Instruction Manual
Electric Oven
NPEO
Contents
Parry-British Built for Purpose
IN251-3
1
Contents ........................................................................................................................................... 1
Product Overview ............................................................................................................................ 2
Safety Instructions............................................................................................................................ 3
Installation Instructions ................................................................................................................... 4
Operating Instructions...................................................................................................................... 5
Cleaning Instructions ....................................................................................................................... 6
Maintenance Instructions................................................................................................................. 7
Fault Finding .................................................................................................................................... 8
Service Information .......................................................................................................................... 9
Wiring Diagram .............................................................................................................................. 10
Warranty Information..................................................................................................................... 11
Disposal & Recycling ...................................................................................................................... 12
Parry Catering Equipment (Midlands) Ltd, Town End Road, Draycott, Derby, DE72 3PT.
Sales Tel: 01332 875544 Fax: 01332 874455
Parry-British Built for Purpose
IN251-3
2
Product Overview
Robust and reliable, the Parry electric oven is manufactured from high grade stainless steel.
Featuring an easy-to-clean enamelled interior, the top mounted fan and graduated drop
down triple glazed door assist steam release. Two chrome adjustable shelves are also
included.
Unpacked weight (kg)
40
Dimensions (w x d x h) mm
600 x 580 x 700
Plug
1
Power rating
2.9kW
220-240V 50Hz ~
Warranty
2 years
The unit leads the industry in:
Design and aesthetic appeal
Performance
Power
Functionality
After sales support
Parry-British Built for Purpose
IN251-3
3
Safety Instructions
IMPORTANT: PLEASE READ INSTRUCTIONS FULLY BEFORE USE
Please be aware that surfaces on this machine may get very hot during, and after use.
ALL APPLIANCES OTHER THAN THOSE FITTED WITH A SEALED MOULDED PLUG MUST BE
FITTED BY A QUALIFIED ELECTRICIAN, IN ACCORDANCE WITH CURRENT REGULATIONS.
The unit should be installed in compliance with the INSTALLATION INSTRUCTIONS and the
NATIONAL REGULATIONS in force at the time. Particular attention should be paid to the
Health and Safety at Work Act.
To prevent shocks, all appliances whether gas or electric, must be earthed.
To avoid scratching the highly polished exterior surface of this equipment whilst in transit,
the protective film on the exterior surfaces has NOT been removed.
It is IMPORTANT that this protective film is peeled off before the equipment is used.
ENSURE THE APPLIANCE IS ISOLATED FROM THE POWER SUPPLY BEFORE INSTALLING,
CLEANING OR MAINTAINING THE APPLIANCE
Parry-British Built for Purpose
IN251-3
4
Installation Instructions
The PEO Paragon Electric Oven can be used as a stand alone oven that can sit on a work
surface or on the floor. There is also the option of fitting a N1871 hob unit to the top of it to
turn it into a four burner electric oven.
N1871 Hob units are sold separately. Other Parry 600mm products can also be fitted to the
top of the NPEO, but the working height may vary depending on the type of unit fitted.
To install the NPEO as an oven only: Take the four small rubber feet provided and screw
them into the riv nuts in the bottom of the unit. These feet will protect the surface that the
unit is being positioned on, as well as providing an air gap, to allow air to vent through the
base of the unit.
To install the NPEO with an N1871 unit on top: Screw the four provided stainless steel
100mm legs into the foot plates on the base of the unit. Remove the top panel from the
NPEO by removing four screws from either side. Take the two locating pins provided and
screw them into each of the riv nuts located on the top fold of the side panels.
The position of the locating pins will correspond with holes in
Parry-British Built for Purpose
IN251-3
5
Operating Instructions
Ensure that all packaging is removed, and all shelves are firmly in place.
Ensure that the operation thermostat is switched off.
Plug in the unit and switch on.
Located on the front top panel there are two knobs and three neon’s. The first knob
controls the power to the heating elements, fans and light. Turning the switch to the
first position turns on the interior light and shows that the unit has power is being
supplied. Power to the machine is also indicated by the illumination of the red neon
on the front of the unit.
