Paradyne FrameSaver DSL 9783 CSU/DSU Manuel utilisateur

FrameSaver®DSL 9783 CSU/DSU

Installation Instructions

Document Number 9783-A2-GN10-30

April 2001

Contents

FrameSaver DSL 9783 CSU/DSU Overview ................................................ 2

Upgrading a Basic Unit to SLV ...................................................................... 3

Product Documentation Online ..................................................................... 3

Package Checklist ......................................................................................... 3

Wiring and Cables You May Need ................................................................ 4

Prior to Installing the CSU/DSU .................................................................... 5

Installing the CSU/DSU ................................................................................ 6

Power-On ...................................................................................................... 9

Status LEDs .................................................................................................. 10

Troubleshooting ............................................................................................. 11

Configuration Setup ...................................................................................... 12

Verifying that Self-Test Passed ..................................................................... 15

Using the Easy Install Screen ....................................................................... 15

Completing Setup From the NOC ................................................................. 17

Cables and Connectors ................................................................................ 19

CSU/DSU Technical Specifications ............................................................... 23

Important Safety Instructions ........................................................................ 24

Government Requirements ........................................................................... 25

Warranty, Sales, Service, and Training Information ...................................... 27

NOTE:

In this document, CSU/DSU refers to the line termination capability of the DSL

endpoint, and does not imply association with traditional T1 or subrate equipment.

FrameSaver DSL 9783 CSU/DSU Overview

The FrameSaver®DSL (Digital Subscriber Line) 9783 CSU/DSU is a component in the

FrameSaver system. This system allows you to perform end-to-end service level

management across a hybrid FrameSaver DSL/ATM/Frame Relay network. Service

providers can isolate and correct problems remotely from their NOC (Network

Operations Center).

The CSU/DSU has an SDSL front endand is a manageable frame relay aware endpoint.

A typical example of using the FrameSaver DSL 9783 CSU/DSU in a network

configuration is shown below.

The FrameSaver DSL 9783 CSU/DSU is available in two feature sets:



Basic Feature Set 1 provides basic frame relay and diagnostic capability.



Advanced SLV (Service Level Verification) Feature Set 2 provides basic features,

plus SLV management and reporting capability.

Refer to

About FrameSaver DSL Devices

in the User’s Guide for a list of FrameSaver

DSL 9783 features, and the capabilities provided by each feature set.

Frame

Relay

CPE

Router/

FRAD

DSL ATM

Access

Network

FrameSaver

xDSL Unit

01-16770a

Frame

Relay DSL

ALARMS

MajorMinor

Fan

POWER

SERIAL

SMCM

CLOCK

ALARM

24681012141618

1357911131517

LAN/WANSLOT

CLOCKB

SERIAL

MCCAC

ALARM

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTEDATTHESOURCE

BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTEDATTHESOURCE

BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE

ATM

Switch

Copper

Loop

ATM

PVC

ATM

Switch

Customer Premises –

Remote Site DSLAM

TDM

Access

Network

FR Network

FR/ATM

IWF

ATM

Switches FR

Switches

Frame Relay NSP’s Network

DHCP

Server

Router

FrameSaver

Endpoint

Customer Premises –

HQ Site

LAN

Frame Relay

NSP's

Network

Operations

Center

OpenLane

NMS

DSL Provider's

Network

Operations

Center

OpenLane

NMS

Upgrading a Basic Unit to SLV

A basic FrameSaver DSL 9783 CSU/DSU can be upgraded to full SLV capability at any

time by ordering a FrameSaver SLV Activation Certificate. A certificate can be ordered

for a single 9783 CSU/DSU, or for many 9783 CSU/DSUs. The OpenLane®SLM

system, Release 5.3 or later, is required to schedule the activation of SLV features, and

to manage the certificate activations included in the certificate.

To upgrade a basic 9783 CSU/DSU to full SLV capability, order the FrameSaver SLV

Activation Certificate (Feature No. 9783-C1-220), providing the model to be activated

(i.e., 9783-C), your OpenLane SLM system license key number, the number of 9783

CSU/DSU activations to be included on the certificate.

To learn more about activating SLV capability, refer to the

FrameSaver SLV Activation

Instructions

(Document No. 9000-A2-GK43), or contact your sales representative.

Product Documentation Online

Complete documentation for this product is available at www.paradyne.com.

Select

Library

→

Technical Manuals

→

FrameSaver Frame Relay Devices.

Select the following document:

9783-A2-GB20

FrameSaver DSL 9783

User’s Guide

To order a paper copy of a Paradyne document:



Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)



Outside the U.S.A., call 1-727-530-8623

Package Checklist

In addition to these instructions, verify that your package contains the following:

❑FrameSaver DSL 9783 CSU/DSU

❑Power cord with power transformer

❑Tie wrap for power cord strain relief

❑DSL network access cable with 8-pin connectors –U.S. models only

❑Ferrite choke –International models only

❑

FrameSaver DSL 9783 CSU/DSU Quick Reference

(Document No. 9783-A2-GL10)

Be sure to register your warranty at www.paradyne.com/warranty.

