inspection

of junction box.

2. Lower frame and top cover: .026" (#23 ga.) galvanized

steel. Accommodates ceilings up to 1 1/2" thick. 3/8" deep

integral lip with four notches at 90 degrees apart to simplify

alignment. Locks into position along length of mounting bars

with locking screws. Indicator lines on housing top and sides to

simplify alignment.

3. Junction box: 2.5" X 5 3/8" X 2" (27 cu. in) .032" (#21 ga.)

galvanized steel. UL listed 90°C supply conductors. Rated for

branch circuit wiring supplying connected luminaires

(daisy chaining).

4. Mounting bars: .059" (#16 ga.) galvanized steel. Bars

pivot for easy attachment and wire-in below ceiling line.

Bars extend to accommodate 16" to 24" O.C. joist spacing.

Bars can accommodate 12" O.C. Joist spacing after a slight

fieldmodification (see Instruction Sheet). Features integral self

tapping phillips/square drive SCREWS for secure attachment to

wood or metal construction. Also available with integral NAILS.

Attaches to T-bar ceilings without the need of accessories.

Bars installed on shortest dimension of frame, but can be easily

repositioned 90 degrees from original position.

5. Ballast: Mounted inside Junction Box. 120V NPF Energy

Star® approved Electronic Ballast. Instant start with end of lamp

life protection, class “P” thermal protection with a class “A”

sound rating. Ballast easily accessible forinspection. Min. starting

temperature is 50°F (10°C).

Features (continued)

6. Socket: NEW TWIST & LOCK Four-pin base, molded

thermoplastic socket, prewired with No. 18 AWM leads to

ballast.

7. Socket bracket: .048" (#18ga.) Galvanized Steel. Designed

to be easily adjusted to accommodate 3/8" to 1 1/2" ceiling

thickness. Three positions available for any installation

orientation of Wall Washers Slope ceiling, or Wall mount

application. Ensures Unitized optics. Reflector trim is secured

toupper portion of socket bracket to ensure a tight to ceiling

installation.

Recommended dimmers (neutral required)

ITSEBAU: IntelliSight Occupancy Dimmer for AmbiStar Ballasts

OS600EBA: Onset Wall Box Dimmer 600VA for AmbiStar

Ballasts

MSP600EBA: MultiSet Pro Dimmer 600VA for AmbiStar

Ballasts

Please add the following letters to part number for color

option:

W = White = Ivory A = Light Almond

Recommended lamping

Lightolier recommends the following Philips lamps:

943272: PLT 26W – 2700K = PHILIPS #38440-4

943273: PLT 26W – 3500K = PHILIPS #26824-3

Labels

cULus Listed (Type I.C., Suitable for Damp Location), Complies

with Air Leakage Requirements stated in the Title 24, the

International Energy Conservation code and Washington State

Energy Code. AirSeal® is a registered trademark ofLightolier.
