Opticom Drawers and Trays
Part Numbers: FMD1, FMD2, FMT1, FMT2
1 - #10-32 x 5/16" screw
1 - Strain Relief Bracket
2 - Bend Radias Brackets
10 - Pan-Ty Cable Ties 4 - #10-32 Hex Nuts
1 - 24" Spiral Wrap
3 - #10 Flat Washers
4 - #12-24 x 1/2" screws 1 - Caution Label
2 - Spools
Fiber optic cable is sensitive to excessive pulling, bending and crushing forces. Consult the manufacturer’s cable specification sheet for
the specific cable in use.
Follow TIA/EIA 568-A, 569, 606, and 607 installation guidelines where applicable.
DANGER: UNMATED CONNECTORS MAY EMIT INVISIBLE LASER RADIATION. DO NOT LOOK DIRECTLY INTO THE END OF THE
CONNECTOR, DO NOT INSPECT WITH MAGNIFYING DEVICES. MAINTAIN CAP ON UNMATED CONNECTORS.
CAUTION:
1 - Port Identification Label
(For part numbers FMD1 and FMD2 ONLY)
(For part numbers FMD1 and FMD2 ONLY)
2 - Adhesive Mounts
FMD1 FMD2 FMT1 FMT2
Contents:
1 - Enclosure
(For part numbers FMD1 and FMD2 ONLY)
1 - Laser Warning Label
ASSEMBLY
(FMD2 shown)
Caution label
Laser warning label
Port identification label
Enclosure
Spool
Bend radius bracket Grommet
Strain relief
bracket
#10-32 x 5/16" screw
For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS067
Page 2 of 4
To engage the cover, slide forward until the cover
slides under the front tabs then secure in place with
#10-32 screw.
Determine which grommet(s) will be used to bring
the cable into the enclosure. Remove the knock-out
at entry location of the fiber tray. Install grommet
following the proper cutting diagram.
Determine where the spools will be located.
Remove the liner from the tape on each spool and
place them inside the enclosure.
Place the strain relief bracket near area where the
cable will enter the enclosure. Fasten with #10-32
hex nut.
Install the hex nut and washer. This will be used to
secure the strength member that comes out of the
cable.
Cut the small circle
for 1" diameter
innerduct
Cut the large circle
for 1-1/2" diameter
innerduct
Cut the straight lines
when not using any
innerduct
DISCARD
DISCARD
For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS067
Page 3 of 4
Secure the sliding tray with #10 washers and
#10-32 hex nuts provided.
Mount the enclosure to the rack using (4) #12-24
screws.
To install the bend radius brackets, slide the bracket
onto tab with the slot facing outside then snap in
place. (FMD SERIES ONLY)
Insert cable through the grommet. Secure the cable
to the strain relief bracket using a cable tie. Strip 1
meter of jacket from the end of the cable. Attach the
strength member of the cable to the #10-32 stud and
#10-32 hex nut. Use the adhesive mount and cable
tie to secure the cable between the#10-32 stud and
the grommet.
1
2
To remove the bend radius
bracket, disengage latch with
a screwdriver.
Slot
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS067
E-mail:
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
Page 4 of 4
Insert the panels into the enclosure as shown. Once
mounted, push the latches in to secure the panel.
Terminate the fibers with an appropriate connector.
Mount each connector in the panel.
Gently loop the excess fiber around the spools.
Replace the cover after all fibers are looped around
the spools
Install the patchcords as
needed.
Attach Laser Warning Label and Caution
Label where they are clearly visible.
To remove the front door:
(FMD SERIES ONLY)
