PELEKIS INTD0909 Manuel utilisateur
www.pelekis.tech
GSM Gateway INTD0909
voice / data
Reference Manual
INTD0909
Please read carefully the instructions in order to
get all the benefits of this device.
Page 2 Firmware Revision
Page 3 General Description - Features
Page 4 Specification
Page 5-6 Wiring-Connection
Page 7-12 Operation Mode
Page 13-27 Programming
Pages 21-27 iOS / Android mobile Application
Page 28-30 Record Function
GSM Gateway
voice / data
Rev. 1.04 April 2019
PELEKIS ELECTRONICS 2ISO9001/2015 Rev. 1.04 April 2019
Firmware Rev. :
v1.01 04/2016 Add Record voice messages.
v1.02 06/2017 Selection between PSTN and GSM line, enabled
v1.03 07/2017 4 SMS programmable number enabled
v1.04 04/2019 iOS / Android Application programming method added
PELEKIS ELECTRONICS 3ISO9001/2015 Rev. 1.04 April 2019
Our GSM device can provide a reliable and robust voice and data Gateway in the
elevators. Combined with every Intelco Emergency phones, ensures bidirectional com-
munication for both trapped passenger and service personnel.
The GSM gateway INTD0909 has a 6.3V integrated backup battery and can oper-
ates up to 6 hours in case of AC failure. All GSM functions can be programmed remotely
by SMS messages. Our GSM also is capable of switching between PSTN and GSM line
and announcing up to 2 recorded voice messages for both cabin trapped passengers and
rescue service, following the European Standards EN81-20, EN81-28.
Caution : The installation and settings of the device, must be done by a qualified person.
General Description:
Full Voice/SMS functionality.
On device record capability, for up to 2 voice messages.
PSTN/GSM Line selection.
Up to 4 calling number from Internal memory.
Full user operation customizing via SMS.
Emergency call SIM-less card ability.(IEN 112)
Up to 4 onboard I/O controlled by SMS.
Battery charge and real time monitoring.
Up to 8 I/O extension capability with our serial controlled extension board
Up to 8 I/O extension capability with our serial controlled extension board.
Features :
PELEKIS ELECTRONICS 4ISO9001/2015 Rev. 1.04 April 2019
Specifications:
Power supply 230V AC 50Hz
On board battery type Sealed Lead Acid GEL type 6V/1.3Ah
Battery charger type Trickle charging with MCU monitoring
Power consumption 3.5W continuous, all features on, all led on
Network bands GSM 850/900/1800/1900MHz
Phone Line connection Standard RJ-45 jack
Ext. Line connection Standard RJ-45 jack
SIM card type Standard, 3V
On board connectivity 2 optically isolated inputs
2 relay outputs
Optional add on card serially controlled ,for ex-
tending up to 8 inputs / 8 Outputs
Operation temperature 0-80°C
Operation humidity 10-80% (non condensing)
Dimensions (External) 60 x 210 x 145 mm (H x W x D)
Weight (Total/w Battery) 1Kg
PELEKIS ELECTRONICS 5ISO9001/2015 Rev. 1.04 April 2019
Connect the antenna at the round terminal on the bottom side of the box. Make sure of
good locking.
Connect any Intelco Emergency phone or any conventional telephone device at the
PHONE terminal on the left side of the.
Install the SIM Card to SIM holder. Make sure that PIN password has be deactivated.
Connect the 2 cables (Black and Red) to the batteries poles.
Connect the power cable to the terminal and plug it to the 230V AC. A red LED will light up
near the 230V AC terminal.
Make a short circuit at the jumper ―RESET‖ beside of the terminal BAT.
Wiring-Connection:
PELEKIS ELECTRONICS 6ISO9001/2015 Rev. 1.04 April 2019
Schematic 1.
N
L
NC
Power
Outputs
Inputs
R1
R1
C1
R2
C2
R1
C1
C2
R2
INTELPHONE
SIM Card
RESET
Fuse 100mA
LED Indication
Line
Battery
Network
signal
strength
Net Status
AC present
Battery (6,3V)
External Line
Bottom Side
PELEKIS ELECTRONICS 7ISO9001/2015 Rev. 1.04 April 2019
Operation
Start Up / Initialization :
In order to startup the GSM Gateway device, please power up the device. This could
be happen by either connecting a 6,3V battery at battery cables (Red-Black) or placing AC
power, or both. Then short RESET pins by placing the RESET jumper. At startup of the
device, one short buzz sound indicates the start of the device.
At the startup, device makes a quick check on AC power supply. If there is no AC power,
and Batteries are connected and are good charged, device will start being powered from
Battery. While device performs the above action all onboard leds are keep blinking every
500 ms .
After 4-5 sec device starts seeking network to connect according the SIM card provider.
During this period, S1,S2 and S3 LEDs are blinking and Network LED is blinking
every 500 ms indicating that no network found. If network can not be found in a specific
period of time, device timeouts the process and moves on SIM-less operation limited
functionality. On the other hand, if device achieve connection with network, immediately
moves on to the Normal Operation mode in full function mode.
When S1,S2 and S3 LEDs stop blinking and Network LED blink every 3 seconds then
onboard buzzer will buzz 2 times with short pause between.
Double buzzing sound let the user know that the startup process is just finished and device
is ready for use.
Functions with SIM Card detected:
Voice Ready
SMS Ready
Data Ready (Not Available)
Battery check
Functions with SIM Card not detected:
Limited Voice Ready ( International Emergency Number (112))
Battery check
PELEKIS ELECTRONICS 8ISO9001/2015 Rev. 1.04 April 2019
Once the Startup/Initialization is completed, the device moves on to the
Normal Operation mode.
In Normal Operation device is performing some actions endless and some action is
occurred from internal or external triggers.
Continuous running Actions:
Battery status check (Real-time).
Battery health check (Every day at 12:00 pm).
Network signal status (Real-time).
SIM Card presents observation (Every 1 minute).
Triggered one-shot Actions:
Incoming call.
Incoming SMS.
Incoming data.(Not Available)
Emergency outgoing call.
Emergency outgoing SMS.
“LOW BATTERY WARNING” outgoing SMS.
“LOW BATTERY-DEVICE IS SUTTING DOWN” outgoing SMS.
“BATTERY DESTROYED-PLEASE REPLACE” outgoing SMS.
Outgoing SMS for Inputs (Auto SMS=1).
Reset if SIM Card presents is lost.
Reset if Network signal is lost.
Normal Operation :
PELEKIS ELECTRONICS 9ISO9001/2015 Rev. 1.04 April 2019
In case of incoming call, device starts ringing the phone device connected to the
terminal ―Line‖ and blinking the ―LINE‖ led according to the ringing frequency.
When the connected phone answers and a connection is established, voice
communication starts and the ―LINE‖ led starts blinking.
Also, at this state the device is able to detect DTMF codes from the telephone line
and make a special function, like caller line hold (if Rescue Service is enabled on the
GSM).
If the connected line is terminated for any reason, the ―LINE‖ led turns off and
immediately turns on/off according to the current earpiece Hook state.*
While in ringing state, the ―LINE‖ led remains off, if the caller terminates the
connection before it is answered.
Incoming Calls :
In case of an outgoing call, the Line connected device can make Hook Off action
and get the Dial Tone.
Call progress function detects special International known telephone Tones* as well
as Human Voice, and manages the call progress operation.
Also, at this state the device is able to detect DTMF codes from the telephone line
and make a special function, like called line hold (if Rescue Service is enabled on the
GSM).
When called number answer and connection is established, voice communication
starts and ―LINE‖ led starts blinking.*
If the connected line is terminated for any reason, the ―LINE‖ led turns off and
immediately turns on/off according to the current earpiece Hook state.*
Outgoing Calls :
* Hook Off : “LINE” led = On — Hook On : “LINE” led = Off
PELEKIS ELECTRONICS 10 ISO9001/2015 Rev. 1.04 April 2019
In this operation, GSM Gateway device is able to Edit-Delete or Ask stored settings that
define its operation.
The device is always ready to receive SMS messages. These messages are processed
and executed accordingly, if they are valid. (see «PROGRAMMING» section)
Any valid formatted incoming SMS, is answered with a SMS text ―OK‖ or a text
contains the requested action.
Any invalid formatted SMS, isn‘t answered with any SMS from the device, in order to
avoid unnecessary charges on the SIM card.
SMS programming functions are divided into two categories, which differ in term of
authorization.
These are USER and ADMIN Authorization.
Caution: Authorization password (User–Admin) must match the SMS code that is requested.
Incoming SMS :
1 Action not ready —Send answer but has no effect on device.
2 Action not available —Send no answer.
User Actions: Admin Actions:
Program 4 calling number 2. Program admin password.
Program low battery calling number. Program auto-run calling number 2.
Program user password. Program voice function 2.
Program buzzer function. Ask IMEI.
Program Incoming call function1. Program SIM Card notifications 2.
Ask monitor 2.
Program Outputs-Relays.
Program Inputs-Optocouplers.
