Philips HQ5430/16 Manuel utilisateur

ENGLISH 4

FRANÇAIS 13

ESPAÑOL 22

PORTUGUÊS 31

HQ5430, HQ5426

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗Store and use the appliance at a temperature

between 5cC and 35cC.

C◗Make sure the appliance and the cord do not

get wet.

Using the appliance

C1Put the appliance plug in the shaver.

2Put the mains plug in the wall socket.

Shaving

1Switch the shaver on by pushing the on/off

slide upwards.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

ENGLISH4

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips system.

3Switch the shaver off by pushing the on/off

slide downwards.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning, the Philips

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philips dealer

for information.

BThe Philips Action Clean may not be available in

all countries. Contact the Customer Care Centre in

your country about the availability of this

accessory.

ENGLISH 5

You can also clean the shaver in the following

way:

Every week: shaving unit

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

C3Press the release button and remove the

shaving unit.

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

ENGLISH6

C2Press the release button and remove the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix the sets up, it

could take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

ENGLISH 7

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

8Put the shaving unit back onto the shaver.

BYou can also clean the shaving heads with a

degreasing liquid (e.g. alcohol). If you do, lubricate

the central point of the guards with a drop of

sewing machine oil after cleaning.This prevents

wear of the shaving heads.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH8

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every 2 years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ4«Philips shaving heads only.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button and remove the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove the shaving heads and place new

ones in the shaving unit.

ENGLISH 9

C5Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

Accessories

The following accessories are available:

- HQ100 Philips Action Clean (shaving head

cleaner).

- HQ101 Philips Action Clean refill (shaving head

cleaning liquid).

- HQ110 Philips shaving head cleaner (shaving

head cleaning spray).

- HQ4«Philips shaving heads.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.

ENGLISH10

BThe shaver has not been cleaned well enough or

has not been cleaned for a long time.

◗Clean the shaver thoroughly before you

continue shaving (see chapter 'Cleaning and

maintenance').

BCause 2: long hairs are obstructing the shaving

heads.

C◗Remove the retaining frame.

C◗Clean the cutters and guards.

Do not clean more than one cutter and guard at

a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may

take several weeks before optimal shaving

performance is restored.

◗Remove the hairs with the brush supplied.

◗Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

BCause 3: the shaving heads are damaged or worn.

Replace the shaving heads every 2 years for

optimal shaving results. See chapter

'Replacement'.

ENGLISH 11

2The shaver does not work when the on/off

slide is pushed upwards.

BCause: the shaver is not connected to the mains.

Insert the mains plug into the wall socket.

ENGLISH12
