Operating Instructions

BP 805 227 BE (0106) 1

Inline Valve

pneumatically actuated

bellows sealed

with position indicator and pilot valve

DVB 016–040 PX

2BP 805 227BE (0106) DVB 16–40PX.bet

In all communications with Pfeiffer Vacuum, please specify the information on the

product nameplate. For convenient reference copy that information into the space

provided below.

Pfeiffer Vacuum, D - 35614 Asslar

Typ:

No:

F-No:

Nominal voltage

This document applies to products with the following part numbers:

DN 16 ISO-KF DN 25 ISO-KF DN 40 ISO-KF Nominal voltage or

voltage range (pilot valve)

PFD38132 PFD48132 PFD58132 24 VDC (+/-10%)

PFD38232 PFD48232 PFD58232 24 VAC (+/-10%)

PFD38432 PFD48432 PFD58432 90–126 VAC / 50-60 Hz

PFD38532 PFD48532 PFD58532 180–253 VAC / 50-60 Hz

The part number can be taken from the product nameplate.

If not indicated otherwise in the legends, the illustrations in this document cor-

respond to the valve with the vacuum connection DN 25 ISO–KF. They apply to

valves with other vacuum connections by analogy.

We reserve the right to make technical changes without prior notice.

All dimensions are indicated in mm.

The inline valves are used as shut-off and venting devices for vacuum

applications.

Product Identification

Validity

Intended Use

BP 805 227BE (0106) DVB 16–40PX.bet 3

Contents

Product Identification 2

Validity 2

Intended Use 2

1 Description 4

1.1 Overview 4

1.2 Functional Principle 4

2 Safety 5

2.1 Symbols Used 5

2.2 General Safety Instructions 5

2.3 Liability and Warranty 5

3 Technical Data 6

4 Installation 8

4.1 Vacuum Connection 8

4.2 Compressed Air Connection 9

4.2.1 Compressed Air Inlet 10

4.2.2 Compressed Air Outlet 11

4.3 Power Connection 11

5 Operation 14

6 Deinstallation 15

6.1 Power Connection 15

6.2 Compressed Air Connection 16

6.3 Vacuum Connection 17

7 Maintenance and Repair 18

7.1 Disassembling the Product 19

7.2 Checking and Cleaning the Parts 29

7.3 Reassembling the Product 30

8 Spare Parts 40

9 Returning the Product 42

10 Disposal 42

Declaration of Contamination 43

4BP 805 227BE (0106) DVB 16–40PX.bet

1 Description

Vacuum connection

DN 16–40 ISO-KF

Position indication

(visual)

Position indicator

(electrical)

Connector

(enclosed)

Pilot valve

Pneumatic

actuator

Compressed air

outlet

Compressed air

inlet

Instant push-in

fittings (enclosed)

1x 2x

When the pilot valve is activated, the inline valve is opened by the pneumatic

actuator. The visual position indicator becomes visible and the electrical position

indicator "valve open" is activated.

Pneumatic actuator

for opening the valve

Pilot valve

activated

Position indicator

"valve open"

activated

Position indicator

visible

Compressed air:

outlet

inlet

When the pilot valve is deactivated, the inline valve is closed by the pressure

spring. The visual position indicator is no longer visible and the electrical position

indicator "valve closed" is activated.

Pilot valve

not activated

Compressed air:

outlet

inlet

Bellows

sealing the valve

Position indicator

"valve closed"

activated

Pressure spring

for closing the valve

Position indicator

invisible

Pneumatic

actuator

1.1 Overview

1.2 Functional Principle

Opening action

Closing action

BP 805 227BE (0106) DVB 16–40PX.bet 5

2 Safety

DANGER

Information on preventing any kind of physical injury.

WARNING

Information on preventing extensive equipment and environmental damage.

Caution

Information on correct handling or use. Disregard can lead to malfunctions or

minor equipment damage.

→See page ...

•=Adhere to the applicable regulations and take the necessary precautions for

the process media used.

Consider possible reactions between the materials (→7) and the process

media.

•=Adhere to the applicable regulations and take the necessary precautions for all

work you are going to do and consider the safety instructions in this document.

•=Before beginning to work, find out whether any vacuum components are con-

taminated. Adhere to the relevant regulations and take the necessary precau-

tions when handling contaminated parts.

Communicate the safety instructions to all other users.

Pfeiffer Vacuum assumes no liability and the warranty becomes null and void if

end-user or third parties

•=disregard the information in this document

•=use the product in a non-conforming manner

•=make any kind of interventions (modifications, alterations etc.) on the product

•=use the product with accessories and options not listed in the corresponding

product documentation.

The end-user assumes the responsibility in conjunction with the process media

used.

