Philips HQ6853 Manuel utilisateur

ENGLISH 4

DEUTSCH 15

FRANÇAIS 27

NEDERLANDS 38

ESPAÑOL 49

ITALIANO 60

PORTUGUÊS 71

TÜRKÇE 83

HQ6853

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

◗Do not recharge the shaver in a closed pouch.

C◗Keep the appliance and the mains cord dry.

Charging

Make sure the appliance is switched off before

you start charging it.

When you charge the shaver for the first time or

after a long period of disuse, let it charge

continuously for 4 hours. Charging normally takes

approx. 1 hour.

You can also shave without charging by

connecting the shaver to the mains.

Do not leave the appliance connected to the

mains for more than 24 hours.

ENGLISH4

Charge indications

Charging

C◗As soon as you start charging the empty

shaver, the green pilot light goes on.

Battery fully charged

C◗When the battery has been fully charged, the

green pilot light starts blinking.

Battery running low

C◗When the battery is running low, the red pilot

light goes on.When you switch the shaver off,

the red pilot light blinks for 4 seconds.

Charging the appliance

Charge the appliance when the red pilot light

blinks.

Do not recharge the shaver in a closed pouch.

C1Put the appliance plug in the shaver.

ENGLISH 5

2Put the mains plug in the wall socket.

3Remove the mains plug from the wall

socket and pull the appliance plug out of

the shaver when the battery has been fully

charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 30 minutes.

Using the appliance

Shaving

1Switch the shaver on by pushing the on/off

slide to position I.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off by pushing the on/off

slide to position 0.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

ENGLISH6

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning, the Philishave

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philishave dealer

for information.

BThe Philishave Action Clean may not be available

in all countries. Contact the Customer Care Centre

in your country about the availability of this

accessory.

You can also clean the shaver in the following

way:

Every week: shaving unit and hair chamber

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

ENGLISH 7

C3Press the release button (1) and remove

the shaving unit (2).

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

ENGLISH8

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix the sets up, it

could take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

8Put the shaving unit back onto the shaver.

For extra thorough cleaning, clean the shaving

heads by putting them in a degreasing liquid (e.g.

alcohol) every six months.To remove the shaving

heads, follow steps 1 to 4 described above. After

cleaning, lubricate the central point on the inside

of the guards with a drop of sewing machine oil

to prevent wear of the shaving heads.

ENGLISH 9

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ55 Philishave Super Reflex shaving heads only.

ENGLISH10

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit.

C5Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

6Put the shaving unit back onto the shaver.

Accessories

The following accessories are available:

- HQ55 Philishave Super Reflex shaving heads.

- HQ100 Philishave Action Clean (shaving head

cleaner).

- HQ101 Philishave Action Clean refill (shaving

head cleaning liquid).

ENGLISH 11

- HQ110 Philishave shaving head cleaner (shaving

head cleaning spray).

Environment

C◗Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this you will help to

preserve the environment.

The built-in rechargeable battery contains

substances that may pollute the environment.

Always remove the battery before discarding the

appliance or handing it in at an official collection

point. Dispose of the battery at an official

collection point for batteries. If you have trouble

removing the battery, you can also take the

appliance to a Philips service centre, which will

remove the battery for you and will dispose of it

in an environmentally safe way.

Disposal of the battery

Only remove the battery if it is completely empty.

1Remove the mains plug from the wall

socket and pull the appliance plug out of

the shaver.

C2Let the shaver run until it stops, undo the

screws and open the shaver.

3Remove the battery.

ENGLISH12
