Panasonic FZ-M1 Series Manuel utilisateur

Getting Started

Useful Information

Troubleshooting

Appendix

Please read these instructions carefully before using this product, and save this

manual for future use.

OPERATING INSTRUCTIONS

Basic Guide

Tablet Computer

Model No. FZ-M1 series

Contents

Getting Started

Introduction.................................................2

Description of Parts ....................................4

First-time Operation....................................7

Turning On / Turning Off...........................13

Useful Information

Handling and Maintenance.......................15

Installing Software ....................................22

Troubleshooting

Troubleshooting (Basic)............................29

Appendix

LIMITED USE LICENSE AGREEMENT...37

Contrat de licence d’usage limité..............40

Specications ...........................................43

LIMITED WARRANTY..............................49

Standard Limited Warranty.......................58

Getting Started

Introduction

Thank you for purchasing this Panasonic product. For optimum performance and

safety, please read these instructions carefully.

nTerms and illustrations in these instructions

CAUTION : Conditions that may result in minor or moderate

injury.

NOTE : Useful and helpful information.

“Windows 10 Pro 64-bit” as “Windows” or “Windows 10”

“Windows 7 Professional 32-bit” and “Windows 7 Professional 64-bit” as

“Windows” or “Windows 7”

indicates Windows 10 Operating System.

indicates Windows 7 Operating System.

Enter

: Press [Enter] key.

Alt

Del

: Press and hold [Alt] key, and then press [Del]

key.

è: Page in these Operating Instructions.

: Reference to the on-screen manuals.

(Start) - [All Programs] : Click (Start), and then click [All Programs].

You may need to double-click in some cases.

(Start) - [All Programs] : Touch (Start), and then touch [All Programs].

l Someillustrationsaresimpliedtohelpyourunderstandingandmaylookdif-

ferent from the actual unit.

lIf you do not sign in / log on as an administrator,

you cannot use some functions or cannot display some screens.

lRefer for the latest information about optional products to the catalogs, etc.

lIn these instructions, the names and terms are referred as follows.

“Multilingual User Interface”as “MUI”

Screen messages are explained in [English (United States)].

(Depending on the language preference, some screen messages in these

instructions are different from the actual screen messages. For example, [Flight

mode] may be displayed instead of [Airplane mode] in some language prefer-

ence.)

nDisclaimer

Computerspecicationsandmanualsaresubjecttochangewithoutnotice.Pana-

sonic Corporation assumes no liability for damage incurred directly or indirectly

from errors, omissions or discrepancies between the computer and the manuals.

Getting Started

nTrademarks

Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft

Corporation of the United States and/or other countries.

Intel, Core, Centrino and PROSet are either registered trademarks or trademarks

of Intel Corporation.

microSDXC Logo is a trademark of SD-3C, LLC.

Adobe, the Adobe logo and Adobe Reader are either registered trademarks or

trademarks of Adobe Systems Incorporated in the United States and/or other

countries.

Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and

licensed to Panasonic Corporation.

HDMI,theHDMILogoandHigh-DenitionMultimediaInterfacearetrademarksorreg-

istered trademarks of HDMI Licensing LLC in the United States and other countries.

Names of products, brands, etc., appearing in this manual are trademarks or reg-

istered trademarks of their respective own companies.

nOn-screen Manual

For further information about the computer, you can refer to the on-screen manual.

lOperating Instructions - Reference Manual

The Operating Instructions - Reference Manual contains the practical informa-

tion to help you fully enjoy the computer’s performance.

lImportant Battery Tips

The Important Battery Tips will provide you with the battery information so that

you can use the battery in the optimum condition to obtain longer operation

time.

To access the on-screen manuals, follow the steps below.

On the Start screen, touch the [Manual Selector] tile, and select the on-screen

manual.

Double-touch [Manual Selector] on the desktop screen, and select the on-screen

manual.

