1ISSUED: 05-08-13 SHEET #:125-9434
Model: MOD-MBLInstallation and Assembly:
Wall Mount with PC Storage
Maximum Load Capacity
Model Max. Load
Wall Mounted MOD-MBL 200 lb (90kg)
Wall Mounted MOD-MBL
with dedicated adapter plate 150 lb (68 kg)
MOD-FPMS 20 lb (9kg)
SP850 150 lb (68 kg)
FPS-1000 150 lb (68 kg)
SA745PU 70 lb (32 kg)
SA750PU 130 lb (59 kg)
SA760PU 170 lb (77 kg)
SA770PU 170 lb (77 kg)
SA752PU 80 lb (36 kg)
SA761PU 130 lb (59 kg)
SA763PU 160 lb (73 kg)
SA771PU 160 lb (73 kg)
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
2ISSUED: 05-08-13 SHEET #:125-9434
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
Parts List
Part Description Quantity Part Number
Aadapter plate 1 201-1724
Bwall plate 1 201-1699
Crubber feet (pack of four) 1 570-1036
DM8 x 15mm socket pin screw 4 520-1068
EM10 x 15 mm penta-pin screw 4 520-9263
FM10 penta-pin tool 1 520-9260
GM6 x 12 mm socket pin screw 4 510-1050
H#10 at washer 4 540-9400
I4 mm allen wrench 1 560-9646
JM6 x 16 mm socket pin screw 4 520-1132
K#8 at washers 4 540-1001
LM5 x 12mm skt pin 4 520-1064
Mcable tie 4 560-9711
NM4 x 12 mm socket pin serrated washer head screw 4 510-1079
O#14 x 2.5" hex head wood screw 3 5S1-015-C03
Pconcrete anchor 3 590-0320
QM5 x 10mm type f screw 4 520-1164
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
3ISSUED: 05-08-13 SHEET #:125-9434
ABCDE
FGHIJ K
M
L
NP Q
O
Attaching adapter plate (A) to tilt box assembly (not included)
with four self taping screws (Q).
Q
B
MOD-FPMS
NOT INCLUDED
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
4ISSUED: 05-08-13 SHEET #:125-9434
1
Attaching Adapter Plate to Screen
Using SP850, FPS-1000
Attaching adapter plate to screen with
VESA hole pattern:
Choose hole pattern and fasteners shown in detail 2 for
mounting screen with VESA mounting patterns. Hand thread
screws (N, L or G) through washers (K or H) and adapter
plate (A) into screen as shown (right). Screw must make at
least three full turns into the mounting hole and t snug into
place. Securely tighten screws using 4 mm allen wrench (I).
• If screws don't get three complete turns in the screen
inserts or if screws bottom out and bracket is still
not tightly secured, damage may occur to screen or
product may fail.
WARNING
A
SCREEN
N, L or G
K or H
VESA®200 x 100 VESA®200 x 200VESA®100 x 100
MOUNTING PATTERNS
M4 x 12 mm screws (N) with #8
washers (K) or M5 x 12 mm screws
(L) with #10 washers (H)
M4 x 12 mm screws (N) with #8
washers (K), M5 x 12 mm screws (L)
M4 x 12 mm screws (N) with #8
washers (K) or
M6 x 12 mm screws (G) with
#10 washers (H)
DETAIL 2
Using the hole pattern shown in detail 1, attach the adapter plate (A) to dedicated adapter plate with four
M10 x 15 mm screws (E) as shown in gure 1.1. Tighten screws using M10 penta-pin tool (F). If attaching to
articulating mount use M10 x 15 mm screws (supplied with mount).
DEDICATED
ADAPTER PLATE
DETAIL 1
MOUNTING PATTERN FOR
DEDICATED ADAPTER PLATES
A
E
Figure. 1.1
LANDSCAPE
PORTRAIT
OR
1
Attaching Wall Plate to dedicated adapter Plates:
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
5ISSUED: 05-08-13 SHEET #:125-9434
Secure adapter plate (A) to universal adapter bracket with four M10 x 15 mm screws (supplied with mount) as
shown below.
1
1
MOUNTING PATTERN
M10 x 15 mm
(supplied with mount)
MOUNTING PATTERN
Attaching Adapter Plate to Universal Adapter Bracket
Using SA745PU, SA750PU, SA760PU, SA770PU
Attaching adapter Plate to Universal Adapter Bracket
Using SA752PU, SA761PU, SA763PU, SA771PU (ACC950 Required)
Secure adapter plate (A) to universal adapter bracket with four M10 x 40 mm screws (supplied with ACC950) as
shown in below.