Wiring and Cables You May Need

The following wiring and cables are used with this product, which uses standard

interface connectors:

❑Standard connectors: An 8-pin modular (similar to RJ48C) or 6-pin modular

(similar to RJ11) wall jack for the DSL network connection.

❑DSL wiring: Unshielded twisted-pair wiring (CAT3, or better). The CAT3 wiring must

meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm).

❑Ethernet wiring: Shielded twisted-pair wiring (CAT5, or better). The CAT5

wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or

26 AWG (.4 mm).

For standard cables, refer to

Cables and Connectors

on page 19 for pin numbers.

For Paradyne cables, contact your sales representative to order them.

Interface

Connection Cables Feature

Number

COM port to a PC

or asynchronous

terminal

DB25-to-DB25:

Standard EIA-232 straight-through cable —

DB25-to-DB9:



DB25-to-8-pin modular adapter



8-pin modular-to-DB9 cable

(14 feet –4.3 m)

3100-F1-920

3100-F2-550

ETHERNET port

to a NIC on a PC

or an Ethernet hub

For connection to a PC NIC:

Standard Ethernet crossover cable —

For connection to an Ethernet Hub:

Standard Ethernet straight-through cable —

User data PORT

to a DTE Standard V.35 straight-through cable —

NETwork to the

DSL wall jack Standard straight-through DSL network cable

with 8-pin modular connectors –similar to an

RJ48C-toRJ48C cable (20 feet –6.1 m).

Cable supplied for use in the U.S.

3100-F1-500

Standard DSL network cable with

6-pin connectors –similar to an RJ11 cable —

Prior to Installing the CSU/DSU

These Installation Instructions assume that the virtual circuits at the DSLAM have

already been configured. Provisioning of these circuits can be simplified by using the

OpenLane SLM (Service Level Management) system, as indicated in

Provisioning Data

Circuits in OpenLane

Provisioning Data Circuits in OpenLane

Use the OpenLane SLM system’s Provision Circuit screen to add new circuits that start

at the FrameSaver DSL endpoint and traverse the SCM and ATM line card in the Hotwire

GranDSLAM, and the default VC sets(from 1 to 4). A group of 250 VCs can be allocated

to each line card, which can be assigned to any port on the card. These custom

connections carry the frame relay traffic.



Note that before the custom cross-connects are configured, the Maximum VCI

number for the uplink VP to be used by these custom connections must be

specified on the Max VCI per VPI screen, and the apply changes executed.



For ATM line cards, custom connections can be used to expand the number of VCs

connected to the card. Each of the 250 VCs can be cross-connected from any VC

on the uplink to any port on the line card.

The following information is collected by the Provision Circuit process:



Uplink VPI/VCI



Slot number and Port number of the DSL connection



Traffic Profile



DSL link VPI/VCI



Frame relay DLCI (provided by NSP)



Frame relay CIR, Be, Bc(provided by NSP)

A Circuit ID is then applied to the newly defined circuit, and stored in both the CSU/DSU

and the OpenLane SLM system.

Installing the CSU/DSU

Place the FrameSaver DSL 9783 CSU/DSU on a flat surface with clearance for the rear

connectors.

Procedure

1. Use the supplied 8-pin DSL network cable (for use in the U.S.), or a 6-pin DSL

network cable (using connectors similar to RJ11), as applicable, for the DSL

connection. Insert one end of the cable into the jack labeled NET. Insert the other

end into the wall jack for DSL data communications.

For domestic models, go to Step 3 on page 7.

2. For certain international models, a ferrite

choke has been provided. Place the ferrite

choke on the network cable, as close as

possible to the rear panel.

Close the two halves around the cable

and snap the latch shut.

DSL

Network

01-16774-02

ETHERNET

COM

POWER NET

NET

DSL

Network

01-16944

NET

Ferrite

Choke

3. Use an 8-pin Ethernet cable for the Ethernet connection for local management.

Insert one end of the cable into the jack labeled ETHERNET.

—Use a straight-through cable to connect the other end of the cable to an

Ethernet hub. Do not connect to the hub’s optional Uplink connection with a

straight-through cable; the Uplink connection requires an Ethernet crossover

cable.

–or –

—Use an Ethernet crossover cable to connect to a PC with an Ethernet Network

Interface Card (NIC) installed or a hub’s Uplink connection.

