Philips 300WN5 Manuel utilisateur

Product Information

Product Features • Technical Specifications • Resolution & Preset Modes •

Philips Pixel Defect Policy • Automatic Power Saving • Physical Specification •

Pin Assignment • Product Views

Product Features

300WN5

z29.5-inch WXGA (1280x768 resolution, 176 degree viewing angle) LCD all-in-one

Monitor TV with excellent display performance

zMultiple video input allowing display of PC, TV, HDTV, VCD, DVD, Progressive DVD

and Camcorder

zNetwork controllability via RS232 interface for managing the performances, setting, etc.

zDigital High Definition Picture (1080i, 720p, 576p, 576i, 480p, 480i)

zDCDiTM de-interlacinf technology for superior depiction of motion

zPicture-in-Picture (PIP) function in PC VGA mode

zLight sensor to adjust brightness automatically

zTeletext (available only in Asia Pacific and Western Europe)

zDigital Nicam/2CS stereo (available only in Asia Pacific and Western Europe)

zComponent Video Input (YPbPr/YCbCr) for DVD (available in AV and TV models only)

zEuroconnector (SCART) (available in Western Europe)

zMultiSystem TV tuner-PAL/NTSC (available in TV model only)

RETURN TO TOP OF THE PAGE

Technical Specifications*

LCD PANEL

• Type TFT LCD

• Screen size 29.5 inch

• Pixel Pitch 0.5025 x 0.1675 mm x RGB

• LCD Panel type 1280 x 768 pixels

R.G.B. vertical stripe

Hard coating surface, anti-glare polarizer

• Effective viewing area (H) 643.2 x (V) 385.92mm

• Display Colors 8 bits interface (16.7M colors)

PC SCANNING

• Vertical refresh rate 58Hz-60Hz

• Horizontal frequency 31kHz-49kHz

PC VIDEO

• Video dot rate < 80 MHz

• Input impedance

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

Installstion and Operating Instructions

Exhibit 3

- Video 75 ohm

- Sync 2.2K ohm

• Input signal levels 0.7 Vpp

• Sync input signal Separate sync

• Sync polarities Positive and negative

• Input Frequency WXGA Hsync 48 kHz, Vsync 60 Hz (N.I.)

SVGA Hsync 38 kHz, Vsync 60 Hz (N.I.)

VGA Hsync 31 kHz, Vsync 60 Hz (N.I.)

• Video interface D-sub, S-Video, TV-RF, SCART (Europe) or composite

and components video (others)

AUDIO

• Input level for

PC/SVHS/SCART 500 mV nominal

• Loudspeaker 5W Stereo Audio (2.5W/channel RMS x2, 200Hz~10kHz, 4

ohm, 10% THD)

OPTICAL CHARACTERISTICS

• Contrast ratio 500:1 (typ.)

• Brightness 500 cd/m2(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity x: 0.283 y: 0.297 (at 9300°K)

x: 0.313 y: 0.329 (at 6500°K)

x: 0.328 y: 0.344 (at 5700°K)

• Viewing Angle (C/R >5)

Upper >88° (typ.)

Lower >88° (typ.)

Left >88° (typ.)

Right >88° (typ.)

• Response time <=16ms (typ.)

sRGB

sRGB is a standard for ensuring correct exchange of colors between different devices (e.g.

digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB

compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors

are calibrated and you can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to

a predefined setting as well as the color gamut. Therefore it is important to select the sRGB

setting in the monitor's OSD.

To do so, at PC mode, open the OSD by pressing the MENU button of your monitor. Use the

down button to go to COLOR SETTINGS and press MENU again. Then move the down

Page 2 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Resolution & Preset Modes

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPMS compliance display card or software installed in your PC, the monitor

can automatically reduce its power consumption when not in use. If an input from a keyboard,

mouse or other input device is detected, the monitor will then 'wake up' automatically. The

following table shows the power consumption and signaling of this automatic power saving

feature:

button to go to NORMAL COLOR and press MENU again.

For more information on sRGB, please visit: www.srgb.com

• Recommended 1280 x 768 at 60Hz

10 factory preset modes:

Resolution Mode H. freq (kHz) V. freq (Hz)

640*480 VGA VESA 60 31.469 59.940

800*600 SVGA VESA 60 37.879 60.317

1024*768 XGA VESA 60 48.363 60.004

1280*768 GTF 60 47.700 60.000

Video

EDTV 480P 31.470 60.000

SDTV 480i 15.734 59.940

EDTV 576P 31.250 50.000

SDTV 576i 15.625 50.000

HDTV 1080i 33.750 60.000

HDTV 720P 45.000 60.000

Power Management Definition

Power LED

Page 3 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

RETURN TO TOP OF THE PAGE

Physical Specifications

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

1. The digital only connector contains 24 signal contacts organized in three rows of eigh

contacts. Signal pin assignments are listed in the following table:

VESA Mode Video H-sync V-sync Used color

ON Active Pulse Pulse 130W (typ.) Blue

OFF Blanked No No < 5W Amber

AC OFF Blanked No No < 2W Off

This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS

has determined that this product meets the ENERGY STAR®guidelines for energy

efficiency.

