Philips GC4500 series Manuel utilisateur
GC4500 series
Always there to help you
User manual
2
3
1
a
b
c
d
f
g
k
j
l
h
i
m
n
o
e
a
b
c
4
GC4500 series
ENGLISH 6
FRANÇAIS 12
ITALIANO 18
ESPAÑOL 25
PORTUGUÊS 31
6ENGLISH
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers,
register your product at www.philips.com/welcome.
Product overview (Fig. 1)
1 Spray nozzle
2 Water filling door
3 Spray button
4 Steam slider
a. Dry setting
b. ECO setting
c.Auto steam setting
5 Steam boost trigger
6 Safety auto-off light (specific types only)
7 Mains cord
8 Temperature indicator light
9 Water tank
10 Temperature dial with Auto steam control
11 Calc clean button
12 Soleplate
13 Quick Calc Release lock
14 Quick Calc Release tray
15 Typeplate
Important
Read the separate important information leaet and this user manual
carefully before you use the appliance. Keep both documents for future
reference.
Using the appliance
Filling the water tank
Note: Your appliance has been designed to be used with tap water. If you
live in an area with hard water, fast scale build-up may occur. Therefore, it is
recommended to use 100% distilled or demineralized water to prolong the
lifetime of your appliance.
1 Open the water lling door.
2 Tilt the iron backwards and ll the water tank with tap water up to
the maximum level.
Note: Do not ll the water tank beyond the MAX indication.
Do not put perfume, vinegar, starch, descaling agents, ironing aids or
other chemicals in the water tank.
3 Close the water lling door ( ‘click’).
Temperature and steam setting
Table 1:
Warning: Do not use steam or steam boost at low temperature, as indicated
in the below table. Otherwise, hot water may leak from the iron.
Fabric type Temperature
setting Auto steam
control Steam
boost
Linen MAX Automatically
adjusted to the
optimal amount
Yes
Cotton ●●● Yes
Wool ●● No
Silk ●● No
Synthetic fabric
(e.g. acrylic, nylon,
polyamide, polyester)
●No steam No
1 Consult table 1 to set the temperature dial to the appropriate
setting for your garment.
2 Select Auto steam setting in the steam slider.
This iron is equipped with Auto steam control. According to the
temperature you select, the iron automatically provides the optimal
amount of steam for the best result.
3 Put the iron on its heel and plug it in.The temperature light goes on
to indicate that the iron is heating up.
4 When the temperature light goes out, the iron has reached the
correct temperature and you could start ironing.
ENGLISH 7
Features
Spray funtion
- Press the spray button to moisten the article to be ironed. This helps
to remove stubborn creases.
Steam boost function
- Press and release the steam boost trigger for a powerful boost of
steam to remove stubborn creases.
Ironing with extra steam
-For extra steam during ironing, press and hold the steam boost trigger.
Vertical steam
- You can use the steam boost function when you hold the iron
in vertical position for removing creases form hanging clothes,
curtains etc.
Eco steam setting / Dry ironing
-In stead of Auto steam, you could choose ECO setting in the steam
slider to save energy, yet to achieve satisfactory ironing results.
- To iron without steam, select dry setting in the steam slider.
ENGLISH8
Safety auto-off (specic types only)
The safety auto-off function automatically switches off the iron if it has not
been used for 30 seconds resting on its soleplate or 8 minutes resting on
its backplate. The auto-off light will light up.
- To let the iron heat up again, pick up the iron or move it slightly.
The auto-off light goes out.
Cleaning and maintenance
Cleaning
1 Unplug the iron and let it cool down.
2 Pour any remaining water out of the water tank from the water
lling door.
3 Wipe akes and any other deposit off the soleplate with a damp
cloth and a non-abrasive (liquid) cleaning agent.
To keep the soleplate smooth, avoid hard contact with metal objects.
Never use a scouring pad, vinegar or other chemicals to clean the
soleplate.
Quick Calc Release
IMPORTANT: To prolong the life time of your appliance and to maintain good
steaming performance, use Quick Calc Release function once every 1 month.
If water in your area is very hard, use this function more frequently.
Note: Make sure that the iron has been unplugged for at least 1 hour and has
completely cooled down, before you use Quick Calc Release.
1 Put the iron on a levelled surface and push up the Quick Calc
Release lock at the back of the iron.
2 Take out the Quick Calc Release tray.
3 Pour out scales in the tray into a sink or dustbin. Clean the tray
using tap water. Remove any excess water from the tray.
ENGLISH 9
Do not pour water, vinegar, descaling agents or other chemicals into the
iron from the opening of the Quick Calc Release.
Do not use vinegar, descaling agents or other chemicals to wash the
tray.
4 Wipe off the scales in the opening of the Quick Calc Release tray
with a damp cloth.
5 Insert the tray back into the iron.
6 Push down the Quick Calc Release lock.
Do not use the iron when the Quick Calc Release tray is not locked.
If you break or lose the tray, contact a consumer care center in your
country (see the worldwide guarantee leaet for contact details).
Calc-clean function
IMPORTANT: Besides Quick Calc Release function, you should also perform
calc-clean once every 1 month to prolong the life of your iron. If water in your
area is very hard, or you see scales coming out from the soleplate during
ironing, use this function more frequently.
1 Make sure the iron is unplugged and the steam slider is set to dry setting.
2 Fill the water tank to the MAX indication.
Do not pour vinegar or other descaling agents into the water tank.
3 Plug in the iron and set the temperature dial to MAX.
4 Unplug the iron when the temperature light goes out.
5 Hold the iron over the sink. Keep pushing the calc clean button and
gently shake the iron forth and back until all water in the water tank
has been used up.
Scales is ushed out, steam and boiling water also come out of the
soleplate.
Note: Repeat steps 2 to 5 if the water that comes out of the iron still contains
scale particles.
6 Take out the Quick Calc Release tray, empty the water in the tray.
Hold the iron vertically to allow small amount of water to ow out.
7 Insert the tray back to the iron and lock it.
8 Plug in the iron and let the iron heat up to dry the soleplate.
9 Unplug the iron when the temperature indicator light goes out.
10 Move the iron gently over a piece of cloth to remove any water
stains on the soleplate.
ENGLISH10
