BALL VALVE
Valve
Dear customer,
Thank you for choosing a Pfeiffer Vacuum product. Your new Pfeiffer Vacuum valves should
support you in your individual application with full performance and without malfunctions. The
name Pfeiffer Vacuum stands for high-quality vacuum technology, a comprehensive and
complete range of top-quality products and first-class service. With this expertise, we have
acquired a multitude of skills contributing to an efficient and secure implementation of our
product.
Knowing that our product must not interfere with your actual work, we are convinced that our
product offers you the solution that supports you in the effective and trouble-free execution of
your individual application.
Please read these operating instructions before putting your product into operation for the
first time. If you have any questions or suggestions, please feel free to contact info@pfeiffer-
vacuum.de.
Further operating instructions from Pfeiffer Vacuum can be found in the Download Center on
our website.
Disclaimer of liability
These operating instructions describe all models and variants of your product. Note that your
product may not be equipped with all features described in this document. Pfeiffer Vacuum
constantly adapts its products to the latest state of the art without prior notice. Please take
into account that online operating instructions can deviate from the printed operating
instructions supplied with your product.
Furthermore, Pfeiffer Vacuum assumes no responsibility or liability for damage resulting from
the use of the product that contradicts its proper use or is explicitly defined as foreseeable
misuse.
Copyright
This document is the intellectual property of Pfeiffer Vacuum and all contents of this
document are protected by copyright. They may not be copied, altered, reproduced or
published without the prior written permission of Pfeiffer Vacuum.
We reserve the right to make changes to the technical data and information in this document.
2/28
Table of contents
1 About this manual 5
1.1 Validity 5
1.1.1 Applicable documents 5
1.1.2 Products concerned 5
1.2 Target group 5
1.3 Conventions 5
1.3.1 Instructions in the text 5
1.3.2 Pictographs 6
1.3.3 Abbreviations 6
1.4 Trademark proof 6
2 Safety 7
2.1 General safety information 7
2.2 Safety instructions 7
2.3 Safety precautions 8
2.4 Limits of use of the product 8
2.5 Proper use 9
2.6 Foreseeable misuse 9
2.7 Personnel qualification 9
2.7.1 Ensuring personnel qualification 9
2.7.2 Personnel qualification for maintenance and repair 10
2.7.3 Advanced training with Pfeiffer Vacuum 10
3 Product description 11
3.1 Function 11
3.2 Scope of delivery 11
3.3 Identifying the product 11
3.3.1 Product types 12
3.3.2 Product features 12
4 Transportation and Storage 13
4.1 Transport 13
4.2 Storage 13
5 Installation 14
5.1 Preparatory work 14
5.2 Mounting orientation 14
5.3 Mounting the valve 14
6 Operation 15
7 Maintenance 16
7.1 General maintenance information 16
7.2 Replacing O-ring seal 16
7.3 Replacing or adding pilot valve 17
8 Decommissioning 18
9 Recycling and disposal 19
9.1 General disposal information 19
10 Malfunctions 20
11 Service solutions by Pfeiffer Vacuum 21
12 Spare parts - Ball valves 23
13 Technical data and dimensions 24
13.1 General 24
Table of contents
3/28
1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
These operating instructions are a customer document of Pfeiffer Vacuum. The operating instructions
describe the functions of the named product and provide the most important information for the safe use
of the device. The description is written in accordance with the valid directives. The information in these
operating instructions refers to the product's current development status. The document shall remain
valid provided that the customer does not make any changes to the product.
1.1.1 Applicable documents
Document Reference
Declaration of conformity included with these operating instructions
1.1.2 Products concerned
This document applies to products with the following part numbers:
Part number Description
BVML-xxxxxx Models for manual ball valves
BVP-xxxxxx Models for pneumatic ball valves
1.2 Target group
These operating instructions are aimed at all persons performing the following activities on the product:
●Transportation
●Setup (Installation)
●Usage and operation
●Decommissioning
●Maintenance and cleaning
●Storage or disposal
The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
1.3 Conventions
1.3.1 Instructions in the text
Usage instructions in the document follow a general structure that is complete in itself. The required ac-
tion is indicated by an individual step or multi-part action steps.
Individual action step
A horizontal, solid triangle indicates the only step in an action.
►This is an individual action step.
