Philips AC3821 Manuel utilisateur

EN User manual 1

KK Қолданушының нұсқасы 21

RU Руководство пользователя 41

76 FA

90 AR

4241 210 95971

Control buttons

Display panel

AC3821

3S 3S

3 4 5 6

11 12 13 14

171615

2 hours

23 24 25 26

27 28 29 30

31 32 33 34

35 36 37 38

39 40 41 42

43 44 45 46

47 48 49 50

51 52 53

English

Contents

1 Important 2

Safety 2

2 You air purier 5

Product overview (g a) 6

Controls Overview (g b) 6

3 Get started 7

Installing the NanoProtect

lter 7

Preparing for humidication 7

4 Use the appliance 8

Understanding the air

quality light 8

Switching on and o 8

Setting the humidity level 8

Switching the operation

mode 9

Using the light on/o function 9

Switching the display mode 9

Changing the Auto mode

setting 10

Changing the fan speed 10

Setting the timer 10

Setting the child lock 11

Water level 11

5 Cleaning 11

Cleaning schedule 11

Cleaning the body of the

appliance 12

Cleaning the air quality

sensor 12

Cleaning the water tank,

water tray and NanoCloud

rotary humidication wick 12

Cleaning the pre-lter 13

Descaling the NanoCloud

rotary humidication wick 13

6 Replace the lter and wick 14

Understanding the healthy

air protect lock 14

Replacing the NanoProtect

lter 14

Replacing the NanoCloud

rotary humidication wick 15

Replacing the anti-bacteria

cartridge 16

7 Troubleshooting 17

8 Guarantee and service 19

Order parts or accessories 19

9 Notices 19

Electromagnetic elds (EMF) 19

Recycling 20

2EN

1 Important

Safety

Read this user manual carefully before

you use the appliance, and save it for

future reference.

Danger

• Do not let water or any

other liquid or flammable

detergent enter the

appliance to avoid electric

shock and/or a fire

hazard.

• Do not clean the

appliance with water,

any other liquid, or a

(flammable) detergent to

avoid electric shock and/

or a fire hazard.

• Do not spray any

flammable materials

such as insecticides or

fragrance around the

appliance.

• The water in the water

tank is not suitable for

drinking. Do not drink this

water and do not use it to

feed animals or to water

plants. When you empty

the water tank, pour the

water down the drain.

Warning

• Check if the voltage

indicated on the

side of the appliance

corresponds to the local

power voltage before you

connect the appliance.

• If the power cord is

damaged, you must have

it replaced by Philips, a

service center authorized

by Philips, or similarly

qualified persons in order

to avoid a hazard.

• Do not use the appliance

if the plug, the power

cord, or the appliance

itself is damaged.

• This appliance can be

used by children aged

from 8 years and above

and persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved.

English

• Cleaning and user

maintenance shall not be

made by children without

supervision.

• Children should be

supervised to ensure that

they do not play with the

appliance.

• Do not block the air inlet

and outlet, e.g. by placing

items on the air outlet or

in front of the air inlet.

Caution

• This appliance is not

a substitute for proper

ventilation, regular

vacuum cleaning, or use

of an extractor hood or

fan while cooking.

• If the power socket used

to power the appliance

has poor connections,

the plug of the appliance

becomes hot. Make

sure that you plug the

appliance into a properly

connected power socket.

• Always place and use the

appliance on a dry, stable,

level, and horizontal

surface.

• Leave at least 20cm free

space behind and on both

sides of the appliance

and leave at least 30cm

free space above the

appliance.

• Do not place anything on

top of the appliance.

• Do not place the

appliance directly below

an air conditioner to

prevent condensation

from dripping onto the

appliance.

• Make sure all filters

are properly installed

before you switch on the

appliance.

• Only use the original

Philips filters specially

intended for this

appliance. Do not use any

other filters.

• Avoid knocking against

the appliance (the air inlet

and outlet in particular)

with hard objects.

• Do not insert your fingers

or objects into the air

outlet or the air inlet to

prevent physical injury

or malfunctioning of the

appliance.

