642 LCD Keypad
User Manual
Esprit+ 642 LCD Keypad 1
TABLE OF CONTENTS
Introduction .......................................................3
Legend ......................................................................... 3
Basic Operation ................................................5
Keypad Indicator Lights ................................................5
Visual Feedback ........................................................... 5
Auditory Feedback ........................................................ 6
Info List ......................................................................... 7
Access Codes ...................................................8
User Codes ................................................................... 8
Duress Code .................................................................8
Programming Access Codes ........................................ 9
Deleting an Access Code ........................................... 10
Arming & Disarming .......................................11
Exit Delay ................................................................... 11
Disarming & Deactivating an Alarm ............................ 11
Alarm Memory Display ............................................... 11
Regular System Arming .............................................. 12
Stay Arming ................................................................ 13
Fast Exit ..................................................................... 14
Instant Arming ............................................................ 14
Force Arming .............................................................. 15
Manual Bypass Arming ............................................... 16
Bypass Recall ............................................................. 16
2 User Manual
One-Touch Arming ......................................................17
Keyswitch/Push-Button Arming ...................................18
Timed Auto-Arming .....................................................18
No Movement Automatic Arming ................................19
Fire Alarms ..................................................................19
Additional Features ........................................22
Chime Zone Selection .................................................22
Keypad Muting ............................................................22
Panic Alarms ...............................................................23
Setting Time and Day .................................................24
Quick Function Keys ...................................................25
Keypad Settings ..........................................................27
Event List ....................................................................27
Partitioning the System ...............................................28
Disarming System A and B Separately .......................31
Testing & Maintenance ...............................................31
Trouble Display ...............................................33
System Check list ...........................................35
Panic Buttons ..............................................................35
Zone Checklist ............................................................35
User Access Code List ................................................37
Esprit+ 642 LCD Keypad 3
1.0 Introduction
Thank you for selecting the Esprit+ Security System from
Paradox Security Systems. The Esprit+ line of security
systems brings together reliable, yet simple products that
offer state of the art security options. These options enable
you to customize many of the advanced features through a
straightforward keypad interface.
The Esprit+ system reports a wide range of status conditions
to the central monitoring station. Automatic test reports can
also be sent to the central station to ensure that your system
is functioning properly. We recommend that such tests be
conducted regularly. Consult your alarm system installer for
instructions.
All the actions performed in your security system will be
executed and displayed through the keypad. We recommend
that you read this manual thoroughly and have your installer
explain basic system operation to you.
1.1 Legend
Throughout this book there are icons to represent points of
interest. The following are used:
= to indicate notes or reminders.
= to indicate a warning or caution.
4 User Manual
= to indicate a tip.
= to indicate a button on the keypad.
[KEY]
Esprit+ 642 LCD Keypad 5
2.0 Basic Operation
Many of the features in your system must be enabled by your
installer. If the feature is not programmed, the keypad will
emit a rejection beep and the action will be canceled.
2.1 Keypad Indicator Lights
The state of each light on the Esprit+ 642 keypad represents
a specific condition in your system as shown in Figure 2.1.
Figure 2.1: Keypad Indicator Lights
2.2 Visual Feedback
Everything you need to know about your security system is
displayed on the Esprit+ 642 keypad. The zones in your
security system are immediately identified and important
messages regarding system status appear on the screen.
Arm (Red)
Ready (Green)
ON = Zone(s) closed
OFF = Zone(s) open
FLASH = During exit delay
ON = System armed
OFF = System disarmed
FAST FLASH = Alarm
6 User Manual
When zone status is normal, the LCD display will read:
system ready. If any zones are open, the display will
read: zones open. While the display will automatically
show which zones are open, you can also press the [U]or
[V]keys to view a specific zone.
Figure 2.2: Overview of Esprit+ 642 LCD Keypad
2.3 Auditory Feedback
Every time you press a key the system will emit a beep. This
sound affirms that you have made an entry. When you enter
information on the keypad, it will guide you with these tones
to communicate acceptance or rejection of your entries. You
should be familiar with the following keypad beep tones:
• Confirmation Beep: when an operation (i.e. arming/
disarming) is successfully entered on the keypad or when
The messages on the LCD
screen display system
status and guide you through
operations.
AC indicates power.
Use these buttons to scroll
through menus.
(option programmed by your
installer)
Esprit+ 642 LCD Keypad 7
the system switches to a new status/mode, the keypad
sounder will produce an intermittent beep tone (four short
beeps).
• Rejection Beep: when the system reverts to its previous
status, or when an operation is incorrectly entered on the
keypad, the sounder will emit a continuous beep tone
(beeep).
2.4 Info List
Your Installer can program the control panel to include
important information such as emergency numbers, tips, or
notes. This information will be saved even after a total power
loss.
How do I View the Info List?
1) Press the [INFO]key.
2) Use the [U] or [V] keys to scroll through the info list.
3) Press the [CLEAR]key to exit.
8 User Manual
3.0 Access Codes
Access codes are personal identification numbers that allow
you to enter certain programming modes and arm or disarm
the system. In addition to the Master Code the Esprit+ control
panel can be programmed to accept up to 48 user codes,
each with a unique access code.
Avoid programming simple or obvious access codes,
such as your telephone number, address, or codes
like 1234.
3.1 User Codes
Your installer will program the panel to accept four- or six-digit
access codes and will assign code definitions to all user
codes. The Master Code (default: 474747) and user codes
are identified by a two digit “code number”, where code
numbers 01-48 represent access codes 1-48 and code
number 00 represents the Master Code. To create or modify
access codes please see section 3.3 on page 9 and section
3.4 on page 10.
3.2 Duress Code
The last user code (code number 48) can be programmed as a
Duress code. If you are forced to arm or disarm your system
under threat, you can enter this access code to produce a
silent alarm at the monitoring station. Check with your installer
to see if this option is enabled on your system.