NOTE

l[Contents] tab or [Search] tab is displayed on the left side of the window.

Select tab and display the desired item.

Getting Started

A: Wireless WAN Antenna

<Only for model with wireless

WAN>

èOperating Instructions - Ref-

erence Manual “Wireless WAN”

B: Wireless LAN Antenna

èOperating Instructions - Ref-

erence Manual “Wireless LAN”

C: Ambient Light Sensor

The ambient light sensor is

equipped with an automatic bright-

ness adjustment function that ad-

justs the display screen. (èpage 17)

Front Camera

 è Operating Instructions - Ref-

erence Manual “Camera”

D: Camera Lens

E: Camera Indicator

F: LED Indicators

: Power Indicator

Off: Power off/Hibernation,

Green: Power on, Blinking

green: Sleep.

: Drive status

: Battery status

èpage 16 “When the battery

indicator does not light on”

èOperating Instructions -

Reference Manual “Battery

Power”

G: Wireless LAN Antenna / Blue-

tooth Antenna

èOperating Instructions - Ref-

erence Manual “Wireless LAN”

“Bluetooth”

H: Windows Button

èOperating Instructions - Ref-

erence Manual “Tablet Buttons”

Description of Parts

ABD E

Front side

Getting Started

A: Microphone

B: Volume Button

èOperating Instructions - Ref-

erence Manual “Tablet Buttons”

C: Power Switch

D: Rotation Lock Button

èOperating Instructions - Ref-

erence Manual “Display Rota-

tion”

E: A Button

èOperating Instructions - Ref-

erence Manual “Tablet Buttons”

F: DC-IN Jack

G: Headset Jack

A headset or headphone can be

connected.

H: USB3.0 Port

èOperating Instructions - Ref-

erence Manual “USB Devices”

I: Security Lock

A Kensington cable can be con-

nected.

For further information, read the

manual that comes with the cable.

J: Expansion Bus Connector

èOperating Instructions - Ref-

erence Manual “Cradle”

K: External Antenna Connector

<Only for model with wireless

WAN>

Left side Right side

EDCBA

Top

Bottom

Getting Started

Description of Parts

Rear Camera

èOperating Instructions - Ref-

erence Manual “Camera”

A: Camera Lens

B: Camera Light

C: Camera Indicator

D: Speaker

E: Battery Indicator

F: Battery Latch

èOperating Instructions - Ref-

erence Manual “Battery Power”

G: Battery Pack

H: microSIM Card Slot

èOperating Instructions - Ref-

erence Manual “Wireless WAN”

I: microSD Memory Card Slot

Operating Instructions - Reference

Manual “microSD Memory Card Slot”

J: Barcode Reader / Serial Port /

LAN Port

Operating Instructions - Refer-

ence Manual

“Barcode Reader”

èOperating Instructions - Ref-

erence Manual “Serial Port”

èOperating Instructions - Ref-

erence Manual “LAN”

K: Built-in Bridge Battery

<Only for model with Built-in Bridge

Battery>

L: Smart Card Reader / Magnetic

Stripe Card Reader / Contactless

Smart Card Reader

Operating Instructions - Refer-

ence Manual “Smart Card”

<Only for model with Magnetic

Stripe Card Reader>

Operating Instructions - Reference

Manual “Magnetic Stripe Card Reader”

<Only for model with Contactless

Smart Card Reader>

èOperating Instructions - Ref-

erence Manual “Contactless

Smart Card Reader”

Rear side

Top (optional)

Getting Started

nPreparation

ACheck and identify the supplied accessories.

Ifyoudonotndthedescribedaccessories,contactPanasonicTechnical

Support (èpage 49).

• AC Adaptor...... 1

Model No: CF-AA6373A

• AC Cord ........ 1 • Battery Pack . . . . . 1

Model No: FZ-VZSU94W

• Soft Cloth .............................................1

• Stylus*1 ...............................................1

• Tether*1 ...............................................1

• Hand Strap*1 ...........................................1

• OPERATING INSTRUCTIONS - Read Me First ...............1

*1 Not included with some models.

