Philips HQ-C485 Manuel utilisateur

ServiceManual

Philips Domestic Appliances and Personal Care

Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification

Hairclipper

HQ-C485

05/03

PRODUCT INFORMATION

General description:

2D ContourTracking System™

2D ﬂexing guide comb offers maximum control and

ensures perfect results every time.

Safety Lock

Safety Lock secures the selected length setting for increased

accuracy and even cutting.

8 length settings (1-21 mm)

8 length settings allow a range of styling possibilities to suit

the whole family

Materials used:

- housing : ABS

- combs : PA / PC

- others : PA / POM / SAN / steel

Features:

lubrication for life - Maintenance free cutting unit

ensures consistent high

performance

Translucent guide comb - For maximum visibility of the

process

3D rounded teeth - For ultimate skin protection

Hygiene - Hinged cutting lid allows easy

cleaning

Ultra light design - Efﬁcient and compact for optimal

handling

Barber set - Styling comb, cleaning brush,

scissors

SAP coding: HQC485

HQ-C485

Never use again a deformed housing clamp (4).

After the product has been repaired, it should function

properly and has to meet the safety requirements as laid

down and ofﬁcally established at this moment.

Product meets the requirements regarding interference

suppression on radio and TV.

TECHNICAL INFORMATION:

Power supply : RC / AC

Charging time : 12 h

Cordless operation time : 35 min

Charging indication : yes - LED on appliance

primary (EU) : 220-240 V - 50/60 Hz

secondary (EU) : 1,3 V - 1500 mA

Dimensions Metal Case : 27,0 x 10,0 x 25,0 cm

Weight Metal Case : 0,94 kg

Weight product (without comb) : 154 g

DISASSEMBLY ADVISE

REPAIR INSTRUCTIONS

- No specific issues

OPTIONAL (ACCESSORIES)

- No specific issues

NOTES :

• In order to guarantee the longest possible

workinglife of the battery:

- do not charge for more than 24 hours

- do not keep the charging unit permanently

plugged in

- discharge the battery completely once a year by

letting the motor run until it stops

• The appliance should be charged again, when not

used for a long period

2-3

HQ-C485

PARTS LIST & EXPLODED VIEW

Pos Service code Description

4203 035 79340

4203 035 53720

4203 035 53730

4203 035 71060

4822 479 30183

Cutter

Small comb

Large comb

Housing clamp

Cleaning brush

3-3

Pos Service code Description

4822 690 30433

4822 690 30434

4822 690 30441

4822 690 30442

Barbers comb

Scissors

Adapter - EU

Adapter - GB
