Philips Azur GC4250 Manuel utilisateur

Azur

GC4250

ENGLISH 4
DEUTSCH 13
FRANÇAIS 22
NEDERLANDS 31
ESPAÑOL 40
ITALIANO 49
PORTUGUÊS 58
NORSK 67
SVENSKA 76
SUOMI 84
DANSK 92
 101
TÜRKÇE 110
GC4250

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Check the cord regularly for possible damage.

◗Do not use the appliance if the plug, the cord or the appliance

itself is damaged.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the iron unattended when it is connected to the

mains.

◗Never immerse the iron in water.

◗Keep the appliance out of the reach of children.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched. Do not allow the cord to come into

contact with the soleplate when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave

the iron even for a short while: set the steam control to position

0, put the iron on its heel and remove the mains plug from the

wall socket.

Before first use

C1Remove the heat-resistant protective cover from the soleplate.

Remove any sticker or protective foil from the soleplate.

Do not use the heat-resistant protective cover during ironing.

2Let the iron heat up to maximum temperature and pass the

iron over a piece of damp cloth for several minutes to remove

any residues from the soleplate.

BThe iron may give off some smoke when you use it for the first time.This

will cease after a short while.

Preparing for use

Filling the water tank

Never immerse the iron in water.

1Make sure the appliance is unplugged.

ENGLISH4

C2Set the steam control to position 0 (= no steam).

3Open the cap of the filling opening.

4Tilt the iron backwards.

C5Fill the water tank with tap water up to the maximum level by

means of the filling cup.

Do not fill the tank beyond the MAX indication.

◗If the tap water in your area is very hard, we advise you to mix it

with an equal amount of distilled water or to use distilled water

only.

Do not put additives, vinegar, starch or chemically descaled water in the

water tank.

C6Close the cap of the filling opening.You will hear a click.

Setting the temperature

C1Remove the heat-resistant protective cover.

Do not leave the heat-resistant protective cover on the soleplate

during ironing.

2Put the iron on its heel.

3Put the mains plug in the earthed wall socket.

C◗A long beep tells you that the iron has been connected to the

mains.The temperature control display lights up and 'OFF'

appears.

ENGLISH 5

C4Press temperature control button ¢to select the required

ironing temperature.

A short beep indicates that the temperature setting has been changed.

◗Check the garment label for the required ironing temperature:

1Synthetic fabrics (e.g. acrylic, nylon, polyamide, polyester)

1Silk

2Wool

3Cotton, linen

- If you do not know what kind(s) of fabric(s) an article is made of,

determine the right ironing temperature by ironing a part that will

not be visible when you wear or use the article.

- Silk, woollen and synthetic materials: iron the reverse side of the

fabric to prevent shiny patches.Avoid using the spray function to

prevent stains.

- Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibres.

C5When you press temperature control button ¢to increase the

ironing temperature, the newly selected temperature indication

and symbol Vstart to blink.

C6Wait until the iron has reached the selected temperature.You

will hear a double beep and the temperature indication and

symbol stop blinking.

C7If you wish to select a lower ironing temperature, just press

temperature control button £to reduce the temperature.

A short beep indicates that the temperature setting has been changed.

C◗When you press temperature control button £to decrease the

ironing temperature, the newly selected temperature indication

and symbol Wstart to blink.

ENGLISH6

C◗Wait until the iron has reached the selected temperature.You will

hear a double beep and the temperature indication and symbol

stop blinking.

Using the appliance

Steam ironing

1Make sure that there is enough water in the water tank.

C2Select the appropriate steam setting. Make sure that the steam

setting you select is suitable for the ironing temperature

selected:

- 1 - 3 for moderate steam (temperature settings 2to 3)

- 4 - 6 for maximum steam (temperature settings 3to MAX)

See section 'Setting the temperature'.

BThe iron will start producing steam as soon as the set temperature has

been reached.

Ironing without steam

C1Set the steam control to position 0 (= no steam).

2Select the recommended ironing temperature.

See section 'Setting the temperature'.

Features

Spray function

You can use the spray function to remove stubborn creases at any

temperature.

Make sure that there is enough water in the water tank.

C1Press the spray button several times to moisten the article to

be ironed.

ENGLISH 7

Shot of steam

A powerful 'shot' of steam helps remove stubborn creases.

The shot-of-steam function can only be used at temperature settings

between 2and MAX.

C1Press and release the shot-of-steam button.

Drip stop

This iron is equipped with a drip-stop function: the iron automatically

stops producing steam when the temperature is too low to prevent

water from dripping out of the soleplate.When this happens you may

hear a sound.

Vertical shot of steam

C1The shot-of-steam function can also be used when you hold

the iron in vertical position.

Never direct the steam at people.

Automatic anti-calc system

C1The built-in anti-calc system reduces the build-up of scale and

guarantees a longer life for the iron.

Alert light and electronic safety shut-off function

The electronic safety shut-off function automatically switches off the

iron if it has not been moved for a while.

The iron is equipped with a blue alert light.

C1The blue alert light burns as long as the iron is plugged in.

ENGLISH8

2The blue alert light starts blinking, 'OFF' starts blinking on the

display and the iron starts beeping to indicate that the iron has

been switched off by the safety shut-off function.

When the iron is in safety shut-off mode, it will still start heating up

again as soon as you move it.

C3If the iron is left in safety shut-off mode for more than one

hour, 'OFF' stops blinking and the beeping stops.

When this happens, press temperature control button ¢to select the

required ironing temperature.

Cleaning and maintenance

After ironing

1Remove the mains plug from the wall socket and let the iron

cool down.

2Wipe flakes and any other deposits off the soleplate with a

damp cloth and a non-abrasive (liquid) cleaning agent.

3Clean the upper part of the iron with a damp cloth.

C4Regularly rinse the water tank with water. Empty the water

tank after cleaning.

Calc-clean function

You can use the calc-clean function to remove scale and impurities.

◗Use the calc-clean function once every two weeks. If the water in

your area is very hard (i.e. when flakes come out from the

soleplate during ironing), the calc-clean function should be used

more frequently.

1Set the steam control to position 0.

2Fill the water tank to the maximum level.

Do not put vinegar or other descaling agents in the water tank.

C3Select the maximum ironing temperature.

4Put the plug in the wall socket.

5Unplug the iron when the temperature has been reached (you

will hear a double beep).

C6Hold the iron over the sink, press and hold the calc-clean

button and gently shake the iron to and fro.

ENGLISH 9

BSteam and boiling water will come out of the soleplate. Impurities and

flakes (if any) will be flushed out.

7Release the calc-clean button as soon as all the water in the

tank has been used up.

Repeat the calc-clean process if the iron still contains a lot of impurities.

After the calc-clean process

- Put the plug in the wall socket and let the iron heat up to allow the

soleplate to dry.

- Unplug the iron when it has reached the set ironing temperature.

- Move the hot iron gently over a piece of used cloth to remove any

water stains that may have formed on the soleplate.

- Let the iron cool down before you store it.

Storage

1Make sure the appliance is unplugged and set the steam control

to position 0.

2Empty the water tank.

C3Put the iron on the heat-resistant protective cover.

Do not use the heat-resistant protective cover during ironing.

C4Wind the mains cord around the cord storage facility.

5Store the iron with the heat-resistant protective cover

horizontally on a stable surface.

ENGLISH10
