Pettec Pet Cam Feel Manuel utilisateur

Pet Cam Feel

For a rewarding

relationship

HERE WE GO...

Thank you for choosing our pet cam. With the PetTec Pet Cam Feel you’ll al-

ways have your darling in view.

READ ALL INSTRUCTIONS AND WARNINGS IN THIS OPERATING

MANUAL BEFORE USING THE PET CAM Feel.

• Please do not disassemble and modify the PetTec Pet Cam Feel. The device

requires neither maintenance nor servicing. In case of malfunction, please

contact our customer service.

• In order to ensure proper use of the device, we recommend that you only

use the original parts. Use only the supplied assembly parts for mounting

the device.

• The device should not be affected by any renovation work, be it the use of

paint or wallpaper.

Legal Notice

• The PetTec Pet Cam Free has been designed for indoor use only. Laws in

your country may limit observation of areas outside of your home or pro-

perty. Please inform yourself about local legislation. To protect the privacy

of others, mount the camera so that you cannot record images of public

areas, streets, or your neighbor’s property. We also recommend informing

relatives, visitors and domestic workers about the camera and its function.

• Please note that the app will not inform you automatically in case of emer-

gency or burglary. If necessary, an emergency call must always be placed

by yourself. Stage10 GmbH does not provide any form of guarantee for mis-

sing or incorrect notifications or recordings.

Important safety instructions

Micro-SD-Card-Slot

PRODUCT OVERVIEW

Temperature and humidity sensor

Power On/Off

Ambient Light On/Off

Speech connection

Speaker

Reset button

Ambient Light

Status LED

Microphone

USB Type-C charging port

Charging control LED

Content:

• PetTec Pet Cam Feel

• Power plug

• USB Type-C to -A Cable

• Manual

• Screws and dowels

• Drilling template

IMPORTANT INSTRUCTIONS

Status LED (front side)

• Permanently red LED – no connection to internet possible

• LED blinking red – ready to connect to Wi-Fi

• LED blinking red quickly – Wi-Fi connection is in progress.

• Permanently blue LED – connection to Wi-Fi works properly

• LED blinking blue – ready for manual connection to Wi-Fi

• LED blinking blue quickly – manual Wi-Fi connection is

established.

• No LED – The camera is turned off / not operational.

Charge control LED (in plug compartment)

• Orange LED - camera is charging

• Green lit LED - battery is fully charged

USV Type-C cable feeder

The connector supplies power to the camera. If required, conventional USB

Type-C cables with different lengths may be used.

Microphone/speaker

The combination of built-in microphone and speaker allows two-way com-

munication.

Micro-SD card slot

Micro-SD cards up to 128GB in size may be used.

Reset button

The reset button must be pressed with a narrow object for approx. 5 seconds

to allow the camera to be reset to factory default settings.

To activate manual Wi-Fi setup, the reset button has to be pressed by a narrow

object for about 1 second.

Power button

Pressing the power button switches the camera on or off!

Pair button

The Pair button triggers a call! In this case, the user of the app is contacted

via video call!

LED button

Pressing the LED button turns the ambient light on or off! Individual settings

can be made in the settings of the camera

GETTING STARTED

1. Please connect the camera with a micro-USB cable and plug it into the

charger plug. The power plug must be connected to a power outlet.

2. After about a minute, the camera will beep and the LED will flash red. This

signals that the camera is ready to connect to the Wi-Fi network.

3. Download the „PetTec Snoop Cube“ app from the Apple App Store or Goo-

gle Play Store and install the app on your mobile device. Now follow the

instructions in the app to complete the camera setup successfully.

4. A Wi-Fi router with internet connection and the associated password must

be available. Your mobile device must be connected to the Wi-Fi network of

your router on which you want to connect the camera.

5. A stable Wi-Fi connection is required to ensure proper operation.

PetTec Snoop Cube App

MOOUNTING OPTIONS

Mounting with the clamp

1. Clamp the camera with , e.g. on the

edge of a piece of furniture, and turn

the housing to find an ideal viewing

angle.

2. Turn to adjust the viewing angle.

Free setting

1. The camera also stands freely on the

clamp.

2. Simply place the device in a safe

place.

Screwed mounting

1. Attach the screws to the wall according to the position of the drilling tem-

plate. Do not tighten the screws all the way, as you will need to leave a gap

to hang the camera.

2. Engage the mounting holes of the camera (at the bottom) into the screws

and press the camera down until it is fixed.

TECHNICAL DETAILS

Requirements

Data storage

Video & Audio

Image sensor

Audio

Motion and

noise detection

Temperature and

humidity detection

Dimensions & Weight

• High-Speed-Internet

• WiFi Connection

• Frequency 2.4 GHz

• Supports Micro-SD cards up to 128 GB

• Micro-SD cards available separately

(Requires class 10 oder higher)

• Resolution: 2304 (H) x 1296 (V)

• Format: H.264

• Field of vision: 110°

• Night vision: up to 10 m

• Full color

• 1/2.8” 3 Megapixel CMOS

• Digital zoom

• Loudspeaker

• Microphone

• Motion detection: 3 setting options available

• Noise detection: 3 setting options available

• Instant push notifications

• Upper and lower limit freely adjustable

• Immediate push notifications for values

outside the set limits

• Dimensions: 79 x 87 x 129mm

• Weight: 200g

Rechargeable battery

Energy

• Battery capacity: 3,350mAh Li-Ion battery

• Charging via USB ty-C cable via USB.power

supply unit

• Charging time: 6-8 hours

• Battery life: Ca. 5 hours

• Maximum power consumption: 2.5W

• Rated power (USB-C): DC 5V/1A

IMPORTANT INFORMATIONS

Radio signal

The radio transmission signal may be adversely affected by external influen-

ces (e.g., electric motors, defective electrical appliances). The range of the

radio transmission signal is usually limited within buildings. Similarly, the

structural works/conditions affect the radio range of the device. Bluetooth

devices such as headphones or speakers can also negatively affect the

radio signal of the device. The signal strength can also be reduced by

environmental influences such as humidity.

Environmental protection

Please note that non-disposable electrical and electronic appliances as well

as batteries must be recycled separately and in an environmentally friendly

manner (European Directive on Waste Electrical and Electronic Equipment).

Use the country-specific return and collection systems for the recycling of

electrical and electronical appliances as well as for batteries. Disposal of bat-

teries in household waste is prohibited.

https://support.pettec.de/hc/de

Declaration of conformity (see chapter „Declaration of

conformity“): Products designated with this symbol ful-

fill all applicable community provisions of the European

Economic Area.

Stage10 GmbH declares that, on the date the equip-

ment accompanied by this declaration is placed on the

market, the equipment conforms with all technical

and regulatory requirements of the relevant directives,

regulations and standards.

CUSTOMER SERVICE

Declaration of conformity

Stage10 GmbH confirms that the product described in these instructions (Pet

Cam Feel) conforms to guideline 2014/53/EU. The complete text of the EU

declaration of conformity is available at the following URL:

MANUFACTURER INFORMATION AND SERVICE

If you have questions about the PetTec Pet Cam Feel or experience

problems using it, first contact us via email at the following address:

info@PetTec.de

PetTec® is a brand of Stage10 GmbH | Leipziger Platz 9 | 10117 Berlin | www.

PetTec.com