• Dimension (WxHxD) * 867.7mm x 505mm x 183mm (incl. Pedestal, Speakers)

726.7mm x 469.3mm x 115mm (w/o Pedestal, Speakers)

• Weight 16.0 kg (incl. Pedestal, Speakers)

14.0 kg (w/o Pedestal, Speakers)

15.0 kg (w/o Pedestal, Speakers; with protective cover)

• Power supply 90 — 264 VAC, 50/60 Hz

• Power consumption PC Mode: 130 W (typ.)

TV Mode: 150 W (typ.)

• Temperature (operating) 0° C to 35° C

• Relative humidity 20% to 80%

• System MTBF 50K hrs (excluding CCFL 40Khrs)

No. Signal

Assignment Pin

No. Signal

Assignment Pin

No. Signal

Assignment

1T.M.D.S. Data2- 9T.M.D.S. Data1- 17 T.M.D.S. Data0-

2T.M.D.S. Data2+ 10 T.M.D.S. Data1+ 18 T.M.D.S. Data0+

3T.M.D.S. Data2/4 11 T.M.D.S. Data1/3 19 T.M.D.S. Data0/5

Page 4 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

2. The 15-pin D-sub connector (male) of the signal cable:

3. RS232 Connector

D-sub 9-pin male connector for communication with plasma engine or PC.

Shield

4No connect 12 No connect 20 No connect

5No connect 13 No connect 21 No connect

6DDC Clock 14 +5V Power 22 T.M.D.S. Clock

Shield

7DDC Data 15 Hot Plug Detect 23 T.M.D.S. Clock+

8No connect 16 Ground (for +5V) 24 T.M.D.S. Clock-

No. Assignment Pin

No. Assignment

1Red video input 9DDC +5V

2Green video input 10 Cable detect

3Blue video input 11 Identical output,

connected to pin 10

4Ground 12 Serial data line (SDA)

5NC 13 H. Sync / H+V

6Red video ground 14 V. Sync

7Green video ground 15 Data clock line (SCL)

8Blue video ground

Pin No. RS-232 (EIA-232-A) Function

Page 5 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

4. SCART Connector

3Transmit Data (TD) from DTE to DCE

2Receive Data (RD) from DCE to DTE

7Request to Send (RTS)

8Clear to Send (CTS)

6DCE Ready (DSR)

5Signal Ground (SG)

1Received Line Signal Detector (DCD)

4DTE Ready (DTR)

9Ring Indicator

Pin No. Signal Pin No.

1Audio right channel output (0.5 Vrms, < 1K

ohms) 2

2Audio right channel input (0.5 Vrms, > 10K

ohms) 1

3Audio left channel output (0.5 Vrms, < 1K

ohms) 6

4Audio ground 4

5Blue signal ground 5

6Audio left channel input (0.5 Vrms, > 10K

ohms) 3

7Blue signal I/O (0.7 Vp-p, 75 ohms) 7

8Function switching I/O (L: < 2V, H: > 10V,

10K ohms) 8

9Green signal ground 9

10 Intercommunication data line No. 1 10

11 Green signal I/O (0.7 Vp-p, 75 ohms) 11

12 Intercommunication data line No. 2 12

13 Red signal ground 13

14 Blanking signal ground 14

15 Red signal I/O (0.7 Vp-p, 75 ohms) 15

16 Blanking signal I/O (L: < 0.4V, H: >1.0V, 75

ohms) 16

17 Composite video signal ground 18

Page 6 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

RETURN TO TOP OF THE PAGE

Product Views

Follow the links to see various views of the monitor and its components.

