Philips qc5365 Manuel utilisateur
QC5365
QC5360
User manual
1
6
Introduction
Congratulations on your purchase and welcome to Philips!
your product at www.philips.com/welcome.
General description (Fig. 1)
1 Cutting element
2 Handle
3 On/off slide
4 Charging light
5 Socket for appliance plug
6 Adapter plug
7 Adapter
8 Hair length settings window
9 Comb
10 Setting selector
11 Cleaning brush
12 Pouch (QC5365 only)
Preparing for use
Note:You can also use the appliance directly from the mains when the battery
is empty.
Charging
time and after a long period of non-use.
up to 60 minutes.
1 Make sure the appliance is switched off.
2 Insert the appliance plug into the socket of the appliance and put the
adapter in the wall socket.
,
is charging.
,When the batteries are fully charged, the charging light
lights up green continuously.After 30 minutes the charging light goes
out to save energy.
Note:You can also use the appliance directly from the mains when the battery
is empty.
Clipping with comb
The appliance comes with 1 comb for different hair lengths.
The hair length settings are indicated in millimetres on the comb.
The settings correspond to the remaining hair length after clipping.
ENGLISH
1 Slide the comb straight into the guiding grooves on both sides of
the handle (‘click’).
2 To set the comb to the desired setting, press the setting selector (1)
and slide the comb to the desired hair length setting (2).
,The settings in the window show the selected hair length in
millimetres after cutting.
Tip:Write down the hair length settings you selected to create a certain
hairstyle as a reminder for future clipping sessions.
3 Slide the on/off slide upwards to switch on the appliance.
4 Move the appliance through the hair slowly.
-
direction.
-
-
the scalp to obtain an even result.
- Make overlapping passes over the head to ensure that you cut all the
hair that needs to be cut.
5 Regularly remove cut hair from the comb.
appliance and blow and/or shake the hair out of it.
Contouring without comb
You can use the appliance without comb to clip hair very close to the skin
(0.5mm) or to contour the neckline and the area around the ears.
Be careful when you clip without comb because the cutting
element removes every hair it touches.
1 Press the setting selector and slide the comb up, then pull the
comb off the appliance.
2 Before you start to contour the hairline around the ears, comb the
hair ends over the ears.
ENGLISH 7
3 Slide the on/off slide upwards to switch on the appliance.
4 Tilt the appliance in such a way that only one edge of the cutting
element touches the hair ends when you shape the contours around
the ears.
Only cut the hair ends.The hairline should be close to the ear.
5 To contour the neckline and sideburns, turn the appliance and make
downward strokes.
Move the appliance slowly and smoothly. Follow the natural hairline.
Cleaning
Never use compressed air, scouring pads, abrasive cleaning agents or
aggressive liquids such as petrol, acetone or ethereal oils to clean the
appliance.
Never immerse the appliance in water or any other liquid, nor rinse it
under the tap.
Note:The appliance does not need any lubrication.
1 Switch off the appliance and disconnected it from the mains.
2 Remove the comb from the appliance and clean it with the cleaning
brush.
3 Push the centre top end of the cutting element upwards with your
thumb until it opens.
4 Use the cleaning brush to remove the cut hair.
ENGLISH8
9
1
2
,
,
1
2
,
3
4
-
-
-
-
5
1
2
10
