Philips CEM5000/55 Manuel utilisateur

Cadastre seu produto e obtenha suporte em

Registre su producto y obtenga asistencia en

www.philips.com/welcome

EN User manual

ES Manual del usuario

PT-BR Manual do Usuário

CEM5000

English

Contents

1 Important 4

Safety 4

Notice 4

2 Your car audio system 6

Introduction 6

What’s in the box 6

Overview of the main unit 7

Overview of the remote control 9

3 Get started 11

Install the car audio 11

Install remote control battery 15

Turn on 15

Set clock 15

4 Listen to radio 16

Tune to a radio station 16

Store radio stations in memory 16

Tune to a preset station 16

Play with RDS 16

5 Use bluetooth devices 18

Pairing bluetooth devices 18

Make a call 18

Call transfer 19

Terminate call 19

Play audio ﬁles from bluetooth devices 19

6 Play audio ﬁles 20

Play a disc 20

Play from USB/SD/SDHC device 20

Control play 21

Search for an MP3/WMA track 21

View play information 21

Intro play 21

Shufﬂe play 21

Repeat play 22

Connect external sound source 22

7 Adjust sound 23

Adjust volume 23

Mute 23

Turn DBB and subwoofer on/off 23

Select preset equalizer 23

Other sound settings 23

8 Adjust system settings 24

BT mode 24

Language 24

LCD contrast 24

Dimmer 24

Blackout 24

Beep 24

Demo 24

Reset 25

9 Additional information 26

Detach the front panel 26

Replace fuse 26

Remove the unit 26

10 Product information 27

11 Troubleshooting 28

About Bluetooth device 28

12 Glossary 30

Notice

The making of unauthorized copies of

copy-protected material, including computer

programs, ﬁles, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a

double insulation system.

Recycling

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When you see the crossed-out wheel bin

symbol attached to a product, it means the

product is covered by the European Directive

2002/96/EC:

1 Important

Safety

Read and understand all instructions•

before you use your apparatus. If damage

is caused by failure to follow instructions,

the warranty does not apply.

This apparatus is designed for negative•

ground (earth) 12 V DC operation only.

To ensure safe driving, adjust the volume•

to a safe and comfortable level.

Improper fuses can cause damage or•

ﬁre. When you need to change the fuse,

consult a professional.

Use only the supplied mounting hardware•

for a safe and secure installation.

To avoid short circuit, do not expose the•

apparatus, remote control or remote

control batteries to rain or water.

Never insert objects into the ventilation•

slots or other openings on the apparatus.

Clean the apparatus and frame with a•

soft, damp cloth. Never use substances

such as alcohol, chemicals or household

cleaners on the apparatus.

Never place any objects other than discs•

into the apparatus.

Never use solvents such as benzene,•

thinner, cleaners available commercially,

or anti-static sprays intended for discs.

Visible and invisible laser radiation when•

open. Avoid exposure to beam.

Risk of damage to the apparatus screen!•

Never touch, push, rub or strike the

screen with any object.

Caution

Use of controls or adjustments or•performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

Speciﬁcations are subject to change without

notice. Trademarks are the property of

Koninklijke Philips Electronics N.V. or their

respective owners. Philips reserves the right

to change products at any time without being

obliged to adjust earlier supplies accordingly.

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products. The correct

disposal of your old product helps prevent

potentially negative consequences on the

environment and human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed of with normal household

waste.

Please inform yourself about the local rules on

separate collection of batteries. The correct

disposal of batteries helps prevent potentially

negative consequences on the environment

and human health.

This product complies with the radio

interference requirements of the European

Community.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and

old equipment.

Any changes or modiﬁcations made to this

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

2009 © Koninklijke Philips Electronics N.V. All

rights reserved.

English

345

1110

2 Your car audio

system

Congratulations on your purchase, and

welcome to Philips!To fully beneﬁt from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With the in-car audio system, you can enjoy

your drive while you listen to:

FM or AM (MW) radio•

Audio from CD or MP3 disc•

Audio from your mobile phone•

Audio from a USB drive•

Audio from a SD/SDHC card•

Audio from external devices•

Besides, you can make a call, answer and hang

up a call on the audio system.

What’s in the box

Check and identify the contents of your

package:

aCar audio system

bRemote control

cRubber cushion

dScrew (4 pieces)

eDisassembly tool (2 pieces)

fFront panel

gTrim plate

hCarrying case for front panel

iUser manual

jQuick start guide

kStandard connector

Select tuner band.•

Select MP3/WMA folder.•

Scroll up menu.•

e/OK/MUTE

Turn the unit on or off.•

Conﬁrm selection.•

Mute or restore the volume.•

Overview of the main unit

aPhone call button with LED indicator

Green button: press to answer•

phone; Press and hold to transfer

call.

Red button: terminate call.•

bMENU

Access system menu.•

cSOURCE

Select audio source.•

SUB-W

fhi

wsrqponmlk

SUB-W

fhi

wsrqponmlk

English

rSEARCH

Store radio stations automatically.•

Search MP3/WMA•

sDBB/SUB-W

Turn on or off Dynamic Bass Boost•

(DBB) sound.

Press and hold to turn on or off•

subwoofer.

Tune to a radio station•

Skip track.•

Fast forward playback.•

Select tuner band.•

Scroll down menu.•

Select MP3/WMA folder.•

Tune to a radio station•

Skip track.•

Fast backward playback.•

wEQ/Audio

Press to select equalizer (EQ) setting.•

Press and hold to access audio•

setting menu.

xPanel power connection

yDisc slot

Eject disc.•

{RESET

Restore default settings•

|SD card slot

fRotary encoder knob

Adjust volume.•

Adjust system settings under•

different menus.