2.1 Symbols Used

2.2 General Safety

Instructions

2.3 Liability and Warranty

6BP 805 227BE (0106) DVB 16–40PX.bet

3 Technical Data

Connection

Nominal voltage

Power

Duty cycle

Nominal diameter

soldered joints

see product nameplate

1 W

100%

0.42

Connection

Rating soldered joints

250 VAC / 25 VA / 0.1 A

50 VDC / 12.5 W / 0.25 A

Connection flange DN 16 ISO-KF DN 25 ISO-KF DN 40 ISO-KF

Actuation opening: pneumatic

closing: by pressure spring

Tube connection

Pressure range ø4 mm or ø6 mm

3 ... 7 bar overpressure

Piston displacement 5.5 cm312.1 cm326.2 cm3

Stroke of valve plate 5 mm 10 mm 14 mm

Conductance 1) 2.5 l/s 8 l/s 20 l/s

Switching frequency2)

Opening time 2)

Closing time 2)

100 / min

100 ms

200 ms

100 / min

110 ms

290 ms

75 / min

250 ms

500 ms

Cycle life 3) 10 million

Tightness 1×10-9mbar l/s

Pressure range min. 1×10-8mbar

Pressure range max. (abs.) 4 bar 2.5 bar

In closing direction

In opening direction

Opens to a pressure

difference ∆p 4)

4 bar

2 bar

4 bar

2 bar

1.5 bar

2 bar

Ambiance

Bakeout

stainless steel body

actuator

pilot valve

0 °C ... 50 °C

150 °C

50 °C

Type of protection

Protection class IP 50 according to DIN 40 050

Installation angle

Flow direction any

any

Pilot valve

Electrical position indicator

Vacuum connection

Compressed air supply

Pressure difference ∆p

Temperatures

BP 805 227BE (0106) DVB 16–40PX.bet 7

Stainless steel body

Bellows / valve plate

Pressure spring

DN 16+25 ISO-KF

DN 40 ISO-KF

Seals

Shell

Cylinder unit

Protective lid

Packing material

1.4301

1.4541 / 14301

1.4301

1.1200

FPM

PBTP

carton box, PE, PU

Stainless steel body 0.44 kg 0.9 kg 1.52 kg

1) For air with molecular flow

2) With pressure difference ∆p=0 and compressed air= 5 bar (overpressure)

3) Cycles without expendable parts (seals) and under clean operating conditions

4) Compressed air = 5 bar (overpressure)

DN 16 ISO-KF

DN 25 ISO-KF

DN 40 ISO-KF

135.9

157.4

177

108.9

128.9

147.8

36.4

92.5

31.5

45.5

100

130

DN F G

100

108

120

Materials

Weight

Dimensions

8BP 805 227BE (0106) DVB 16–40PX.bet

4 Installation

Skilled personnel

The vacuum connection may only be established by persons who

have suitable technical training and the necessary experience or who

have been instructed by the end-user of the product.

DANGER

Caution: overpressure in the vacuum system >1bar

Injury caused by released parts and harm caused by escaping

process gases can result if clamps are opened while the vacuum

system is pressurized.

Do not open any clamps while the vacuum system is pressurized. Use

the type clamps which are suited to overpressure.

Caution

Caution: dirt sensitive area

Touching the product or parts thereof with one's bare hands increases

the desorption rate.

Always wear clean, lint-free gloves and use clean tools when working

in this area.

Caution

Caution: vacuum component

Dirt and damages impair the function of the vacuum component.

When handling vacuum components, take appropriate measures to

ensure cleanliness and prevent damages.

Keep the lids.

4.1 Vacuum Connection

Personnel qualifications

Overpressure 1 bar

Dirt sensitive area

Handling of vacuum compo-

nents

Protective lids

BP 805 227BE (0106) DVB 16–40PX.bet 9

Remove the protective lids and install the valve to the vacuum system by means of

the small flange fittings.

Any installation angle and flow direction may be chosen.

Seal with

centering ring

Clamp

ISO-KF connection

flange Protective lid

Skilled personnel

The compressed air connection may only be established by persons

who have suitable technical training and the necessary experience or

who have been instructed by the end-user of the product.

Caution

Specifications for the compressed air:

•=free of particles >5 µm

•=3 ... 7 bar overpressure

•=dry, free of oil or containing oil (Keep using the same quality).

If using compressed air which contains oil, dispose of it in accordance

with the relevant regulations.

Caution

The plastic tube must meet the following specifications:

•=bursting pressure ≥10 bar overpressure

•=material: PA soft or PU.

Caution

To ensure leak tightness of the instant push-in fitting

•=cut the plastic tube square

•=make sure the outside of the plastic tube is not damaged.

Vacuum connection

4.2 Compressed Air

Connection

Personnel qualifications

Specifications for compressed

air

Specifications for plastic tube

Tightness of connection

10 BP 805 227BE (0106) DVB 16–40PX.bet

Caution

Caution: plastic thread

The plastic thread is damaged by tilting or overturning the instant

push-in fitting.

•=use the enclosed instant push-in fitting (with extra-long thread)

only.

•=screw in the instant push-in fitting without tilting it and without

exceeding the tightening torque of 0.5 Nm.

For connection of a ø6 mm plastic tube, exchange the instant push-in fitting.

Compressed air

outlet Compressed air

inlet

Tightening torque 0.5 Nm

Install ø6 fitting.

Unscrew ø4 fitting.

Push the tube into the instant push-in fitting until the mechanical stop is reached.

Check that it is correctly mounted by slightly pulling.

Compressed air

outlet Compressed air

inlet

Plastic tube

Plastic threads

4.2.1 Compressed Air Inlet

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Pfeiffer Vacuum Unité de contrôle

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 256 A Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVB Series Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum AVA 016 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVB 016 PA Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVL 063 P Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVA 016 H Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 500 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVB 016 Series Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVL 016 P Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum DualGauge TPG 262 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 361 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum DCU 002 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVB Series Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum HPU 001 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum RVG 050 C Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVB 16 P A Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum UVH 040 CU Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum UVH 016 VI Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum OmniControl Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum N Series Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum TPG 500 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVR 116 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum PM Z01 295 Manuel utilisateur

Pfeiffer Vacuum

Pfeiffer Vacuum EVI 105 PI Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
