Philips AJ6200D/98 Manuel utilisateur

www.philips.com/welcome

Always there to help you

AJ6200D/98

User manual

Question?

Contact

Philips

Contents

1 Important 3

2 Your clock radio 3

What's in the box 3

Overview of the main unit 4

3 Get started 5

Connect power 5

Set time 6

Turn on 6

4 Play from iPod/iPhone 7

Compatible iPod/iPhone 7

Listen to audio from iPod/iPhone 7

Charge the iPod/iPhone 7

Adjust volume 7

5 Listen to FM radio 8

Tune to FM radio stations 8

Store FM radio stations automatically 8

Store FM radio stations manually 8

Select a preset radio station 9

6 Other features 9

Set alarm timer 9

Set sleep timer 10

Play audio from an external device 10

Adjust display brightness 11

7 Product information 11

Specications 11

8 Troubleshooting 12

9 Notice 12

3EN

1 Important

Warning

•Never remove the casing of this clock radio.

•Never lubricate any part of this clock radio.

•Never place this clock radio on other electrical

equipment.

•Keep this clock radio away from direct sunlight, naked

amesorheat.

•Make sure that you always have easy access to the

power cord, plug or adaptor to disconnect the clock

radio from the power.

• Make sure that there is enough free space

around the product for ventilation.

• The clock radio shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

clockradio(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Only use power supplies listed in the user

manual.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• The batteries should not be exposed

toexcessiveheatsuchassunshinere

or the like.

2 Your clock radio

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

What's in the box

AJ6200D

User Manual

www.philips.com/welcome

Always there to help you

Question?

Contact

Philips

4EN

Overview of the main unit

a SOURCE

• Press to select a source.(DOCK/FM/

AUDIO IN)

• Press and hold for 3 seconds to switch

to standby mode.

b SLEEP

• Set sleep timer.

c SNOOZE/BRIGHTNESS

• Snooze alarm.

• Adjust display brightness.

d Display panel

• Show current information.

e Dock for iPod/iPhone

NIOIDUA

BUZZ

KCOD

f AL1/AL2

• View alarm settings.

• Activate or deactivate alarm timer.

g VOLUME +/-

• Adjust volume.

h First Knob (HOUR/PRESET)

• Adjust hour.

• Select a preset radio station.

i Second Knob (MINUTE/TUNING)

• Adjust minute.

• Tune to an FM radio station.

• Skip to the previous or next track.

5EN

j Third Knob (SET TIME/SET RADIO/

CLOCK/SET AL1/SET AL2)

• Set time.

• Scan/store FM radio stations.

• Set alarm.

k BUZZ/FM/DOCK

• Select an alarm source for Alarm 1 and

Alarm 2.

l (5.0 V 1 A)

• Charge your iPod/iPhone through USB

cable (not included).

m AUDIO IN

• Connect an external audio device.

n FM ANT

• Improve FM reception.

3 Get started

Always follow the instructions in this chapter in

sequence.

Connect power

The unit can only be powered by supplied AC

power. Batteries are only used for alarm backup

if not connected with AC power.

Option 1:AC power

Warning

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you disconnect the AC

power, always pull the plug from the socket. Never pull

the cord.

Connect the AC power cord to the wall socket.

Tip

•To save energy, turn the unit off after use.

6EN

Option 2: Battery power

Caution

•Batteries contain chemical substances, so they should

be disposed of properly.

Note

•Batteries are not supplied with the accessories.

•bAt shows on the display when the battery level is low.

1 Open the battery compartment.

2 Insert 2 batteries (type: 1.5V LR6/AA) with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

Set time

1 Rotate the Third Knob to "SET TIME" to

activate clock setting mode.

» Hour and minute digits blinks.

2 Rotate the First Knob to adjust the hour.

3 Rotate the Second Knob to adjust the

minute.

4 Press OK on the First Knobtoconrm.

» The setting time is displayed.

5 Rotate the Third Knob to CLOCK after

setting.

» The hour and minute digits stops

blinking.

Note

•When an iPod/iPhone is connected, the clock radio

synchronizes time from the iPod/iPhone automatically.

Turn on

The clock radio turns on automatically once

your plugged in.

Switch to standby mode

Press SOURCE for 3 seconds to switch to

standby mode.

» The source indicator on the display panel

turns off.

7EN

4 Play from iPod/

iPhone

You can enjoy audio from iPod/iPhone through

this clock radio.

Compatible iPod/iPhone

The clock radio supports these iPod and iPhone

models:

Made for.

• iPod touch (5th generation)

• iPod nano (7th generation)

• iPhone 5

Listen to audio from iPod/

iPhone

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Place the iPod/iPhone in the dock.

2 Press SOURCE repeatedly to select iPod/

iPhone mode.

» The on the display panel lights up.

3 Play audio on the iPod/iPhone.

4 Rotate the Second Knob to select

previous or next track.

To remove the iPod/iPhone:

Pull the iPod/iPhone out of the dock.

Charge the iPod/iPhone

When the clock radio is connected to power,

the docked iPod/iPhone starts charging.

Adjust volume

You can adjust volume by pressing

VOLUME +/- repeatedly.

8EN

5 Listen to FM

radio

Tune to FM radio stations

Tip

•Position the antenna as far as possible from TV,VCR, or

other radiation source.

•For better reception, fully extend and adjust the

position of the antenna.

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press SOURCE repeatedly to select FM

tuner source.

» FM on the display panel lights up.

2 Rotate and hold the Second Knob for two

seconds.

» The clock radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune in to more radio

stations.

