Philips HQ6847/16 Manuel utilisateur

ENGLISH 4

DEUTSCH 12

FRANÇAIS 21

NEDERLANDS 30

ESPAÑOL 39

ITALIANO 48

PORTUGUÊS 57

TÜRKÇE 66

HQ6847

Important

◗Only use the HQ6000 Powerplug supplied to

charge the appliance.

◗The Powerplug transforms 110-240Volts to

12Volts.

C◗Make sure the HQ6000 Powerplug does not

get wet.

C◗The shaver runs at a safe low voltage of 12

Volts.It is watertight and can be cleaned

under the tap.Do not rinse with water hotter

than 80cC.

Charge indications

C◗Charging

As soon as you start charging the empty shaver,

the green pilot light will go on.

C◗Batteries fully charged

When the batteries have been fully charged,the

green pilot light will start blinking.

A fully charged shaver has a cordless shaving time

of up to 45 minutes.

C◗Batteries running low

When the batteries are running low,the lower

light becomes red.When you have switched off

the shaver,the red light will blink for 4 seconds.

ENGLISH4

Charging

Recharge and keep the appliance at a

temperature between 5cC and 35cC

The Powerplug is suitable for mains voltages

ranging from 100 to 240V.

Do not leave the shaver connected to the mains

continuously.

C1Insert the appliance plug into the shaver as

far as the line on the plug.

2Put the Powerplug in the socket.

Do not recharge the shaver in a closed pouch.

3When charging for the first time or after a

long period of disuse:leave the shaver to

charge continuously for 4 hours.

Charging normally takes approx.1 hour.

4Remove the Powerplug from the socket

and pull the appliance plug out of the

shaver when the batteries have been fully

charged.

With the special Philishave Car Cord (HQ6010),

you can also charge the appliance at 12Volts (e.g.

in a car).This cord is available from your Philishave

dealer.

Shaving

1Switch the appliance on by pressing the

on/off button once.

ENGLISH 5

C2Move the shaving heads quickly over the

skin,making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2-3 weeks to get accustomed

to the Philishave system.

3Switch the appliance off by pressing the

on/off button once.

C4Put the protective cap on the shaver to

prevent damage.

Replace the shaving heads (type HQ6 Quadra

Action) every 2 years for optimal shaving results.

Trimmer

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit every week

with hot water (60cC-80cC).

When you clean the appliance,it is not necessary

to take the shaving heads (cutters and guards)

ENGLISH6

apart.If you want to take them apart,be sure not

to mix up the cutters and guards,since grinding of

the cutters in the guards only guarantees optimal

performance for each matching set.If you

accidentally mix up the sets,it could take several

weeks before optimal shaving is restored.

Every week:shaving unit

1Switch the appliance off,remove the

Powerplug from the socket and pull the

appliance plug out of the shaver.

C2Press the release button and open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

(60cC-80cC) for some time.

C4Leave the shaving unit open to let the

appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

Every six months:trimmer

1Switch the appliance off,remove the

Powerplug from the socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush.

ENGLISH 7

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Replacing the shaving heads

Replace the shaving heads every two years for

optimal shaving results.

1Switch the appliance off,remove the

powerplug from the socket and disconnect

the appliance plug from the shaver.

C2Press the release button to open the

shaving unit.

C3Turn the wheel anti-clockwise and remove

the retaining frame.

C4Remove the shaving heads and place the

new ones in the shaving unit in such a way

that the parts with the small holes point

towards the centre of the shaving unit.

Make sure that the projections of the shaving

heads fit exactly into the recesses.

C5Reassemble the shaving unit by pressing

the wheel and turning it clockwise.

If the shaving heads have been properly inserted,

ENGLISH8

a shiny circle is visible on top of the shaving unit.

Replace damaged or worn shaving heads with

Philishave HQ6 Quadra Action shaving heads

only.

Storing

C◗Put the protective cap on the shaver to

prevent damage.

◗Store the appliance in the luxury pouch.

Disposal of batteries

Remove the batteries when you discard the

appliance.Do not throw the batteries away with

the normal household waste,but hand them in at

an official collection point.You can also take the

batteries to a Philips Service Centre,which will

dispose of them in an environmentally safe way.

Only remove the batteries if they are completely

empty.

1Remove the Powerplug from the socket

and pull the appliance plug out of the

shaver.

C2Let the shaver run until it stops,undo the

screws and open the shaver.

3Remove the batteries.

ENGLISH 9

The shaver may not be connected to the mains

again after the batteries have been removed.

Troubleshooting

Reduced shaving performance:

BCause 1:The shaving heads are dirty.The shaver

has not been rinsed long enough or the water

used was not hot enough.

1Clean the shaver thoroughly before you

continue shaving (see 'Cleaning').

BCause 2:Long hairs are obstructing the shaving

heads.

C2Remove the retaining plate.

C3Clean the cutters and guards.

Do not clean more than one cutter and guard at

a time,since they are all matching sets.If you

accidentally mix up the cutters and guards,it

could take several weeks before optimal shaving

performance is restored.

4Remove the hairs.

5Put the retaining plate back into the

shaving unit.

BCause 3:Shaving heads are damaged or worn.

6Remove the retaining plate.

ENGLISH10

7Remove the old shaving heads from the

shaving unit and replace them with new

ones.

Damaged or worn shaving heads (cutters and

guards) must only be replaced by the original

Philishave HQ6 Quadra Action shaving heads!

8Put the retaining plate back into the

shaving unit.

Shaver does not work when the on/off button is

pressed:

BCause:The batteries are empty.

9Recharge the batteries.

Guarantee & service

If you need service or information or if you have

a problem,please consult the worldwide

guarantee leaflet or visit ourWeb site:

www.philips.com.

ENGLISH 11

Wichtig

◗Verwenden Sie zumAufladen des Geräts nur

das mitgelieferte Steckernetzgerät HQ 6000.

◗Das Steckernetzgerät wandelt 100 bis 240Volt

in eine Betriebsspannung von 12Volt um.

C◗Achten Sie darauf,dass das Steckernetzgerät

HQ 6000 nicht nass wird.

C◗Der Rasierer arbeitet mit einer ungefährlichen

Niedrigspannung von 12Volt.Er ist

wasserdicht und kann unter fließendem

Wasser gereinigt werden.Spülen Sie ihn aber

nicht mitWasser ab,das heißer als 80 cC ist.

Ladeanzeige

C◗Aufladen

Sobald Sie beginnen die Akkus aufzuladen,

leuchtet die grüne Kontroll-Lampe kontinuierlich

auf.

C◗Akkus voll aufgeladen

Sobald die Akkus aufgeladen sind,beginnt die

grüne Kontroll-Lampe zu blinken.

Mit voll aufgeladenen Akkus können Sie sich ca.

45 Minuten rasieren.

C◗Akkus zu schwach

Wenn dieAkkus zu schwach werden,beginnt die

untere Kontroll-Lampe rot zu leuchten.Wenn Sie

den Rasierer ausgeschaltet haben,blinkt die rote

Kontroll-Lampe 4 Sekunden lang.

DEUTSCH12