4EN

• Do not use this appliance

when you have used

indoor smoke-type insect

repellents or in places

with oily residues, burning

incense, or chemical

fumes.

• Do not use the appliance

near gas appliances,

heating devices or

fireplaces.

• Always unplug the

appliance after use

and before filling water,

cleaning, or carrying out

other maintenance.

• Do not use the appliance

in a room with major

temperature changes.

• To prevent interference,

place the appliance

at least 2m away from

electrical appliances that

use airborne radio waves

such as TVs, radios, and

radio-controlled clocks.

• When the appliance is

not used for a long time,

bacteria may grow on the

filters. Check the filters

after a long period of

disuse. If the filters are

very dirty, replace them

(see the chapter "Replace

the filter and wick").

• The appliance is only

intended for household

use under normal

operating conditions.

• Do not use the appliance

in wet surroundings or in

surroundings with high

ambient temperatures,

such as the bathroom,

toilet, or kitchen.

• The appliance does

not remove carbon

monoxide (CO) or

radon (Rn). It cannot be

used a safety device in

case of accidents with

combustion processes

and hazardous chemicals.

• Only fill the water tank

with cold tap water. Do

not use ground water or

hot water.

• Do not put any substance

other than water in the

water tank. Do not put

fragrance in the water

tank.

• If you do not use the

humidification function

for a long time, clean

the water tank and

NanoCloud rotary

humidification wick tray,

and air dry the NanoCloud

rotary humidification wick.

English

• If you need to move the

appliance, disconnect the

appliance from the power

supply first. Then empty

or remove the water tank

and water tray. Carry the

appliance horizontally by

the handles on both sides

of the appliance.

• Unplug the appliance

during filling and cleaning.

2 You air purifier

Congratulations on your purchase, and

welcome to Philips!

To fully benefit from the support that

Philips offers, register your product at

www.Philips.com/welcome.

The Philips air purifier brings fresh,

humidified air to your house for the

health of your family. It offers you

advanced evaporation system with

NanoCloud technology, using a special

humidification filter which adds H2O

molecules to the dry air, and produces

healthy humid air without formation

of water mist. Its humidification filter

retains bacteria, calcium and other

particles from the water. It delivers only

pure humidified air in your home. No

more dry air in the winter season or

from the air conditioning.

Read this user manual carefully before

you use the appliance, and save it for

future reference.

6EN

Controls Overview

(fig b)

Control buttons

Power on/off button

Child lock button

Auto mode button

Fan speed button

Humidity setting button

Light dimming button

2-in-1 mode on/off button

Timer/Reset button

Display panel:

Sleep mode

Auto mode

Allergen mode

Purification ONLY mode

2-in-1 mode

Filter replacement alert

Water refill alert

Pre-filter and wick cleaning alert

PM2.5 display

Indoor Allergen Index display

Product overview (fig a)

AControl panel

BWater tank

CAnti-bacteria cartridge

DWick support

EWater tray

FOmni wheels

GWick wheel

HNanoCloud rotary humidification

wick (FY3435)

IBack side cover

JPre-filter

KNanoProtect filter Series 3

(FY2422)

LNanoProtect filter Active Carbon

(FY2420)

MAir outlet

English

Preparing for

humidification

1 Pull out the water tank (fig j).

2 Lift the water tray upwards and pull

it out horizontally (fig k).

3 Remove all packaging material

of the NanoCloud rotary

humidification wick (fig l).

Note

• The humidification wick has been

assembled on the wick wheel upon

purchase.

4 Place the wick wheel on the wick

support (fig m).

Note

• When placing the wick wheel on the

wick support, make sure that the

projections on the wick wheel falls

into the corresponding grooves.

5 Place the water tray back into the

appliance (fig n).

6 Turn the top cap of the water tank

anti-clockwise to unscrew it

(fig o).

7 Fill the water tank with cold tap

water (fig p).

8 Turn the top cap clockwise to tightly

lock it onto the water tank (fig q).

9 Place the water tank back into the

appliance (fig r).