01-16687-02

Hub

ETHERNET

COM

POWER NET

Ethernet

Straight-Through

Cable

ETHERNET

4. Connect one end of the DTE’s cable to the user data port labeled PORT. Plug the

other end of the cable into the DTE (router or FRAD). Tighten the screws on each

side of the connector.

5. Use a VT100-compatible asynchronous terminal or a PC to set up management

access to the unit. Insert the DB25 end of the EIA-232 cable into the CSU/DSU’s

COM port. Tighten the screwson each side of the connector. Insertthe other end of

the cable into the terminal or PC.

The terminal or PC’s configuration must be compatible with the CSU/DSU’s. Refer

to the procedure on page 13 of

Configuration Setup

. If connecting an external

modem to the COM port, refer to

Connecting an External Modem

on page 22.

01-16689-02

ETHERNET

COM

POWER NET

DTE

PORT

COM

Port

01-16685-02

ETHERNET

COM

POWER NET

VT100

Terminal

6. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the

transformer into an AC outlet.

Install the supplied tie wrap for strain relief, as shown.

Installation of the hardware is now complete. When the power cord is installed, the

CSU/DSU goes through a power-on self-test.

Power-On

When power is applied, the CSU/DSU performs self-diagnostics and the PWR LED is

on. The self-diagnostics include a power-on self-test where all of the LEDs are on.

Refer to

Status LEDs

on page 10 for information about the LEDs. Refer to

Troubleshooting

on page 11 for LED indications requiring action.

01-16773-02

ETHERNET

COM

POWER NET

Grounded

Power

Outlet

Tie

Wrap

Power

Jack

01-16769-02

ALM

TEST

ATM

DSL

NetworkSystem Port

9783-C

SLV

FrameSaver®DSL

SDSL

System OK –green

Alarm –red

Test –yellow

ATM –green/yellow

DSL –green

User Data Port –green

Status LEDs

After a successful self-test, the LEDs should appear as indicated in BOLD in the

Condition column below.

LED Condition Status

System LEDs

OK ON The CSU/DSU has power.

ALM ON

OFF

An alarm condition exists.

No alarms have been detected by the CSU/DSU.

TEST ON

OFF

The CSU/DSU is performing the power-on self-test, or a test

initiated by the service provider is currently active.

No tests are active.

Network LEDs

ATM ON –Green

ON –Yellow

OFF

ATM LED is active and cell delineation is in sync.

ATM mode is active and there is loss of cell delineation.

The ATM link is not active.

DSL Blinking

OFF

The CSU/DSU is in start-up or is retraining. The LED blinks

on and off about five times per second.

The DSL link is ready to transmit and receive data.

No DSL link has been established, or the link is down.

Port LED

OK ON

OFF

The user data port is transmitting and receiving data.

The user data port is idle. This occurs when the port is:



Disabled, or



Configured to monitor DTR and/or RTS, and the lead is

not asserted.

Autres manuels pour FrameSaver DSL 9783 CSU/DSU

Table des matières

Autres manuels Paradyne Routeur réseau

Paradyne

Paradyne Hotwire 7995 Manuel utilisateur

Paradyne

Paradyne FrameSaver SLV 9664 Manuel utilisateur

Paradyne

Paradyne Hotwire 6371 Manuel utilisateur

Paradyne

Paradyne BitStorm 6211 CPE Manuel utilisateur

Paradyne

Paradyne HotWire 5246 Manuel utilisateur

Paradyne

Paradyne Hotwire 6381 Manuel utilisateur

Paradyne

Paradyne Hotwire 6211 Instructions d'installation

Paradyne

Paradyne Hotwire 6351 Manuel utilisateur

Paradyne

Paradyne Hotwire 6321/6322 IDSL Router Manuel utilisateur

Paradyne

Paradyne 1752 SHDSL Manuel utilisateur

Paradyne

Paradyne FrameSaver DSL 9788 Router Manuel utilisateur

Paradyne

Paradyne 6211-I1 Manuel utilisateur

Paradyne

Paradyne Hotwire 6302 Manuel utilisateur

Paradyne

Paradyne Hotwire 6351 Manuel utilisateur

Paradyne

Paradyne Hotwire 6212 Instructions d'utilisation d'origine

Paradyne

Paradyne FrameSaver 9783 Manuel utilisateur

Paradyne

Paradyne iMarc DSL 9783 Manuel utilisateur

Paradyne

Paradyne FrameSaver 9123 Manuel utilisateur

Paradyne

Paradyne JetFusion 2100 Series Manuel utilisateur

Paradyne

Paradyne Hotwire 6341 Manuel utilisateur

Paradyne

Paradyne Hotwire 6212 Instructions d'utilisation d'origine

Paradyne

Paradyne FrameSaver 9783 Manuel utilisateur

Paradyne

Paradyne Hotwire 6341 Manuel utilisateur

Paradyne

Paradyne Hotwire Routers Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