BRead the LIMITED USE LICENSE AGREEMENT before breaking the seal

on the computer’s packaging (èpage 37).

First-time Operation

1 Inserting the Battery Pack.

Turn over the computer and insert the battery pack

until it touch to the secured position.

Make sure no foreign objects are under the computer.

CAUTION

lMake sure the latch is securely locked. Otherwise the

battery pack may fall when you carry the computer.

lDo not touch the terminals of the battery pack and the

computer. Doing so can make the terminals dirty or

damaged, and may cause malfunction of the battery

pack and the computer.

㪉

㪈

Getting Started

First-time Operation

NOTE

Note that the computer consumes electricity even when the

computer power is off. If the battery pack is fully charged,

the battery will fully discharge in the following period of time:

Status FZ-VZSU94W FZ-VZSU95W

(optional)

When power is off

Approx. 7 weeks Approx. 17 weeks

In sleep*2 Approx. 7 days Approx. 17 days

In hibernation Approx. 7 weeks Approx. 17 weeks

*2 <Only for model with LAN>

If “Wake Up from wired LAN” is enabled, the period

of time will be shorter.

2 Connect your computer to a power out-

let.

The battery charging starts automatically.

CAUTION

l DonotdisconnecttheACadaptoruntiltherst-time

operation procedure is completed.

l Whenusingthecomputerforthersttime,donotcon-

nect any peripheral device (including wired LAN cable)

except the battery pack and AC adaptor.

lHandling the AC adaptor



Problems such as sudden voltage drops may arise dur-

ing periods of thunder and lightning. Since this could

adversely affect your computer, an uninterruptible

power source (UPS) is highly recommended unless

running from the battery pack alone.

3 Turn on the computer.

Press the power switch (A) until the power indicator

(B) lights.

CAUTION

lDo not press the power switch repeatedly or do not

hold the power switch for four seconds or longer.

lAny changes from the default setting of the Setup Util-

ity must not be made until the First-time Operation is

completed.

㪈

㪉

Getting Started

Select language and OS (32-bit or 64-bit).

CAUTION

lCarefully choose your language because you cannot

change it later. If you set a wrong language, you need

to reinstall Windows.

ASelect language and OS (32bit or 64bit) on “Select

OS” screen and touch [OK].

The language setting will start by touching [OK] on

theconrmationscreen.

The language and OS setting will be completed in

about 15 minutes.

BWhen termination screen is displayed, touch [OK]

to turn off the computer.

CTurn on the computer.

5 Setup Windows.

Select language and click [Next].

Follow the on-screen instructions.

lThe computer restarts several times. Do not touch

the screen or tablet buttons, and wait until the drive

indicator has turned off.

lAfter the computer is turned on, the screen remains

black or unchanged for a while, but this is not a

malfunction. Wait for a moment until the Windows

setup screen appears.

lSetup of Windows will take approximately

5 minutes / 10 minutes.

Gotothenextstep,conrmingeachmessageon

the display.

lFollow the steps below.

AWhen “Enable sensors” is displayed, touch [En-

able this sensor].

BWhen the [User Account Control] screen is dis-

played, touch [Yes].

CAtthe[DisplayRotationTool]conrmation

screen, touch [Yes].

The computer restarts automatically, and the set-

ting is enabled.

Getting Started

First-time Operation

lYou can set the Wireless Network after the setup of

Windows is complete.

If “Let’s get connected” is displayed,

you can select “Skip this step”.

“Join a wireless network” screen may

not appear.

CAUTION

lYou can change the user name, password, image and

security setting after setup of Windows.

lRemember your password. If you forget the password,

you cannot use Windows. Creating a password reset

disk beforehand is recommended.

lDo not use the following words for user name: CON,

PRN, AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to

LPT9, LPT, &, space.