A
A
UNIVERSAL ADAPTER BRACKET
UNIVERSAL ADAPTER BRACKET
ACC-950 SPACER AND
M10 X 40 MM SCREWS
(SUPPLIED WITH ACC950)
M10 x 40 mm
(supplied with ACC950)
M10 X 15 MM SCREW
(SUPPLIED WITH MOUNT)
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
6ISSUED: 05-08-13 SHEET #:125-9434
Remove rubber feet from base.
Secure four rubber feet (C) to bottom of CPU
as shown below.
2
CPU
A
SAFETY
STRAP
Attach CPU to Tilt Box
A
Skip to Step 5 Page 8 if mounting wall plate (B) to wall.
Secure wall plate (B) to adapter plate (A) with four M8 x 15 mm screws (D) using 4 mm allen wrench (I)
as shown below.
3
Attaching Adapter Plate to Wall Plate
SCREEN NOT SHOWN
FOR CLARITY
B
CPU
C
D
NOTE: Safety belt may need to be loosened to attach
CPU to adapter plate (A).
Press CPU against adhesive strips on adapter plate (A)
and tightly secure safety belt against CPU.
CPU MAY APPEAR DIFFERENT
THAN ILLUSTRATED
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
7ISSUED: 05-08-13 SHEET #:125-9434
Thread two M10 x 15 mm penta-pin screws (E) into top
holes of wall plate (B) leaving 1/8" space between head
of screw and wall plate as shown below.
Hook wall plate (B) and two exposed M10 x 15 mm
penta-pin screws (E) into keyhole slots on mount.
Thread two M10 x 15 mm penta-pin screws (E) into top
holes of wall plate (B) leaving 1/8" space between head
of screw and wall plate as shown below.
Hook wall plate (B) and two exposed M10 x 15 mm
penta-pin screws (E) into keyhole slots on mount.
4Secure with two M10 x 15 mm penta-pin screws (E)
using M10 penta-pin tool (F) as shown below.
KEYHOLE SLOT
4Secure with two M10 x 15 mm penta-pin screws (E)
using M10 penta-pin tool (F) as shown below.
Attaching Wall Plate to Wall Arm Mount
Using SP850, FPS-1000
Attaching Wall Plate to Wall Arm Mount
Using SA752PU, SA761PU, SA763PU, SA771PU
1/8"
1/8"
KEYHOLE SLOT
B
E
E
E
E
E
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
8ISSUED: 05-08-13 SHEET #:125-9434
Remove two M5 x 20 mm screws from the rollbrake. Lift adapter plate of wall arm mount out from tilt bracket as
shown.
NOTE: M5 X 25 mm screw may need to be loosened a few turns to allow adapter bracket to be removed using 4
mm allen wrench (N).
Secure adapter plate of wall arm mount to wall plate (A) with
four M10 x 15 mm penta-pin screws (E) using M10 penta-pin
tool (F) as shown below.
Insert the puck of adapter plate into the tilt
bracket slot as shown. Attach brake pad assembly so
that the brake pad is snug against the adapter plate.
Adjust roll position of adapter plate to level screen then
lock puck in place by tightening M5 x 25 mm screw on
the underside of tilt bracket.
Tighten all (M5 x 20 mm, M5 x 25 mm) screws.
Attaching Adapter Plate to Wall Arm Mount
Using SA745PU, SA750PU, SA760PU, SA770PU
4
M5 X 20 MM SCREW
ROLL BRAKE
ADAPTER PLATE
M5 X 25 MM SCREW
TILT BRACKET
ADAPTER PLATE
B
E
WALL ARM MOUNT
M5 X 20 MM SCREW
ROLL BRAKE
ADAPTER PLATE
M5 X 25 MM SCREW
TILT BRACKET
WALL ARM MOUNT
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
9ISSUED: 05-08-13 SHEET #:125-9434
Installation to Wood Stud Wall
Use a stud nder to locate the edges of the stud. Use of an edge-to-edge stud nder is highly recommended.
Based on their edges, draw a vertical line down each stud center. Place wall plate (B) on wall as a template. Level,
and mark the center of the three mounting holes. Make sure that the mounting holes are on the stud centerlines.
Drill three 5/32" (4 mm) dia. holes 2.5" (64 mm) deep. Fasten two #14 x 2.5" wood screws (O) leaving 1/4" of
thread exposed as shown in Figure 5.1.
Hook wall plate (A) onto exposed #14 x 2.5" wood screws (O). Secure using one #14 x 2.5" wood screws (O) as
shown in gure 5.2
Skip to Step 6.