Return to previous menu.•

hDisplay panel

Unlock the panel•

jUSB socket

kMP3 LINK

External device socket•

l5/6

Select preset station 5/6.•

Select preset 5th/6th speed dial•

number.

mSHUF, 4

Set shufﬂe play mode.•

Select preset station 4.•

Select preset 4th speed dial number.•

n3, REP

Set repeat play mode.•

Select preset station 3.•

Select preset 3rd speed dial number.•

oINTRO, 2

Turn intro play on or off.•

Select preset station 2.•

Select preset 2nd speed dial number.•

p1,

Start play•

Pause or resume play.•

Select preset station 1.•

Select preset 1st speed dial number.•

qDISP/DIM

Display radio frequency, clock and•

radio program type (if available).

Display track, elapsed time, artist,•

alburm, title, folder, ﬁle and clock.

Press and hold to access illuminate•

dimmer settings.

dNumeric pad

Enter phone number.•

e*/EQ

Input symbol• *.

Select EQ setting.•

f1,

Start play.•

Pause or resume play.•

Select preset station 1.•

Select preset 1st quick dial number.•

gSHUF, 4

Set shufﬂe play mode.•

Select preset station 4.•

Select preset 4th quick dial number.•

h/OK

Mute or restore volume.•

Conﬁrm selection.•

Select tuner band.•

Scroll up/down menu.•

Select MP3/WMA folder.•

Store radio stations automatically.•

Brows ﬁles or folders.•

kSOURCE

Select audio source.•

lVOLUME +/-

Adjust volume.•

Terminate call•

n/TOP

Return to previous/top menu.•

oMENU

Access system menu.•

pAUDIO

Access audio setting menu.•

qINFO

Display playback information.•

Overview of the remote

control

Tune to a radio station•

Skip track.•

Fast backward/forward playback•

Turn the unit on or off.•

Answer phone.•

Dial number.•

Transfer phone call.•

English

r#/SUB-W

Input symbol #. Turn on or off•

subwoofer.

sINTRO, 2

Turn intro play on or off.•

Select preset station 2.•

Enter phone number.•

Select preset 2nd quick dial number.•

t3, REP

Set repeat play mode.•

Select preset station 3.•

Enter phone number.•

Select preset 3rd quick dial number.•

u0+/DBB

Enter phone number.•

Turn on or off Dynamic Bass Boost•

(DBB) sound.

Input symbol• +.

Note on the power supply lead (yellow)

When you connect other devices to this•

apparatus, ensure that the rating of the

car circuit is higher than the total fuse

value of all the connected devices.

Notes on speaker connection

Never connect speaker wires to the•

metal body or chassis of the car.

Never connect speaker wires with stripes•

to one another.

Overview of parts

These are the supplied parts needed to

connect and install this unit.

aIn-car audio system and sleeve

bStandard connector

cScrews (4 pieces)

dDisassembly tools

eRubber cushion

fFront panel

gTrim plate

34 5

3 Get started

Caution

Use the controls only as stated in this user•manual.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of your apparatus.The

model number and serial number are on the

bottom of your apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Install the car audio

These instructions are for a typical installation.

However, if your car has different requirements,

make the corresponding adjustment. If you have

any questions regarding installation kits, consult

your Philips car audio dealer.

Caution

This unit is designed for negative ground•(earth) 12 V DC operation only.

Always install this unit in the car dashboard.•Other locations can be dangerous as the rear

of the unit heats up during use.

To avoid short-circuit: before you connect,

•ensure that the ignition is off.

Ensure that you connect the yellow and red•power supply leads after all other leads are

connected.

Ensure that all loose leads are insulated with

•electrical tape.

Ensure that the leads do not get caught under

•screws orin parts that will move (e.g. seat rail).

Ensure that all ground (earth) leads are run to•a common ground (earth) point.

Use only the supplied mounting hardware for a

•safe and secure installation.

Improper fuses can cause damage or ﬁre.

•When you need to change the fuse, consult a

professional.

English

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Récepteur de voiture

Philips

Philips CEM5000/00 Manuel utilisateur

Philips

Philips CarStudio CEM2101/00 Manuel utilisateur

Philips

Philips CarStudio CEM2101/12 Manuel utilisateur

Philips

Philips CarStudio CEM5100 Manuel utilisateur

Philips

Philips CEM151 Manuel utilisateur

Philips

Philips CEM250X/78 Manuel utilisateur

Philips

Philips CEM3000X/78 Manuel utilisateur

Philips

Philips CE130 Manuel utilisateur

Philips

Philips ce133 Manuel utilisateur

Philips

Philips CID3692 Manuel utilisateur

Philips

Philips CEM2100 Manuel utilisateur

Philips

Philips CEM220X/78 Manuel utilisateur

Philips

Philips CEM220/93 Manuel utilisateur

Philips

Philips CE152/10 Manuel utilisateur

Philips

Philips CEM3000B/05 Manuel utilisateur

Philips

Philips CEM2000/00 Manuel utilisateur

Philips

Philips CEM1000 Manuel utilisateur

Philips

Philips CE133G Manuel utilisateur

Philips

Philips CarStudio CEM3100 Manuel utilisateur

Philips

Philips CE150 Manuel utilisateur

Philips

Philips CE152 Manuel utilisateur

Philips

Philips CID2680 Manuel utilisateur

Philips

Philips CMB2102/55 Manuel utilisateur

Philips

Philips CED230 Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Pioneer

Pioneer DEH-P645R Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Sony

Sony MEX-1HD - Audio Library System Manuel utilisateur

Pioneer

Pioneer DVH-P500UB Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

Sony

Sony CDX-4160 - Cd Receiver Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur
