Philips HQ7100 Manuel utilisateur

HQ7100

ENGLISH 4

 12

 21

 29

 36

 44

 52

 61

 69

 77

 85

 93

 102

 110

 118

 126

Important

Read these instructions for use carefully before using

the appliance and save them for future reference.

Only use the powerplug supplied.

The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

The powerplug contains a transformer. Do not

cut off the powerplug to replace it with another

plug, as this will cause a hazardous situation.

Do not use a damaged powerplug.

If the powerplug is damaged, always have it

replaced by one of the original type in order to

avoid a hazard.

Make sure the powerplug does not get wet.

Store the appliance at a temperature between 5

cC and 35 cC.

Always unplug the shaver before cleaning it

under the tap.

The appliance complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

Be careful with hot water. Always check if the water

is not too hot, to prevent your hands from getting

burnt.

This washable shaver is not suitable for shaving

in the shower.

Do not immerse the shaver in water.

Water may leak from the socket at the bottom

of the appliance when you rinse it.This is normal

and not dangerous because all electronics are

enclosed in a sealed power unit inside the shaver.

Noise level: Lc = 56 dB [A]

ENGLISH





1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

3 Switch the shaver on by pressing the on/off

button once.

The power-on lights go on to indicate that the

motor is running.

4 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

5 Switch the shaver off by pressing the on/off

button once.

The power-on lights go out.

6 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

7 Put the protection cap on the shaver every

time you have used it, to prevent damage to

the shaving heads.



For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

ENGLISH 5

2 Close the trimmer (‘click’).



Regular cleaning guarantees better shaving

performance.

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands from

getting burnt.

Note:Water may leak from the socket at the bottom of

the appliance when you rinse it.This is normal and not

dangerous.



1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button to open the shaving

unit.

3 Clean the shaving unit and the hair chamber by

rinsing them under a hot tap for some time.

ENGLISH6

Make sure you clean the inside as well as the

outside of the shaving unit.

4 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

5 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

by using the brush supplied.



1 Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

2 Clean the cutters and guards with the brush

supplied.

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

3 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn the lock clockwise.

4 Close the shaving unit.

ENGLISH 7



Clean the trimmer every time you have used it.

1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.



Put the protection cap on the shaver to prevent

damage to the shaving heads.



Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ8

Philips shaving heads only.

Note:Do not mix up the cutters and the guards to

guarantee optimal shaving performance.

1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

ENGLISH8

2 Press the release button to open the shaving

unit.

3 Turn the lock anticlockwise (1) and remove the

retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit. Put the retaining frame

back into the shaving unit and turn the lock

clockwise.

Make sure that the projections of the shaving

heads t exactly into the recesses.

5 Close the shaving unit.



The following accessories are available:

HQ8000 powerplug.

HQ8 Philips Shaving Heads.

HQ110 Philips Shaving Head Cleaning Spray.

HQ8010 car cord.



Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an ofcial collection point for

recycling. By doing this you will help to preserve

the environment.

ENGLISH 9



If you need information or if you have a problem,

please visit the Philips website at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will nd its phone

number in the worldwide guarantee leaet). If there

is no Customer Care Centre in your country, turn

to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and

Personal Care BV.

ENGLISH10



1 Reduced shaving performance.

Cause 1: the shaving heads are dirty.The shaver has

not been rinsed long enough or the water used was

not hot enough.

Clean the shaver thoroughly before you continue

shaving. See chapter ‘Cleaning and maintenance’.

Cause 2: long hairs are obstructing the shaving heads.

Clean the cutters and guards with the brush

supplied. See chapter ‘Cleaning and maintenance’,

section ‘Every six months: shaving heads’.

Cause 3: the shaving heads are damaged or worn.

Replace the shaving heads. See chapter

‘Replacement’.

2 The shaver does not work when the on/off

button is pressed.

The appliance is not connected to the mains.

Put the powerplug in the wall socket.

3 The shaving unit has come off the shaver.

The shaving unit has not been placed correctly.

If the shaving unit becomes detached from the

shaver, you can easily put it back by inserting

the hinge into the slot in the rim of the hair

chamber and pushing it home until it locks into

place (‘click’).

ENGLISH 11



Преди да използвате уреда, прочетете

внимателно това ръководство за експлоатация и

го запазете за справка в бъдеще.

Използвайте само доставения с комплекта

щепсел.

Щепселът трансформира 100-240 волта до

безопасно ниско напрежение под 24 волта.

В щепсела на захранването има

трансформатор. Не отрязвайте щепсела, за да

го замените с друг, защото това ще доведе

до опасна ситуация.

Не използвайте повреден щепсел.

Ако щепселът се повреди, винаги трябва

да осигурявате замяната му с такъв от

оригиналния тип, за да се избегне опасност.

Внимавайте щепселът да не се мокри.

Съхранявайте уреда при температура между

5 cC и 35 cC.

Винаги изваждайте щепсела на

самобръсначката от контакта, преди да я

миете под течаща вода.

Уредът съответства на международно

одобрената нормативна уредба за

безопасност IEC и може да се почиства

безопасно под чешмата.

Внимавайте с горещата вода. Винаги

проверявайте дали водата не е прекалено

гореща, за да предпазите ръцете си от изгаряне.

Тази миеща се самобръсначка не е

подходяща за бръснене под душа.