Sequence of multi-part action steps
The numerical list indicates an action with multiple necessary steps.
1. Step 1
2. Step 2
3. ...
About this manual
5/28
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Abbreviations
Abbreviation Meaning in this document
BV Ball valve
CDA Clean dry air
Delta P Delta pressure
DN Nominal diameter as size description
FKM Fluoropolymer rubber
HV High vacuum
IPA Isopropyl alcohol
ISO Flange: Connection in accordance with ISO 1609 and ISO 2861
PTFE Synthetic fluoropolymer of tetrafluoroethylene
UHV Ultra-high vacuum
Tbl. 1: Abbreviations used in this document
1.4 Trademark proof
●Apiezon® is a registered trademark of M&I Materials Ltd
●Allen® is a registered trademark of Apex Brands, Inc
●Loctite® is a registered trademark of Henkel IP & Holding GmbH, Germany
About this manual
6/28
2 Safety
2.1 General safety information
The following 4 risk levels and 1 information level are taken into account in this document.
DANGER
Immediately pending danger
Indicates an immediately pending danger that will result in death or serious injury if not observed.
►Instructions to avoid the danger situation
WARNING
Potential pending danger
Indicates a pending danger that could result in death or serious injury if not observed.
►Instructions to avoid the danger situation
CAUTION
Potential pending danger
Indicates a pending danger that could result in minor injuries if not observed.
►Instructions to avoid the danger situation
NOTICE
Danger of damage to property
Is used to highlight actions that are not associated with personal injury.
►Instructions to avoid damage to property
Notes, tips or examples indicate important information about the product or about this docu-
ment.
2.2 Safety instructions
Risks during installation
WARNING
Risk of injury due to incorrect installation
Dangerous situations may arise from unsafe or incorrect handling
►Do not put hands or any other body part or objects in the valve.
WARNING
Risk of injury due to overpressure in the vacuum system > 1000 hPa
Released parts and escaped gases can result in injury.
►Do not open clamps while the vacuum system is pressurized.
►Use the clamp types that are suited for overpressure.
WARNING
Risk of injury due to overpressure in the vacuum system > 2500 hPa
KF flange connections with elastomer seals cannot withstand such pressures. Process media can
leak and cause potential damage to your health.
►Use O-rings provided with an outer centering ring.
Safety
7/28
Risks during maintenance, decommissioning and disposal
WARNING
Health hazard through poisoning from toxic contaminated components or devices
Toxic process media result in contamination of devices or parts of them. During maintenance work,
there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub-
stances causes environmental damage.
►Take suitable safety precautions and prevent health hazards or environmental pollution by toxic
process media.
►Decontaminate affected parts before carrying out maintenance work.
►Wear protective equipment.
2.3 Safety precautions
Duty to provide information on potential dangers
The product holder or user is obliged to make all operating personnel aware of dangers
posed by this product.
Every person who is involved in the installation, operation or maintenance of the product
must read, understand and adhere to the safety-related parts of this document.
Infringement of conformity due to modifications to the product
The Declaration of Conformity from the manufacturer is no longer valid if the operator
changes the original product or installs additional equipment.
●Following the installation into a system, the operator is required to check and re-evalu-
ate the conformity of the overall system in the context of the relevant European Direc-
tives, before commissioning that system.
General safety precautions when handling the product
►Observe all applicable safety and accident prevention regulations.
►Check that all safety measures are observed at regular intervals.
►Never put hands or any other object in the valve.
2.4 Limits of use of the product
Parameter Limit value
Installation orientation Product to be installed directionally, with flow indicated by a visible ar-
row
Allowable ambient humidi-
ty
0 - 95% non-condensing
Process temperature
range
20 °C - 150 °C
Heating capabilities Body can be heated up to 150 °C with optional heater kits
Maximum internal pres-
sure
1400 hPa
Maximum delta P before
opening
1400 hPa in open direction. 1400 hPa in closing direction.
Open / close speed 1.0 s to open/close
Pneumatic supply 4000 - 7000 hPa
Solenoid electrical specifi-
cations
120 V AC
24 V DC
240 V AC
24 V AC
4.5 W
Position indicators Optical: NPN
Optical: PNP
Safety
8/28
Parameter Limit value
Reliability 20,000 cycles in a clean environment
Leak rate High Vacuum: 1 x 10-7hPa l/s
Tbl. 2: Limits of use for ball valves
2.5 Proper use
►Use the valve only for isolating in a vacuum system.
