Philips HQ7845/16 Manuel utilisateur

ENGLISH 4

BAHASA MELAYU 15

BAHASA INDONESIA 27

TI”NG VI◊T 39

 50

HQ7845

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug supplied to charge

the appliance.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

◗The powerplug contains a transformer. Do

not cut off the powerplug to replace it with

another plug, as this will cause a hazardous

situation.

◗If the powerplug is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

C◗Make sure the powerplug does not get wet.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

◗Do not recharge the shaver in a closed pouch.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

Charging

Make sure the appliance is switched off before

you start charging it.

ENGLISH4

When you charge the shaver for the first time or

after a long period of disuse, let it charge

continuously for 4 hours.

Charging normally takes approx. 1 hour.

Do not leave the appliance connected to the

mains for more than 24 hours.

You can also shave without charging by

connecting the shaver to the mains. In this case,

the green pilot light burns during shaving.

Charge indications

Charging

C◗As soon as you start charging the empty

shaver, the green pilot light goes on.

Batteries fully charged

C◗When the batteries have been fully charged,

the green pilot light starts blinking.

ENGLISH 5

Batteries running low

C◗When the batteries are running low, the red

pilot light goes on.When you have switched

the shaver off, the red pilot light blinks for 4

seconds.

Charging the appliance

Do not recharge the shaver in a closed pouch.

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

3Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver when the batteries have been

fully charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 45 minutes.

Using the appliance

Shaving

1Switch the shaver on by pressing the on/off

button once.

ENGLISH6

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off by pressing the on/off

button once.

C4Put the protection cap on the shaver every

time you have used it in order to prevent

damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit and the hair

chamber with hot water every time you have

used the shaver.

ENGLISH 7

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

C◗For easy and optimal cleaning, the Philishave

Action Clean (shaving-head cleaner, type

HQ100) is available.Ask your Philishave dealer

for information.

BThe Philishave Action Clean may not be available

in all countries. Contact the Customer Care Centre

in your country about the availability of this

accessory.

You can also clean the shaver in the following

way:

Every day: shaving unit and hair chamber

When you clean the appliance, it is not necessary

to take the shaving heads (cutters and guards)

apart. If you want to take them apart, be sure not

to mix up the cutters and guards, since grinding of

the cutters in the guards only guarantees optimal

performance for each matching set. If you

accidentally mix up the sets, it could take several

weeks before optimal shaving performance is

restored.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button (1) to open the

shaving unit (2).

ENGLISH8

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

4Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue

as this may damage the shaving heads.

C5Open the shaving unit again and leave it

open to let the appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH 9

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every 2 years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ6 Philishave Quadra shaving heads only.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button (1) to open the

shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit in such a way that

the parts with the small holes point

towards the centre of the shaving unit.

Make sure that the projections of the shaving

heads fit exactly into the recesses.

ENGLISH10

C5Put the retaining frame back into the

shaving unit, press the wheel (1) and turn it

clockwise (2).

Accessories

The following accessories are available:

- HQ6 Philishave Quadra shaving heads.

- HQ8000 powerplug.

- HQ100 Philishave Action Clean

(shaving head cleaner).

- HQ101 Philishave Action Clean refill

(shaving head cleaning liquid).

- HQ110 Philishave shaving head cleaner

(shaving head cleaning spray).

Environment

The built-in rechargeable batteries contain

substances that may pollute the environment.

Disposal of batteries

Remove the batteries when you discard the

appliance. Do not throw the batteries away with

the normal household waste, but hand them in at

an official collection point.You can also take the

appliance to a Philips service centre, which will

remove the batteries for you and will dispose of

them in an environmentally safe way.

ENGLISH 11

Only remove the batteries if they are completely

empty.

1Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver.

C2Let the shaver run until it stops, open the

trimmer, undo the screws and open the

shaver.

3Remove the batteries.

Do not connect the shaver to the mains again

after the batteries have been removed.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.

ENGLISH12