6 Restart the computer

ATouch (Start).

BTouch (Power) - [Restart].

lA portion of the Panasonic PC Settings Utility func-

tions will be enabled after the computer restarts.

7 Update the on-screen manual

AConnect to the internet. Sign in /

Log on to Windows as an administrator.

For further information, refer to Connect to a

network.

BUpdate the on-screen manual.

Double-touch the [Panasonic PC

Settings Utility] on the desktop screen, and then

touch [Support] - [Manual] - [Launch Manual

Selector].

Double-click [Manual Selector] on the

desktop.

Follow the on-screen instructions.

Autres manuels pour FZ-M1 Series

Table des matières

Autres manuels Panasonic Comprimé

Panasonic

Panasonic FZ-L1 Series Manuel utilisateur

Panasonic

Panasonic Toughbook U1 Ultra Manuel utilisateur

Panasonic

Panasonic Toughbook FZ-A1 Manuel utilisateur

Panasonic

Panasonic TOUGHPAD JT-B1 Series Manuel d'utilisation et d'entretien

Panasonic

Panasonic FZ-G1A Series Manuel utilisateur

Panasonic

Panasonic Toughbook U1 Ultra Manuel utilisateur

Panasonic

Panasonic Toughbook CF-U1 Manuel utilisateur

Panasonic

Panasonic Toughbook FZ-G1 Manuel utilisateur

Panasonic

Panasonic FZ-A1ADAAZAM Manuel utilisateur

Panasonic

Panasonic Toughbook H2 Manuel utilisateur

Panasonic

Panasonic FZ-N1C Manuel utilisateur

Panasonic

Panasonic FZ-N1 Series Manuel utilisateur

Panasonic

Panasonic Toughbook FZ-A1 Manuel utilisateur

Panasonic

Panasonic FZ-G1 Series Manuel utilisateur

Panasonic

Panasonic FZ-A1BDAAZAE Manuel utilisateur

Panasonic

Panasonic Toughbook H2 Manuel utilisateur

Panasonic

Panasonic Toughbook CF-H1ADBBGJM Manuel utilisateur

Panasonic

Panasonic FZ-M1 Series Manuel utilisateur

Panasonic

Panasonic Toughbook FZ-T1 Series Manuel utilisateur

Panasonic

Panasonic FZ-A2 series Manuel utilisateur

Panasonic

Panasonic CF-H1BDBBZCM Manuel utilisateur

Panasonic

Panasonic FZ-A1series Manuel utilisateur

Panasonic

Panasonic Toughbook CF-D1N series Manuel utilisateur

Panasonic

Panasonic FZ-M1 Series Manuel utilisateur

Manuels Comprimé populaires d'autres marques

Laser

Laser MID-1060 Guide de l'utilisateur

MUNBYN

MUNBYN IRT09J Guide de démarrage rapide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuel utilisateur

Dell

Dell Latitude ST Manuel du propriétaire

Lenovo

Lenovo IdeaTab S6000L Manuel du propriétaire

Venturer

Venturer WT9L11 Manuel utilisateur

EDUGEAR

EDUGEAR UnoBook Manuel utilisateur

Philips

Philips PI3210G/58 Manuel utilisateur

ADLINK Technology

ADLINK Technology IMT-BT Manuel utilisateur

TwinMOS

TwinMOS TwinTAB-T102D1 Manuel utilisateur

Archos

Archos 9.7 xenon Manuel utilisateur

Getac

Getac E100 Manuel utilisateur

HANNspree

HANNspree HANNspad SN70T3 Manuel utilisateur

Philips

Philips PI3105W2/55 Manuel utilisateur

LG LG-V935 Manuel utilisateur

Zeki

Zeki TBDB763B Manuel utilisateur

Ricoh

Ricoh eQuill Manuel utilisateur

DT Research

DT Research DT365CT Instructions de montage
