Paradox Digiplex DGP-620 Instructions de montage

20-Zone & 48-Zone LED Keypads V1.3

Installer’s Guide

TABLE OF CONTENTS

INTRODUCTION ................................................3

Specifications ..............................................................3

INSTALLATION .................................................4

Connecting the Keypad ..............................................4

Connecting Keypad Zones .........................................4

Programmable Output (PGM) .....................................6

Finding an Unlabeled Keypad’s Serial Number ..........6

PROGRAMMING ...............................................7

Enter Module Programming Mode ..............................7

Programming Methods ...............................................8

Feature Select Programming .........................................8

Decimal Programming ...................................................9

Level Programming .......................................................9

WinLoad Programming ..................................................9

Module Broadcast .......................................................9

SYSTEM OPTIONS ..........................................11

Basic Overview .........................................................11

Partition Assignment .................................................12

Zone Display .............................................................12

Confidential Mode .....................................................13

Muting .......................................................................14

Beep on Exit Delay ...................................................14

Chime on Zone Closure ............................................14

Beep on Trouble .......................................................15

Keypad Tamper Enable ............................................16

Access Control .........................................................16

PGM PROGRAMMING ....................................17

PGM State ................................................................17

PGM Activation Event ...............................................17

PGM Deactivation Event ..........................................18

PGM Timed Mode ....................................................19

PGM Timer ...............................................................19

PGM Base Time .......................................................20

PGM Override ...........................................................20

Digiplex LED Keypads 3

1.0 INTRODUCTION

Thank you for choosing Paradox®Security Systems. The

Digiplex™ Security System is an advanced technology security

system that will provide reliable security protection and powerful

features that are easy to use.

The elegant Digiplex™ LED Keypads will allow easy access to

the security system’s functions. The illuminating LEDs provide

the system’s status at a glance.

Since all programming is accomplished through the keypad,

please read this manual carefully.

1.1 SPECIFICATIONS

Power input: 9-16 Vdc, 45mA typical

Operation Speed: 16 MHz

PGM current limit: 50 mA

Number of inputs: 1

Number of zones: 1 standard zone, no tamper recognition

Power indication: Yellow LED on

Locate indication: Greenand yellowLEDs flashsimultaneously

Network fault indication:Red and yellow LEDs flash alternately

Locate deactivation: Tamper switch

Weight: 200 g

Compatibility: Digiplex DGP-48 Control Panels

4 Installer’s Manual

2.0 INSTALLATION

2.1 CONNECTINGTHEKEYPAD

The Digiplex™ LED Keypads are connected to the control

panel's communication network in a star and/or daisy chain

configuration. The 4-wire communication network provides

power and two-way communication between the control panel

and all modules connected to it. Connect the four terminals

labeled red, black, green and yellow of each keypad to the

corresponding terminals on the control panel as shown in Figure

2.1. Refer to the Digiplex Control Panel's Reference &

Installation Manual for the maximum allowable installation

distance from the control panel.

2.2 CONNECTINGKEYPAD ZONES

Each keypad has one traditional hardwired input terminal,

allowing you to connect one detector or door contact directly to

the keypad. For example, a door contact located at the entry

point of an establishment can be wired directly to the input

terminal of the entry point keypad instead of wiring the door

contact all the way to the control panel.

Connect the device to the keypad's input terminal as shown in

Figure 2.1.

The keypad zone follows the control panel’s EOL

definition.

Digiplex LED Keypads 5

In order to communicate its status to the control panel, devices

connected to the keypad's input terminal must be assigned to a

zone in the control panel and the zone's parameters must be

defined.

The control panel does not recognize tampers

originating from the keypad zone.

For more information on zone assignment, please refer to the

Digiplex Control Panel's Reference & Installation Manual. Please

note that even with the ATZ (zone doubling) feature enabled, the

keypad supports only one detection device.

6 Installer’s Manual

2.3 PROGRAMMABLEOUTPUT(PGM)

Each keypad has one on-board PGM. A PGM is a programmable

output that toggles to its opposite state (i.e. a normally open PGM

will close) when a specific event has occurred in the system (see

section 5.2 of this manual). Upon activation, the PGM can provide

50mA to any device connected to it. If the current drawn is to

exceed the current limit, a relay should be connected to the PGM

as shown in Figure 2.1.

2.4 FINDINGAN UNLABELEDKEYPAD’SSERIALNUMBER

If the keypad’s serial number is missing, you can view the serial

number by entering 000 in Step 3 of Module Programming Mode

(see section 3.1 of this manual, page 7). The serial number will

illuminate one number at a time as you press the button

([10] LED represents zero).

Digiplex LED Keypads 7

3.0 PROGRAMMING

To program the Digiplex LED keypad you must enter “Module

Programming Mode”. Use the Digiplex LED Keypads Programming

Guide to keep track of which sections were programmed and how.

We strongly recommend you read this entire manual before you

begin programming.

3.1 ENTERMODULEPROGRAMMINGMODE

The keypad, like all other modules in the Digiplex system, is

programmed through the control panel. To do so, enter the

“Module Programming Mode”:

Step 1:

From Normal Mode press and hold the [0] key.

The keypad will emit a Confirmation Beep.

Step 2:

Enter the [INSTALLERCODE](by default 000000).

The [PRG]LED will flash.

Step 3:

Enter section [953].

The [PRG] LED and the [10] LED will illuminate ([10] represents

zero).

(To view an unlabeled keypad’s serial number, enter section [000]

instead of [953] and use the button to view the numbers one at

a time.)

8 Installer’s Manual

Step 4:Now in “Module Programming Mode”.

Enter the keypad’s 8-digit [SERIALNUMBER].

The keypad will emit a Confirmation Beep and the [PRG] LED will flash.

Step 5:

Enter the 3-digit [SECTION]you want to program.

The keypad will emit a Confirmation Beep. The [PRG]LED and

the numerical LEDs for any lt or previously programmed data will

illuminate.

Step 5:

Enter the required [DATA].

Depending on the section entered, the data required may differ.

The control panel will now redirect all programming to the

selected keypad. Every time the [CLEAR]button is pressed it will

revert to the preceding step, unless entering data, in which case

it will erase the current data entry. Please note that the serial

number is located on the keypad's PC board.

3.2 PROGRAMMINGMETHODS

3.2.1 Feature Select Programming

Program sections [001] to [005] by enabling or disabling options.

Within the sections, numbers from [1] to [8] represent a specific

keypad option (refer to the Digiplex LED Keypads Programming

Guide). Press the button corresponding to the desired option and the

digit’s LED will illuminate. This means the option is enabled. Press

the button again to extinguish the digit’s LED, thereby disabling the

option. Press the [ENTER]button when the options are set.
