FrameSaver 9120
Network Access Module (NAM)
Installation Instructions
Document Number 9121-A2-GN10-10
December 1997
Before You Begin
Make sure you have:
A small, flat-head screwdriver.
A small, Phillips screwdriver if transferring an ISDN BRI DBM to the new NAM, or if
installing the NAM in a FrameSaver 9000 Series Access Carrier.
1-Slot Assembled Access Unit Installation Instructions
(Document No.
9000-A2-GN10) to re-install the access unit once the NAM is installed,
if using a 1-slot housing.
FrameSaver 9000 Series Access Carrier Installation Instructions
(Document No.
9000-A2-GN1D) for power-up verification procedures, if using an access carrier.
ISDN BRI Dial Backup Module (DBM) Installation Instructions
(Document No.
9000-A2-GN19) to de-install, then re-install a DBM if one is currently installed on
the NAM being installed or replaced.
Configuration information for the NAM being installed or replaced.
If an ISDN BRI DBM is installed on a NAM being installed or replaced, the DBM must
be de-installed, then re-installed onto the replacement NAM.
Package Checklist
Verify that your package contains the following:
NAM
NAM I/O card, if installing the NAM in an access carrier
Warranty card
Training reply card
912x Series T1 Access Units Safety and Regulatory, Warranty and Equipment
Return Information
(Document No. 9121-A2-GX40)
Appropriate cables
496-15149
2
Safety Instructions
Please read the EMI warning and Important Safety Instructions that come with this
NAM.
!HANDLING PRECAUTIONS FOR STATIC-SENSITIVE DEVICES
This product is designed to protect sensitive components from
damage due to electrostatic discharge (ESD) during normal
operation. When performing installation procedures,
however, take proper static control precautions to
prevent damage to equipment. If you are not sure
of the proper static control precautions, contact
your nearest sales or service representative.
Removing a NAM from a 1-Slot Housing
Before replacing a NAM, locate or record the access unit’s configuration options, or
transfer the configuration using the FTP (file transfer protocol) feature. This is useful
when setting up the replacement NAM, verifying operation, or troubleshooting.
1. Disconnect the power cord/transformer, first from the ac outlet, then from the rear
of the access unit.
2. Disconnect the other cables.
3. Open the 1-slot housing using a small flat-head screwdriver. Gently pry open the
housing at each of the four connecting tab points. However, if the screwdriver is
too big or you do not open carefully, you could cause damage to the housing.
496-1504
3
4. Remove the cover.
496-1504
5
3
5. Lift the NAM and the integrated I/O card/backplane (rear panel) from the base.
496-15044
Integrated
I/O Card/Backplane
NAM
Base
6. Work the NAM away from the I/O card (not the backplane,
since the backplane might bend) by very carefully and
gently pulling and rocking the NAM connectors
away from the I/O card connectors. Work
first from one side, then the other,
until the NAM is separated from the
I/O card. Set the NAM aside.
If an ISDN BRI DBM is Installed
1. Remove the DBM from the NAM being replaced.
2. Re-install the DBM onto the replacement NAM.
Refer to the
ISDN BRI Dial Backup Module (DBM) Installation Instructions
to de-install
and re-install the DBM.
496-1504
6
496-1504
7
496-1504
8
Guide
4
Installing a NAM in a 1-Slot Housing
1. Remove the NAM from its shipping box.
2. Carefully align the NAM connectors with the
integrated I/O card/backplane (rear panel)
connectors. (See Step 3 of
Removing a
NAM from a 1-Slot Housing
on Page 2
if you need to open the housing first.)
3. Gently, but firmly press the connectors
together until they are fully seated.
Be careful not to force or bend
any pins.
4. Place the NAM and integrated I/O card/backplane
into the 1-slot housing’s base. Make sure the
backplane rests inside the guides on the
base at the rear of the access unit.
5. Place the cover over the base, aligning the four connecting tabs. Make sure the
backplane rests inside the guides on the cover at the rear of the access unit.
6. Press the cover and base together until all four connecting tabs snap into place.
7. Reconnect the power cord/transformer, verifying that the faceplate’s OK LED lights
once the self-test is passed.
Refer to the
1-Slot Assembled Access Unit Installation Instructions
before
re-installing the cables.
