Pelonis HV-1004 Manuel utilisateur

UTILITY HEATER

MODEL: HV-1004

PLEASE READ AND SAVE THESE INSTRUCTIONS

OWNER’S MANUAL

145*210mm 单黑君字高调整2017.6.15

When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric

shock, and injury to persons, including the following:

1. Read all instructions before using the heater.

2. This heater is hot when in use. To avoid burns, do not let bare skin touch the hot surface. If provided,

always use handles when moving this heater. Keep combustible materials such as furniture, pillows,

bedding, papers, clothes and curtains at least 3’(0.9 m) away from the front of the heater and from the

sides and rear.

3. Extreme caution is necessary when any heater is used by or near children or invalids, and whenever

the heater is left operating and unattended.

4. Always unplug the heater when it is not in use.

5. Do not operate the heater with a damaged cord or plug, or if the heater malfunctions, or has been

dropped or damaged in any manner. Return the heater to an authorized service facility for examination

and electrical or mechanical adjustment or repair.

6. Do not use the heater outdoors.

7. This heater is not intended for use in a bathroom, laundry areas or similar moist indoor location. Never

locate the heater where it may fall into a bathtub or other water container.

8. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners or similar items.

Arrange the cord away from high traffic areas where it can be tripped over.

9. This appliance has a polarized plug (one blade is wider than the other). To reduce the

risk of shock, this plug is only intended to fit into a polarized outlet one way. If the plug does not fit

into outlet properly, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT

attempt to defeat this safety feature. Doing so could result in an electric shock hazard.

10. This heater draws 12.5 A during operation. To prevent overloading a circuit, do not plug the heater into a

circuit that already has other appliances plugged into it.

11. It is normal for the plug to feel warm to the touch. However, a loose fit between the

AC outlet and plug may cause overheating and distortion of the plug. Contact a qualified electrician

to replace a loose or worn outlet.

CAUTION:

12. To disconnect the heater, first turn the controls to the OFF position, and then remove the plug from outlet.

Never pull the plug out by the cord.

SAVE THESE IMPORTANT INSTRUCTIONS

FOR FUTURE REFERENCE.

17. Avoid the use of an extension cord because the extension cord may overheat and

cause a risk of fire. Always plug heaters directly into a wall outlet/receptacle.

18. The output of this heater may vary, and its temperature may become intense enough to burn exposed skin.

Use of this heater is not recommended for persons with reduced sensitivity to heat or an inability to react in

order to avoid burns.

19. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or relocatable

power tap (outlet/power strip).

CAUTION:

14. To prevent a possible fire, do not block air intakes or exhaust openings in any manner. Do not use on a soft

surface, such as a bed, where openings may become blocked.

15. A heater has hot and arcing or sparking parts inside. Do not use it in the areas where gasoline, paint, or

flammable liquids are used or stored.

16. Use this heater only as described in this manual. Any other use that is not recommended by the manufacturer

may cause fire, electric shock, or personal injury.

13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, because this may cause

an electric shock or fire, or may damage the heater.

GETTING TO KNOW YOUR HEATER

ASSEMBLY INSTRUCTION

IMPORTANT !

Your heater is equipped with a polarized alternating current line plug (a

plug having one blade wider than the other). This plug will fit into the

power outlet only one way. This is a safety feature.If you are unable to

insert the plug fully into the outlet, try reversing the plug.If the plug should

still fail to fit, contact your electrician to replace your outlet. DO NOT

defeat the safety purpose of the polarized plug.

Carefully remove your heater and all parts from the box.

The package includes:

1 - Heater

2 - Carry Handle

3 - Screws

Handle Assembly：

1. Place the heater in upright position.

2. Use the provided screws to attached the carry handle top of heater.

3. Use screw driver to tighten the screws firmly. Please ensure that

screws are not over-tightened.

1. CARRY HANDLE

4. POWER & SETTING CONTROL

5. THERMOSTAT CONTROL

2. PROTECTING BRACKET

3. POWER INDICATOR LIGHT

6. TIP-OVER SWITCH

(Caution hot, do not use the

protecting brackets as carry

handle when the unit is working.)

SPECIFICATIONS

HV-1004ledoM

Power Supply 120 V AC, 60 Hz

1500 W

12.5 A

Power Consumption

Electric Current (A)

CLEANING AND MAINTANENCE

CAUTION:

DO NOT ALLOW WATER TO RUN INTO THE INTERIOR OF THE HEATER AS THIS COULD

CREATE A FIRE OR ELECTRIC SHOCK HAZARD, DAMAGING THE UNIT.

1. Before any cleaning, make sure that:

a. The heater is turned OFF.

b. Disconnect power supply at source by removing plug from power outlet.