►Use the valve only in closed indoor areas.
2.6 Foreseeable misuse
Improper use of the product invalidates all warranty and liability claims. Any use that is counter to the
purpose of the product, whether intentional or unintentional, is regarded as misuse, in particular:
●Use outside the mechanical and electrical application limits in accordance with the technical data
●Use with corrosive or explosive media, if this is not explicitly permitted
●Use outdoors
●Use with bare hands or with powder gloves
●Use after unauthorized technical changes (on the inside or the outside of the product)
●Use with replacement or accessory parts that are unsuitable or are not approved
2.7 Personnel qualification
The work described in this document may only be carried out by persons who have appropriate profes-
sional qualifications and the necessary experience or who have completed the necessary training as
provided by Pfeiffer Vacuum.
Training people
1. Train the technical personnel on the product.
2. Only let personnel to be trained work with and on the product when under the supervision of
trained personnel.
3. Only allow trained technical personnel to work with the product.
4. Before starting work, make sure that the commissioned personnel have read and understood
these operating instructions and all applicable documents, in particular the safety, maintenance
and repair information.
2.7.1 Ensuring personnel qualification
Specialist for mechanical work
Only a trained specialist may carry out mechanical work. Within the meaning of this document, special-
ists are people responsible for construction, mechanical installation, troubleshooting and maintenance
of the product, and who have the following qualifications:
●Qualification in the mechanical field in accordance with nationally applicable regulations
●Knowledge of this documentation
Specialist for electrotechnical work
Only a trained electrician may carry out electrical engineering work. Within the meaning of this docu-
ment, electricians are people responsible for electrical installation, commissioning, troubleshooting, and
maintenance of the product, and who have the following qualifications:
●Qualification in the electrical engineering field in accordance with nationally applicable regulations
●Knowledge of this documentation
In addition, these individuals must be familiar with applicable safety regulations and laws, as well as the
other standards, guidelines, and laws referred to in this documentation. The above individuals must
have an explicitly granted operational authorization to commission, program, configure, mark, and earth
devices, systems, and circuits in accordance with safety technology standards.
Safety
9/28
Trained individuals
Only adequately trained individuals may carry out all works in other transport, storage, operation and
disposal fields. Such training must ensure that individuals are capable of carrying out the required activi-
ties and work steps safely and properly.
2.7.2 Personnel qualification for maintenance and repair
Advanced training courses
Pfeiffer Vacuum offers advanced training courses to maintenance levels 2 and 3.
Adequately trained individuals are:
●Maintenance level 1
─Customer (trained specialist)
●Maintenance level 2
─Customer with technical education
─Pfeiffer Vacuum service technician
●Maintenance level 3
─Customer with Pfeiffer Vacuum service training
─Pfeiffer Vacuum service technician
2.7.3 Advanced training with Pfeiffer Vacuum
For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of
courses and technical trainings.
For more information, please contact Pfeiffer Vacuum technical training.
Safety
10/28
Ce manuel convient aux modèles suivants
10
Table des matières
Autres manuels Pfeiffer Vacuum Unité de contrôle
Pfeiffer Vacuum
Pfeiffer Vacuum TPG 500 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum TPG 366 MAXIGAUGE Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum PM Z01 295 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum HPU 001 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum EVA 016 H Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum OmniControl Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum RVG 050 C Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum TVV 001 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum EVA 016S Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum EVB 16 P A Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum DCU 002 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum EVI 105 PI Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum UDV 146 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum DCU 002 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum TPG 256 A Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum PM Z01 310 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum UDV 046 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum TPG 366 MAXIGAUGE Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum AVA 016 Manuel utilisateur
Pfeiffer Vacuum
Pfeiffer Vacuum EVB 016 S A/X Manuel utilisateur
Manuels Unité de contrôle populaires d'autres marques
Festo
Festo Compact Performance CP-FB6-E Manuel de la liste des pièces
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur
JS Automation
JS Automation MPC3034A Manuel utilisateur
JAUDT
JAUDT SW GII 6406 Series Guide rapide
Spektrum
Spektrum Air Module System Manuel utilisateur
BOC Edwards
BOC Edwards Q Series Manuel utilisateur