5
Recommended Order for Installing a NAM into an Access
Carrier
1. Install the I/O card.
2. Connect all cables into the I/O card.
3. Install the NAM.
4. Go to the
FrameSaver 9000 Series Access Carrier Installation Instructions
for
power-up verification procedures.
T1 NAM
NET
DBM
DSX
PORT 1
PORT 2
COM
NET
DBM
DSX
Port 1
Port 2
COM
97-15050a
NAM
I/O
6
Installing the I/O Card into the Access Carrier
The NAM’s I/O card provides the COM port, network, DSX, and
DTE connections. The I/O card inserts directly behind the NAM
that it supports.
1. Remove the I/O card from the shipping box. Handle only
by the top and bottom edges to avoid damaging the card.
2. At the rear of the carrier, align the I/O card with the
upper and lower tracks of the slot. Push gently towards
the midplane until it stops and you cannot push the card
any further.
97-1574
4
Rear View
Screws
3. There are two captive screws on the I/O card. Using a
screwdriver, alternately tighten each screw until the
screws are all the way in.
7
Connecting to the Network
1. Insert the 8-pin connector on the
RJ48C network cable into the NET
interface.
2. Insert the other end of the cable into
the RJ48C modular jack.
Connecting to an M66 Block
Use the optional T1 mass termination cable to connect up to seven NAMs to an M66
block. The T1 mass termination cable is a 5-foot RJ48H cable consisting of a 50-pin
plug-to-seven RJ48C plugs. See the RJ48H Connector for T1 Mass Termination Cable
table on page 20 for pin assignments.
1. Insert up to seven of the RJ48C plugs on the RJ48H network cable into the NET
interface(s).
2. Insert the 50-pin plug end of the cable into the M66 block.
97-15749
M66 Block
NAMs
RJ48C
Plugs 50-Pin Plug
Plug Number
Label
RJ48C
Jack
T1 NAM
NET
DBM
DSX
NET
97-15053-01
COM
T1 NAM
NET
DBM
DSX
PORT 1
PORT 2
Port 1
97-15054-01
DTE
Cable
DTE
Cable
V.35, RS-449,
V.11/X.21
Adapter Cable
DTE
DTE Port 2
8
Connecting to a DTE
If the DTE cable type is V.35, RS449, or V.11/X.21 (separately orderable):
1. Connect the plug to the
V.35, RS449, or V.11/X.21
end of the adapter cable
(as appropriate).
2. Connect the EIA-530A
end of the adapter cable
to PORT 1 or PORT 2.
If the DTE cable type is
EIA-232E or 530A:
1. Connect the EIA-232E
or EIA-530A end of the
DTE cable to PORT 1
or PORT 2.
Connecting to the DSX
1. Insert the DB15 end of the DSX
cable into the DSX interface.
2. Insert the other end of the cable
into the FCC Part 68 Registered
CPE (Customer Premises
Equipment, such as a PBX).
T1 NAM
NET
DBM
DSX
PORT 1
DSX
97-15055-01
PBX
9
Connecting the COM Port to a User Interface
1. Insert the 8-pin end of the cable into the COM port.
2. Insert the other end of the cable into the user interface (VT100-compatible terminal
emulation) connector.
Set the speed of the async (VT100-compatible) terminal so it
matches the NAM's factory-loaded data rate of 19.2 kbps, character
length set to 8, parity set to None, and stop bits set to 1.The flow
control should be set to None or Hardware.
PORT 2
COM
COM
97-15792
COM Port-to-Terminal/Printer
Cable or
COM Port-to-PC Cable
*
*
Ferrite
Choke
3. Install the supplied ferrite choke on the COM port cable. To do this, open the ferrite
choke and place it as close to the cable connector as possible. Then, close the two
halves around the cable and snap the choke shut, pressing down on the plastic
latch to secure it in place.
4. Press Return on the keyboard to display the Main Menu. If you need to configure
for other than a direct link, see the
FrameSaver 9120, Technical Reference
(Document No. 9121-A2-GH30).
10
Installing the ISDN-U Cable
(if an ISDN BRI DBM is installed)
1. Insert the 8-pin connector on the ISDN-U cable into the DBM interface.
2. Insert the other end of the cable into the ISDN service RJ49C jack.
3. Reconnect the power cord, first to the rear of the access unit, then to the power
outlet.
T1 NAM
NET
DBM
DSX
PORT 1
PORT 2
COM
NET
DBM
DSX
Port 1
Port 2
COM
97-15751a
RJ49C
Jack