3 Get started

Installing the

NanoProtect filter

The appliance comes with the

NanoProtect filter fitted inside. Remove

the packaging of the filter before using

the appliance and place it back into the

appliance described as follows:

Note

• Make sure that the side with the tag

is pointing towards you.

1 Pull the top part of the back panel

towards you to release it from the

appliance (fig c).

2 Press the two clips down and pull

the pre-filter towards you (fig d).

3 Remove the NanoProtect filter from

the appliance (fig e).

4 Remove all packaging materials of

the NanoProtect filter (fig f).

5 Place the NanoProtect filter back

into the appliance (fig g).

6 Put the pre-filter back into the

appliance, mount the pre-filter onto

the bottom of the appliance first,

and then push the clips on the top

of pre-filter against the appliance

(fig h).

7 To reattach the back cover, mount

the panel onto the bottom of the

appliance first, and then push

the top of the panel against the

appliance (fig i).

8EN

4 Use the

appliance

Understanding the air

quality light

IAI

level

Air quality

light color

Air quality

level

1-3 Blue Good

4-6 Blue-Purple Fair

7-9 Purple-Red Poor

10-12 Red Very poor

The air quality light automatically goes

on when the appliance is switched on,

and lights up all colors in sequence.

In a short time the air quality sensors

select the color that corresponds to the

ambient air quality.

Switching on and off

1 Put the plug in the power socket.

»The appliance beeps.

2 Touch to switch on the

appliance.

»The appliance operates under

the 2-in-1 mode by default with

displayed on the screen.

»When the appliance is warming

up, " " displays on the

screen. After measuring the

particulate matter only in the

air, the appliance shows the IAI

level and operates in the auto

mode by default.

»After measuring the air

quality for approximately

30 seconds, the air quality

sensor automatically selects

the appropriate air quality light

color.

3 Touch and hold for 3 seconds to

switch off the appliance.

Note

• After the appliance is switched

off by the on/off button , if the

plug is still in the power socket, the

appliance will operate under the

previous settings when it is switched

on again.

Setting the humidity

level

1 Touch the humidity button

repeatedly to set the desired air

humidity to 40%, 50%, 60% or " "

(fig s).

Note

• When the humidity level " " is

chosen, the appliance will keep

humidifying the room until the

ambient humidity level reaches

70%RH.

• When the target humidity level is

reached, the wick wheel will stop

rotating. It will start rotating again

when the humidity drops below the

target level.

• If you want to increase the humidity

level quickly, you can select a

higher fan speed.

Table des matières

Langues :

Autres manuels Philips Purificateur d'air

Philips

Philips AC3737 Manuel utilisateur

Philips

Philips AC2958 Manuel utilisateur

Philips

Philips AC2889/90 Manuel utilisateur

Philips

Philips AC2885 Manuel utilisateur

Philips

Philips AC1215 Manuel utilisateur

Philips

Philips 2000i Series Manuel utilisateur

Philips

Philips AC0817 Manuel utilisateur

Philips

Philips 3000i Series Manuel utilisateur

Philips

Philips AC5665 Manuel utilisateur

Philips

Philips 2000i Series Manuel utilisateur

Philips

Philips AC4091 Manuel utilisateur

Philips

Philips AC1758 Manuel utilisateur

Philips

Philips HR4345/00 Manuel utilisateur

Philips

Philips Air Performer AFM765 Manuel utilisateur

Philips

Philips AC3259/10 Manuel utilisateur

Philips

Philips AC0830/10 Manuel utilisateur

Philips

Philips AC1215/10 Manuel utilisateur

Philips

Philips AC4081 Manuel utilisateur

Philips

Philips 1000i Series Manuel utilisateur

Philips

Philips MicroCube AC5659/10 Manuel utilisateur

Philips

Philips 600 Series Manuel utilisateur

Philips

Philips AC3259/30 Manuel utilisateur

Philips

Philips AC4001 Manuel utilisateur

Philips

Philips AC4025/10 Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Sharp

Sharp FU-40SE Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur

vollara

vollara Air & Surface Pro+ Manuel utilisateur