Your heater is now ready to be cleaned.

2. Regular Cleaning:

a. Do not spray cleaning liquid or other chemicals on the unit.

b.The most common cause of overheating is deposits of dust or fluff entering the heater. Interior dust can

often be removed by using a vacuum cleaner with a crevice tool attachment.

c. To clean enclosure, use a clean, soft and lightly damp cloth to gently wipe off the dirt form the surface

of the unit. Be sure not to wet the heating element and the switches. Allow the unit to dry completely

before using it.

OPERATING INSTRUCTIONS

To operate, connect to properly polarized outlet only. Match wide blade of plug to wide slot and fully insert. Be

sure to plug into a 120V AC, 60Hz outlet. This heater will not operate until the unit is plugged in.

YOUR HEATER IS EQUIPPED WITH A 4-POSITION CONTROL SWITCH.

OFF

FAN

OFF

FAN ONLY

LOW HEAT OUTPUT (900W)

HIGH HEAT OUTPUT (1500W)

POWER & SETTING CONTROL THERMOSTAT CONTROL

MIN MAX

SAFETY FEATURES

Tip Over Switch: As a safety measure, the unit will shut off in the event of it being knocked over. Should this

occur, simply turn the heater off and stand it back up to a regular upright position, then switch it back on.

Overheat Protection: This heater is equipped with thermal cut-off, which temporarily shuts off the heater when

it reaches high temperatures. Once this happens, turn the heater off and unplug. Allow it to cool for 5-10.

minutes. Inspect unit and check to make sure it is not covered with objects. After heater has cooled down,turn it

back on to resume normal operation.

Heat Setting Control: Set the power & setting control switch to HIGH for fast warm-up of a room.

Once the room is comfortable, slowly rotate the thermostat control counterclockwise until the heater shuts

off. The thermostat will now maintain the temperature by cycling the heater on and off. Once the room is

comfortable, select a lower power setting to reduce electrical consumption and to prevent the roomfrom

becoming too warm. During particularly cold weather, the LOW power setting may be insufficient to satisfy

the thermostat, select a higher setting for these periods.

Fan Only Setting: To operate fan only setting, turn thermostat to MAX and set the Power& Setting Control

to FAN ONLY setting.

STORAGE

1. Perform the cleaning procedures described in “Cleaning/Maintenance”.

2. Wipe all parts to dry.

3. Pack the heater in a plastic bag and store it in a cool, dry place.

PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE HEATER YOURSELF.

DOING SO COULD VOID THE WARRANTY AND CAUSE DAMAGE OR PERSONAL

INJURY.

TROUBLESHOOTING

If your heater fails to function normally, please follow these procedures.

Problem Probable Cause Solution

A) Room temperature has been warmed

up to thermostat setting.

A) To increase the room temperature, adjust

thermostat control knob to a higher setting by turning

clockwise.

Heater stopped

roducing heat. B) Heater was accidentally knocked over,

activating the Tip-Over switch.

B) Turn heater off and position it upright on a flat

and even surface. Turn heater on to resume normal

operation.

A) Heater is not plugged into a 120 V

polarized outlet.

A) Ensure unit is in OFF position. Plug in unit and

attempt to turn on again

B) Breaker/Fuse has been tripped. B) Please check your electrical box to confirm the

breaker has not been tripped. Ensure unit is in OFF

position. Plug in unit and attempt to turn on again.

Attempt to plug unit into another receptacle in the

house.

Heater is not

working.

C) Thermal Cut-Off has been activated

ecause unit has overheated.

C) Turn heater off and allow cool for 5-10 minutes.

Once heater has cooled off, check to make sure there

are no objects on or very close to the unit. To

resume operation, plug unit back in once it has

cooled off.

A) A drop of oil fell on the heating coil

during the manufacturing process. It will

quickly evaporate and should not occur

again.

A) Ensure room in which heater is situated is well

ventilated.

The heater is

creating a burning

smell. B) Check & ensure there are no

combustible materials within 3' (0.9 m)

of the heater.

B) Remove any combustible items from the heater.

The heater is

making small

crackling sounds

It is normal for the appliance to emit small

crackling sounds when it’s turned on for

the first time. Do not be alarmed.

After a small period of time, crackling sound will

dissipate and is not likely reoccur .

Power indicator

light is not on.

Unit is turned off or is unplugged. Connect to properly polarized outlet and match wide

blade of plug to wide slot and fully insert. Be sure to

plug into a 120 V AC, 60 Hz outlet. Turn the power

&setting control switch on.

CAUTION:

For questions or comments,please write to:

Midea America Corporation

Customer Care Center

[email protected]

1-866-646-4332

11411 NW 107th Street,

Suite 12

Miami, FL 33178