Product Description

RETURN TO TOP OF THE PAGE

18 Blanking signal ground 17

19 Composite video signal output (1 Vp-p, 75

ohms, sync: negative) 20

20 Composite video signal input (1 Vp-p, 75

ohms, sync: negative) 19

21 Plug shield (common ground) 21

Page 7 of 7Product Information

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\PRODUCT\PRODUCT.HTM

Installing your LCD Monitor/TV

Product Description • Connecting to Your PC, TV antenna, DVD/VCR etc. • Getting Started

Performance

Product Description

Side View (Left)

RETURN TO TOP OF THE PAGE

Rear View

TV version

1INPUT Selecting input source

Increase or decrease the channel number

moving up or down to highlight the function in OSD

Increase or decrease the level of audio volume

moving left or right of to highlight the sub-menu in the selected

function of OSD

4MENU Open the OSD or confirm the selected function

5DC power switch On/Off

Page 1 of 7Installing your LCD Monitor/TV

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\INSTALL\INSTALL.HTM

RETURN TO TOP OF THE PAGE

Audio/Video version

1AC IN AC power in

2AC Power AC power switch

3D-Sub PC analog D-Sub input

4PC - Audio PC Stereo input

5DVI-D PC

6RS232 RS232 network connection

7External/

EURO-AV SCART connection (for Europe only)

8Composite Video Output Composite video CVBS ouput

9Audio (L) Output Audio (L) output

Audio (R) Output Audio (R) output

10 Audio (L) Output Audio (L) output for the detachable speaker (L)

Audio (R) Output Audio (R) output for the detachable speaker (R)

11 Line out Audio output for external speakers

Page 2 of 7Installing your LCD Monitor/TV

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\INSTALL\INSTALL.HTM

RETURN TO TOP OF THE PAGE

Monitor version

1AC IN AC power in

2AC Power AC power switch

3D-Sub PC analog D-Sub input

4PC - Audio PC Stereo input

5DVI-D PC

6RS232 RS232 network connection

7External/

EURO-AV SCART connection (for Europe only)

8Audio (L) Output Audio (L) output for the detachable speaker (L)

Audio (R) Output Audio (R) output for the detachable speaker (R)

9Line out Audio output for external speakers

Page 3 of 7Installing your LCD Monitor/TV

2004/3/4file://W:\DFU\Philips\LCT-TV\300WN5\ENGLISH\300WN5\INSTALL\INSTALL.HTM

Autres manuels pour 300WN5

Table des matières

Autres manuels Philips Téléviseur LCD

Philips

Philips 26HF5545D Manuel utilisateur

Philips

Philips 42HFL9320A Manuel utilisateur

Philips

Philips 32PFL3205/12 Manuel utilisateur

Philips

Philips 23-LCD FLAT TV CRYSTAL CLEAR III 23PF8946 Manuel utilisateur

Philips

Philips 32PF9976 Manuel utilisateur

Philips

Philips 43PFL4901/F7 Manuel utilisateur

Philips

Philips 32PFL3506/F7 Manuel utilisateur

Philips

Philips 32PFL3605/60 Manuel utilisateur

Philips

Philips 32PFL3406H/12 Manuel utilisateur

Philips

Philips Q543.1E LA Manuel utilisateur

Philips

Philips 23PF8946A/37 Manuel utilisateur

Philips

Philips 19PFL2409/F8 Manuel utilisateur

Philips

Philips 26PF8946/12 Manuel utilisateur

Philips

Philips 15PF9925 - annexe 2 Manuel utilisateur

Philips

Philips 3000 series Manuel utilisateur

Philips

Philips 30PF9975/69 Manuel utilisateur

Philips

Philips Hospitality 39HFL3684S/F7 Manuel utilisateur

Philips

Philips 40PFL9704H Manuel utilisateur

Philips

Philips 40PFL6606H Manuel utilisateur

Philips

Philips 50PFL3008K/12 Manuel utilisateur

Philips

Philips 32HF7543 Manuel utilisateur

Philips

Philips 17-LCD HDTV MONITOR FLAT TV CRYSTAL CLEAR III... Manuel utilisateur

Philips

Philips 32PFL5332D - 32" LCD TV Manuel utilisateur

Philips

Philips 26PFL3405H Manuel utilisateur

Manuels Téléviseur LCD populaires d'autres marques

LG 32LC4R* Manuel utilisateur

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuel utilisateur

Salora

Salora 22LED1600 Manuel utilisateur

Samsung

Samsung LA32E420 Mode d’emploi

Dell

Dell W1900 19 Instructions d'utilisation

Samsung

Samsung LN40C670M1F Manuel utilisateur

Samsung

Samsung Series 4+ Manuel utilisateur

Samsung

Samsung 5 Series Manuel utilisateur

Grundig

Grundig 40 VLE 8230 BP Manuel utilisateur

Sony

Sony Bravia XBR-43X830C Manuel utilisateur

LG 32LS350 Manuel utilisateur

VIORE

VIORE LED32VF60 Manuel utilisateur

Toshiba

Toshiba Regza 42HL167 Manuel utilisateur

JVC

JVC LT-32A220 Manuel utilisateur

Sony

Sony Bravia KDL-V32XBR2 Manuel utilisateur

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuel utilisateur

Dynex

Dynex DX-40L261A12 Manuel utilisateur

JVC

JVC LT-23C50BU Manuel utilisateur
