Philips CEM1000/00 Manuel utilisateur

www.philips.com/welcome

Registre su producto y obtenga asistencia en

Registre seu produto e obtenha assistência em

CEM1000

EN Quick Start Guide

1ab

efg

bcd

ghi

5mm

5mm5mm5mm5mm

English

Overview of parts 1

These are the supplied parts needed to connect

and install this unit.

aMain unit

bSleeve

cFront panel

dTrim plate

eRubber cushion

fDisassembly tools

gScrews (4 pieces)

hStandard ISO connector

Select country/region

1Press to turn on the unit.

2Rotate to select an option:

[USA] (United States)•

[Latin] (Latin America)•

[Europe] (Western Europe)•

[ASIA](AsiaPacic)•

[Mid-East ] (Middle East)•

[Russia] (Russia)•

3Press toconrm.

Connection

For cars with ISO connectors 234

1Pull out the ISO connectors from car

dashboard and connect them to the bigger

end of the supplied standard connector.

2Connect the other end of the supplied

standard connector to the unit.

3Connecttheantennaandamplieras

illustrated, if applicable.You can connect the

caraudiototheamplierthroughRCA-TO-

RCA cables (not supplied).

Connector Connect to

1 ANTENNA Antenna

2 REAR LINE

OUT R

Rear right speaker

3 REAR LINE

OUT L

Rear left speaker

For cars without ISO connectors 4 5

1 Connecttheantennaandamplieras

illustrated, if applicable.

2Cut off the bigger end of the supplied

standard connector.

3Check the car’s wiring carefully, then connect

them to the supplied standard connector.

1 Green/black strip Left speaker (Rear)

2 White/black strip Left speaker

(Front)

3 Gray/black strip Right speaker

(Front)

4 Purple/black strip Right speaker

(Rear)

e RED Ignition key +12V DC when

ON/ACC

f BLUE Motor/electric antenna relay

controllead/Amplierrelay

control lead

g BLACK Ground

h YELLOW To the +12V car battery

which is energized at all times

4Connect the supplied standard connector to

the unit.

Mount into the dashboard 6

1If the car does not have an on-board drive or

navigation computer, disconnect the negative

terminal of the car battery.

2Remove the two screws on the top of the

unit.

3Remove the mounting sleeve with the

supplied disassembly tools.

4Install the sleeve into the dashboard and bend

thetabsoutwardtoxthesleeve.

5Place the supplied rubber cushion over the end of the mounting bolt.

6Slide the unit into the dashboard until you hear a click sound.

7Reconnect the negative terminal of the car battery.

Attach the front panel 6

1Attach the trim plate.

2Insert the right side of the panel in the chassis until it is correctly engaged.

3Press the left side of the panel until the mechanism locks it into place.

Turn on

1Press to turn on the unit.

To turn off the unit, press•for over 3 seconds.

Set clock

1Press MENU.

2Press or repeatedly until current time is displayed.

3Rotate clockwise to set hour.

4Press toconrm.

5Rotate anti-clockwise to set minute.

6Press toconrm.

View clock

1Press and hold OPTIONS repeatedly until the clock is displayed.

Listen to radio

1Press SOURCE repeatedly to select Tuner.

2Press or to select band: [FM1], [FM2], [FM3], [AM1], or [AM2].

3Press or to tune to a radio station manually.

The radio station is broadcast.•

To search for a radio station automatically, press•or for over 3 seconds.

Document order number: CEM1000_00_QSG_V3.0