The second switch position turns on the fans
The third position activates the rear 1.8KW element. This allows the unit to be used
as a fan oven. The top green neon illuminates when this position is selected.
The fourth position selects the rear 1.8KW element, plus the bottom 1.1KW element.
These work together to give the oven a combined power rating of 2.9KW. Both green
neon’s will be illuminated to signify that both elements are in use.
The second knob controls the temperature of the oven, note that the green indicator
neon will come on when the dial is first turned, but will go out when the oven has
reached the required temperature.
Since the fan assisted oven heats up more quickly and generally cooks food at a lower
temperature than a conventional oven, preheating the oven is often unnecessary. However,
food such as bread, scones and Yorkshire puddings, do prefer to be placed in a pre-heated
oven.
Cooking guidelines
Frozen Meat and Poultry
Joints of meat and whole birds should be defrosted slowly, preferably in a domestic
refrigerator (allowing 5-6 hours per 450g (1lb)), or at room temperature (allowing 2-3 hours
per 450g (1lb)). If, however, it is found necessary to accelerate this process, frozen food can
be defrosted in the fan oven at a temperature of 70/80°C (150 / 175 degrees F). A 1.5 kg (3
lb) oven-ready chicken, placed in the meat pan, will defrost in approximately 1 ¼ -1 ½ Hours.
Food should not be placed directly on the floor of the oven.
Warming Dishes
Take care particularly with delicate tableware. Place the dishes to be warmed in the oven.
Turn the oven control to 90°C
Parry-British Built for Purpose
IN251-3
6
Cleaning Instructions
The appliance should be cleaned after every use.
Allow unit to cool down before cleaning
Turn off unit at the mains power.
Wipe down the machine with a soft cloth, do not use abrasive materials.
Stainless steel cleaners maybe used and cleaning instructions on the product must be
adhered to.
Never clean the unit with water jets.
How to Replace the Oven Light
WARNING: SWITCH OFF AT MAINS SUPPLY AND UNPLUG THE OVEN BEFORE REPLACING
LAMP.
Open the oven door and remove the rod shelves.
Grip the light glass dome, unscrew anti-clockwise and lift out.
Reach into the aperture and unscrew the faulty lamp anti-clockwise.
Fit replacement lamp, and refit dome. When unscrewing the faulty lamp use a thick
cloth to protect your fingers should the lamp break.
Door Removal
Turn off mains supply and unplug. The door is removable to facilitate occasional cleaning of
heavy soiling from the oven floor and from the door itself. Please note that the door is
heavy, and care should be taken not to pinch your fingers during the removal and
replacement.
Open the door fully and lift the clips on each of the hinges.
Next, close the door halfway until the clips lock against the door and lift the whole
door up and out of the slots in the oven casing.
To replace, insert the hinges into the slots in the casing so that the hinge locks over
the recessed slot.
Open the door fully and flick the clips towards the oven casing and push down. The
door should now open and close as before. Please note that the triple glazed door is
not meant to be taken apart for cleaning.
Parry-British Built for Purpose
IN251-3
7
Maintenance Instructions
Ensure the appliance is isolated from the power supply before installing, cleaning or
maintaining the appliance.
Maintenance and service must only be undertaken by a qualified electrician.
Parry Catering provides a complete after-sales service by offering the sales of spare parts
directly to customers. Buying spares straight from the manufacturer allows customer to
experience exceptional value and speedy delivery on all spare parts.
For more information on buying spares visit:
www.parry.co.uk/parry-commercial-catering-spares
Parry-British Built for Purpose
IN251-3
8
Fault Finding
Fault
Check
Solution
No power light
Check that the unit is plugged
in and turned ON
Check that the unit is
plugged in to a socket.
Try a different socket
Check fuse in the plug
If the problem persist,
please contact your
distributor.
Power light ON, no heat or
green indictor lights
Possible thermostat failure
Please contact your
distributor
Power light ON, green light(s)
ON but uneven cooking
Possible fan failure
Please contact your
distributor
Power light ON, green light(s)
ON but not no heating
Possible element failure
Please contact your
distributor