• Installer must verify that the supporting surface will safely support the combined load of the equipment and all
attached hardware and components.
• Tighten wood screws so that wall plate is rmly attached, but do not overtighten. Overtightening can damage the
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud nder
is highly recommended.
• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs. Install-
ers are responsible to provide hardware for other types of mounting situations
WARNING
5
1/4"
Figure 5.1 Figure 5.2
B
O
O
Visit the Peerless Web Site at www.peerless-av.com For customer care call 630-375-5100 or 800-865-2112.
10 ISSUED: 05-08-13 SHEET #:125-9434
SOLID CONCRETE
CINDER BLOCK
1/4"
Installation to Solid Concrete or Cinder Block
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" (35 mm) of actual con-
crete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid
part of the block, generally 1" (25 mm) minimum from the side of the block. Cinder block must meet ASTM C-90 specica-
tions. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to avoid
breaking out the back of the hole when entering a void or cavity.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Make sure that the wall will safely support four times the combined load of the equipment and all attached hardware and
components.
WARNING
5
CUTAWAY VIEW
INCORRECT CORRECT
wall
plate
wall
plate
plaster/
drywall
plaster/
drywall
concrete concrete
1
3
2
P
Drill holes and insert anchors (P).
Place plate (B) over anchors (P) and secure with screws (O).
Tighten all fasteners.
B
P
O
concrete
surface
• Tighten screws so that wall plate is rmly attached,
but do not overtighten. Overtightening can damage
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Always attach concrete expansion anchors directly
to load-bearing concrete.
• Never attach concrete expansion anchors to
concrete covered with plaster, drywall, or other
nishing material. If mounting to concrete surfaces
covered with a nishing surface is unavoidable,
the nishing surface must be counterbored as
shown below. Be sure concrete anchors do not
pull away from concrete when tightening screws. If
plaster/drywall is thicker than 5/8" (16 mm), custom
fasteners must be supplied by installer.
WARNING
Place wall plate (B) on wall as a template. Level, and mark the center of the three mounting holes. Drill three 5/16"
(8 mm) dia. holes to a minimum depth of 2.5" (64 mm). Insert anchors (P) in holes ush with wall as shown. Fasten
two #14 x 2.5" wood screws (O) leaving 1/4" of thread exposed as shown in Figure 5.3.
Hook wall plate (A) onto exposed #14 x 2.5" wood screws (O). Secure using one #14 x 2.5" wood screws (O) as
shown in gure 5.4.
B
O
O
P
Figure. 5.3 Figure. 5.4
Table des matières
Autres manuels peerless-AV Support et étagère
peerless-AV
peerless-AV PM 610 Mode d’emploi
peerless-AV
peerless-AV DS-LEDA27-4x4 Manuel utilisateur
peerless-AV
peerless-AV PR565 Manuel utilisateur
peerless-AV
peerless-AV PLCM-1 Manuel utilisateur
peerless-AV
peerless-AV KIL742 Manuel utilisateur
peerless-AV
peerless-AV DS-LED27BDL Series Manuel utilisateur
peerless-AV
peerless-AV LCT620AD Mode d’emploi
peerless-AV
peerless-AV SF640 Manuel utilisateur
peerless-AV
peerless-AV PR560M Manuel utilisateur
peerless-AV
peerless-AV DS-LEDZRD Series Manuel utilisateur
peerless-AV
peerless-AV SHARP NEC WMK-7598T Manuel utilisateur
peerless-AV
peerless-AV SMARTMOUNT STL670 Manuel utilisateur
peerless-AV
peerless-AV Paramount PF630 Mode d’emploi
peerless-AV
peerless-AV DS-LEDFLAAF-3X3 Manuel utilisateur
peerless-AV
peerless-AV SR898-EUK Manuel utilisateur
peerless-AV
peerless-AV ESA746PU Mode d’emploi
peerless-AV
peerless-AV Smartmount ST24D Mode d’emploi
peerless-AV
peerless-AV SmartMountXT STX660P Manuel utilisateur
peerless-AV
peerless-AV LG-WMF86BH Manuel utilisateur
peerless-AV
peerless-AV MOD-WP2 Manuel utilisateur
Manuels Support et étagère populaires d'autres marques
Salamander
Salamander Acadia AC/W/L400/WH Manuel utilisateur
Fohhn
Fohhn VAT-09 Guide de l'utilisateur
ricoo
ricoo FS0522 Manuel utilisateur
AMSOIL
AMSOIL BMK-22 Guide rapide
Kargo Master
Kargo Master 48220 Manuel utilisateur
Milestone AV Technologies
Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur
