F1-30

Rugged Military COTS Computer

with Intel® 5th gen Core i7-5650U,

NVIDIA GT730M, Dual LAN, DC-In

9-36V, Operating Temperature -40~

+70°C

Quick Installation Guide

Safety information

Electrical safety

To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

When adding or removing devices to or from the system, ensure that the power cables for

the devices are unplugged before the signal cables are connected. If possible, disconnect all

power cables from the existing system before you add a device.

Before connecting or removing signal cables from the motherboard, ensure that all power

cables are unplugged.

Seek professional assistance before using an adapter or extension cord. These devices could

interrupt the grounding circuit.

Make sure that your power supply is set to the correct voltage in your area.

If you are not sure about the voltage of the electrical outlet you are using, contact your local

power company.

If the power supply is broken, do not try to fix it by yourself. Contact a qualified service

technician or your local distributor.

Operation safety

Before installing the motherboard and adding devices on it, carefully read all the manuals

that came with the package.

Before using the product, make sure all cables are correctly connected and the power cables

are not damaged. If you detect any damage, contact your dealer immediately.

To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots,

sockets and circuitry.

Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may become wet.

Place the product on a stable surface.

If you encounter any technical problems with the product, contact your local distributor

Statement

means, without prior written permission from the publisher.

All trademarks are the properties of the respective owners.

All product specifications are subject to change without prior notice

-Page 1-

Revision History

Revision Date (yyyy/mm/dd) Changes

Version 1.0 2019/07/12 Initial release

Packing list

□F1-30 Fanless Rugged System

□CD (Driver + Quick Installation Guide)

Ordering information

Model Number Description

F1-30 Rugged COTS computer with Intel®5th Gen. Broadwell ® Core™ i7-

5650U processor, NVIDIA GeForce GT 730M graphics, Operating

Temperature -40~+70°C

If any of the above items is damaged or missing, please contact your local distributor.

-Page 2-

Table Contents

SAFETY INFORMATION ................................................................................................................................................... 1

ELECTRICAL SAFETY .........................................................................................................................................................1

OPERATION SAFETY .........................................................................................................................................................1

STATEMENT ................................................................................................................................................................... 1

REVISION HISTORY ......................................................................................................................................................... 2

PACKING LIST ................................................................................................................................................................. 2

ORDERING INFORMATION ............................................................................................................................................. 2

TABLE CONTENTS ........................................................................................................................................................... 3

CHAPTER 1: PRODUCT INTRODUCTION .......................................................................................................................... 4

1.1 KEY FEATURES ..........................................................................................................................................................4

1.2 DIMENSIONS ...........................................................................................................................................................5

1.3 FRONT PANEL COMPONENT ........................................................................................................................................6

1.4 F1 PHOENIX CONTACT CONNECTOR PIN DEFINE................................................................................................................... 7-10

-Page 3-

Chapter 1: Product Introduction

1.1 Key Features

System

CPU Intel® Core™ i7-5650U Processor (2 Cores, 4 Threads) up to 3.2GHz

Memory Type 2 x XR-DIMM up to 16 GB

BIOS AMI® BIOS

Graphics NVIDIA®GPU GT730M supports CUDA 384

VGA analog support resolution up to 2048x1536

Storage Device Onboard 64GB SATAIII uSSD

Ethernet 2 x 10/100/1000 Ethernet

Serial Port 4 x RS232

USB 4 x USB2.0

I/O Interface

COM (RS232) X1/X2/X3/X4

LAN (Gigabit Ethernet) X5/X6

DIO1 X7

DIO2 X8

USB X9/X10/X11/X12

VGA X13

DC-IN POWER IN

Mechanical & Environment

Construction Aluminum chassis with fanless design

Power Requirements 9~36V DC-IN

Dimension (W x H x D) 190.5 x 230 x 320.5 mm (7.50 " x 9.05 " x 12.62")

Weight 16 Kg (35.24 lb)

Ingress Protection IP65

Operating Temp. -40 to 70°C (ambient with air flow)

Storage Temp. -40 to 70°C

Relative Humidity Up to 95%RH @40°C, non-condensing

* Specifications are subject to change without notice*

-Page 4-

1.2 Dimensions

-Page 5-

1.3 Front Panel Component

I/O labeling Function

X1/X2/X3/X4 RS232 Ports (4 ports)

X5/X6 Gigabit Ethernet (2 ports)

X7 DIO1 (8 bit DIO)

X8 DIO2 (8 bit DIO)

X9/X10/X11/X12 USB2.0 (4 ports)

X13 VGA

POWER IN DC-IN (9-36V input, 150W max.)

GND Ground screw

PWR Power Switch w/ indicator LED

-Page 6-

-Page 7-

F1 Phoenix Contact Connector Pin Define

I/O

Pin define

D-9

RS-232-1

DCD

RXD

TXD

DTR

GND

DSR

RTS

CTS

I/O

Pin define

D-9

RS-232-2

DCD

RXD

TXD

DTR

GND

DSR

RTS

CTS

I/O

Pin define

D-9

RS-232-3

DCD

RXD

TXD

DTR

GND

DSR

RTS

CTS

I/O

Pin define

D-9

RS-232-4

DCD

RXD

TXD

DTR

GND

DSR

RTS

CTS

-Page 8-

I/O

Pin define

RJ45

LAN1

D1+

D1-

D2+

D2-

D3-

D3+

D4+

D4-

I/O

Pin define

RJ-45

LAN2

D1+

D1-

D2+

D2-

D3-

D3+

D4+

D4-

I/O

Pin define

DIO-1

DIO0

DIO1

DIO2

DIO3

DIO4

DIO5

DIO6

DIO7

+5V

11~12

N/A

-Page 9-

I/O

Pin define

DIO-2

DIO8

DIO9

DIO10

DIO11

DIO12

DIO13

DIO14

DIO15

+5V

11~12

N/A

I/O

Pin define

USB-A

USB 1

VCC

D-

D+

Ground

5~8

N/A

I/O

Pin define

USB-A

USB 2

X10

VCC

D-

D+

Ground

5~8

N/A

I/O

Pin define

USB-A

USB 3

X11

VCC

D-

D+

Ground

5~8

N/A