To tune to a station manually:

Rotate the Second Knob repeatedly until you

ndoptimalreception.

Store FM radio stations

automatically

Note

•You can store a maximum of 20 FM radio stations.

1 In FM mode, rotate the Third knob to SET

RADIO.

» FM begins to blink.

2 Press and hold OK on the First Knob for

three seconds.

» The clock radio stores all the available

FM radio stations, and broadcasts the

rstavailablestationautomatically.

Store FM radio stations

manually

1 In FM mode, rotate the Third Knob to

SET RADIO.

» FM begins to blink.

2 Rotate and hold the Second Knob for two

seconds.

» The last selected channel is displayed

on the display panel.

3 Rotate the First Knob again to select the

target preset position.

4 Press OK on the First Knobtoconrm.

5 Repeat steps 2-4 to store other stations.

Note

•To remove a pre-stored station, store another station

in its place.

9EN

Select a preset radio station

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press SOURCE repeatedly to select FM

tuner source.

» FM on the display lights up.

2 Rotate the First Knob repeatedly to select

a preset radio station.

6 Other features

Set alarm timer

In standby mode, you can set two alarms to ring

at different time.

Note

•Make sure that you have set the clock correctly.

1 Rotate the Third Knob to SET AL1 or SET

AL2 to activate alarm setting mode.

» The / and time digits blink.

2 Rotate the First Knob to adjust the hour.

3 Rotate the Second Knob to adjust the

minute.

4 Press OK on First Knobtoconrm.

5 Rotate the Third Knob to CLOCK after

setting.

Select alarm source

For alarm sound, you can select buzzer, your last

listened radio station, or the last played audio

on your iPod/iPhone.

Tip

•If DOCK is selected as the alarm source, yet the audio

cannot be played, buzzer will sound when alarm time

comes.

•If FM is selected as the alarm source and the DOCK is

playing under FM mode, buzzer will sound when alarm

time comes.

10EN

Activate/deactivate alarm timer

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

1 Press AL1/AL2 to view alarm settings.

» The / lights up.

2 Press AL1/AL2 again to activate or

deactivate the alarm timer.

» The / appears if alarm timer is on

and disappears if it is off.

• To stop the ringing alarm, press the

corresponding AL1/AL2.

» The alarm repeats ringing for the next

day.

Snooze the alarm

When alarm sounds, press SNOOZE.

» The alarm snoozes and repeats ringing

nine minutes later.

BUZZ

KCOD

Set sleep timer

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

This clock radio can switch to standby mode

automatically after a preset period.

• Press SLEEP repeatedly to select the sleep

timer period (in minutes).

» When the sleep timer is activated,

appears.

To deactivate the sleep timer:

• Press SLEEP repeatedly until [OFF] (off)

appears.

Play audio from an external

device

Note

•Make sure that the Third Knob switched to CLOCK

before setting.

You can listen to audio from an external device

through this clock radio.

1 Connect an audio cable to:

• the AUDIO IN socket on the clock radio.

• the headphone socket on an external device.

2 Press SOURCE repeatedly to select the

Audio-in source.

» The on the display panel lights up.

3 Play the external device (refer to its user

manual).

15 30 60 90 120

OFF

Table des matières

Autres manuels Philips Radio-réveil

Philips

Philips AJ 3630 Manuel utilisateur

Philips

Philips R7606 Manuel utilisateur

Philips

Philips TAR3306/05 Manuel utilisateur

Philips

Philips AJB3552/12 Manuel utilisateur

Philips

Philips AJ3280 - annexe 2 Manuel de service

Philips

Philips AJ3050/05 Manuel utilisateur

Philips

Philips AJ3916/79 Manuel utilisateur

Philips

Philips AJ3112 Manuel utilisateur

Philips

Philips AJ3925 - Cd Clock Radio Manuel utilisateur

Philips

Philips AJ3115/05 Manuel utilisateur

Philips

Philips Magnavox AJ 3925 Manuel utilisateur

Philips

Philips AJ3160 Manuel utilisateur

Philips

Philips AJ3230 Manuel utilisateur

Philips

Philips AJB4300 Manuel utilisateur

Philips

Philips AJ 3936 Manuel utilisateur

Philips

Philips AJ3600 Manuel utilisateur

Philips

Philips AJ6200D/12 Manuel utilisateur

Philips

Philips AJ3125 Manuel utilisateur

Philips

Philips AJ3720 Manuel du système

Philips

Philips AJ3230 Manuel utilisateur

Philips

Philips AJL305 Manuel utilisateur

Philips

Philips AJ3225 Manuel utilisateur

Philips

Philips AJ100/37B Manuel utilisateur

Philips

Philips iBoom Home Manuel utilisateur

Manuels Radio-réveil populaires d'autres marques

Denver

Denver CRQ-105 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Sony

Sony Dream Machine ICF-C763L Manuel utilisateur

Sanyo

Sanyo DMP-P6 Manuel utilisateur

RCA

RCA RPC100 Manuel utilisateur

Yamaha

Yamaha ISX-80 Manuel utilisateur

Pyle

Pyle PLMR20W Manuel utilisateur

Blaupunkt

Blaupunkt CR7BK Manuel utilisateur

HoMedics

HoMedics SS-5500-2EU Manuel utilisateur

RCA

RCA RC66i Manuel utilisateur

Versaudio

Versaudio Vers Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR8100 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manuel utilisateur

Roberts

Roberts ChronoDAB Manuel utilisateur

AEG

AEG MRC 4132 BT Manuel utilisateur

Tokai

Tokai TC-155 Manuel utilisateur

Timex

Timex T300 Manuel utilisateur
